Apache ServiceMix 4.0

1
Apache ServiceMix 4.0

• The Next Generation ESB

Guillaume Nodet
2
About the author
Guillaume Nodet

• Open Source
• PMC Chair of the Apache ServiceMix project
• Involved in Apache Geronimo, Apache ActiveMQ,
  Apache ODE, Apache CXF, Jencks
• Previously involved in XFire, Mule

• IONA Principal Engineer
• Since LogicBlaze acquisition in April 2007

3
Schedule

• JBI 1.0
• Overview
• Architecture
• WSDL Messaging Model
• Normalized Message Router
• Lessons learned
• Apache ServiceMix 4.0
• Goal
• Standard based
• Simplified API

• Building blocks
• OSGi as a platform
• Spring for configuration
• Intuitive EIP router
• High performance message broker
• Easy to use Services Framework
• Around the container
• Eclipse tooling
• Long term
• JBI 2.0, SCA
• Demo

4
JBI 1.0 what is JBI?

• Integration Systems
• Plug-in Components
• Normalized exchanges
• WSDL
• Decoupling

5
JBI 1.0 architecture
6
JBI 1.0 WSDL messaging model

• Abstract model
• Concrete model
• Service providers
• Service consumers

7
JBI 1.0 WSDL messaging model
Abstract model

• Message type
• Normal
• Faults
• Operation
• Qualified name
• Message Exchange Pattern
• Message types
• Interface
• Qualified name
• Operations
• Extended interfaces

8
JBI 1.0 WSDL messaging model
Concrete model

• Binding type
• Endpoint
• Endpoint name
• Binding type
• Service
• Qualified name
• Interface name
• Endpoints

9
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

10
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Consumers and providers
• WSDL description
• Abstract model
• Decoupled

11
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Normalized Message
• XML payload
• Properties
• Attachments

12
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Delivery Channel
• Communication between a component and the NMR

13
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Endpoint activation
• Declaring Service endpoint
• Providing metadata

14
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Service invocation and MEP
• In-Only
• Robust-In-Only
• In-Out
• In-Optional-Out

15
JBI 1.0 Normalized Message Router

• Consumers and providers
• Normalized Message
• Delivery Channel
• Run-time Endpoint Activation
• Service invocation and MEPs
• Message Exchange
• Endpoints

• Endpoints
• External
• Internal
• Addressing
• Implicit
• Explicit
• Dynamic

16
JBI 1.0 Lessons learned

• Pros
• Normalized exchanges
• Normalized Message Router
• Cons
• Classloader architecture
• JBI packaging
• Writing components is complex
• Role of the component ?

17
ServiceMix 4.0 Goal

• Enterprise OSGi Container
• Lightweight
• ESB and SOA container
• Ease of use

18
ServiceMix 4.0 Standard based

• Short Term
• JBI 1.0
• JAX-WS, WS-

• On the long term
• JBI 2.0 support
• SCA

• IONA Support
• Involved in JBI 2.0 EG, OSGi Alliance (leading
  OSGi Enterprise Edition EG), SCA

19
ServiceMix 4.0 Simplified API

• No more components
• Deployment / Classloader is delegated to OSGi
• Bundles as the packaging and extension mechanism
• Leverages OSGi architecture
• Leverage spring-osgi (optionally)
• Endpoints as first-class citizens
• Endpoint are activated when registered in the
  OSGi registry
• Channel is now on the Endpoint
• Endpoints use push delivery rather than pulling
  the channel

20
Building blocks

• Avoid reinventing the wheel
• Framework OSGi (Apache Felix)
• SOAP support Apache CXF
• JMS broker Apache ActiveMQ
• Routing Engine Apache Camel

21
Apache Camel

• Java DSL for EIP

• from(http//localhost8080/requests/).
• tryBlock().
• to(activemqqueuerequests).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).
• setFaultBody(constant(ltnack/gt))

• from((activemqqueuerequests?transacted
  true).
• process(requestTransformer).
• to(http//host8080/Request).
• filter(xpath(//nack)).
• process(nackTransformer).
• to(jdbcstore)
• from(http//localhost8080/responses/).
• tryBlock().
• to(activemqqueueresponses).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).

22
Apache Camel

• Java DSL for EIP

• from(http//localhost8080/requests/).
• tryBlock().
• to(activemqqueuerequests).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).
• setFaultBody(constant(ltnack/gt))

• from((activemqqueuerequests?transacted
  true).
• process(requestTransformer).
• to(http//host8080/Request).
• filter(xpath(//nack)).
• process(nackTransformer).
• to(jdbcstore)
• from(http//localhost8080/responses/).
• tryBlock().
• to(activemqqueueresponses).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).

from(http//localhost8080/requests/).
tryBlock(). to(activemqqueue
requests). setOutBody(constant(lt
ack/gt)). handle(Throwable.class).
setFaultBody(constant(ltnack/gt))
23
Apache Camel

• Java DSL for EIP

• from(request).
• tryBlock().
• to(requestStorage).
• setOutBody(constant(ack)).
• handle(Throwable.class).
• setFaultBody(constant(nack))
• from(requestStorage).
• process(requestTransformer).
• to(requestProvider).
• filter(isNack).
• process(nackTransformer).
• to(dbStorer)
• from(responseConsumer).
• tryBlock().
• to(responseStorage).
• setOutBody(constant(ack)).
• handle(Throwable.class).

from(request). tryBlock().
to(requestStorage).
setOutBody(constant(ack)).
handle(Throwable.class).
setFaultBody(constant(nack))
24
Apache Camel

• Java DSL for EIP

• from(http//localhost8080/requests/).
• tryBlock().
• to(activemqqueuerequests).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).
• setFaultBody(constant(ltnack/gt))

• from((activemqqueuerequests?transacted
  true).
• process(requestTransformer).
• to(http//host8080/Request).
• filter(xpath(//nack)).
• process(nackTransformer).
• to(jdbcstore)
• from(http//localhost8080/responses/).
• tryBlock().
• to(activemqqueueresponses).
• setOutBody(constant(ltack/gt)).
• handle(Throwable.class).

ltroutegt ltfrom urihttp//localhost8080/request
s/ /gt lttrygt ltto uriactivemqqueuerequest
s /gt ltprocess refsetAck /gt ltcatchgt
ltexceptiongtjava.lang.Throwablelt/exceptiongt
ltprocess refsetNack /gt lt/catchgt
lt/trygt lt/routegt
25
Tooling

• Cimero

26
Tooling

• Cimero
• Contributed to Eclipse STP by Bull
• Currently under IP process at Eclipse
• Extend to provide support for Camel
• Roundtrip with Camel

27
Roadmap

• ServiceMix 3.1.2 being release(first official
  release after graduation)
• ServiceMix 3.2 following (beginning of October)
• ServiceMix 4.0-m1 in october
• Milestones every month or so until 4.0 final (Q1
  2008)
• Contributors are welcome!

28
Questions ?

• Guillaume Nodet
• Blog http//gnodet.blogspot.com
• Email gnodet_at_gmail.com

29
