Title: 615260 Enterprise Systems SAP Stream Wednesdays


1
615-260 Enterprise Systems SAP Stream
(Wednesdays)
L14 Procurement and SOA NetWeaver
2
Goal for this lecture
  • To provide a description and explanation of the
    SAP R/3 Procurement process (Module 4) similar to
    that required in Project 2 for the R/3 Sales
    Process (Module 6).
  • Provide feedback on the Essay Services-oriented
    IT Architecture and SAP NetWeaver

3
Lecture Outline
  • Process functionality in R/3 Procurement
  • Database structure in R/3 Procurement
  • Service-Oriented IT Architecture SAP NetWeaver
  • (Ill go a little beyond what was expected from
    you.)
  • 4. Summary

4
Project 2, Question 3 (5 marks)
  • (3) Sales Process Functionality (5 marks)
  • The process you have just completed initially
    seems very complex. Presumably SAP has designed
    it the way it is because their customers have
    requested it to be this way.
  • Why would SAPs customers have wanted such a
    complex process? What is the point of having all
    the document types shown above? (You might
    construct a table showing the purpose, and value
    to the organization, of each document type.)
  • Is this process best practice? Explain your
    answer.

5
Project 2, Question 4 (5 marks)
  • (4) R/3 Sales Database (5 marks)
  • The relational database is at the heart of
    systems like SAP R/3.
  • Within the constraints of this 1,500-word
    assignment, describe the tables (define key
    columns and types of information stored) used to
    store your Sales Order.
  • In what ways, if at all, does the content of
    these tables change as each step in the process
    is executed?

6
1. Process Functionality, Procurement Process,
(similar to Project 2, Q.3, 5 marks)
  • The process you have just completed initially
    seems very complex. Presumably SAP has designed
    it the way it is because their customers have
    requested it to be this way.
  • Why would SAPs customers have wanted such a
    complex process? What is the point of having all
    the document types shown above? in this process.
  • (You might construct a table showing the purpose,
    and value to the organization, of each document
    type.)
  • Is this process best practice? Explain your
    answer.

7
Figure 4.1, page 4.2
8
P/AP/CP Organization Information flows
Gelinas and Sutton, p.405
Warehouse shown in DFD

Requis-itions
9
GS p.408
1.0 Order goods services
2.0 Receive goods services
3.0 Establish Payable
4.0 Make Payment
10
GS p.408
1
1.0 Order goods services
2
4
3
5
2.0 Receive goods services
1
3.0 Establish Payable
1
6
7
4.0 Make Payment
8
2
11
(No Transcript)
12
Purchasing Documents (1)
  • Purchase Requisition
  • Document requesting Purchasing Department to
    purchase goods.
  • E.g., a Purchase Requisition for 10 cartons of
    Floppy Disks.
  • Can be prepared by any department (division)
    requiring goods or services.

13
Purchasing Documents (2)
  • Request for Quotation
  • Document sent to potential vendors inviting them
    to tender for goods.
  • R/3 can perform vendor analysis and generate
    letters for successful/unsuccessful vendors.
  • Once Vendor is chosen, the purchase requisition
    is converted to a purchase order.
  • Usually prepared by Purchasing Department.

14
(No Transcript)
15
Purchasing Documents (3)
  • Purchase Order
  • Formal request to vendor to supply certain goods.
  • Can be created with or without reference to an
    RFQ or a purchase requisition.
  • Usually prepared by Purchasing Department.

16
Notes page 4-28
17
Purchasing Documents (4)
  • Goods Receipt
  • Document confirming that the goods have been
    received and the correct amount of each type has
    been delivered.
  • Usually prepared by Receiving/Shipping
    Department.

18
Purchasing Documents (5)
  • Vendor Invoice
  • Vendor sends invoice for payment of
    goods/services
  • In R/3, the procurement process is concluded by
    verification of the vendor invoice.
  • Usually entered by Accounts Payable Department.

19
(No Transcript)
20
(No Transcript)
21
Module 4 Procurement
  • In M4.1 you created a material master record
    A- Headlamp Extra Bright.
  • In M4.2 you purchased 10 units of inventory item
    A- (i.e. executed part of the stock material
    process), recorded receipt of goods, and accepted
    the vendors invoice.
  • In M4.3, you executed another version of the
    procurement process, similar to M4.2, except that
    the goods purchased were accounted for
    differently (not as assets).

22
(No Transcript)
23
Integration with Accounting
  • Invoice Receipt (Document type RE)
  • Debit 191100 Goods received/Invoice received
    (specified during configuration?)
  • Credit 160001 Trade Payables Domestic (Specify
    Accounts Payable control account in the Vendor
    Master record)
  • Goods receipt (Document type WE)
  • Debit 300000 Raw Materials (specify through
    Valuation class Raw Materials 1 (3000) in
    Materials Master, p.4.22, or at the time of entry
    of Purchase requisition, see Step 11, p.4.31,
    account 476100 Computer supplies)
  • Credit 191100 Goods received/Invoice received

24
(No Transcript)
25
(No Transcript)
26
1. Process Functionality, Procurement Process,
Summary
  • The process you have just completed initially
    seems very complex. Presumably SAP has designed
    it the way it is because their customers have
    requested it to be this way.
  • Why would SAPs customers have wanted such a
    complex process? What is the point of having all
    the document types shown above? in this process.
  • (You might construct a table showing the
    purpose, and value to the organization, of each
    document type.)
  • Is this process best practice? Explain your
    answer.

27
Why is the MM module of R/3 structured this way?
  • MM Processes
  • Flexibility to ensure system supports various
    different procurement processes within the one
    entity and across entities for a wide range of
    organizations around the world.
  • Integration to enhance supply chain management
  • Reduce stock-order lead times
  • Simplify time-consuming tasks
  • Increase accuracy
  • Improve communication between departments
  • Save

28
2. R/3 Database, Procurement Process, (similar to
Project 2, Q.4, 5 marks)
  • The relational database is at the heart of
    systems like SAP R/3.
  • Within the constraints of this 1,500-word
    assignment, describe the tables (define key
    columns and types of information stored) used to
    store your Sales Order.
  • In what ways, if at all, does the content of
    these tables change as each step in the process
    is executed?

29
GS p.408
1
1.0 Order goods services
2
4
3
5
2.0 Receive goods services
1
3.0 Establish Payable
1
6
7
4.0 Make Payment
8
2
30
The SAP R/3 Procurement Process is structured
around four types of stored data
31
MM Organizational Elements
1
  • Plant
  • A plant is a manufacturing facility or branch
    within a company. Examples Central delivery
    warehouse, regional sales office, manufacturing
    facility.
  • Storage Location
  • A storage location is an organizational unit that
    allows the differentiation of material stocks
    within a plant. Inventory control (stock count)
    is carried out at the storage location level in
    the plant.
  • Warehouse
  • Another storage location within a plant

32
Example MM Organizational Elements in Company
Code 3000 (Notes, Fig. 4.5)
33
All Inventory is held in storage locations MMO2
34
MM Organizational Elements (2)
  • Purchasing Organization
  • A purchasing organization is an organizational
    level that negotiates conditions of purchase with
    vendors for one or more plants.
  • It is legally responsible for completing
    purchasing contracts.
  • Purchasing organizations can be assigned to
    company codes and plants depending on whether
    purchasing is organized centrally or in a
    distributed fashion.
  • A Purchasing Group is a buyer or group of buyers
    responsible for certain purchasing activities.

35
Organizational Elements in R/3
36
Material Master Records (1)
2
  • Material master records are used by all
    components of the R/3 Logistics system.
  • Each user department has their own view of the
    data (see Figure 4.6)
  • Purchasing, Accounting, Goods receiving, Sales
    and Distribution, etc.
  • You created a MM master record in M4.1.

37
(No Transcript)
38
Figure 4.6
39
Material Master Records (2)
  • To enhance consistency and reduce data
    redundancy, Material master records are divided
    into levels (Figure 4.7) probably stored in
    different tables in the database
  • Client level data can be used by various company
    codes, e.g., 3000 and 4000. For example, the
    client level data of material A-XXX is also
    available in co-code 4000.
  • Plant level data can be used by all plants in a
    given company code, e.g., see Fig 4.5.
  • Storage location level data, e.g., the five
    storage locations in plant 3000 can share this
    level data (see Fig 4.5)
  • Material types define what sort of processing is
    relevant to different materials.

40
Notes, Figure 4.7
41
Vendor Master Records
3
  • Like material master data, Vendor master data is
    also divided into levels (pages 4.11-12)
  • Level 1 General level data (data that is valid
    for the entire client)
  • Level 2 Purchasing level (data that is valid
    for the entire purchasing organization)
  • Level 3 Accounting data (data that is valid for
    a particular company code)
  • Why this structure? To ensure data consistency
    and to minimize data redundancy

42
2. R/3 Database, Procurement Process, Summary
  • The relational database is at the heart of
    systems like SAP R/3.
  • Within the constraints of this 1,500-word
    assignment, describe the tables (define key
    columns and types of information stored) used to
    store your Sales Order.
  • In what ways, if at all, does the content of
    these tables change as each step in the process
    is executed?

43
The SAP R/3 Procurement Process is structured
around four types of stored data
44
Why? (1)
  • Organizational elements
  • Support monitoring and reporting of materials and
    material consumption at the company, plant,
    storage location and warehouse levels
  • Allows for centralised or decentralised
    purchasing management and performance reporting
  • Vendor records track liabilities and quality of
    vendor service

1
45
Why? (2)
  • Material Master Records
  • User only gets to see their view of the data
    (improves security, more efficient, saves time)
  • Level data can be shared Client, Plant, Storage
    Location (enhances consistency and reduce data
    redundancy)

2
46
Why? (3)
4
  • Purchasing documents
  • Different documents record processing at various
    stages of the procurement process e.g. Purchase
    Requisition gt RFQ gt Purchase Order gt Goods
    receipt gt Vendors invoice
  • Each document can be customized to suit the
    organizations requirements.
  • Each document has its own type, number range and
    control mechanisms

47
Lecture Outline
  • Process functionality in R/3 Procurement
  • Database structure in R/3 Procurement
  • Services-Oriented IT Architecture SAP NetWeaver
  • (Ill go a little beyond what was expected from
    you.)
  • 4. Summary

Good reference SAP NetWeaver for Dummies
48
Web Services and the Gartner Hyperbole (Hype)
Cycle, May 2003
In your career in IT you need to learn to fight
your way through hype!
49
Q.1 What is a Services-oriented IT Architecture?
(2 marks)
  • Description of SOA (1 mark)
  • Explanation of how Web Services is the primary
    enabling technology HTTP, XML, SOAP, WSDL, and
    UDDI (definitions of which are readily found on
    the web). (1 mark)
  • Poor 0.25, OK 0.5, Good 0.75, Very good
    1.0
  • Most students are expected to be Good to Very
    good on Q.1.

50
Definition of Services-oriented (IT) Architecture
  • A services-oriented architecture (SOA) is a
    framework for constructing and interlinking an
    organization's back-end systems with the goal of
    lowering cost and adding flexibility.
  • the central technological change giving new
    life to SOAs is the adoption of Web services, a
    set of XML protocols that dramatically simplifies
    the process of exchanging data between disparate
    systems.
  • Like existing middleware systems, Web
    services-based server software provides the
    technical underpinnings, such as security and
    reliable communications, for corporate systems.
  • http//www.zdnet.com.au/insight/software/0,390237
    69,39143923,00.htm

51
Definition of Services-oriented (IT) Architecture
  • A services-oriented architecture (SOA) is a
    framework for constructing and interlinking an
    organization's back-end systems with the goal of
    lowering cost and adding flexibility.

XML messages
Application A, e.g., on Computer A
Web services facade
Application B, e.g., on Computer B
Web services facade
Web services technology
52
Q.2 Why is it frequently argued today that many
firms will adopt a services-oriented IT
architecture in future? (2 marks)
  • By enabling applications to communicate more
    easily, A services-oriented architecture, or
    SOA, offers a promising design approach for
    making computing systems more flexible and
    cost-effective.
  • Gartner projects that the adoption of Web
    services and SOAs will greatly reduce the cost of
    releasing and customising applications. (to
    half)
  • 2 marks for overall answer
  • Most students are expected to be OK to good on Q.2

53
The Heterogeneity Problem (within one company) ?
Expensive to integrate applications.
54
Enterprise Application Integration (EAI)
55
(No Transcript)
56
Q.3What is SAP NetWeaver? (4 marks)
  • Reasonable description of the four main parts of
    the NetWeaver refrigerator (2 marks)
  • Explanation of the three types of integration (i)
    at the portal, (ii) via a data warehouse, and
    (iii) real-time transaction processing (via
    business process modeling) (1 mark)
  • Explanation that NetWeaver is the underlying
    technological platform on which SAP plans to
    build its entire future set of applications. It
    will allow customers unparalleled integration at
    the business-process level, point (iii) above. (1
    mark)
  • Most students are expected to be good to very
    good on Q.3

57
Slide from L02 What is SAP R/3?
SAP NetWeaver replaces the old blue diamond. It
is the infrastructure on which applications like
ERP and CRM will run in future.
This is the old picture
58
Access through any device
  • SAP Mobile Infrastructure
  • Enables mobile apps to run disconnected or
    connected
  • Built for handheld devices (Pocket PC, EPOC,
    Linux)
  • Browser or native front-end
  • Multiple-backend connections.
  • Various mobile business applications available

SAP NetWeaver
PEOPLE INTEGRATION
Multi channel access
Portal
Collaboration
INFORMATION INTEGRATION
Bus. Intelligence
Knowledge Mgmt
Master Data Mgmt
Composite Application Framework
Life Cycle Mgmt
PROCESS INTEGRATION
Integration Broker
BusinessProcess Mgmt
APPLICATION PLATFORM
J2EE
ABAP
DB and OS Abstraction
59
Portal (competes with best of breed vendors,
e.g., Plumtree)
SAP NetWeaver
  • SAP Enterprise Portal
  • Platform independence
  • Any source/audience,role-based
  • Team collaboration (both real-time
    asynchronous)
  • Authoring, Versioning, Indexing, Searching, for
    unstructured information
  • 1700 installations in 2003

PEOPLE INTEGRATION
Multi channel access
Portal
Collaboration
INFORMATION INTEGRATION
Bus. Intelligence
Knowledge Mgmt
Master Data Mgmt
Composite Application Framework
Life Cycle Mgmt
PROCESS INTEGRATION
Integration Broker
BusinessProcess Mgmt
APPLICATION PLATFORM
J2EE
ABAP
DB and OS Abstraction
60
Data Warehouse
  • SAP Business Intelligence
  • End-to-end solution forenterprise-wide BI
  • Business content for rapiddeployment
  • Fully integrated with portal
  • Open architecture (Crystal, Ascential)
  • 6000 installations in 2003
  • 95 extract non-SAP data

SAP NetWeaver
PEOPLE INTEGRATION
Multi channel access
Portal
Collaboration
INFORMATION INTEGRATION
Bus. Intelligence
Knowledge Mgmt
Master Data Mgmt
Composite Application Framework
Life Cycle Mgmt
PROCESS INTEGRATION
Integration Broker
BusinessProcess Mgmt
APPLICATION PLATFORM
J2EE
ABAP
DB and OS Abstraction
61
Business Process Integration. (XI is the part
that provides the SOA!!)
  • SAP Exchange Infrastructure (XI)
  • For both internal and external process
    integration(with SAP and non-SAP)
  • Prepackaged collaboration knowledge
  • Ecosystem of non-SAP collaboration content
  • 45 installations in 2003

SAP NetWeaver
PEOPLE INTEGRATION
Multi channel access
Portal
Collaboration
INFORMATION INTEGRATION
Bus. Intelligence
Knowledge Mgmt
Master Data Mgmt
Composite Application Framework
Life Cycle Mgmt
PROCESS INTEGRATION
Integration Broker
BusinessProcess Mgmt
APPLICATION PLATFORM
J2EE
ABAP
DB and OS Abstraction
62
(No Transcript)
63
Visual programming
64
ABAP and Java programming
SAP NetWeaver
  • SAP Web Application Server
  • J2EE compliant Java and ABAP side by side
  • Zero footprint UI (Browser)
  • Model-driven UI, patterns
  • Highly scalable and reliable, advanced caching
  • OS and DB independent
  • Native Web services
  • 1500 install. in 2003

PEOPLE INTEGRATION
Multi channel access
Portal
Collaboration
INFORMATION INTEGRATION
Bus. Intelligence
Knowledge Mgmt
Master Data Mgmt
Composite Application Framework
Life Cycle Mgmt
PROCESS INTEGRATION
Integration Broker
BusinessProcess Mgmt
APPLICATION PLATFORM
J2EE
ABAP
DB and OS Abstraction
65
Q.4 To what extent does SAP Netweaver meet the
goals for a services-oriented IT architecture? (2
marks)
  • It is pretty good. In NetWeaver, SAP has
    embraced open standards (e.g., J2EE, XML, web
    services) as much as possible (whilst also
    attempting to preserve the value of their
    customers existing SAP-related investments
    (including knowledge).
  • From a competitive perspective they are probably
    a year or two in front of their main competitors
    (Oracle, PeopleSoft) in the applications arena.
  • 2 marks for overall answer
  • Most students are expected to be OK to good on
    Q.4

66
(No Transcript)
67
(No Transcript)
68
Summary
  • Have provided a description and explanation of
    the SAP R/3 Procurement process (Module 4)
    similar to that required in Project 2 for the R/3
    Sales Process (Module 6).
  • Have provided feedback on Project 1
    Services-oriented IT Architecture and SAP
    NetWeaver
Write a Comment
User Comments (0)
About PowerShow.com
