Title: Physical properties of snowpack


1
Physical properties of snowpack
  • Birute Vaitelyte, Marta Martínez,
  • Lui Yuen Shan

2
Aims of the study
  • Study thermal insulation capacity of the snow and
    how plants and insects are affected
  • How the snow density changes according to the
    temperature gradients between snow surface
    temperature and ground temperature

3
Snow Density
4
  • When snow fall at the beginning, it is usually in
    hexagonal shape.
  • Once it landed, it start to metamorphose
  • Metamorphism means to change or transform into
    other shape and state

5
Three types of metamorphism
  • Destructive metamorphism
  • Constructive metamorphism
  • Melt metamorphism

6
Destructive metamorphism
  • Edge of the crystal is rounded, snow crystals
    deteriorate and become round ice grain
  • Causes Weight of snow, wind, temperature
  • Result Surface area to volume of the ice ?
  • The density and strength of snow ?

7
Constructive metamorphism
  • Snow crystals edge is sharpened
  • Causes Temperature gradient within the
    snowpack.
  • Result Structural strength of the snowpack ?
  • Density is usually kept constant

8
Melt metamorphism
  • Contributes most to the change in density of snow
  • Causes Melt-freeze cycles (melt during day
    freezing at night )
  • Result Snow density and strength ?

9
Results and Conclusion
  • Density of snow is the highest in the middle
    layer (30-40cm)
  • Lowest density in the top most layer ( 50-70cm)
  • The lowest layer of snow pack usually has the
    moderate density due to the constructive
    metamorphism caused by the ground heat.

10
  • Result is not obvious because
  • The depth of snow is not deep enough ?
  • Not heavy enough to give pressure (weight) on
    the snow in lower layer for obvious destructive
    metamorphism to increase the snow density in the
    middle layer.
  • There is some flora or grass on the ground that
    affect sampling of pure snow.

11
Temperature
  • Once snow falls to the ground it begins to change
    in a process called metamorphism
  • The form of the crystals and the texture of the
    sedimentary layer of snow change over time

12
  • Snow pack temperature affects the availability of
    snow pack to buffer extreme melt events.
  • Snow temperature of a layer helps to determine
    the rate of metamorphism
  • If snow is warm process occurs faster

13
Results and conclusionsGround temperature may
affect snow temperature?
14
(No Transcript)
15
  • Observations
  • Correlation between distance from the ground and
    temperature of the snow
  • Each day we see that the closer in the ground,
    the higher temperature we have.
  • Same pattern every day but pine forest
    temperature is lower than bog forest temperature
  • Air temperature fluctuates a lot between days but
    ground and snow temperature remains without big
    changes
  • Near ground, temperature is constantly near 0 C

16
Insulative Quality of snow
  • Snow serves as an effective thermal insulation
    layer. An accumulation of snow provides
    protection from wind serving as a "roof" over the
    subnivean spaces occupied by many plants, small
    mammals.
  • Snow is also an effective insulator, especially
    when newly fallen, because it forms an emulsion
    of crystals and air. It traps dead air that
    increases the insulative efficiency.
  • The formula used to calculate insulative quality
    is
  • It ? (z/G)I
  • Where z is the thickness (cm), G is the density
    (g/cm3) of each layer i ( Marchand 1996)

17
The InvertebratesSupranivean and Intranivean
Fauna
  • Marten Seidel
  • Renata Süß
  • Esther Jiménez Casanueva
  • Laima Laukaityte

18
Content
  • Introduction
  • Supranivean Fauna
  • Intranivean Fauna
  • Methods
  • Results
  • Conclusion

19
1. Introduction
  • Invertebrate is a term to describe any animal
    without a spinal column
  • Seasonal snow cover is an atmospheric sediment of
    short duration
  • Life can continue above, in and under snow
  • Fauna which lives on and above the snow cover is
    called supranivean fauna
  • Fauna which lives in or below the snow cover is
    called intranivean fauna

20
1. Introduction
  • Wintertime is a passive time for flora and fauna
  • Low temperature, thick snow cover and less
    incoming light
  • set limits for metabolic cell functions
  • reduce energy availability

21
1. Introduction
  • Fauna and flora developed special adaptations to
    cope with this stress factors
  • Five different strategies
  • migration
  • dormancy
  • communal behavior
  • winter activity
  • physiological escape.

22
2. Supranivean Faunaon snow cover
  • During sampling period no supranivean
    invertebrates were observed on snow
  • Species appear only on or above snow cover when
    climatic conditions fit to their requirements
  • Low temperatures might be one explanation for the
    absence of these invertebrates

23
2. Supranivean Faunaabove snow cover
  • There are groups of invertebrates which
    overwinter above the snow cover
  • Samples from passive overwintering invertebrates
    were collected
  • Traces of these animals are mostly galls

24
2. Supranivean Faunaabove snow cover - examples
  • Galls of Rhabdophaga rosaria were collected on
    Salix phylicifolia
  • Characteristic rose-like excrescences (gallnuts)
    located at the peaks of willow branches

25
2. Supranivean Faunaabove snow cover - examples
  • - Each rosette contains a single larva which
    pupates inside the gall

26
2. Supranivean Faunaabove snow cover - examples
  • Galerucella lineola (brown willow beetle) on
    leaves of Salix phylicifolia
  • light reddish brown beetle, about 5-7 mm
  • feeds on leaves of willows, poplars
  • eggs laid on the lower and upper side of leaves
  • beetles feed only single cell layers away
  • they do not create holes

27
2. Supranivean Faunaabove snow cover - examples
  • Galerucella lineola

28
3. Intranivean Fauna
  • Invertebrates migrate vertically into the ground
    to prevent freeze damages
  • Snow cover is an excellent insulator
  • snow layers near soil are usually warmer than air
  • animals tend to live in or under the snow, to
    avoid the cold temperature ? can stay active
    during winter

29
4. Methods
  • Samples from Myrtillus type pine forest and from
    pine bog forest
  • Snow profile was dug and snow samples were taken
    in different depths
  • Each sample was taken in horizontally direction
    by using plastic sampling containers (Volume one
    liter)
  • In the laboratory
  • snow was melted in a plankton net
  • melting water was filtered and collected in
    plastic test tubes
  • melting water samples were examined
  • individuals were identified and counted
  • amount of individuals per m3
  • the vertical distribution of animals was
    estimated

30
5. ResultsCollembola
31
5. ResultsAcari
32
5. Results
33
5. ResultsPseudoscorpion
34
5. ResultsAraneae
35
5. Resultsfor pine bog forest
36
5. Resultsfor myrtillus - type pine forest
37
5. Resultscomparison between both sites
38
5. Resultscomparison between both sites
39
6. Conclusion
  • Highest individual and species density in the
    snow layer closest to the soil surface
  • It is assumed that temperature affect the
    vertical distribution of invertebrates
  • During the sampling period temperatures were very
    low (max. -23C) ? possible explanation for the
    high abundance of species and individuals in the
    lowest layer of the snow cover
  • Other factors which might influence migration
  • food availability, snow density or competition

40
6. Conclusion
  • high total amount of individuals in the upper
    most snow layers of the pine bog forest
  • higher solar radiation
  • the snow layers density is relatively low ?
    enables migration

41
6. Conclusion
  • Pine bog forest hosts high numbers of Collembola
    and Myrtillus-type pine forests host high numbers
    of Acari
  • Reasons might be soil properties
  • Peatlands have very wet and acidic soils (pHlt
    4.0)
  • Myrtillus-type pine forests not so acidic soil pH
    and less moister content
  • ? differences in the species composition

42
6. Conclusion
  • Comparable results were reported in similar
    studies which were done during the last years

43
Case study of twig lice egg density and goldcrest
winter demand
  • Maria Luisa Castrillo
  • Iago Fernandez Perello
  • Vincent Viblanc

44
Aims of the study
  • Density and mortality variations in overwintering
    eggs of two species of twig lice Lachnus pineti
    and Lachnus spp
  • Repercussions on the foraging and feeding
    behaviour of the common goldcrest Regulus regulus

45
Overwintering in Pine aphids
  • Lachnus pineti and Lachnus spp increase their
    chances of survival by overwintering in the egg
    stage.
  • In the beginning of autumn, females lay their
    eggs on pine needles where the latest remain
    until next thaw.
  • From this study we shall see whether or not a
    difference can be observed about oviposition
    site, as we expect the females to prefer young
    annual shoots having higher nutritional value
    than older ones.

46
Material and methods
  • The eggs of 2 different species were studied
    Lachnus pineti and Lachnus spp.
  • The density of twig lice eggs, both total and
    living densities, were estimated via obtaining
    field samples of pine branches and counting the
    total number of eggs found on the needles.
  • Dead or living eggs can be easily separated by
    visual determination. Living eggs are smooth and
    shiny whereas dead eggs are rough and dehydrated

47
Living and dead eggs of Lachnus pineti and
Lachnus spp.
  • Top Live and dead eggs of Lachnus spp
  • Bottom Live and dead eggs of Lachnus pineti

48
Results
49
Results
  • The egg density is higher in the first annuals

50
Results
  • Survival of twig lice eggs decreases through the
    annuals

51
Results
  • Daily food necessities of the goldcrest 6 g
  • Average weight of one egg 0,26 mg
  • Around 23,000 eggs are required per bird and day
    !!!
  • This means that the goldcrest must find and eat
    an average of 48 eggs per minute in order to
    complete its daily food needs.
  • Therefore, the goldcrest does not rely only on
    the availability of aphid eggs but complements
    its daily food intake with other insects found
    amongst pine branches.

52
Discussion
  • The twig lice prefer to lay their eggs on the
    first annual needles
  • Lice prefer to feed on the first annuals, because
    of higher energetic value of the younger shoots.
  • The survival of eggs of the first annual is
    higher.
  • Goldcrest optimizes its energetic intake by
    foraging on the younger shoots

53
References
  • Gray, D. M. and D. H. Male, 1981. Handbook of
    Snow Principles, Processes, Management and Use.
    Willowdale, Ontario, Canada, Pergamon Press,
    776p.
  • Holopainen, I. J et all, 1994. Northern Winter
    as an Ecological Factor, University of Joensuu,
    Finland, 22p.
  • Marchand, P. J., 1996. Life in The Cold,
    University Press of New England.
  • McClung, D. and P. Schaerer, 1993. The Avalanche
    Handbook. The Mountaineers, Seattle, WA.
  • http//www.blueiceonline.com/howsite/snowpit_about
    .html
  • http//www.geotech.org/survey/geotech/Snow20Metam
    orphosis.pdf.
Write a Comment
User Comments (0)
About PowerShow.com
