Chapter 8 Movement

1
Chapter 8Movement
2
The Control of Movement

• Three categories of vertebrate muscles include
• Smooth muscles - control the digestive system and
  other organs

• Skeletal muscles/striated muscles - control
  movement of the body in relation to the
  environment.

• Cardiac muscles - heart muscles that have
  properties of skeletal and smooth muscles

3
Fig. 8-1, p. 233
4
The Control of Movement

• Muscles are composed of many individual fibers.
• The fewer muscle fibers an axon innervates, the
  greater the precision of movement.

• A neuromuscular junction is a synapse where a
  motor neuron axon meets a muscle fiber.

• In skeletal muscles, axons release acetylcholine
  which excite the muscle to contract.

5
The Control of Movement

• Movement requires the alternating contraction of
  opposing sets of muscles called antagonistic
  muscles.

• A flexor muscle is one that flexes or raises an
  appendage.

• An extensor muscle is one that extends an
  appendage or straightens it.

6
The Control of Movement

• Myasthenia gravis is an autoimmune disease in
  which the immune system forms antibodies that
  attack the acetylcholine receptors at
  neuromuscular junctions.
• Causes the progressive weakness and rapid fatigue
  of the skeletal muscles.

7
The Control of Movement

• Skeletal muscle types range from
• Fast-twitch- fibers produce fast contractions but
  fatigue rapidly.

• Slow-twitch- fibers produce less vigorous
  contraction without fatiguing.

• People vary in their percentage of fast-twitch
  and slow-twitch muscles.

8
The Control of Movement

• Slow-twitch fibers are aerobic and require oxygen
  during movement and therefore do not fatigue.

• Nonstrenuous activities utilize slow-twitch and
  intermediate fibers.

• Fast-twitch fibers are anaerobic and use
  reactions that do not require oxygen, resulting
  in fatigue.

• Behaviors requiring quick movements utilize
  fast-twitch fibers.

9
The Control of Movement

• The human anatomy is specialized for endurance in
  running.

• Reflected in the shape of our toes, leg bones,
  muscles and tendons and the high percentage of
  slow-twitch muscles in our legs.

• Extensive sweat glands and reduced body hair
  improve temperature regulation.

10
The Control of Movement

• Proprioceptors are receptors that detect the
  position or movement of a part of the body and
  help regulate movement.

• A muscle spindle is a kind of proprioceptor
  parallel to the muscle that responds to a
  stretch.

• causes a contraction of the muscle.
• Stretch reflex occurs when muscle proprioceptors
  detect the stretch and tension of a muscle and
  send messages to the spinal cord to contract it.

• allows fluidity of movement.

11
The Control of Movement
12
The Control of Movement

• The Golgi tendon organ is another type of
  proprioceptor that responds to increases in
  muscle tension.

• Located in the tendons at the opposite ends of
  the muscle.

• Acts as a brake against excessively vigorous
  contraction by sending an impulse to the spinal
  cord where motor neurons are inhibited.

13
(No Transcript)
14
Fig. 8-5, p. 235
15
The Control of Movement

• Reflexes are involuntary, consistent, and
  automatic responses to stimuli.

• Infants have several reflexes not seen in
  adults

• Grasp reflex - grasps objects placed in the
  hand.

• Babinski reflex - extends big toe and fans others
  when the sole of the foot is stroked.

• Rooting reflex - turns head and sucks when cheek
  is stimulated.

16
Fig. 8-6, p. 236
17
The Control of Movement

• Few behaviors are purely reflexive or
  non-reflexive and movements vary in their
  sensitivity to feedback.

• Ballistic movements are movement that once
  initiated can not be altered or corrected.

• Example stretch reflex, dilation of the pupil.

18
The Control of Movement

• Many behaviors consist of rapid sequences of
  individual movements.

• Central pattern generators are neural mechanisms
  in the spinal cord or elsewhere that generate
  rhythmic patterns of motor output.

• Example wing flapping in birds.

19
The Control of Movement

• A motor program refers to a fixed sequence of
  movements that is either learned or built into
  the nervous system.

• once begun, the sequence is fixed from beginning
  to end.

• Automatic in the sense that thinking or talking
  about it interferes with the action.

• Example Mouse grooming itself, skilled musicians
  playing a piece, or a gymnasts routine.


20
Brain Mechanisms of Movement

• The primary motor cortex is located in the
  precentral gyrus located in the frontal lobe.

• Axons from the precentral gyrus connect to the
  brainstem and the spinal cord which generate
  activity patterns to control the muscles.

21
Fig. 8-7, p. 240
22
Brain Mechanisms of Movement

• Specific areas of the motor cortex are
  responsible for control of specific areas of the
  body.

• some overlap exists.

23
Fig. 8-9, p. 241
24
Fig. 8-10, p. 242
25
Brain Mechanisms of Movement

• The motor cortex can
• Direct contraction of specific muscles.
• Direct a combination of contractions to produce a
  specified outcome.

26
Brain Mechanisms of Movement

• Other areas near the primary motor cortex also
  contribute to movement

• Posterior parietal cortex- respond to visual or
  somatosensory stimuli, current or future
  movements and complicated mixtures of a stimulus
  and an upcoming response.
• Damage to this area causes difficulty
  coordinating visual stimuli with movement.

• Primary somatosensory cortex- integrates touch
  information and movement.

27
Brain Mechanisms of Movement

• Cells in the following areas are involved in the
  preparation and instigation of movement

• Prefrontal cortex
• Responds to lights, noises and other sensory
  signals that lead to movement.

• Calculates predictable outcomes of actions and
  plans movement according to those outcomes.

28
Brain Mechanisms of Movement

• Premotor cortex
• is active during preparation for movement and
  receives information about a target in space.

• integrates information about position and posture
  of the body and organizes the direction of the
  movement in space.

• Supplementary motor cortex
• Important for organizing a rapid sequence of
  movements.

29
Fig. 8-8, p. 241
30
Brain Mechanisms of Movement

• The conscious decision to move and the movement
  itself occur at two different times.

• A readiness potential is a particular type of
  activity in the motor cortex that occurs before
  any type of voluntary movement.

• Begins at least 500 ms before the movement
  itself

• Implies that we become conscious of the decision
  to move after the process has already begun.

31
Fig. 8-12, p. 246
32
The Control of Movement

• Damage to the primary motor cortex of the right
  hemisphere leads to the inability to make
  voluntary movements with the left side.

• Some individuals with this condition experience
  anosognosia and insist they can and do make
  voluntary movements.

• In the absence of the motor cortex, the premotor
  cortex fails to receive feedback if an intended
  movement was executed.

33
The Control of Movement

• Messages from the brain must reach the medulla
  and spinal cord to control the muscles.

• Axons from the brain are organized into two
  pathways

• Dorsolateral tract.
• Ventromedial tract.

34
Brain Mechanisms of Movement

• Dorsolateral tract - a set of axons from the
  primary motor cortex to surrounding areas and the
  red nucleus and allows control of peripheral
  areas of the body. (hands, fingers, toes)
• Red nucleus - a midbrain area with output mainly
  to the arm muscles.

• Axons extend directly to their target neurons in
  the spinal cord and crosses from one side of the
  brain to the opposite side of the spinal cord.

35
Fig. 8-13, p. 246
36
Brain Mechanisms of Movement

• Ventromedial tract - set of axons from the
  primary cortex, supplementary motor cortex, and
  other parts of the cortex.

• Axons go to both sides of the spinal cord and
  allow control of

• muscles of the neck.
• shoulders and trunk.
• Enables movements such as walking, turning,
  bending, standing up and sitting down.

37
Brain Mechanisms of Movement

• The ventromedial tract also includes axons from
  the midbrain tectum, reticular formation, and the
  vestibular nucleus.

• Vestibular nucleus - brain area that receives
  input from the vestibular system.

38
Brain Mechanisms of Movement

• The cerebellum is a structure in the brain often
  associated with balance and coordination.

• Damage to the cerebellum causes trouble with
  rapid movement requiring aiming and timing.

• Examples clapping hands, speaking, writing, etc.

39
Brain Mechanisms of Movement

• Studies suggest that the cerebellum is important
  for the establishment of new motor programs that
  allow the execution of a sequence of actions as a
  whole.
• The cerebellum may be linked to habit forming and
  damage may impair motor learning.

• The cerebellum also seems critical for certain
  aspects of attention such as the ability to shift
  attention and attend to visual stimuli.

40
Brain Mechanisms of Movement

• The cerebellum contains more neurons than the
  rest of the brain combined and high capacity for
  information processing.

• The cerebellar cortex is the surface of the
  cerebellum.

• The cerebellum receives input from the spinal
  cord, from each of the sensory systems, and from
  the cerebral cortex and sends it to the
  cerebellar cortex.

41
Brain Mechanisms of Movement

• Neurons in the cerebellar cortex are arranged in
  precise geometrical patterns

• Purkinje cells are flat cells in sequential
  planes.

• Parallel fibers are axons parallel to one another
  and perpendicular to the plane of Purkinje
  cells.

• The regular pattern of arrangement allows outputs
  of well-controlled duration and the greater the
  number of excited Purkinje cells, the greater
  their collective duration of response.

42
Fig. 8-14, p. 248
43
The Control of Movement

• The basal ganglia is a group of large subcortical
  structures in the forebrain important for
  initiation of behaviors.

• Comprised of the following structures
• Caudate nucleus.
• Putamen.
• Globus pallidus.

44
The Control of Movement

• Caudate nucleus and putamen receive input from
  the cerebral cortex and send output to the globus
  pallidus.

• Globus pallidus connects to the thalamus which
  relays information to the motor areas and the
  prefrontal cortex.

• Basal ganglia selects the movement to make by
  ceasing to inhibit it.

45
The Control of Movement

• The learning of new skills requires multiple
  brain areas involved in the control of movement.

• Basal ganglia is critical for learning motor
  skills, organizing sequences of movement, and
  learning automatic behaviors.

• Example driving a car
• Relevant neurons in the motor cortex also
  increase their firing rate and the pattern of
  activity becomes more consistent as the skill is
  learned.

46
Fig. 8-15, p. 249
47
Disorders of Movement

• Parkinsons disease is a neurological disorder
  characterized by muscle tremors, rigidity, slow
  movements and difficulty initiating physical and
  mental activity.
• Associated with an impairment in initiating
  spontaneous movement in the absence of stimuli to
  guide the action.

• Symptoms also include depression and memory and
  reasoning deficits.

48
Disorders of Movement

• Caused by gradual and progressive death of
  neurons, especially in the substantia nigra.

• Substantia nigra sends dopamine-releasing axons
  to the caudate nucleus and putamen.

• Loss of dopamine leads to less stimulation of the
  motor cortex and slower onset of movements.

49
Fig. 8-17, p. 255
50
Disorders of Movement

• Studies suggest early-onset Parkinsons has a
  genetic link.

• Genetic factors are only a small factor to late
  on-set Parkinsons disease (after 50).

51
Fig. 8-18, p. 255
52
Disorders of Movement

• Exposure to toxins are one environmental
  influence.

• MPTP is converted to MPP which accumulates and
  destroys neurons that release dopamine.

• MPTP found in some illegal drugs and pesticides.

53
Disorders of Movement

• Cigarette smoking and coffee drinking are related
  to a decreased chance of developing Parkinsons
  disease.

• Research suggests marijuana use increases the
  risk of Parkinsons disease.

• Damaged mitochondria of cells seems to be common
  to most factors that increase the risk of
  Parkinsons disease.

54
Disorders of Movement

• The drug L-dopa is the primary treatment for
  Parkinsons and is a precursor to dopamine that
  easily crosses the blood-brain barrier.

• Often ineffective and especially for those in the
  late stages of the disease.

• Does not prevent the continued loss of neurons.
• Enters other brain cells producing unpleasent
  side effects.

55
Disorders of Movement

• Other possible treatments for Parkinsons
  include

• Antioxidants.
• Drugs that stimulate dopamine receptors or block
  glutamate.

• Neurotrophins.
• Drugs that decrease apoptosis.
• High frequency electrical stimulation of the
  globus pallidus.

• Transplant of neurons from a fetus.

56
Disorders of Movement

• Implantation of neurons from aborted fetuses
  remains controversial and only partially
  effective.

• Most patients show little or no benefit a year
  after surgery.

• Patients with only mild symptoms showed the
  benefit of failing to deteriorate further.

• Stem cells are immature cells grown in tissue
  culture that are capable of differentiating and
  are an attractive alternative.

57
Disorders of Movement

• Huntingtons disease is a neurological disorder
  characterized by various motors symptoms.

• affects 1 in 10,000 in the United States
• usually appears between the ages of 30 and 50.
• Associated with gradual and extensive brain
  damage especially in the caudate nucleus,
  putamen, globus pallidus and the cerebral cortex.

58
Disorders of Movement

• Initial motor symptoms include arm jerks and
  facial twitches.

• Motors symptoms progress to tremors and writhing
  that affect the persons walking, speech and other
  voluntary movements.

• Also associated with various psychological
  disorders

• Depression, memory impairment, anxiety,
  hallucinations and delusions, poor judgment,
  alcoholism, drug abuse, and sexual disorders.

59
Disorders of Movement

• Presymptomatic tests can identify with high
  accuracy who will develop the disease.

• Controlled by an autosomal dominant gene on
  chromosome 4.

• The higher the number of consecutive repeats of
  the combination C-A-G, the more certain and
  earlier the person is to develop the disease.

• No treatment is effective in controlling the
  symptoms or slowing the course of the disease.

60
Fig. 8-22, p. 260
61
Disorders of Movement

• A variety of neurological diseases are related to
  C-A-G repeats in genes.

• For a variety of disorders, the earlier the
  onset, the greater the probability of a strong
  genetic influence.

62
Fig. 8-23, p. 260
