EFFECTIVENESS OF VASCULAR ACCESS MONITORING

1
EFFECTIVENESS OFVASCULAR ACCESS MONITORING

• William D. Paulson, MD
• Sunanda J. Ram, PhD
• Jack Work, MD
• Steve Jones, PhD
• Division of Nephrology and Hypertension
• LSU Health Sciences Center
• Shreveport, LA
• Paulson, Ram, Zibari Vascular Access Anatomy,
  examination, management. Semin Nephrol 22
  183-194, 2002

2
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

3
THE PROBLEM ACCESS SURVIVAL
Allon KI 2001
4
RATIONALE OF MONITORING

• PROGRESSIVE STENOSIS
• INCREASED GRAFT RESISTANCE
• DECREASED Qa, INCREASED VP, STASIS
• GRAFT THROMBOSIS FAILURE

5
CURRENT DOGMA

• GRAFTS SHOULD BE MONITORED FOR HEMODYNAMICALLY
  SIGNIFICANT STENOSIS
• MONITORING COMBINED WITH CORRECTION IMPROVES
  PATENCY AND DECREASES THROMBOSIS
• NKF-K/DOQI (2001)

6
MONITORING NOT ROUTINELY ADOPTED

• MONITORING METHODS ARE GENERALLY TEDIOUS AND/OR
  INTRUSUVE
• NO REIMBURSEMENT
• INADEQUATE STAFFING
• SKEPTICISM THAT MONITORING IS EFFICACIOUS

7
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

8
MONITORING METHODS

• PHYSICAL EXAM
• RECIRCULATION
• VENOUS PRESSURE
• DYNAMIC
• STATIC
• ARTERIAL PRESSURE
• STATIC
• Qa
• DILUTION METHODS
• DUPLEX ULTRASOUND
• ANATOMY
• DUPLEX ULTRASOUND
• ANGIOGRAPHY

9
VENOUS ARTERIAL PRESSURES
Besarab Dialysis Access 2002
10
Qa BY ULTRASOUND DILUTION
Yeun Depner Dialysis Access 2002
11
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

12
WHAT DETERMINES Qa?
CONCLUSIONQa MONITORING REQUIRES REPRODUCIBLE
CONDITIONS
13
2 REPRESENTATIVE PATIENTS
DeSoto AJKD 2001
14
Qa vs. MAP HCT
Jones Paulson ASN 2001
15
Qa IS NOT STABLE
Paulson AJKD 2000
16
RAPID CHANGE IN Qa
Rehman AJKD 1999
17
WOULD YOU USE THESE TESTS?

• ?Qa -60 to 80
• Schneditz NDT, 1998
• Rehman AJKD, 1999
• DeSoto AJKD, 2001
• EQUIVALENT CHANGES
• Na 56 to 252 mEq/L
• Hct 16 to 72

18
RAPID RATE OF STENOSIS IN NEW GRAFTS
THROMBOSIS IN lt90 DAYS, N 17
THROMBOSIS IN 90 DAYS, N 21
Atray ASN 2001
19
IMPLICATIONS FOR Qa MONITORING

• Qa HAS POOR REPRODUCIBILITY
• STRONGLY INFLUENCED BY HEMODYNAMIC EVENTS
• STENOSIS OFTEN PROGRESSES RAPIDLY IN NEW GRAFTS
• IS Qa MONITORING EFFECTIVE?

20
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

21
STUDIES THAT SUPPORT MONITORING

• NONRANDOMIZED
• VENOUS PRESSURE
• SCHWAB KIDNEY INT 1989
• BESARAB KIDNEY INT 1995
• RANDOMIZED
• Qa
• SANDS ASAIO J 1999
• STENOSIS
• MAYER VASC SURG 1993
• MARTIN J VASC INTERVENT RADIOL 1999

22
Qa MONITORINGEFFECT ON ACCESS MORBIDITY COSTS

• REPORTED MONITORING RESULTED IN
• REDUCED THROMBOSIS RATE
• REDUCED HOSPITALIZATION
• REDUCED COST
• NO IMPROVEMENT IN GRAFT SURVIVAL
• STUDY DESIGN
• NONRANDOMIZED
• SEQUENTIAL CONTROL MONITORING GROUPS

MCCARLEY KI 2001
23
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

24
DEFICIENCIES OF STUDY DESIGNS

• NO CONTROL GROUP
• HISTORICAL OR SEQUENTIAL CONTROL GROUP
• SMALL N
• INAPPROPRIATE STATISTICAL TESTING

25
HISTORICAL OR SEQUENTIAL CONTROL GROUPS

• ADVANTAGES
• GENERATE HYPOTHESIS
• VALID WHEN OUTCOME OF CONTROL GROUP IS UNIFORM
• ALLOWS SMALLER N
• COMPLETE STUDY MORE QUICKLY
• DISADVANTAGE
• OVERESTIMATION OF TREATMENT EFFECT

26
NEED TO MAKE THE RIGHT COMPARISONS

• DURING WW II, RESCUE WORKERS DIGGING IN THE
  RUINS OF AN APARTMENT HOUSE BLOWN UP IN THE
  LONDON BLITZ FOUND AN OLD MAN LYING NAKED IN A
  BATHTUB. HE SAID TO HIS RESCUERS "YOU KNOW, THAT
  WAS THE MOST AMAZING EXPERIENCE I EVER HAD. WHEN
  I PULLED THE PLUG THE WATER STARTED DOWN THE
  DRAIN, THE WHOLE HOUSE BLEW UP!"
•
  GORDIS EPIDEMIOLOGY 2000

27
WE ARE ALL BIASED

• WE BELIEVE WE CAN MAKE A DIFFERENCE
• WE ARE BIASED IN FAVOR OF INTERVENTION
  TREATMENT
• WE MINIMIZE OR IGNORE POTENTIAL ADVERSE EFFECTS
  OF INTERVENTION TREATMENT

28
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• RESULTS OF CLINICAL STUDIES
• IMPORTANCE OF CLINICAL STUDY DESIGN
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

29
PREDICTIVE ACCURACY OF Qa
Paulson AJKD 2002
30
DEFINITIONS OF PREDICTIVE ACCURACY

• SENSITIVITY
• FOR THROMBOSED GRAFTS, WITH LOW Qa
• FALSE POSITIVE RATE
• FOR PATENT GRAFTS, WITH LOW Qa

31
HYPOTHETICAL ROC CURVE
32
PREDICTION OF THROMBOSIS BY Qa
Paulson ASN 2002
33
PREDICTION OF GRAFT FAILURE BY Qa
McDOUGAL KI 2001
34
PREDICTION OF THROMBOSISOR FAILURE BY ?Qa
Paulson ASN 2002
35
PREDICTION OF THROMBOSISQa ?Qa COMBINED
Paulson AJKD, 2000, 2001
36
UF MAP INFLUENCE THROMBOSIS
Paulson AJKD 2002
37
ACCURACY OF DYNAMIC VP IN PREDICTING THROMBOSIS
OR FAILURE
Frinak AJKD 2002
38
ACCURACY OF STATIC VP IN PREDICTING THROMBOSIS OR
FAILURE
Dember KI 2002
39
STATIC VPPREEMPTIVE REPAIR OF STENOSIS

• 64 PATIENTS WITH HIGH VP
• OBSERVATION GROUP (N 32) INTERVENTION GROUP (N
  32)
• REPAIR FOR THROMB OR
  REPAIR GRAFT
• CLINICAL DYSFUNCTION
• 3.5 YEAR FOLLOW-UP
• 14 GRAFTS ABANDONED 14 GRAFTS
  ABANDONED

Dember ASN 2002
40
INFLUENCE OF PREEMPTIVE INTERVENTION ON GRAFT
SURVIVAL
Ram ASN 2001
41
SUMMARY OF LSU STUDY

• INTERVENTION BASED UPON Qa OR STENOSIS DID NOT
  IMPROVE GRAFT SURVIVAL
• SEVERAL FACTORS MAY EXPLAIN RESULT
• Qa WAS AN INACCURATE PREDICTOR OF THROMBOSIS
• CONTROL GROUP HAD HIGH PREEMPTIVE PTA RATE
• POTENTIAL HARM OF UNNECESSARY PTA
• ACTIVE INVOLVEMENT OF DIALYSIS STAFF IN
  MANAGEMENT OF GRAFTS MAY BE MORE IMPORTANT THAN
  MONITORING BASED UPON ALGORITHMS.

42
MONITORING OUTLINE

• CURRENT DOGMA
• NKF K/DOQI CLINICAL PRACTICE GUIDELINES
• MONITORING METHODS
• FACTORS THAT INFLUENCE EFFECTIVENESS OF
  MONITORING
• IMPORTANCE OF CLINICAL STUDY DESIGN
• RESULTS OF CLINICAL STUDIES
• SUMMARY CONCLUSION
• WHERE TO WE GO FROM HERE?

43
WHY DO PREEMPTIVE INTERVENTION?

• BENEFITS
• INCREASE DIALYSIS EFFICIENCY
• FEWER CENTRAL VEIN CATHETERS
• REDUCE THROMBOSIS RATE
• REDUCE HOSPITALIZATION COSTS (?)
• DISADVANTAGES
• LACK OF ACCURATE MONITORING METHOD
• IS APPARENT BENEFIT OF MONITORING DUE TO HIGH
  PREVALENCE OF STENOSIS?
• MAY NOT PROLONG GRAFT LIFE
• MORE PROCEDURES
• HIGHER COSTS FROM UNNECESSARY PROCEDURES
• UNNECESSARY PROCEDURES MAY SHORTEN GRAFT LIFE

44
POTENTIALLY HARMFUL FALSE POSITIVE

• STABLE STENOSIS
• HEMODYNAMICALLY INDUCED DECREASED IN Qa
• ANGIOPLASTY
• STIMULATION OF NEOINTIMAL HYPERPLASIA
• GRAFT FAILURE

45
CONCLUSION

• STAFF COMMITTED TO ACCESS MAINTENANCE SURVIVAL
  IS KEY
• PHYSICAL EXAM AND CLINICAL CORRELATION MAY
  PROVIDE MOST OF BENEFIT
• HIGH PTA RATE CAN REDUCE THROMBOSIS
• POTENTIAL HARM OF UNNECESSARY PTA
• IT IS NOT ESTABLISHED THAT MONITORING PROLONGS
  GRAFT LIFE
• RANDOMIZED CONTROLLED TRIALS ARE NEEDED
