Implementing Remote Procedure Calls

1
Implementing Remote Procedure Calls

• Authored by Andrew D. Birrel and Bruce Jay
  Nelson
• Presented by Terry, Jae, Denny

2
Outline

• An introduction to RPC
• Principles to follow in RPC
• An implementation of RPC
• Binding
• Packet-level Transport Protocol
• Other issues

3
1. Introduction to RPC

• Basic idea
• Extend local procedure calls
• General steps
• Caller calls a remote procedure
• System suspend caller
• Pass parameters of the call to callee
• Invoke desired procedure executed in callee
• Callee returns the result back to caller
• Caller receives the result and resumes.

4
RPC Advantages

• Clean and simple semantics
• Local call alike
• Efficient Procedure steps can be executed
  rapidly
• Generality
• Procedures the most important mechanism for
  communication between parts of the algorithm
• Think about distributed computation

5
RPC Major issues

• The precise semantics of a call when
• Machine failure
• Communication failures
• The presentation of address in the absence of a
  shared address space
• Integration of remote calls into existing
  programming systems.
• Binding
• Data and control protocol between caller and
  callee
• Data integrity and security in an open
  communication network.

6
Aim to built RPC package

• Primary goal Make distributed computation easy.
• Secondary goals
• Expected to be efficient.
• Semantics should be as powerful as possible.
• Provide clients secure communication with RPC.

7
Built RPC Fundamental Decisions

• Paradigm for expressing control and data transfer
• Procedure call
• Reason
• Procedures are popular
• The major control and data transfer mechanism in
  the language
• Alternatives
• shared space

8
Built RPC principle

• Semantics of remote procedure calls
• as close as possible to local procedure calls
• Fail to obey this principle are likely to make
  the package difficult to use
• Following this rule
• Have to discard some attractive ideas
• No timeout limiting duration of a call
• Local calls does not set timeout

9
RPC Structure

• Concepts of stubs
• Five modules
• User
• User-stub
• The RPC communicate package (RPCRuntime)
• Server-stub
• Server

10
RPC Steps

• Normal call by user
• invokes corresponding procedure in the user-stub
• User-stub place a specification of the target
  procedure and the arguments into packet
  (marshalling)
• User-stub ask RPCRuntime to send
• RPCRuntime in callee receive packets
• RPCRuntime pass packet to server-stub
• Server-stub unpack (unmarshalling ) and call
  local call
• Server returns to server-stub
• Result passed back to process in the caller

11
Structure RPCRuntime

• RPCRuntime
• A standard part of the operation system
• In charge of
• Retransmission of not ACKed packets
• Acknowledgments of received packets
• Routing and encryption of packets
• TCP/IP protocol?

12
Structure User and server stubs

• User and server stubs
• Automate generated by a program called Lupine
• Generation is specified by a interface module
• Interface module
• A list of procedure names
• With the types of their arguments and results
• Compare to Sun RPC
• Interface compiler generate client and server
  stubs from the interface definition of the service

13
Structure

• Interface module provide sufficient info to
  Lupine
• Export interface
• Program module that implements procedures in an
  interface
• Import interface
• program calling procedures from an interface

14
How to use?

• Designing the interface
• Write interface module
• Presents the interface to Lupine
• Write user and server code
• Invoke the inter-machine binding
• Handle failures.

15
2. Binding

• Aim
• Binds an importer of an interface to an exporter
  of an interface
• Two questions
• How does a client of the binding mechanism
  specify what he wants to be bound to?
• How does a caller determine the machine address
  of the callee and specify to the callee the
  procedure to be invoked?
• Compare with port-mapper used in Sun RPC

16
Binding naming

• Name of an interface has two parts
• Type
• At some level of abstraction which interface the
  caller expects the callee to implement
• Instance
• Which particular implementor of an abstract
  interface is desired.

17
Binding Locating an appropriate exporter

• Distributed database used
• In the database
• Entry for instance
• Individual whose connect-site is a network
  address
• Entry for type
• A Group whose members are keys of the instance
• of that type which have been exported.

18
Binding exporter side

• When An exporter wishes to make his interface
  available to clients
• Server calls the server-stub
• Server-stub calls a procedure, ExportInterface in
  the RPCRuntime
• ExportInterface is given the interface name (type
  and instance), and a dispatcher.

19
Binding exporter side (cont)

• The procedure check the DB, making sure that
• the instance is the member of the type
• and connect-site of the instance is the network
  address of the exporting machine.
• Now Grapevine update the exporter information
• Every export is assigned a unique identifier
  (counter).

20
Binding importer side

• When a importer wishes to bind an exporter
• User call user-stub
• User-stub calls a procedure, ImportInterface, in
  the RPCRuntime, giving the desired interface type
  and instance.
• RPCRuntime ask Grapevine for instance, get
  connect-site

21
Binding importer side (cont)

• RPCRuntime make RPC call to the RPCRuntime on
  that machine asking for the binding information
  associated with this interface type and instance.

• If the specified machine is not exporting then
  binding fails.
• Else returns
• The corresponding unique identifier
• the table index to the importing machine
• Binding succeeds
• User-stub record info for next time
• The exporter network address
• Identifier
• Table index of dispatcher

22
Binding

• Now user-stub make a call on the imported remote
  interface
• The call packet contains the unique identifier
  and table index of the desired interface
• RPCRuntime on the callee machine receives the
  packet
• Uses the index to look up its table of current
  exports
• Verifies the unique identifier
• Pass the packet to the dispatcher procedure
  specified in the table

23
Binding compare to Port Mapper

• Compare to Port Mapper in Sun RPC
• Port mapper
• Runs locally
• Port as result
• Our implementation
• Use distributed database
• Does not use TCP/IP, do not have port
• Interface type and instance to find
• Result is table index to the dispatcher and
  unique ID
• Which is better?

24
3. Packet-level transport protocol

• Specialized packet-level protocol gives us
• Minimizing the time between initiating a call and
  result
• Minimizing the load imposed on a server

25
Packet-level transport protocolTwo schemes

• Simple calls
• Complicated calls

26
Simple calls

• All of the call arguments will fit in a single
  packet
• So do result
• Calls are frequent

27
Simple calls how to

• Caller sends a call packet containing
• A call identifier
• Call identifier
• Calling machine identifier
• Machine-related Process identifier
• Sequence number of the transaction
• Activity is defined
• machine ID, process ID
• data specifying the desired procedure, and
  arguments
• Callee return a result packet containing
• The same call identifier
• the results

28
Simple calls how to (cont)

• A call packet is ACKed by the result packet
• A result packet is ACKed by the next call packet
• If duration of a call and the interval between
  calls are less than the transmission delay
• Two packets per call, one in each direction, one
  call, one ACK
• If calls last longer or intervals longer
• Two additional packets send (a retransmission, an
  explicit ACK)
• An overhead we can endure

29
Simple calls Call identifier

• Call identifier is used for several reasons
• Allows the caller to determine that the result is
  the result of current call
• Allows the callee to eliminate duplicate call
  packets

30
Simple Protocol summary

• No special connection establishment protocol
• receive of a call packet is enough
• No communication to maintain idle connection
• No explicit connection termination protocol
• discard state information after an interval.
• Relies on the unique identifier to detect
  duplicates
• Also assume that the call sequence number from an
  activity does not repeat.

31
Complicated Calls

• Packet transmitted are modified to request an
  explicit ACK
• Caller periodically sends probe packet to callee
• Callee expected to ACK to the probe
• Caller wait as long as probes are ACKed
• When communication failure
• caller should be told fairly soon (no ACK for
  probe)
• Only detect failure in communication levels
• principle of making RPC semantics similar to
  local calls.

32
Complicated Calls (cont)

• If the arguments are too large, multiple packets
• Last of these packets request explicit ACK
• Use only one packet buffer at each end for the
  call
• Avoid to include buffering and flow control
• Call-relative sequence number
• for multiple data packets within a call

33
Complicated Call performance

• If transferring a large amount of data in one
  direction
• Sends up to twice as needed
• if represented as procedure calls
• Still desirable
• Dominant advantage over requiring one ACK for
  each packet
• Simplifies and optimizes the implementation

34
Other issues

• Exception handling
• Emulate signals
• exception and catch
• Add a call failed exception
• Raise if communication difficulty happened
• The primary way for clients to note the
  difference between local and remote calls
• Take process creation and swap into consideration
• Process creation and swaps consume significant
  cost
• Aim to lower the cost
• After the refinement
• simple calls create no processes
• only a few process swaps in each call

35
Thank you!
