iTech

1
Welcome
2
iTech
3
Hardware Requirements For iTEC Pro

OR
PF80793
4
Screenshot of iTech
5
iTech Raising Planter
6
iTech Lower Planter
7
The Ultimate Choice in Accuracy

• John Deere Automatic Guidance Family
• AutoTrac SF1
• AutoTrac SF2
• AutoTrac RTK

8
Making the Ultimate Choice
9
AutoTrac Performance and Expectations

AutoTrac System Performance
Signal Accuracy at StarFire Receiver




Vehicle factors
Implement factors
Vehicle Kit
Field Conditions
StellarSupport.com
10
StarFire Network SF2
11
StarFire RTK
12
RTK Xtend

• Allows an automatic backup mode to operate with
  RTK level accuracy for up to 15 minutes after
  RTK radio communication is lost.
• Allows for superior productivity in terrain with
  hills and trees
• 2 minutes in first hour of operation

13
SF2 vs. RTK

• SF2
• GPS drift Shift Track needed
• High Accuracy Shift Track needed
• Low initial investment
• Geographic flexibility
• No maintenance required
• Recurring subscription
• One subscription per tractor

• RTK
• High repeatability no Shift Track
• High Accuracy no Shift Track
• Higher initial investment
• 12 mile line of sight range restriction.
• Base station maintenance
• No subscription
• Multiple tractors per base station

14
Vehicle Factors

• Ballast ensure tractor is weighted properly.
  (Power hop, Wheel Slip, etc)
• Tractor balance Tire pressure, tread settings,
  saddle tanks, fluid in tires, wheel weights, etc.
• MFWD or Differential Lock engaged
• Minimize cab side-to-side movement

15
Field Conditions

• Soil Surface
• Rough, Cloddy, Rocks
• Surface residue
• Soil Profile
• Soil Type
• Compaction
• Moisture Levels

16
Implement Factors

• Implement must be square and pull evenly to
  tractor.
• Missing/unevenly spaced shanks.
• Gauge wheels
• Cylinder stop adjustments
• Drawn vs. Integral
• 3 pt. Implements
• Sway blocks, float pins, lift links, etc

17
Uneven Draft Load
Even Draft Load

• 8220 MFWD w/ Row crop cultivator
• Minimal draft load 3-5 slip
• Right pass - cultivator was within the previous
  disked pass
• Left pass 1/2 the cultivator was within the
  disked pass and 1/2 was in non-disked ground.

18
No AutoTrac to RTK

• CURRENT COMPONENTS
• None

• NEEDED COMPONENTS
• StarFire Receiver 4,495
• AutoTrac Activation 7,000
• GS2 Display 4,995
• RTK Radio 4,295w/RTK Activation
• Subscription 1,000-1,200
  Fee/Year
• TOTAL 21,785
• Will require a wiring harness(es) of some sort


19
SF1 AutoTrac to RTK

• CURRENT COMPONENTS
• StarFire Receiver
• Wiring Harness(es)
• Display

• NEEDED COMPONENTS
• SF1 to SF2 Upgrade 2,000
• AutoTrac Upgrade 4,000
• RTK Radio 4,295
• w/RTK Activation
• Subscription 1,000-1,200
• Fee/Year
• TOTAL 10,295

20
SF2 AutoTrac to RTK

• CURRENT COMPONENTS
• SF2 Receiver
• Display
• SF2 AutoTrac
• Harness(es)

• NEEDED COMPONENTS
• RTK Radio 4,295
• w/RTK Activation
• Subscription 1,000-1,200
• Fee/Year
• TOTAL 5,295

21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Swath Control Pro

• Controls boom and planter sections or rows
  (Tru-Count system)
• Compatible only with GS2 system.
• SprayStar update required or Rate Controller.
• Adjustable settings for boom shutoff timing.

26
GS2 Rate Controller Goal

• Enable rate control, guidance, and boom/section
  control on the GS2 display
• First platform - pull-type sprayers
• Now released for Planters

27
Components
ISO Implement Connector
GreenStar 2 System
Terminator
Footswitch
Fuse
Flexbox
Existing Sprayer Harness
Switchbox (optional)
28
Components
29
Components
30
Main Page
Flowmeter Reading
Speed
Target and Actual Rates
Setup
Boom Section Indexing
Totals
Diagnostics
Tank Level
Rate Selection
Section Status
Productivity
31
Other Operations

• Setup

32
Configurable Home Pages
33
Configurable Home Pages
34
Thank You!
