Title: Technology Review-II


1
Technology Review-II
  • Professor Martin
  • Professor Xiong
  • CSUS
  • This lecture is based primarily on Romney
    Steinbart(2003). It also draws on Martin (2002).
  • Updated on Monday, September 9, 2003

2
Agenda
  • REA
  • Developing a REA Diagram
  • Implementing an REA Diagram in a Relational
    Database
  • The Purpose of REA

3
The REA Data Model
  • Data modeling is the process of defining a
    database so that it faithfully represents all
    aspects of the organization, including its
    interactions with the external environment.

4
The REA Data Model
  • The REA data model is a conceptual modeling tool
    specifically designed to provide structure for
    designing AIS databases.
  • The REA data model provides structure in two
    ways
  • By identifying what entities should be included
    in the AIS database
  • By prescribing how to structure relationships
    among the entities in the AIS database

5
Sample REA Diagram
Sales Person
Participates in
Stock flow
Inventory
Sales
Participates in
Economic Duality
Customer
Participates in
Stock flow
Cashier
Cash
Receive Cash
Participates in
6
Basic REA Template
Internal Agent
Participates in
inflow
Resource A
Get Resource A
Participates in
External Agent
Economic Duality
Participates in
Internal Agent
outflow
Resource B
Give up Resource B
Participates in
External Agent
7
An AIS Viewed as a Set of Give-to-Get Exchanges
Revenue Cycle
Give Cash
Get Inventory
Expenditure Cycle
Give Cash
Get Employees Time/Service
Human Resources/Payroll Cycle
Give Cash
Production Cycle
Get Cash
Get Employees Time/Service
Financing Cycle
Get Finished Goods Inventory
Give/Use Raw Materials
Give (Use) Machine Time Services
8
Types of Entities
  • An entity is any class of objects about which
    data is collected.
  • The REA data model classifies entities into
    three distinct categories
  • Resources acquired and used by an organization
  • Events engaged in by the organization
  • Agents participating in these events

9
Types of Entities
  • Resources are defined as those things that have
    economic value to the organization.
  • What are some examples?
  • cash
  • inventory
  • equipment

10
Types of Entities
  • Events are the various business activities about
    which management wants to collect information for
    planning or control purposes.
  • What are some examples?
  • sales events
  • taking customer orders

11
Types of Entities
  • Agents are the third type of entity in the REA
    model.
  • Agents are the people and organizations that
    participate in events and about whom information
    is desired.
  • What are some examples?
  • employees
  • customers

12
Structured Relationships
  • The REA data model prescribes a basic pattern for
    how the three types of entities (resources,
    events, and agents) should relate to one another.

13
Structured Relationships
Get resource A
Resource A
Give up resource B
Resource B
14
Structured Relationships
Internal Agent
Get resource A
External Agent
Internal Agent
Give up resource B
External Agent
15
Agenda
  • REA
  • Developing a REA Diagram
  • Implementing an REA Diagram in a Relational
    Database
  • The Purpose of REA

16
Developing an REA Diagram
  • Developing an REA diagram for a specific
    transaction cycle consists of three steps
  • Identify the pair of events that reflect the
    basic economic exchange.
  • Identify the resources affected by each event and
    the agents who participate in those events.
  • Determine the cardinalities of each relationship.

17
Identify EconomicExchange Events
  • The basic economic exchange in the revenue cycle
    involves the sale of goods or services and the
    subsequent receipt of cash in payment for those
    sales.
  • The REA diagram for SSs revenue cycle shows the
    drawing of sales and cash collections events
    entities as rectangles and the relationship
    between them as a diamond.

18
Identify EconomicExchange Events
  • In drawing an REA diagram for an individual
    cycle, it is useful to divide the paper into
    three columns, one for each type of entity.
  • Left column should be used for resources.
  • Middle column should be used for events.
  • Right column should be used for agents.

19
Identify Resources and Agents
  • Once the events of interest have been specified,
    the resources that are affected by those events
    need to be identified.
  • The sales event involves the disposal of
    inventory.
  • The cash collections event involves the
    acquisition of cash.

20
Identify Resources and Agents
  • After specifying the resources affected by each
    event, the next step is to identify the agents
    who participate in those events.
  • There will always be at least one internal agent
    (employee) and, in most cases, an external agent
    (customer).

21
Specify Cardinalities
  • The cardinality of a relationship indicates how
    many occurrences of one entity in the
    relationship can be linked to a single occurrence
    of the other entity in the relationship.
  • Cardinalities are often expressed as a pair of
    numbers.
  • The first number is the minimum, and the second
    number is the maximum.

22
Specify Cardinalities
  • The minimum cardinality of a relationship
    indicates the fewest number of rows that can be
    involved in that relationship.
  • Minimum cardinalities can be either 0 or 1.
  • A minimum cardinality of zero means that each
    occurrence of the entity on the other side of the
    relationship need not be linked to any
    occurrences of the entity on this side of the
    relationship.

23
Specify Cardinalities
  • The minimum cardinality of zero in the (0, N)
    cardinality pair to the left of the customer
    entity in the customer-sales relationship
    indicates that a given customer need not be
    linked to any sales events.

Sales
(0, N)
Customer
24
Specify Cardinalities
  • Minimum cardinalities of zero are common for
    relationships between two temporarily linked
    events. Why?
  • Because at any given time the second event in the
    pair may not yet have occurred.
  • A minimum cardinality of 1 indicates that each
    instance of that entity must be associated with
    at least one instance of the other entity.

25
Specify Cardinalities
  • The minimum cardinality below the sales entity in
    the sales-customer relationship reflects the
    general business rule that each sales event must
    be associated with some specific customer.

Sales
Customer
(1, 1)
26
Specify Cardinalities
  • The maximum cardinality of a relationship
    indicates the largest number of rows that can be
    involved in that relationship.
  • Maximum cardinalities can be either 1 or N.
  • The N indicates that each row in the table may be
    linked to many rows in the other table.

27
Specify Cardinalities
  • Three basic types of relationships between
    entities are possible, depending on the maximum
    cardinality associated with each entity.
  • One-to-one relationship
  • One-to-many relationship
  • Many-to-many relationship

28
Specify Cardinalities
  • Cardinalities are not arbitrarily chosen by the
    database designer.
  • They reflect facts about the organization being
    modeled and its business practices obtained
    during the requirements analysis stage of the
    database design process.

29
Examples
Cash Receipts
Sales
  • )

(1, 1)
(0, 1)
Sales
Cash Receipts
(1, 1)
(0, N)
Sales
Cash Receipts
(0, 1)
(1, N)
Sales
Cash Receipts
(0, N)
(1, N)
30
Agenda
  • REA
  • Developing a REA Diagram
  • Implementing an REA Diagram in a Relational
    Database
  • The Purpose of REA

31
Implementing an REA Diagram in a Relational
Database
  • An REA diagram can be used to design a
    well-structured relational database.
  • A well-structured relational database is one that
    is not subject to update, insert, and delete
    anomaly problems.

32
Create Tables
  • A properly normalized relational database has a
    table for each entity and each many-to-many
    relationship.
  • From the previously discussed REA diagram, nine
    tables would be created one for each of the
    seven entities and one for each of the
    many-to-many relationships.

33
Create Tables
  • Inventory
  • Sales
  • Salesperson
  • Customer
  • Cashier
  • Cash collections
  • Cash
  • Sales-inventory
  • Sales-cash collections

34
Identify Attributes for Each Table
  • Primary keys
  • Usually, the primary key of a table representing
    an entity is a single attribute.
  • Other Attributes
  • Additional attributes are included in each table
    to satisfy transaction processing requirements.

35
Implement One-to-One and One-to-Many
Relationships
  • One-to-One Relationships
  • In a relational database, one-to-one
    relationships between entities can be implemented
    by including the primary key of one entity as a
    foreign key in the table representing the other
    entity.

36
Implement One-to-One and One-to-Many
Relationships
  • One-to-Many Relationships
  • In a relational database, one-to-many
    relationships can be also implemented in relation
    to databases by means of foreign keys.

37
Agenda
  • REA
  • Developing a REA Diagram
  • Implementing an REA Diagram in a Relational
    Database
  • The Purpose of REA

38
Documentation
  • REA diagrams are especially useful for
    documenting an advanced AIS built using
    databases.
  • REA diagrams provide two important types of
    information about a database
  • Information about the relationships among data
    items
  • Information about the organizations business
    practices

39
Information About Business Practices
  • The cardinalities in REA diagrams provide useful
    information about the nature of the company being
    modeled and the business policies that it follows.

Events
Resources
Sales
Inventory
(0, N)
(1, N)
40
Information About Business Practices
  • The relationship between sales and inventory is
    called line items and represents the fact that
    each sale consists of one or more items of
    merchandise.
  • Each item appears as a separate line item on the
    sales invoice.
  • The quantity sold indicates that a customer may
    buy more than one of a given item.

41
Extracting InformationFrom the AIS
  • A complete REA diagram serves as a useful guide
    for querying an AIS database.
  • Queries can be used to generate journals and
    ledgers from a relational database built on the
    REA model.

(0, 1)
(1, N)
Cash collections
Sales
42
Extracting InformationFrom the AIS
  • In a one-to-many relationship between cash
    collection and sales, remittance number is a
    foreign key in the sales table.
  • Each sales transaction is paid in full by a cash
    collection event.
  • What is the query logic?
  • Total accounts receivable is the sum of all sales
    for which there is no remittance number.

43
Topics Discussed
  • REA-Introduction
  • Developing a REA Diagram
  • Implementing a REA Diagram in a Relational
    Database

44
Review
  • Which of the following is not considered a
    resource in an REA model?
  • Cash
  • Accounts Receivable
  • Inventory
  • Equipment

45
Review
  • 2. Which of the following is not a type of entity
    in the REA data model?
  • Customers
  • Sales
  • Invoices
  • Delivery trucks

46
Review
  • 3. Which type of relationship cardinality must be
    implemented in a relational database as a
    separate table?
  • One-to-one relationship
  • One-to-many relationship
  • Many-to-many relationship
  • all of the above

47
Review
  • 4. In a company pays for each purchase it makes
    with a separate check and does not make
    installment payments on any purchases, then the
    relationship between cash disbursement and
    purchases would be modeled as being with of the
    following?
  • One-to-one relationship
  • one-to-many relationship
  • many-to-many relationship
  • paid-in-full relationship

48
Review
  • 5. The key of a many-to-many relationship between
    the sales and inventory events would be
  • invoice number
  • item number
  • both invoice number and item number
  • either invoice number or item number

49
Review
  • 6. Which of the following elements of the REA
    data model must be implemented as tables in a
    relational database?
  • Resources
  • events
  • agents
  • all of the above

50
Review
  • 7. Which set of cardinality pairs most accurately
    models the sales of low-cost, mass-produced items
    by a retail store?
  • inventory(0,N) (0,N) Sales
  • inventory(0,N) (1,N) Sales
  • Inventory (1,N) (1,N) Sales
  • inventory(1,N) (1,N) Sales

51
Review
  • 8. A company wants to store information about
    both currently used and alternative suppliers?
  • Purchases(0,N) (0,1) suppliers
  • Purchases(1,N) (1,1) suppliers
  • Purchases(0,1) (1,N) suppliers
  • Purchases(1,1) (0,N) suppliers

52
Example
  • Draw an REA Diagram , complete cardinalities, for
    Joes revenue cycle
  • Joes is a small ice cream shop located near the
    local universitys baseball field. Joes serves
    walk-in customers only. The shop carries 26
    flavors of ice cream. Customers can buy cones,
    sundaes, or shakes. When a customer pays for an
    individual purchase, a sale transaction usually
    includes just one item. When a customer pays for
    a family or a group purchase, however, a single
    sale may include many different items. All sales
    must be paid for at the time the ice creams is
    served.
Write a Comment
User Comments (0)
About PowerShow.com
