Design of Environmentally Benign Processes: Integration of Solvent Design

1
Design of Environmentally Benign Processes
Integration of Solvent Design Separation
Process Synthesis
C

A

P

E

C

• Peter M. Harper, Martin Hostrup, Rafiqul Gani
• CAPEC
• Dept. of Chem. Eng., Tech. Univ. of Denmark
• http//www.capec.kt.dtu.dk

2
Overview

• Introduction
• Methodology
• Problem Formulation
• Solution Approach
• Tools needed
• Application examples
• Conclusions

3
Introduction-I Definitions

• Environmentally Benign Process
• All environmental aspects have been considered.
• The process complies (AT LEAST) with all
  regulatory requirements.
• Pollution
• Causes
• Solvents, energy use, by-products in effluent
  streams.
• Prevention, Treatment Cure

4
Introduction -II Integration
Integration of synthesis, design, pollution
prevention, etc., means solving various problems
simultaneously

• Objective Develop a combined methodology in
  order to determine (interactively), optimal,
  environmentally benign processes

5
Superstructure representation
6
Methodology-I Problem Formulation

• New process (pollution prevention)
• Existing process (treatment/cure)
• Variables are fixed
• Problem more constrained (less degrees of
  freedom)
• More difficult to solve

Process model Process constraints Environmental
constraints Solvent alternatives
7
Problem Formulation Steps

• 1. Analyse process, divide into reaction
  separation blocks.
• 2. List separation techniques to be considered.
• 3. External mediums? Eliminate if none found.
• 4. Screen out infeasible separation techniques.
• 5. Binary mixture analysis Azeotropes,
  miscibility,
• 6. Generate solvent alternatives.
• 7. Multicomponent mixture analysis Separation
  boundaries, etc.
• 8. Check separation stream for reactants.
  Recycle?
• 9. Formulate optimization problem in terms of
  superstructure, objective function, constraints,
  etc.

8
Methodology-II Solution Approach
Sub-Problems Process Design Solvent
Design/Selection Material Design/Selection Waste/E
nergy Aspects
9
Sub-Problems Process Design

• Conditions of operation
• Temperature / Pressure
• Separation unit (distillation column) design
• Separation efficiency curves
• Product specifications
• Design parameters (feed location, reflux, )
• Reaction synthesis and optimization
• Volume / Residence time
• Temperature profile
• Operational constraints
• Separation boundaries
• Solvent/material design (selection)
• Energy consumption waste

10
Process Design Separation techniques

• Need for (appropriate) thermodynamic models.
  Thermodynamic Model Selection
• Need for Properties (Database/Property
  prediction)

11
Sub-Problems Solvent Design/Selection I

• Find compounds matching desired properties
• Performs database search
• Generates missing data
• Based on properties controlling the search/design
  operation
• Ability to identify novel compounds
• Suitable for substitution problems

12
Molecule Generation

• Multilevel Approach
• All generation is rule-based (feasibility, method
  considerations).
• Increasing complexity on the generated molecular
  descriptions.
• Output from previous level is used as input for
  the next next level.

Level 3/4
13
Generation criteria/properties

• Group contribution
• Correlation
• EOS
• UNIFAC
• Rigorous phase calculations
• Link to database
• Calculation order optimised for speed

14
Sub-Problems Material Design/Selection

• Designing or selecting the most appropriate
  membrane material for a particular application.
• Computer Aided Membrane Design still an emerging
  field.
• Database approach combined with shortcut
  simulations
• Allows for realistic input data to be used in the
  selection process.
• The choice of material can change the efficiency
  of a process by several orders of magnitude.

15
Sub-Problems Waste/Energy Aspects

• Local (process-wide) energy aspects can be
  addressed using the simulation engine.
• Off-process energy requirements must be handled
  using LCA techniques - taking local conditions
  into account.
• Waste/effluent minimisation can (in part) be
  handled using the simulator/optimiser.
• Impact assessment tools must be used...

16
Methodology- III Problem Solution

• Flexible interactive solution of the problem
• Rigorous models used in the NLP-step
• Linear model generated for the MILP-step
• Any sub-problem can also be solved independently

17
Methodology - IV Tools Needed

• Process Simulator (steady state, dynamic)
  Modelling tool
• Solvers (NLP, MINLP, AE, DAE, etc.)
• Flowsheet generation tool (process synthesis)
• CAMD (solvent selection/design)
• Physical properties database (gt 13000 compounds)
• Environmental properties database
• Materials database
• Properties estimation tool (Pure component
  mixture properties)
• Impact Assessment tools

18
Application Examples
Solvent Design/Selection Sub-problem -
Replacement solvent (Isoamyl acetate) for
extraction of acetic acid from water Process
Flowsheet Synthesis Integrated problem -
Separation of acetone and chloroform
19
Example-I Design criteria

• Compound type Acyclic alkanes, ethers, esters,
  aldehydes, ketones and acids.
• Pure component properties
• Tflash gt 310 K, Tboil gt 421 K Tmelt lt 310 K
• Mixture properties
• Sl lt 0.01 m gt 0.1 ? gt 7 B gt 1
• Solvent must not form azeotrope with acetic acid
• Liquid-liquid phase behaviour at 298 K

20
Example-I Results performance

• 2332 Alternatives were found
• Candidates sorted using m? as ranking criteria
• Structure analysis/matching to identify CAS-NO

21
Example-I Environmental Aspects

• D Drug, S Primary Irritant, T
  Reproductive-Effector, M Mutagen, C Tumorigen

22
Example-II Integrated Problem
Problem A process stream of 50 mole Acetone and
50 mole Chloroform at 300K, is to be
separated.
No external medium known Binary ratios of
properties identify the following alternatives
Note Acetone-chloroform forms a high boiling
azeotrope that is pressure sensitive
23
Pressure dependence
24
Pressure dependence
25
Solvent design sub-problem

• CAMD problem
• 340 lt Tboil lt 420
• Selectivity gt 3.5
• Solvent powergt 2.0
• No azeotropes
• Number of compounds designed 47792Number of
  compounds selected 53
• Number of isomers designed 528 Number of
  isomer selected 23
• Total time used to design 57.01 s

Solution 1-Hexanal Methyl-n-pentyl
ether (Benzene)
26
Phase behaviour
27
Phase behaviour
28
Problem formulation Solution
Objective function Maximize Profit
Earnings Solvent cost Energy
costs Constraints Acetone purity gt
0.99 Chloroform purity gt 0.98
Results
29
Conclusions

• A systematic, knowledge intensive framework for
  design for the environment on the process level.
• Pollution prevention
• Use of thermodynamic knowledge
• Synthesis of flowsheets
• Optimizes operational parameters
• Cure/Treatment
• Verification by simulation
• Uses existing operational constraints
• Identifies needed changes in operational
  parameters
• Use of rigorous models

30
More information ?

• CAPEC Web-Sites
• www.capec.kt.dtu.dk (Primary site)
• www.capec.kt.dtu.dk/eurecha (EURECHA inf. site)
• www.escape11.kt.dtu.dk (European Symposium on
  Computer Aided Process Engineering - 11, May 2001
  Denmark)
