Title: Overview of CanSat Imaging System


1
Overview of CanSat Imaging System
2
Personnel
  • EE Members
  • Nigel Dunham Senior EE, CanSat Team Leader.
  • YiYang Senior EE.
  • Ibrahima Diack Senior EE.
  • Anthony Olson Senior EE.
  • Mishari Al-Nahedh Senior EE.
  • AE Members
  • Stephen Mance Sophomore AE, AE team leader.
  • Laura Stiles Sophomore AE.
  • Jess Snyder Sophomore AE.
  • Ryan Shaffer Sophomore AE.
  • Dr. Prescott and Dr. Sorensen are also the
    CanSat competition advisors

3
Outline of Approach
  • The CanSat system must
  • Capture multiple ground images
  • Assemble ground images to create a map of the
    ground using commercial or custom software.
  • Imaging system needs to compensate for rocking,
    etc. while aerial.
  • Record the time, position, and altitude when each
    digital image was taken.
  • Display position, altitude, orientation, and the
    time the image is captured in real time at the
    ground command center using capable software.
  • A command uplink starts recording of digital
    images.

4
Design Constraints
  • All structure and components shall fit inside
    soda can
  • The CanSats total mass will be 370 grams or less
  • A parachute will be sized for a flight of at
    least three minutes and less than seven minutes
  • The parachute must survive 20 Gs of shock
  • Flexible wire antennas are allowed to extend
    beyond the surface of the CanSat opposite of the
    parachute.
  • The CanSat power must last at least one hour.
  • The CanSat operation must be activated by an
    activation uplink command.
  • Operations cannot start until the uplink command
    is received.
  • The activation uplink command may be sent after
    the launch control officer (LCO) allows the
    operation.
  • The cost of the CanSat hardware must not exceed
    500.

5
Block Diagram of CanSat System
  • 4 Subsystems
  • Imaging
  • Communications
  • Navigation
  • Structure

Important Note U-processor encompasses the
entire project and all 5 team members will work
on this aspect for each subsystem.
6
Microcontroller
  • CanSat will require microcontroller to have
  • RS232 for digital GPS data
  • Minimum of 6 I/O channels
  • 3 for GPS data
  • 1 for Imaging
  • 1 for Tx and 1 for Rx
  • Possible Microcontroller
  • Model Parallax BASIC Stamp DC-16
  • Very good in terms of cost vs. functionality
  • (30 for complete u-processor with 16 I/O
    channels)
  • High ratings for simplicity of programming

7
Structure and Parachute
  • Structure
  • The structure that will house the avionics will
    be built by the AE team. This structure will fit
    inside a 12 oz soda can.
  • It will be custom made of a lightweight
    carbon-fiber composite
  • Parachute Design
  • Parachute will be designed by AE team
  • Design is in accordance with design
    constraints
  • Material will be light weight, strong and
    flexible

8
Imaging Subsystem
9
Image Capturing
  • The CanSat system will capture multiple ground
    images and then assemble these images to create a
    map of the ground using commercial or custom
    software.

10
Available Devices (1)
  • Place a digital camera in side the CanSat system
  • Send a periodic signal to the shutter to take
    pictures
  • Retrieve images saved in the cameras memory
    using a UBS cable connect to the computer.

11
Available Devices (2)
  • Place a mini video camera inside of the CanSat
    system
  • Transmit real-time video signal back to control
    center
  • Capture images at the control center

12
Comparison
  • Using a digital camera to take aerial pictures is
  • a better choice because
  • Easy to rectify.
  • No need to provide power to the transmitter.
  • Easy to retrieve images.

13
Imaging Design Constraints
  • Weight
  • Size
  • Cost
  • Image quality
  • System Stability

14
Possible Design
  • Adequate room for the imaging system
  • Stability

15
HF Radio Transceivers
16
Transceivers
  • What is the Need?
  • Reliably exchange data between
  • CanSat and ground station
  • Wireless Transceiver
  • IEEE 802.11
  • Optical transceivers
  • RF Transceivers

17
Choosing a Transceiver
  • Range (over Two miles)
  • - 802.11 offers ranges up to 100 meters
  • - Infrared technology only several feet
  • - RF communications up to several mile
  • Interferences
  • - 802.11 uses Direct Sequence Spread Spectrum
    for max throughput
  • limited ability to overcome fading and in
    band jammers
  • - Interferences not an issue for optical
    communications
  • - RF transceivers use Frequency Hopping Spread
    Spectrum to avoid
  • interferences

18
Choosing a Transceiver
  • Long Range Requirements
  • Output power
  • More output power will boost signal. (1W?30dB
    vs. 100mW ?20dB link budget)
  • Downside is that applications need to be
    compact and power efficient
  • Receiver Sensitivity
  • Every -6dB doubles range in line of sight
    conditions (or -10dB indoor)
  • Industry average is -93 dBm
  • Antenna Gain
  • Higher gain results in a greater range
  • Line of Sight
  • Range diminishes indoor

19
Buying VS Building
  • 900-928 MHz RF transceivers for this project
  • Cost to build is about 20
  • However cost doesnt include testers, software
    and regulatory very time consuming
  • Modules can be bought for about 60
  • Consider building when thousands of transceivers
    are involved

20
Potential Modules
  • Honeywell HRF-09325XM
  • Up To 6 dBm Output Power Into 50 Ohms
  • 20mA Transmit Current At 1mW Output, 33mA Receive
    Current
  • Direct Connection To Microprocessor Via SPI Bus
  • Integrated Ant. Switch
  • Receiver Has 85 dbm Sensitivity at 19.2 kbps
  • Digital Encoding, Decoding
  • 23mm x 23mm x 4.5mm , Surface Mountable
  • Prog. Power Levels, Freq. And Tx/Rx/Standby
  • Operates From Single 2.8-3.3v Power Supply

21
Potential Modules
  • Aerocomm AC 4790 RF
  • True peer-to-peer protocol.
  • Ultra-fast sync time (25 msec).
  • Small form factor 1.65 x 1.9 inches.
  • API commands to control packet routing.
  • Software-controlled sensitivity.
  • Network node discovery.
  • Offers Ranges up to 4 miles
  • Variable output power 5mW to 1000mW
  • Operates from single 3.3V to 5.5V
  • power supply
  • Typical power consumption 68mA

AC 4790 Module
22
Interface With Microcontroller
Same serial data rate required for communication
23
GPS Navigation Subsystem
24
Position and Altitude
  • What is needed
  • Position (longitude and latitude)
  • Altitude
  • Time
  • What are the different options?
  • Pressure sensor
  • altitude
  • Global Positioning System GPS
  • Position, altitude, and time

25
Pressure Sensor background
  • The pressure sensor measures the atmospheric
    pressure and generates a voltage proportional to
    the air pressure.
  • The higher the air pressure, the higher the
    voltage.
  • Example manufacturer equation
  • V 5.0(0.009P 0.095) P 22.222 V 10.556
  • This should result in a number between 100 and
    102 kPa at sea level
  • At an altitude of 3000 ft. above sea level gt 70
    kPa

Pressure Sensor
26
GPS background
  • Global Positioning System (GPS) is a
    satellite-based navigation system
  • 24 satellites are in orbit around earth at an
    altitude of 12,000 miles or 20,000 km
  • Satellite velocity 7,000 mph
  • Each satellite orbits the earth twice daily
  • Advantages to GPS
  • GPS works in any weather conditions, anywhere in
    the world, 24 hours a day.
  • There are no subscription fees or setup charges
    to use GPS.

27
GPS Background
  • Three satellites are needed to calculate 2D
    position (longitude and latitude)
  • Four satellites are needed to calculate 3D
    position (longitude, latitude, and altitude)
  • Accuracy is 15 - 20 feet for newer models
  • Signals transmitted
  • 8 low power signals
  • L1, L2, L3, , L8
  • Civilian use L1 at 1575.42 MHz

28
GPS Background
  • GPS Receiver
  • Axiom Sandpiper II GPS Module
  • Channels 12
  • Frequency L1 1575 MHz
  • Altitude -3000 ft to 30,000 ft.
  • Accuracy lt15m or 49 ft.
  • Serial Interface RS-232
  • Size 1.6 x 2.8 x 0.35 in.
  • Weight 20 grams
  • Cost 25 - 30
  • Antenna
  • Any GPS antenna with SMA connector
  • Cost 15 - 20

Axiom Sandpiper II GPS Module
Trimble Mini GPS Antenna with SMA connector
29
Interface with Microcontroller
Transmission to ground unit must be done in Real
Time.
30
Project Strategy
31
Division of Labor
  • The CanSat system will be divided into 4
    subsystems Imaging, Data Transmission,
    Navigation, and Structure.
  • The overall team will break off into technology
    groups and design/debug each subsystem
  • Imaging Team Yi Yang and Anthony Olson
  • Data Transmission Team Nigel Dunham, Mishari
    Al-Nahedh, Ibra Diack
  • Navigation Nigel, Yi, Anthony, Mishari, Ibra
  • Structure Team AE team members
  • After the completion of each subsystem, the
    entire team will configure our selected
    microcontroller to work with every specific
    subsystem.

32
Plan of Action
  • The following must be accomplished in an
    extremely timely manner
  • Select digital camera for imaging portion of
    project. (completed)
  • Design, build, and test imaging portion of
    CanSat.
  • Design, build, and test two transceivers that
    will be used for wireless communication between
    the CanSat and the ground command center
    (laptop).
  • Select and modify GPS unit that will provide
    position, altitude, and time stamp of the digital
    images.
  • Configure microcontroller for interfacing with
    the imaging system, navigation system, and the
    wireless communication system.
  • Write program(s) that will control the functions
    inside of the microcontroller.
  • Programs and tasks that cannot yet be estimated.
  • Test the completed CanSat system using HABS.

33
HABS
  • High Altitude Balloon System (HABS)
  • HABS can lift 18.5 pounds.
  • HABS with CanSat will be allowed to rise to an
    altitude of 7500-9000 feet above the ground
    surface. This should allow for reasonable
    testing of all subsystems.
  • Testing will take place at the KU soccer practice
    field located at 23rd and Iowa (shown below).

34
Project Milestones
Milestone 1 Imaging and TxRx subsystems should
be complete and microprocessor should be
configured for reliable operation.
Milestone 2 All subsystems should be completed
and HABS testing should begin immediately.
35
Weekly Schedule of Tasks
36
Risks and Contingency Plan
  • Main areas of risk and possible solution
  • Problem Weight limit of 370 grams
  • Solution Careful design of system paying
    serious detail to weight of components
  • Problem Many components are highly sensitive to
    electrostatic discharge
  • Solution Anti-static mats or bands should be
    used
  • Problem Ceiling of 500 for hardware
  • Solution Building as much of the system as
    possible will help with the overall cost limit
  • Problem Unfamiliar technology will be used
  • Solution A team effort will be used to learn
    new software, etc.

37
Contingency Plan
  • We have allowed enough time for completion of
    each subsystem, in case of subsystem failure. If
    subsystem failure occurs
  • Re-examine system design
  • Double check programs and timing of
    u-controller
  • Re-test system
  • Get outside help (Dr. Prescott, Dr. Sorensen)
  • If problem isnt fixed, we must redesign
    subsystem

38
Questions?
Write a Comment
User Comments (0)
About PowerShow.com
