Title: Phylogeny and Systematics, Ch 25, U208PP
1Phylogeny and Systematics, Ch 25, U208PP
2- This chapter describes how biologists trace
phylogeny (the evolutionary history of a species
or group of related species) - phylogeny used to draw heavily on the fossil
record - Biologists now also use systematics, an
analytical/mathematical approach - systematics may use computer analysis of
molecular sequences to infer relationships
between groups
Our goal is to accurately reconstruct the
relationships among different parts of Darwins
tree of life
How good is this evidence?
To do that, we are going to consider fossil,
morphological, and molecular evidence
3- Biologists draw on the fossil record
- Which provides information about ancient organisms
Figure 25.1
4The Fossil Record
- Sedimentary rocks
- Are the richest source of fossils
- Are deposited into layers called strata
Figure 25.3
5So you want to become a fossil? Here are the
steps
- Die, but die in the right place
- Do not be decomposed or scavenged
- Chemically change so that your hard parts
fossilize - Do not be damaged by geologic processes, like
earthquakes or erosion - Become exposed after thousands or millions of
years - Be found by someone competent to understand you
are a valuable fossil and not just some dumb ol
rock.
6- Though sedimentary fossils are the most common
- Paleontologists study a wide variety of fossils
7- The fossil record
- Is based on the sequence in which fossils have
accumulated in such strata - Fossils reveal
- Ancestral characteristics that may have been lost
over time - Fossils CAN show
- Location, age of fossil, size and body
organization - But frequently CANT show
- Internal anatomical changes
- Behavior
- Changes in body function
- Molecular changes/alleles
- color
Yea. And we have something else to be cautious
of
Whoa. So what you are saying is that the fossil
record may be incomplete (since not everything
fossilized or survived as a fossil to be
discovered) and that even existing fossils have
limitations?
8Sorting Homology from Analogy
- A potential misconception in constructing a
phylogeny - Is similarity due to convergent evolution, called
analogy, rather than shared ancestry
9- Convergent evolution occurs when similar
environmental pressures and natural selection - Produce similar (analogous) adaptations in
organisms from different evolutionary lineages
Figure 25.5
10- Analogous structures or molecular sequences that
evolved independently - Are also called homoplasies
THESE DO NOT REFLECT EVOLUTIONARY RELATIONSHIPS!
11Morphological and Molecular Homologies
- In addition to fossil organisms
- Phylogenetic history can be inferred from certain
morphological and molecular similarities among
living organisms - In general, organisms that share very similar
morphologies or similar DNA sequences - Are likely to be more closely related than
organisms with vastly different structures or
sequences
12- Currently, systematists use
- Morphological, biochemical, and molecular
comparisons to infer evolutionary relationships
Figure 25.2
13Evaluating Molecular Homologies
- Systematists use computer programs and
mathematical tools - When analyzing comparable DNA segments from
different organisms
14- Phylogenies are based on common ancestries
inferred from fossil, morphological, and
molecular evidence
15- Concept 25.2 Phylogenetic systematics connects
classification with evolutionary history - Taxonomy
- Is the ordered division of organisms into
categories based on a set of characteristics used
to assess similarities and differences
16Binomial Nomenclature
- Binomial nomenclature
- Is the two-part format of the scientific name of
an organism - Was developed by Carolus Linnaeus
- Administered today by international scientific
organizations, r.g., International Code of
Botanical Nomenclature
- The binomial name of an organism or scientific
epithet - Is latinized
- Is the genus and species
17Canis familiaris
Escherichia coli
Quercus niger
Tyrannosaurus rex
Homo sapiens
Staphlococcus aureus
Lymantria dispar
Quercus rubra
18Hierarchical Classification
- Linnaeus also introduced a system
- For grouping species in increasingly broad
categories
Figure 25.8
19Linking Classification and Phylogeny
- Systematists depict evolutionary relationships
- In branching phylogenetic trees
Figure 25.9
20- Each branch point
- Represents the divergence of two species
21- Deeper branch points
- Represent progressively greater amounts of
divergence
