Designing and Building Parallel Programs

1
Parallel/Distributed Programming Summary Report

• Designing and Building Parallel Programs

Prepared by Solange Artie
2
Introduction

• Parallelism
• A strategy for performing large complex tasks
  faster.
• Parallelism is done by
• Breaking up the tasks into smaller tasks.
• Assigning the smaller tasks to multiple workers
  to work simultaneously.
• Coordinating the worker.

3
Parallel Computers and Computation

• Attributes of parallel computation
• Concurrency- the ability to perform many actions
  simultaneously, essential if a program is to
  execute on many processors.
• Scalability- indicates resilience to increasing
  processor counts, and is equally important as
  processor counts appear likely to grow in most
  environment.
• Locality- depends on the ratio of remote to local
  access costs.
• Modularity- decomposition of complex entities
  into simpler components.

4
Parallel Computers and Computation

• Multicomputer
• Consists of one or more Von Neuman computers
  connected by an interconnection network.
• A simple and realistic machine model that
  provides a basis for the design of scalable and
  portable parallel programs.
• Tasks/Channels
• Simplifies the programming of multi-computers by
  providing abstractions that allow us to discuss
  concurrency, locality, and communication in a
  machine dependent fashion, and providing a basis
  for the modular construction of parallel programs.

5
Designing Parallel Algorithms

• Steps
• Partition- first partition a problem into many
  small pieces, or tasks.
• Communication- organize the communication
  required to obtain data required for task
  execution.
• Agglomeration- decrease communication and
  development costs, while maintaining flexibility
  if possible.
• Map-minimize execution time.

6
Quantitative Basis for Design

• Mathematical performance model characterize
• Execution time
• Efficiency
• Scalability
• How these models are used through parallel
  program design and implementation cycle
• Characterize the computation and communication
  requirements for parallel algorithm by building
  simple performance models. In which models can be
  used to choose between algorithmic alternatives,
  to identify problem areas in the design and to
  verify that algorithms meet performance
  requirements.
• Define the performance models and conduct simple
  experiments to determine unknown parameters like
• Computation time
• Communication costs
• Validate assumptions
• Compare the performance of the parallel program
  with its performance model, there. Help
  implementation error and quality of the model.

7
Putting Components Together

• Major Points in Modular Design Techniques
• The central tenets of modular designs such as
  simple interfaces and information hiding, apply
  in parallel programming just as in sequential
  programming.
• Data distribution is an important implementation
  that, if abstracted and of a module interface,
  can facilitate code reuse.
• Performance models can be composed, but care must
  be taken to account for communication costs at
  interfaces, overlapping of computation and
  communication and other factors.

8
Compositional C(CC)

• ltActual vs. Baseline Variance.gt
• ltCost overrun explanations.gt

• CC
• Provides a small set of extension to C for
  specifying currency, locality, communication, and
  mapping.
• Construct can be used to build libraries that
  provide the task and channel abstractions.
• Provides basic mechanisms that can be used to
  implement a variety of different parallel program
  structures.

ltScope changes from last milestone review.gt

• ltActual vs. Baseline Variance.gt
• ltProject file link for more info.gt

9
Fortran M

• Fortran M
• Provides a direct and complete implementation of
  the task/channel programming model.
• Incorporates language constructs for defining
  tasks and channels.
• It allows mapping decisions to be changed
  independently of other design aspects.

10
High Performance Fortran

• F90's array language and HPF's data distribution
  directives and related constructs chief features
• An array language comprising array assignments,
  array intrinsic, and (in HPF) FORALL and
  INDEPENDENT constructs is used to reveal the
  fine-grained concurrency inherent in
  data-parallel operations on arrays.
• Data distribution directives are introduced to
  provide the programmer with control over
  partitioning, agglomeration, and mapping (and
  hence locality).
• An HPF compiler translates this high-level
  specification into an executable program by
  generating the communication code implied by a
  particular set of data-parallel operations and
  data distribution directives.

11
High Performance Fortran

• Pros
• The most attractive feature of the data-parallel
  approach as exemplified in HPF is that the
  compiler takes on the job of generating
  communication code.
• Two advantages
• It allows the programmer to focus on the tasks of
  identifying opportunities for concurrent
  execution and determining efficient partition,
  agglomeration, and mapping strategies.
• It simplifies the task of exploring alternative
  parallel algorithms in principle, only data
  distribution directives need be changed.
• Con
• A problematic feature of HPF is the limited range
  of parallel algorithms that can be expressed in
  HPF and compiled efficiently for large parallel
  computers.

12
Message Passing Interface

• Parallel algorithm designs developed using the
  techniques that has already been discussed can be
  translated into message-passing programs.
• Principal features of the message-passing
  programming model
• A computation consists of a (typically fixed) set
  of heavyweight processes, each with a unique
  identifier (integers 0..P--1).
• Processes interact by exchanging typed messages,
  by engaging in collective communication
  operations, or by probing for pending messages.
• Modularity is supported via communicators, which
  allow subprograms to encapsulate communication
  operations and to be combined in sequential and
  parallel compositions.

13
Message Passing Interface

• Principle features continued
• Algorithms developed using the techniques set out
  in earlier can be expressed directly if they do
  not create tasks dynamically or place multiple
  tasks on a processor.
• Algorithms that create tasks dynamically or place
  multiple tasks on a processor can require
  substantial refinement before they can be
  implemented in MPI.
• Determinism is not guaranteed but can be achieved
  with careful programming.

14
Performance Tools

• Analytic performance model
• Is an idealization of program behavior that must
  be validated by comparison with empirical
  results.
• This validation process can reveal deficiencies
  in both the model and the parallel program.
• Performance analysis
• Is most effective when guided by an
  understanding rooted in analytic models, and
  models are most accurate when calibrated with
  empirical data.

15
Performance Tools

• Basic techniques and surveyed popular tools for
  collecting, transforming, and analyzing
  performance data
• Data collection level- profile and counter data
  are easier to obtain and to analyze, while races
  can show fine detail.
• Data transformation and visualization levels-
  data reduction techniques are able to reduce raw
  performance data to more meaningful and
  manageable quantities.
• Data visualization tools- can facilitate the
  navigation of large multidimensional data sets.

16
Random Numbers

• Linear congruential method commonly used
  sequential random number and can be adapted for
  parallel execution.
• Exemplifies how parallel computation can
  introduce new issues even in apparently simple
  problems.
• In the case of random numbers, these issues
  include reproducibility, scalability, the
  preservation of randomness, and the greater
  number of random values consumed when executing
  on many processors.

17
Hypercube Algorithm

• The hypercube template
• Is one of the most useful communication
  structures in parallel computing.
• Allows information to be propagated among P tasks
  in just log P steps.
• Nearest-neighbor exchange on a two-dimensional
  torus
• Used to implement finite difference computations,
  matrix multiplication and graph algorithms.
• Learning to recognize and apply templates such as
  the hypercube, torus, etc can greatly simplify
  the task of designing and implementing parallel
  programs.
