Managing complexity Advanced Perl

1
Managing complexity(Advanced Perl)

• Using perl for specific tasks with help from
  Bioperl and others

2
Login

• Username bioinfouser
• Password loginbioinfo

3
Funny?
4
Goals

• I already assume you know perl basics -- some
  more advanced features
• Learn how to write OO code
• More flexible modules
• Understand other modules
• Some APIs that you may need.
• Bioperl
• PerlDBI

5
What I assume you already know

• Scalars
• Arrays
• Hashes
• Control structures (if-then, for, foreach, while,
  etc.)
• File IO

6
Managing complexity

• By managing complexity
• Make hard tasks easy(er)
• Perl itself does this
• Regular expressions, text manipulations
• Extensions (modules) do this
• May come at the expense of execution speed
• You may not care
• Consider the big picture
• Development time
• Errors
• Extremely custom software
• Some things need speed

7
How complex is it now?

• Perl is a very compact language in terms of
  human languages
• Perl is large compared with other languages
• TMTOWTDI
• Perl has approximately 233 reserved words
• Java has approximately 47 reserved words
• Both are easy to learn harder to use effectively

8
General practices

• Always use !/usr/bin/perl w or use warnings
• Consider use strict for scripts longer than 10
  lines
• You cant have too many comments
• head
• cut
• perldoc

9
Getting values into the program or subroutine.

• Perl is pass by value
• A scalar can have as a value a pointer to an
  array, hash, function etc.
• The args to a program or function arrive in a
  special variable called _at__
• my first_value shift _at__
• my first_value _1
• my first_value shift

10
References
my _at_array (one, two, three,
four) function_call(_at_array) function_call(\_at_ar
ray) function_call(one,two,three) sub
function_call my passed shift _at__ print
passed
Output one ARRAY(0x80601a0) ARRAY(0x804c9a0)
11
Debugging complex data structures.

• Print the reference
• It will tell you a little bit of information
• Use the Dumper module.
• This will give you a snapshot of the whole data
  structure

12
Some more advanced features
13
Regular expressions

• Not Perl specific
• Very useful
• What they do
• String comparisons
• String substitutions
• Substring selection

14
Regex
Could put m
string /find/ string /find/ string
/find/ string /find/
. Match any character \w Match "word"
character (alphanumeric plus "_") \W Match
non-word character \s Match whitespace
character \S Match non-whitespace character \d
Match digit character \D Match non-digit
character \t Match tab \n Match newline \r
Match return
15
Repetition
string /(ti)2/ string
/ATG?C3A3,T4,6/
Character Classes
string /ATGCN/ string /ATGCNatgcn/i
16
Selection/Replacement
string /(A3,8)/ print 1
string s/a/A/ string tr/atgc/ATGC/
17
Additional syntax
string /AT?AT/
string m/var/log/messages
_ ATATATAGTGTGCGTGATATGGG (one,two,three)
/AT..AT/g
18
What is a module

• Two types
• Object-oriented type
• Provides something similar to a class definition
• Remote function call
• Provides a method to import subroutines or
  variables for the main program to use

19
Howto Making a module
Create a file called workSaver.pm pack
age workSaver sub doStuff print Stuff
done\n 1 statement that evaluates to
true Now you can use with use
workSaver Some restrictions apply
20
HowtoMaking a module cont.

• This method would work very well for subroutines
  that are used in several programs.
• Reduces the clutter in your program
• Provides one maintenance point instead of unknown
  number.
• Eases bug fixes
• Careful of boundaries

21
More Complete method

• Allows you to pollute the namespace of the
  original program selectively.
• Makes the use of functions and variables easier
• Still used about the same way as the simple
  method but things are clearer

22
More Complete
package functional use strict use Exporter our
_at_ISA ("Exporter") our _at_EXPORT qw () our
_at_EXPORT_OK qw (variable1 variable2
printout) our VERSION 2.0 our variable1
"var1" our variable2 "var2" my variable3
"var3" sub printout my passed_variable
shift print "Your variable is passed_variable
mine are variable1 , variable2, variable3
\n" 1
23
CPAN

• Wouldnt it be nice to have a place where
• You could find a bunch of perl modules
• It would be brows able
• Searchable
• Big pipe for people to download stuff
• Other people would be encouraged to submit fixes
  and updates
• And it was all free

24
Sources of modules/Information

• www.CPAN.org
• www.bioperl.org
• www.perl.com
• www.cetus-links.org/oo_infos.html

25
Bioperl

• Set of modules that are extremely useful for
  working with biological data. Actively
  maintained.
• www.bioperl.org is a very good place to get the
  basics of bioperl
• We will go through an example to see a typical use

26

• Bioperl has several basic types of objects
• Seq a sequence the most common type BioSeq
• Location objects where it is how long it is etc.
• Interface objects BioxyzI No implementation
  mostly a documentation

27
Bioperl documentation

• Several different ways to find out about a module
• perldoc BioSeq
• bioperl.org/usr/lib/perl5/site_perl/5.8.0/bptutori
  al.pl 100 BioSeq
• DataDumper to print the data structure
• Print the variable

28
Bio perl demo
29
Why use a database

• Transaction control - only one user can modify
  the data at any one time.
• Access control - some people can modify data,
  some can read data, others can create
  data-structures.
• Fast handling of lots of data
• Precise definition of data (mostly).
• Easy to share data resources with others

30
Many choices

• There are many types MS Access, Excel(sortof),
  sybase, oracle, postgres, msql, mysql
• They each have their niche and function best in
  certain cases, there is also considerable
  overlap.
• SQL structured query language is a common thread

31
MySQL is better than YourSQL

• Free on Unix
• Good developer support
• Constant bug fixes and feature addition
• Good scalability to medium size and load, OK
  performance.
• Easy to install.
• Used at Ensemble and UCSC genome browsers, so a
  lot of information is readily available in that
  format.

32
Table Structure - Schema
Gene table Gene_ID Name
Gene ATP7B Aliases Wilson disease-associated
protein Copper-transporting ATPase 2 References
Enzyme Commission 3.6.3.4 UniGene
Hs.84999 AffyProbeU133 204624_at AffyProbeU95
37930_at RefSeq NM_000053 GenBank
AF034838 GenBank U11700 LocusLink 540
Alias table Alias_ID Gene_ID Alias
Reference table Reference_ID Gene_ID Reference Dat
aSource
33
SQL (MySQL dialect)

• SELECT col_name FROM table WHERE col_name
  value
• SELECT COUNT() FROM table WHERE col_name is like
  value
• SELECT count(distinct(col_name)) FROM table where
  col_name is not null
• CREATE, UPDATE, DELETE, INSERT have similar forms

34
SQL cont.

• USE database_name
• Also can be specified on the command line D
• SHOW TABLES lists all the tables in that
  database (also SHOW DATABASES).
• DESCRIBE table_name lists the columns and
  datatypes for each column
• or SHOW COLUMNS FROM table_name

35
More advanced SELECTS

• SELECT (column_list) FROM (table_list) WHERE
  (constraints) GROUP_BY (grouping columns)
  ORDER_BY (sorting columns) LIMIT (limit number)
• SELECT col_name from (table1, table2) where
  table1_val table2_val and table1_val2 gt value
• Example of a equi-join

36
Getting the names right

• If you only have one table you only need to use
  the column name
• When you are using joins this may not be
  adequate.
• If two tables have the column primary you would
  need to call the column table1.primary or
  table2.primary

37
Data Types

• INT
• Tinyint 128 to 127
• Smallint 32768 to 32767
• Mediumint 8388608 to 8388607
• Int 2147683648 to 2147483647
• Bigint 9223372036854775808 to 9223372036854775807

• FLOAT
• Float 4 bytes
• Double 8 bytes

38

• CHAR
• Char(n) character string of n n bytes
• Varchar(n) character string up to n long L1
  bytes
• Text upto 216 bytes
• BLOBs Binary Large OBjects

39
Perl DBI

• Method for perl to connect to a database
  (virtually any database) and read or modify data.

• The statements are constructed very similar to
  SQL statements that would be entered on the
  command line so learning SQL is still necessary

40
Statements in DBI

• Connect
• Used to establish initial connection
• Prepare
• Prepare a statement to execute
• Execute
• Execute the statement
• Do
• prepare a statement that does not return results
  and execute it

41

• Fetch
• Several types used to get returned data
• Disconnect
• Disconnect from the server

42
Types of fetch

• fetchrow_array
• Used to fetch an array of scalars each time
• Can also use fetchrow_arrayref
• fetchrow_hash
• Used to fetch a hash indexed by column name.
• Slower but cleaner code.
• Can also use fetchrow_hashref.

43
More advanced statements

• Quote
• Used to properly quote data for use with a
  prepare statement
• value dbh-gtquote(blast_result)
• Placeholders
• Speeds up execution, optional
• my prep dbh-gtprepare (select x from y where
  z ?)
• loop_start
• prep-gtbind_param(1,z)
• prep-gtexecute()
• loop_end
