Title: Formal Processor Verification


1
Formal Verification of Pipelined Microprocessors
2
Outline
  • Task
  • Verify that a pipelined processor correctly
    executes sequential programs
  • Part I Background
  • Definition of the problem Bryant
  • Methodology Jones
  • Part II State of the Art
  • Verification with ACL2 Hunt
  • Verification with UCLID Bryant
  • Part III Future
  • Techniques trends at Intel Jones
  • Future CAD tools Hunt
  • Panel discussion All

3
Challenge
  • Views of System Operation
  • Instruction Set
  • Instructions executed in sequential order
  • Instruction modifies programmer-visible state
  • Microarchitecture
  • At any given time, multiple instructions in
    flight
  • State held in hidden pipeline registers and
    buffers
  • Verification Task
  • Prove all instruction sequences execute as
    predicted by instruction set model

4
Simplified Processor Example
Bdat
  • Simplified RISC pipeline
  • Register-Register and Register-Immediate
    operations
  • Data hazards handled by register forwarding
  • Each step of operation defined by function dpipe

5
Reference Model
PC
  • Only programmer-visible state
  • Much simpler control logic
  • Assume verified against instruction set
    definition
  • Each step of operation defined by function dspec

6
Example HP/Compaq Alpha 21264
  • Pipeline State
  • Multiple caches
  • Instruction queues
  • Dynamically-allocated registers
  • Memory queue
  • Many buffers between stages
  • Verification Tasks
  • Does it implement the Alpha ISA?

Microprocessor Report, Oct. 28, 1996
7
Complexities of Modern Processors
  • Deep Pipelines Superscalar Operation
  • Many instructions in flight simultaneously
  • Complex mechanisms to prevent hazards
  • Out of Order Execution
  • Dont process instructions in program order
  • Use interlocks to guarantee preservation of
    sequential semantics
  • Speculative Execution
  • Begin executing instructions at predicted branch
    target
  • If discover misprediction, cancel pending updates
  • Register Renaming
  • Dynamically allocate physical registers

8
Things Working in Our Favor
  • (Almost) Precise Specification
  • Instruction Set Reference Manual
  • Describes effect of each instruction on state
    next instruction selection
  • Overall behavior should match sequential
    instruction execution
  • Helpful Processor Mechanisms
  • Pipeline Flushing
  • Complete all in-flight instructions without
    fetching new ones
  • Synchronizes pipeline with instruction set model
  • Misprediction Recovery
  • Processor will get correct result whether or not
    it predicts correctly
  • Verifier can ignore prediction logic

9
Flushing Simplified Processor
  • Stop incrementing program counter
  • Inject No-Op instructions into pipeline
  • After 3 cycles, register file will be fully
    updated

10
Applying Data Abstraction to Hardware Verification
  • Idea
  • Abstract details of data encodings and operations
  • Keep control logic precise
  • Applications
  • Verify overall correctness of system
  • Assuming individual functional units correct
  • Technology
  • Use restricted subset of first-order logic
  • Hunt 87, Srivas Bickford 90
  • Implement efficient decision procedures
  • Multiple methods of performing verification

11
Abstracting Data from Bits to Integers
x0
x1
x2
xn-1
  • View Data as Symbolic Terms
  • Arbitrary integers
  • Verification proves correctness of design for all
    possible word sizes
  • Can store in memories registers

12
Required Logic
  • Scalar Data Types
  • Formulas (F ) Boolean Expressions
  • Control signals
  • Terms (T ) Integer Expressions
  • Data values
  • Arbitrary values from some infinite domain

13
Modeling Data Selection
  • If-Then-Else Operation
  • Mulitplexor
  • Allows control-dependent data flow

14
Abstraction Via Uninterpreted Functions
f
  • For any Block that Transforms or Evaluates Data
  • Replace with generic, unspecified function
  • Only assumed property is functional consistency
  • a x ? b y ? f (a, b) f (x, y)

15
Abstraction Via Uninterpreted Functions
F3
F2
F1
  • For any Block that Transforms or Evaluates Data
  • Replace with generic, unspecified function
  • Also view instruction memory as function

16
Abstracting Reference Model
PC
  • Abstract with identical functions as in pipeline
    model
  • Assume functional consistency
  • x y ? f(x) f(y)

17
Modeling Data-Dependent Control
Cond
Adata
p
Branch?
Branch Logic
Bdata
  • Model by Uninterpreted Predicate
  • Yields arbitrary Boolean value for each control
    data combination
  • Produces same result when arguments match
  • Pipeline reference model will branch under
    same conditions

18
Modeling Memories
  • Memory M Modeled as Function
  • M(a) Value at location a
  • Initially
  • Arbitrary state
  • Modeled by uninterpreted function m0
  • Writing Transforms Memory
  • M? Write(M, wa, wd)
  • Future reads of address wa will get wd

19
Required Logic
  • Scalar Data Types
  • Formulas (F ) Boolean Expressions
  • Control signals
  • Terms (T ) Data Expressions
  • Data values
  • Functional Data Types
  • Functions (Fun) Data ? Data
  • Functional units
  • Read Write functions for memories
  • Predicates (P) Data ? Boolean
  • Data-dependent control

20
EUF Equality with Uninterp. Functs
  • Decidable fragment of first order logic
  • Formulas (F ) Boolean Expressions
  • ?F, F1 ? F2, F1 ? F2 Boolean connectives
  • T1 T2 Equation
  • P (T1, , Tk) Predicate application
  • Terms (T ) Integer Expressions
  • ITE(F, T1, T2) If-then-else
  • Fun (T1, , Tk) Function application
  • Functions (Fun) Integer ? Integer
  • f Uninterpreted function symbol
  • Read, Write Memory operations
  • Predicates (P) Integer ? Boolean
  • p Uninterpreted predicate symbol

21
Term-Level Symbolic Simulation
  • Simulator Operation
  • Register states are term-level expressions
  • Denoted by pointers to nodes in Directed Acyclic
    Graph (DAG)
  • Simulate each cycle of circuit by adding new
    nodes to DAG
  • Based on circuit operations
  • Construct DAG denoting correctness condition

22
Decision Problem
  • Logic of Equality with Uninterpreted Functions
  • Truth Values
  • Dashed Lines
  • Model Control
  • Logical connectives
  • Equations
  • Integer Values
  • Solid lines
  • Model Data
  • Uninterpreted functions
  • If-Then-Else operation
  • Task
  • Determine whether formula is universally valid
  • True for all interpretations of variables and
    function symbols

23
Finite Model Property for EUF
  • Observation
  • Any formula has limited number of distinct
    expressions
  • Only property that matters is whether or not
    different terms are equal

24
Boolean Encoding of Integer Values
  • For Each Expression
  • Either equal to or distinct from each preceding
    expression
  • Boolean Encoding
  • Use Boolean values to encode integers over small
    range
  • EUF formula can be translated into propositional
    logic
  • Tautology iff original formula valid

25
Pipeline Class 1
  • Linear Pipeline
  • E.g., Intel 486
  • Each instruction flows through fixed sequence of
    stages
  • Flush time pipeline depth
  • Instructions Per Cycle (IPC) ? 1.0

26
Pipeline Class 2
  • Superscalar Pipeline
  • E.g., Intel Pentium
  • Multiple instructions can flow through pipeline
  • Interlocks prevent dependent instructions from
    executing at same time
  • Instructions Per Cycle (IPC) ? 1.0

27
Pipeline Class 3
Instr Mem
Reorder Buffer
Execution Units
  • Out-of-Order Pipeline
  • E.g., Intel Pentium II, III, 4
  • Instruction execution need not follow program
    order
  • Complex control to make safe
  • Flush time depends on Reorder Buffer size

28
Pipeline Class 3b
Instr Mem
Reorder Buffer
  • Parametric Modeling
  • ROB of length K for integer symbol K
  • One verification proves correctness for family of
    designs
  • No bound on flush time

29
Challenge Model Generation
  • How to generate term-level model
  • How to guarantee faithfulness to RTL description
  • Comparison of Models
  • Register Transfer Level
  • Golden representation of most hardware designs
  • Written in Verilog or VHDL
  • Abstracts functional elements from gate-level
    model
  • Synthesis allows automatic map to gate level
  • Term level
  • Abstracts bit-level data representations to words
  • Abstracts memories to mutable functions
  • Abstracts functional elements to uninterpreted
    functions

30
Generating Term-Level Model
  • Manually Generate from RTL
  • How do we know it is a valid abstraction?
  • Hard to keep consistent with changing RTL
  • Automatically Generate from RTL
  • Andraus Sakallah, DAC 04
  • Must first generate cycle-level bit-level model
    from HDL
  • Difficult to do from Verilog/VHDL
  • Must decide which signals to keep Boolean, which
    to abstract
  • Confused by bit field extraction primitives of
    HDL
  • Synthesize RTL from Word-Level Model
  • Difficult to make efficient

31
Evaluating Different Verification Approaches
  • What Class of Systems can be Modeled?
  • Linear pipelines much simpler than out-of-order
  • Can some system attributes be expressed
    parametrically
  • More powerful form of verification
  • How Efficient is Verifier?
  • Consider both computational and manual effort
  • What scale system can be verified
