Title: DESIGN OF EXPERIMENT


1
DESIGN OF EXPERIMENT
INTRODUCTION
TO
TOOLS AND TECHNIQUES
TRAINING PROGRAMS DEVELOPED FOR DURACELL
CHINA BY SCENTIA INTERNATIONAL INC.
2
DESIGN OF EXPERIMENT
(3) Day Session
SECTION ONE Introduction to Design of
Experiment Quality
  • Purposes and Practices of DOE as linked to the
    use of quality tools
  • Define how DOE is currently applied in
    manufacturing operations
  • Identify key resources necessary to conduct
    successful DOE Programs
  • Learn basic advantages and limitations of DOE
    process
  • Identify specific goals for use of DOE in
    manufacturing processes


SECTION TWO Key Elements for Successful
Application of DOE
  • Introduction to Experimentation
  • Selection of criteria for design of DOE projects
  • Learn how to choose sampling data collection
    alternatives
  • Learn useful statistical tests for variables
    factors that effect DOE


Conduct a step by
step, in-class
experiment
  • Relate the principles of

Taguchi
loss and analysis to DOE applications
SECTION THREE Select and design an in-house
DOE project
  • Determine baseline criteria for your DOE project
  • Define the experimental levels for your
    in-house DOE project

  • Generate present a timeline and resource list
    for your DOE project
  • Define specific goals for your selected DOE
    project

(2) Day Session
SECTION FOUR Review in-house DOE and advanced
topics
  • Team summary review of experiment design,
    application, and results
  • Analysis of common roadblocks experienced in
    DOE design and application
  • Learn modeling methods for DOE and using DOE
    in problem solving


SECTION FIVE Learn how to improve
production operations
  • Learn to direct product and process design
    using DOE
  • Learn how to improve management of production
    operation product design
  • Show how DOE can reduce variance in your
    manufacturing operations system
  • Evaluate accuracy of the DOE results in
    seeking solutions to process problems

3
Purposes and practices of Design of Experiments
  • A Method to
  • describe
  • predict
  • and control
  • variables in a process in order to understand and
    improve the process or product.
  • In order to improve a process or system one must
    first understand it. If it is not understood,
    then any change made to it is tampering. The
    effect then is almost always detrimental to the
    quality of the process and product.

4
Purposes of DOE
  • To gain knowledge about the effects of variables
    (factors) in a process
  • Identify primary and secondary variables
  • Determine optimum levels of variables
  • Determine interactions of variables

5
Purposes of DOE
  • Identify key factors to design (or re-design) a
    process or product for better quality/efficiency.
  • Identify critical design parameters (1.2)
  • Provides a base to monitor measurements and tests
  • Can help in Failure Modes and Effects Analysis
    (FMEA)

6
Practices of DOE
  • Uses statistical principles to obtain accurate
    results
  • Yields more information than one-at-a-time
    experiments
  • Statistically valid design gives statistically
    valid results
  • Uses confidence testing to determine significance
    of effects

7
Practices of DOE
  • Leads to good engineering practice such as
  • Highly structured and thoughtful design and
    implementation encourages good design practice.
  • Provides a base to mathematically model a process
    using response surface methodology. (session 2)
  • Promotes systematic and logical testing that
    validates and verifies intuition and experience.
  • Encourages good decisions through documentation
    and data analysis.

8
Practices of DOE
  • DOE builds on basic quality tools
  • Depends on an in-control process
  • Control charts
  • Histograms
  • Flow Charts
  • Identification of factors
  • Cause and Effect diagrams
  • Pareto charts and Check sheets
  • Monitoring of changes made by DOE
  • Control Charts
  • Scatter plots

9
Purposes and practices of Design of Experiments
  • Summary
  • DOE provides an mechanism for active change in
    the improvement process.
  • A very effective high level tool that can be used
    in detail operations, sequential processes or
    overall systems.

10
DOE in Manufacturing Injection Molding Example
11
Tensile test Pareto Chart
  • Effects of Molding Variables on Tensile Strength

12
Interactions plot
  • What are the interactions that would effect the
    process? Example of fiber length and fiber
    concentration

13
Interactions Plot
  • What are the interactions that would effect the
    process? Example of temperature and mold
    thickness.

14
Interactions plot - 3-way example
  • What are the interactions that would effect the
    process? Example of all three factors.

15
DOE in Manufacturing
  • Composites injection molding example
  • Better able to manage the process for cost,
    time and quality
  • Better able to predict the effects of adjustments
    of the process
  • Can better meet customer requirements

16
DOE in manufacturing
  • The process in now easier to manage in the system
    for
  • Production amounts
  • Production times
  • Inventory/material required
  • Relationship to other operations

17
Identify resources necessary for successful DOE
  • Remember DOE is a prevention cost activity
  • More difficult to measure savings
  • Training and planning are critical and on-going

18
Identify DOE resource needs
  • Management support necessary
  • Time and money for training
  • Need management perspective to see impact on the
    whole system
  • Downtime, if necessary of process
  • Material/product costs (25-30 on experiment 1)
  • Knowledge and expertise
  • Statisticians (if any) can be of help
  • Experts involved in, or related to, the process
    being tested

19
Identify DOE resource needs
  • A method to help determine time and material
    resource needs
  • What product/process will be targeted and why?
  • How much time/material will be necessary to
    conduct experiment 1? (then multiply by four)
  • What will be the effect on production?
  • When will be the best time to conduct the
    experiment
  • Production schedule personnel
  • External conditions that may affect results
  • How much time to analyze and document the
    experiment

20
Advantages and limitations of DOE
  • Advantages
  • Statistical foundation yields a lot of
    information for relatively low cost
  • Provides main, secondary and interaction effects
    of factors being tested
  • Basic designs can be conducted and evaluated
    without significant statistical knowledge or
    expertise
  • Much more information than obtained from
    one-at-a-time experimentation
  • Pro-active tool for directing improvements

21
Advantages and limitations of DOE
  • Limitations
  • Not valid if process is not in-control or
    statistically stable
  • Requires more analytical skill than basic quality
    tools
  • Sometimes is used on processes when simpler tools
    would suffice
  • Care must be take not to confuse results, for
    example
  • Maintain homogeneity in material
  • External conditions should be as stable as
    possible
  • Requires good planning and documentation

22
Identifying specific goals for DOE
  • Ask Why am I using this tool on this problem?
  • This will help identify the desired response
    variable (the goal) for the experiment and ensure
    DOE should be used.
  • Ask How will improving the desired response
    variable improve the process?
  • Validates the need for conducting the experiment

23
Identifying specific goals for DOE
  • Ask How will improving the targeted process
    affect the system?
  • Protects against sub-optimization of a process at
    the expense of the system
  • Ask Can I maintain constant external
    conditions?
  • Helps to prevent introduction of special causes
    that would corrupt the analysis
  • If the external conditions cannot be maintained
    constant then they can be planned for

24
Identifying specific goals for DOE
  • Ask What are the main factors to be considered
    in this experiment?
  • Using a Cause and effect diagram will help answer
    this question
  • All who are part of the process (management to
    line people) should be involved
  • Ask Do I have baseline information for a
    benchmark?
  • If no baseline has been obtained this should be
    the first goal of data collection

25
End Section One
26
Main Tab Page for Section Two
27
Introduction to the experimental method
28
Introduction to the experimental method
The Factorial Pattern Row A B C D 1 2 -
__________k1 3 - 4 - - ________
__k2 5 - 6 - - 7 - - 8 - - -
__________k3 9 - 10 - - 11 - -
12 - - - 13 - - 14 - - - 15 - - - 16
- - - -__________k4
29
Introduction to the experimental method
  • How the factors and interactions are tested
    (refer to the factorial pattern on the previous
    page)
  • Factor A against desired response in rows 1 2
    (also rows 3 4)
  • Rows 1 8 together show effect of C on effect of
    B and effect of A (3-way)
  • Rows 1-4 show the change of A at high B and at
    low B (2-way)
  • Software does all this automatically

30
Introduction to the experimental method
  • Summary
  • Full factorials cover full design space
  • Full factorials are easy to lay out - repeating
    pattern in standard order
  • Multiple factors are tested and interactions

31
Design of the DOE
  • Cause and effect diagram (right side)
  • Review section 1 item 5
  • Determine how to measure the response variable

32
Design of the DOE
  • Screening designs (more later)
  • Cause and effect diagram (left side)
  • Historical data as baseline

33
Design of the DOE
  • Blocking
  • Planning for known variation (noise) that may be
    inherent in the experimental sample. For example
  • two replications from same lot
  • 1/2 of design in lot A and 1/2 in lot B
  • Randomization
  • To avoid time trends and other variation not
    known
  • Never run in sequence order
  • Avoids the effects of hidden variable
  • Validates statistical conclusions
  • Use tables or numbers from hat

34
Design of the DOE
  • Replication
  • Measure experimental variability
  • Improve estimate of effects
  • Determine if change in factor levels is special
    (induced) or common cause variation
  • A replication of a run is an independent and
    random application of the run including set up.
  • A repeat is application of a run without a new
    setup.

35
Data Collection
  • Strive for homogenous material
  • Same lots etc.
  • Reduce effects of time through randomization or
    new setup (example chemical bath degradation)
  • Use blocking and randomization to minimize
    external effects

36
Data Collection
  • Record keeping
  • Emphasize integrity and accuracy of documentation
  • Resisting estimating (let the data perform its
    function)
  • Note special conditions in the data collection
    sheet
  • Always include as much information as possible -
    name, time, date, location, operator, shift, etc.

37
Results will be no better than the quality of
data you obtain and record. Complete accuracy
and integrity in the data is critical
Data Collection
38
Statistical tests for DOE variables and factors
  • Calculating effects
  • A effect is the difference in the averages
  • Main effects
  • E(A)?A - ?A-
  • Interaction effects
  • E(AB)1/2(?A - ?A-)B - (?A - ?A-)B-

39
Statistical tests for DOE variables and factors
  • Standard deviation of experiment runs
  • Se?(?Si2/k)
  • Standard deviation of effects
  • SeffSe ?(4/N)
  • where N in the total number of trials
  • T-statistic
  • using t-tables (appendix) and degrees of freedom
    where
  • degrees of freedom
  • d.f.( of observations per run-1) X ( of runs)
  • See example with in class experiment

40
Statistical tests for DOE variables and factors
  • Charting the results
  • Pareto charts of results with significance limits

41
Statistical tests for DOE variables and factors
  • Interaction plots
  • parallel lines mean no interaction
  • normal lines mean strong interaction

42
Statistical tests for DOE variables and factors
  • Cube Plots
  • Shows the effects at planes and corners of the
    factorial

43
In class experiment
  • Determine the effects of
  • Heat treatment
  • Vendor
  • Size
  • on the durability of paper clips.
  • Will use 3 factors at 2 levels as defined by the
    experiment sheet

44
In class experiment
  • Groups of four people with the following tasks
    assigned
  • Test engineer _________________
  • Runs the test (bends the clips)
  • Analyst ______________________
  • Leads the team in calculating results
  • Recorder_____________________
  • Ensures all data is properly recorded
  • Lead engineer_________________
  • Ensures runs and treatments are performed in
    proper order and form

45
In class experiment
46
In class Experiment
47
In class experimentTime order plot of data
48
In class experimentSummary Table for
experimental results
49
In class experiment
50
In class experiment
  • Calculate effects
  • Calculate t-ratios
  • Construct Pareto Chart of effects
  • Construct Cube plot
  • Construct interaction charts
  • See appendix for chart blanks

51
End Section Two
52
Main Tab Page for Section Three
53
Review of Taguchi loss and DOE applications
  • Deviation from target is loss
  • Loss can be calculate for point or sample
  • Loss at a point is L(X) k(x-m)2
  • Loss of the sample set is Lks2 (in per unit)
  • kA/ª2 (A is the cost of failure at the spec
    limit, ª2squared distance from target to failure
    value)
  • xmeasured value
  • mtarget value
  • sstandard deviation of the sample

54
Review of Taguchi loss and DOE applications
  • DOE builds a model to identify both product and
    process target values
  • Robust design (product or process) will include
    DOE experiments.
  • Testing existing target values on products or
    process using DOE and historical data

55
Group design of a DOE
  • Flight time of a paper helicopter
  • Customers have been complaining about the short
    flight times of PHL (Paper Helicopter Ltd.)
    helicopters. Management want your group to
    redesign the helicopters to increase flight times.

56
Group design of a DOEHelicopter standard design
57
Group design of a DOE
  • Factors that may affect flight time
  • Approved possible modifications
  • Factor Standard Allowed change
  • Paper type Copier Heavy colored
  • Paper clip none yes
  • Taped body no yes (3 inches)
  • Taped wing joint no yes
  • Body width 75mm 100mm
  • Wing length 75mm 100mm
  • Each team must select only three factors

58
Group design of a DOE
  • Responsibilities and duties
  • Lead engineer________________
  • Final decision on prototype
  • Test Engineer________________
  • Final say on conducting tests
  • Assembly Engineer____________
  • Final say on building issues
  • Recorder____________________
  • Leads data collection and analysis

59
Group design of a DOE
60
Group design of a DOE Time order plot of data
61
Group design of a DOE Summary Table for
experimental results
62
Group design of a DOE
63
Your own DOE project
  • Determine baseline for the project
  • Is the process in-control?
  • If not then special causes must be eliminated
    before proceeding
  • Do you have historical data available?
  • If not then determine data collection method and
    collect data
  • If the process is in-control then proceed. If not
    see step 1.

64
Determine factors and levels for your DOE
  • Use a cause and effect diagram with others in
    involved to determine factors to be tested
  • Use only three factors

65
Determine factors and levels for your DOE
  • To determine levels
  • To be done with others involved with, expert in,
    or affected by the process.
  • What is the current baseline level?
  • What levels would those involved suggest be the
    edges of the operating range (or just ones all
    want to test)
  • Document the levels and the reason for the
    selected level

66
Generate Time line
  • Using a Gantt chart or project timeline determine
    the following task milestone dates
  • Finalize project design
  • Determine necessary resources
  • Conduct experimental runs
  • Analyze data
  • Present to group and instructor (July 26th)

67
Generate DOE resource list
  • A method
  • What product/process will be targeted and why?
  • How much time/material will be necessary to
    conduct experiment 1? (then multiply by four)
  • What will be the effect on production?
  • When will be the best time to conduct the
    experiment
  • Production schedule personnel
  • External conditions that may affect results
  • How much time to analyze and document the
    experiment

68
Identifying goals for your DOE
  • Why am I using this tool on this problem?
  • How will improving the desired response variable
    improve the process?
  • How will improving the targeted process affect
    the system?

69
Identifying goals for your DOE
  • Can I maintain constant external conditions?
  • What are the main factors to be considered in
    this experiment?
  • Should have been completed already
  • Do I have baseline information for a
    benchmark?
  • Should have been completed already

70
Good luck and see you in July
  • If you have questions feel free to email
    Professor Hawks at
  • hawksv_at_byu.edu

71
End Section Three
Write a Comment
User Comments (0)
About PowerShow.com
