Title: Loop Filter Optimization


1
Loop Filter Optimization
  • Dean Banerjee
  • Deborah Brown
  • Khang Nguyen

2
Overview
  • Introduction
  • PLL Loop Filter Design Issues
  • Common Method for Loop Filter Design and
    Optimization
  • New Approach for Loop Filter Design and
    Optimization

3
Loop Filter Design Issues
  • Spur Level vs. Lock Time Tradeoff
  • Loop bandwidth
  • Phase margin
  • Pole ratios
  • Filter Order

4
Loop Bandwidth
  • Smaller Larger
  • Loop Bandwidth Loop Bandwidth
  • Lower Spurious Noise Faster Lock Time

5
Phase Margin
  • Relates to stability of system
  • Typically ranges from 40 to 55 degrees
  • Higher phase margin results in more stable
    system, but if too high can cause increased lock
    time
  • For minimum RMS phase error designs, 50 degrees
    is a good starting point

6
Pole Ratios
  • T3/T1 ratio and T4/T3 ratio
  • Higher pole ratios
  • Less spurious noise
  • Decreases value of highest order capacitor
  • Watch out for VCO input capacitance

7
Filter Order
  • Benefits of higher filter order
  • Lower spur levels
  • Drawbacks of higher filter order
  • More passive components
  • More resistor noise due to added resistors
  • VCO capacitance more likely to cause distortion

8
PLL VCO Selection
  • PLL Selection
  • Covers the frequency range
  • Divide Ratios supported by N and R counters
  • Why would I choose one part over another?
  • VCO Selection
  • VCO Gain
  • VCO input capacitance
  • Adds in parallel with highest order loop filter
    capacitor.
  • Can cause problems if highest order loop filter
    capacitor is too small.
  • Phase Noise vs. Tuning Range Tradeoff

9
Common Method for Loop Filter Design and
Optimization
  • Choose arbitrary values for filter parameters,
    calculate filter components, and then analyze.
    If loop filter does not meet lock time and spur
    requirements, then adjust filter parameter values
    and re-optimize.

10
Disadvantages of Common Method
  • Iterative Process
  • Very time consuming
  • Very tedious
  • Based on trial and error
  • Does not always achieve the optimal solution

11
New Approach for Loop Filter Design and
Optimization
  • Give me the best loop filter that meets my lock
    time and spur level requirements.

12
Four Easy Steps Using theNew Method
  • Define System Level Parameters
  • Determine Loop Filter Design Parameters from
    System level parameters
  • Determine Loop Filter Components from Loop Filter
    Design Parameters
  • System Level Performance from Loop Filter
    Components

13
Introduction to EasyPLL
  • Allows you to
  • Specify your PLL system requirements
  • Choose the best parts that meet your
    requirements.
  • Determine your Loop Filter Components
  • Analyze the simulation results
  • Examine various wave forms
  • Change parameters in any order
  • Order a Custom Eval Board when you are done.

14
Get Loop Filter Parameters
  • The old way was to just pick a phase margin and
    loop bandwidth by rules of thumb and experience
  • EasyPLL picks all parameters in an optimal way to
    ensure that the system parameters are met
  • EasyPLL picks which phase margin yields the
    fastest possible lock time

15
Design Loop Filter
  • EasyPLL chooses time constants in an optimal way
    that typically can result in up to a 30
    improvement in lock time
  • EasyPLL exactly solves for all component values
    (except 4th order filters, for which it
    approximates)
  • EasyPLL returns exactly what is specified

16
Determine System Level Performance
  • EasyPLL also simulates all results so that the
    design can be double checked
  • The impact of rounding component values to
    standard values can be seen
  • EasyPLL provides detailed and complete simulations

17
Four Easy Steps in EasyPLL
18
Choose a PartEnter System Requirements
1 2
3
19
Choose a PartSelect a PLL and VCO
1
2
3
20
Create a DesignEnter Performance Requirements
-Phase Margin -Loop Bandwidth are set to AUTO
3
-Optimize for Lock Time and set constraints
1 2
2nd Order Filter
21
View Component Values
-Phase Margin chosen as 49.2 deg -Loop
Bandwidth chosen as 8.7 KHz
- Lock time achieved - Spur gain missed
22
Increase to 3rd Order Filter
-Phase Margin adjusted to 45.5 deg -Loop
Bandwidth adjusted to 8.6 KHz
- Lock time achieved - Spur gain achieved
Change to 3rd Order Filter
23
Analyze a Design Locktime
  • Viewing the Lock time graph verifies that we met
    our Lock time requirement of lt300uS

24
Analyze a Design Spur Level
  • Running the Spur Estimate simulation verifies our
    Spur Gain of -5 dB at a 500 KHz offset and a
    corresponding Spur Level of -86 dBc.

25
Analyze a Design Bode Plot
  • The Bode Plot graph shows the Phase Margin and
    Loop Bandwidth that were calculated for you by
    EasyPLL.

26
Build It Design Check
  • Run the Design Check to make sure its a good
    design
  • Valuable tips on how to improve your design.

27
Build It Order Custom Board
  • Review the Bill of Materials
  • Click on Order Custom Board
  • Enter your credit card information
  • Custom/tested board will be shipped within 5
    business days.

28
Final Result
29
Conclusion
  • New Approach for Loop Filter Design and
    Optimization
  • Quicker design time
  • Optimized loop filter designs
  • No more guessing!
  • Design your loop filter in minutes rather than
    days

30
Where to Find More Information
  • WIRELESS.NATIONAL.COM home page
  • Links to techonline server archive of this
    presentation
  • Deans book PLL Performance, Simulation and
    Design Handbook, 2nd Edition!
