ESnet Workshop Internet2 Update

1
ESnet Workshop - Internet2 Update

• Rick Summerhill
• Director, Network Research, Architecture, and
  Technologies
• ESnet Workshop
• April 23, 2007
• Alexandria, VA

2
Brief Overview

• Infrastructure Update
• Architecture
• Deployment
• Connectivity
• Dynamic Services
• Current Status
• Schedule

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Nodes
9
Nodes
10
Nodes
11
Nodes
12
Nodes
13
Nodes
14
Nodes
15
Rollout
16
East Coast Connectivity

• IP Services
• IRNC 10 Gig circuit between Amsterdam and New
  York City
• Amsterdam side is a GEANT2 router
• NYC side is MAN LAN
• Supports Peering between GEANT2 and MAN LAN
  connectors, including Internet2 and ESnet
• GEANT2 funded 10 Gig circuit between Frankfort
  and Washington, DC
• Frankfort side is GEANT2 router
• Washington, DC side is NGIX-East
• Supports Peering between GEANT2 and NGIX-East
  connectors, including Internet2 and ESnet

17
East Coast Connectivity, continued

• Circuit Services - support for P2P circuits as
  needed
• IEEAF 10 Gig circuit between Amsterdam and New
  York City
• Amsterdam side is the NetherLight HDXc
• New York City side is the MAN LAN HDXc
• SURFnet 10 Gig circuit between Amsterdam and New
  York City
• Amsterdam side is the NetherLight HDXc
• New York City side is the MAN LAN HDXc
• Internet2 HOPI 10 Gig circuit between London and
  New York City
• London side is Alcatel Equipment
• NYC side is MAN LAN HDXc

18
East Coast Connectivity, continued

• Circuit Services - support for P2P circuits as
  needed
• GEANT2 circuit between Europe and Washington, DC
• Connects to Alcatel on the European side
• Connects to NGIX-East Ciena equipment on the
  Washington, DC side
• GEANT2 circuit between Paris and New York City
• Connects to Alcatel on the Paris side
• Connects to HDXc in MAN LAN on the NYC side
• MAN LAN and NGIX-East connected to Atlantic Wave

19
Dynamic Circuit Services in Internet2

• Intra domain work
• HOPI
• The Ciena Network
• Eventually, the Infinera Platform
• Inter domain work
• Collaborations with other networks
• Following and participating in standards bodies

20
Internet2 Network Infrastructure with Multiple
Services
Routed IP Network
Router Layer
Ethernet Layer
Switched SONET Layer (vcat, lcas)
SONET Switched Network
Provisioned Services
Switched WDM Optical Layer
Ethernet VLAN Switched Network (i.e., HOPI)
Multi-Layer GMPLS Networks
Separate (Peering) Control Plane Instantiations
for each of the above
21
Intra Domain work

• Challenges
• Multi-vendor environment
• Multi-layer environment
• Current Development
• Concentrating on the Ciena and HOPI platforms,
  each on a single wave on the Internet2 DWDM
  Platform
• Also having discussions with Infinera about
  Virtual DWDM platform
• HOPI has been in place for several years, and
  functions as a test-bed
• The Ciena network is to provided persistent
  services to applications
• For example, the LHC project

22
Ciena Control Plane Work

• What is the best way to control the Inter domain
  network
• Implementation should support a large number of
  platforms, eventually
• Evolving to a UNI-2.0 interface at this time
• It is currently a TL-1 interface
• Thoughts about using proprietary interfaces have
  been thoroughly discussed
• Software platform should be extensible and vendor
  independent
• Tremendous support from Ciena on all aspects of
  this project

23
Inter Domain Development

• Primary collaboration is with the DICE group -
  Dante (GEANT2), Internet2, CANARIE, and Esnet
• Working closely with ESnet on interfacing OSCARS
  and HOPI - involves AAA work, using OSCARS
  interface
• Reporting back progress to the GLIF and other
  organizations
• For example, Phosphorus, in coordination with the
  SURFnet and University of Amsterdam participants
• Also having discussions with JGN2
• Coordinating with OGF on various schema -
  topology, path computation, signaling
• Working with the appropriate standards bodies -
  ITU, IETF, and OIF

24
Development Team

• Tom Lehman, Jerry Sobieski leading the efforts
• Xi Yang
• Chris Tracy
• Jarda Fildr
• Make software available to the community

25
Multi-Domain Control Plane
GEANT

• Multi-Domain Provisioning
• Interdomain ENNI (Web Service and OIF/GMPLS)
• Multi-domain, multi-stage path computation
  process
• AAA
• Scheduling

Internet2 Network
RON
RON
Dynamic Ethernet
Dynamic Ethernet
TDM
ESNet
Domain Controller
Ctrl Element
Ethernet
Data Plane
SONET Switch
Control Plane Adjacency
IP Network (MPLS, L2VPN)
LSP
Router
Slide from Tom Lehman
26
Slide from Tom Lehman
27
Spring Member Meeting

• Suggest you attend the HOPI / Dynamic Services
  Session on Tuesday at 115pm
• More complete description of current status
• Demo of various capabilities
• Update on Workshops
