Title: Storage Platform: Defining Leadership


1
Storage Platform Defining Leadership
  • Jeffrey Goldner
  • ArchitectWDEGjeffgo _at_ microsoft.com
  • Microsoft Corporation

2
Session Outline
  • Trends affecting Windows storage features
  • Market
  • Standards
  • Customer Requirements
  • Intersections with the hardware industry
  • Key challenges
  • Todays situation
  • Current initiatives to address these challenges
  • What comes next

3
Session Goals
  • Attendees should leave this session with the
    following
  • A better understanding of the trends that impact
    Windows Storage
  • A better understanding of current Microsoft
    initiatives dealing with some key storage
    industry challenges
  • A better understanding of how storage hardware
    and software vendors can align with these goals
  • The knowledge to find resources for these
    initiatives

4
Storage Devices Key Windows Strategies
Leading platform supporting storage fabrics
Optimized platform features enabling new customer
scenarios in Personal Storage
Timely, comprehensive, quality platform support
for optical devices
Preferred platform for developing, integrating,
and deploying storage devices
5
Key trends affecting Windows Storage
  • Market
  • Movement from direct to fabric attached storage
  • Declining disk prices
  • Higher capacity drives
  • lower-cost consumer drivetechnologies
  • Standards
  • Moving beyond device interfaces
  • Management
  • Security
  • Data integrity
  • Compliance

6
Key Trends Affecting Windows Storage (cont)
  • Customer Requirements
  • More global businesses
  • Want data 24x7
  • Want fast access
  • More diverse, high volume data
  • Scientific data, video images, etc.
  • Data protection more complex
  • Backup and retention
  • Now requires management of multiple copies of
    data
  • Archiving often overlooked when using disk-based
    backup
  • Disaster recovery
  • Need for greater distance between sites
  • More businesses now using replication solutions
  • Security
  • Growing recognition of need for secure solutions
  • Especially problematic with small form factors
    devices

7
Intersections With the Hardware Industry
  • Working jointly with the industry to ease the
    complexity of storage networks
  • Interoperability
  • Reliability
  • Management
  • Security
  • Performance
  • Goal is to integrate storage capabilities into
    the operating system
  • Alignment of the Windows platform and hardware
    capabilities
  • Enable new classes of applications to use these
    capabilities
  • Enable vendors to take advantage of their
    value-added functions
  • Make sure end-to-end scenarios are covered
  • Ensure customer data is available and secure

8
Key Challenges
Todays challenges have lead to initiatives to
produce solutions
9
Todays Challenges
  • Larger, hotter drives placed closer together
  • Use of redundant arrays is it more reliable in
    the desktop market?
  • Hidden corruption on mirrors
  • Not enough focus on mechanical layouts
  • Fabric attached storage has additional complexity
  • More components that could fail
  • High availability is achieved through redundancy
  • Comes at a high cost
  • OS may not be able to interpret true cause of
    errors
  • Transient conditions, maintenance operations
  • Backup and recovery
  • Device, driver, application reliability
  • Consistency of data
  • Limited backup window precludes complete backups
  • Access to previous versions

10
ChallengesReliability (MS Internal Study)
Component Failures
  • Microsoft data
  • Disk drive is least reliable component
  • Desktop, notebook and server
  • Only covers component failure
  • Not random corruptions
  • Loss of data

11
Todays Challenges
  • Customer impact
  • Larger volume of data at risk in catastrophic
    failures
  • Risk of backup failure still high
  • Are customers willing to pay more for higher
    reliability?
  • Additional disk devices for backup purposes?

12
Initiatives
  • Disks
  • Predictive failure analysis for disk drives
  • Drive industry to standardized implementations
  • Disk diagnostics and background processes to
    check data integrity
  • Qualification program enhancements
  • Fabrics
  • New tools for viewing fabrics
  • Increased resilience in the OS
  • Coordinating with management applications
  • Backup
  • Use snapshot solutions coordinated with the OS
  • Follow driver and provider models
  • New device handling approach
  • Reliability Problems
  • Disk drives
  • Heat
  • Vibration
  • Random corruption
  • Fabric
  • Cable failure
  • Maintenance operations
  • Managing errors
  • Backup Integrity
  • Open files
  • Unreadable tape media
  • Device driver problems

13
Todays Challenges
  • Performance Challenges
  • Sequential performance is most commonly cited
    statistic
  • This statistic gives an idealized performance
    measurement
  • Vendor performance metrics look good
  • Driving customers to lower-cost technologies
    before they can assess the impact to business
    goals
  • BUT most I/O in a multitasking operating system
    is not sequential
  • Random performance
  • At the device level, little performance
    improvement over the last 5 years
  • Requires expensive hardware solutions to improve
    random I/O performance (spindles vs. capacity)
  • Disk drive margins tend to be low, so market
    opposition to improving mechanical performance
  • Customer impact
  • Although system performance has improved, not
    able to take advantage of full potential if you
    cant get to the data
  • Drive customers to higher-priced storage

14
Initiatives
  • Performance Initiatives
  • System and application optimizations
  • Help decrease random I/O
  • Memory Manager optimized to increase use of
    sequential I/O
  • Pre-fetch for application launch and OS boot
  • Rearrange data to increase
  • Speed of OS loading
  • Speed of application launch
  • Low Priority I/O
  • Allows some applications to run in the
    background user application gets disk priority
  • Scheduled File I/O
  • Application can reserve bandwidth for specific
    file (such as audio playback)
  • I/O takes priority (counterpart to low priority)
  • Volume alignment
  • Best practice analyzers
  • Application and load-specific tools to ensure
    adequate storage performance
  • Performance Problems
  • Multitasking system means there are always
    multiple processes accessing disk drives
  • Random I/O access slow

15
Todays Challenges
  • Manageability Challenges
  • Too many storage management pieces
  • Number of tools increases with number of
    components
  • Interfaces
  • Standards
  • Integrating new Windows storage features
  • Time-lag to industry adoption
  • Customer impact
  • Confusion
  • Complex storage management

16
Initiatives
  • Manageability Initiatives
  • Better tools and interfaces
  • Storage management infrastructure reduces need
    for multiple vendor tools
  • Adopting and promoting standards
  • Interfaces for SATA, Fibre Channel and iSCSI
  • Applying Windows system initiatives to storage
    management
  • Windows Management Instrumentation
  • WS Management
  • Management Problems
  • Proliferation of tools, interfaces, standards
  • Time-lag for hardware industry adoption of new
    Windows storage features

17
Todays Challenges
  • Interoperability Challenges
  • Hardware-hardware
  • Lack of standards conformance
  • Hardware-software
  • Non-alignment with OS driver models
  • Integration with OS
  • Slow adoption of infrastructure enhancements
  • Customer impact
  • Limited choices when building storage
    infrastructure
  • Difficulty diagnosing problems
  • Potential data loss, downtime, disruption of
    business

18
Initiatives
  • Interoperability Initiatives
  • New programs such as Simple SAN
  • Includes interoperability requirements for
    hardware and software vendors
  • Conformance to driver models
  • Adoption of storage interfaces
  • New Windows tools to help diagnose problems
  • Enhanced tests for hardware qualification
  • Vendor education
  • Windows driver and provider models
  • Refining models to meet vendor needs
  • The OS is the common denominator in all
    interoperability design
  • Requires conformance to standards
  • Interoperability Problems
  • Hardware
  • Drivers may not be optimal for all attached
    hardware
  • Lack of adherence to standards
  • Can lead to
  • Suboptimal performance
  • Inability to access device
  • Hardware/software
  • Drivers not conforming to current models
  • Prevents correct detection and recovery by the OS
    or applications

19
Todays Challenges
  • Security Challenges
  • Management interfaces
  • Each hardware component has its own security
    management interface
  • Device passwords rarely updated
  • No integration of interfaces with the operating
    system (e.g., cant distribute credentials)
  • No standards on how the integration is done
  • Data
  • Data on removable devices not protected
  • Data in-flight may need to be encrypted
  • Devices
  • Many connect to networks with protocols that are
    not secure
  • Implementation of secure network infrastructure
    is difficult
  • Currently few/no policies restricting the use of
    devices
  • Customer impact
  • Corporate data at risk
  • Personal data at risk

20
Initiatives
  • Security Initiatives
  • Centralized infrastructure for fabric attached
    storage
  • Standards-based implementation
  • RADIUS, CHAP
  • Fibre Channel and iSCSI
  • Protection of management interfaces
  • Authentication of devices
  • Encryption where supported by the protocols
  • Data
  • File level encryption
  • Block level encryption being investigated
  • OS integration with devices that have built-in
    encryption (such as flash media)
  • Devices
  • Administrator policies for preventing user access
    to removable devices
  • Standardized implementation of rights management
  • Security Problems
  • Management Interfaces
  • Not integrated with OS
  • Not standardized
  • Data
  • Data on removable devices not protected
  • Devices
  • Switches/arrays access non-secure IP protocol
  • Few or no policies restricting device use

21
Next Wave Storage Solution Initiatives
  • Small and medium businesses
  • Simple SAN initiative aims to simplify SANs for
    the small and midsize market
  • Program qualification for
  • Simple SAN solution components
  • Simple SAN complete solutions
  • Large/Enterprise market
  • Many challenges remain, especially with regard to
    interoperability and manageability
  • Increased focus on managing storage
  • More capability built in to the operating system
  • Industry prediction by 2006, SAN management
    functions will be embedded as part of the OS

22
Microsoft Directions
  • Driving initiatives for a better storage
    experience
  • Listening to customers, partners, industry
  • Making storage infrastructure a better fit with
    industry standards and partner needs
  • Adoption of system level management initiatives
  • Leading on providing a programmatic framework for
    storage vendors to deliver the best solutions on
    the Windows platform

23
Call To Action
  • Adopt Windows Storage Interfaces
  • These will improve the storage experience
  • Help us drive towards
  • Greater reliability
  • Higher performance
  • Increased interoperability
  • Improved security
  • Better storage management
  • Follow the logo program
  • Submit products for qualification
  • Keep up with updates to the program

24
Community Resources
  • Community Sites
  • http//www.microsoft.com/communities/default.mspx
  • List of Newsgroups
  • http//communities2.microsoft.com/communities/news
    groups/en-us/default.aspx
  • Attend a free chat or webcast
  • http//www.microsoft.com/communities/chats/default
    .mspx
  • http//www.microsoft.com/seminar/events/webcasts/d
    efault.mspx
  • Non-Microsoft Community Sites
  • http//www.microsoft.com/communities/related/defau
    lt.mspx

25
Additional Resources
  • Questions about this presentation
  • hec5stor _at_ microsoft.com
  • Storage at Microsoft
  • http//www.microsoft.com/windowsserversystem/stora
    ge/default.mspx
  • Community (Storage)
  • http//www.microsoft.com/windowsserversystem/stora
    ge/community/default.mspx
  • news//msnews.microsoft.com/microsoft.public.stora
    ge
  • Logo program information
  • http//www.microsoft.com/whdc/winlogo/default.mspx
  • Standards organizations (Storage)
  • http//www.t10.org
  • http//www.t13.org
  • http//www.snia.org
Write a Comment
User Comments (0)
About PowerShow.com
