Multithreading

1
Multithreading
2
Introduction

• Multithreading is a programming mechanism where
  multiple programming actions are processed
  simultaneously.
• An analogy would be the human body Respiration,
  blood circulation, and digestion can occur
  concurrently.
• The .Net Framework Class Library makes
  concurrency primitives available to programmers.
• An example
• A user wishes to download a large audio or video
  clip from the World Wide Web.
• The user does not want to wait until the entire
  clip downloads before starting the playback.
• To solve this problem, the programmer can put
  multiple threads to work
• One thread downloads a clip.
• Another thread plays the clip.
• These activities, or tasks, occur concurrently.
• To avoid choppy playback, we synchronize the
  threads so that the player thread does not begin
  until there is sufficient amount of clip in
  memory.
• Garbage Collection is another example of
  multithreading.

3
Thread States (Continued)

• At any time, a thread is said to be in one of
  several thread states.
• During the life-cycle of a thread, it will
  transition from one state to another.
• Two classes are needed for multithreaded
  applications Thread and Monitor.
  (System.Threading namespace)
• A new thread begins its lifecyle in the Unstarted
  state. The thread remains in this state until
  your program calls Thread method Start.
• When the later method is called, the thread is
  placed in the Started (Ready) state.
• The thread that invoked Start and the newly
  Started thread and any other threads in the
  program execute concurrently.
• The highest priority started thread enters the
  Running state. It begins executing when the
  operating system assigns a processor to the
  thread.

4
Thread States (Continued)

• When a thread becomes a running thread, it
  executes its ThreadStart delegate, which
  specifies the actions the thread will perform
  during its lifecycle.
• The ThreadStart delegate is an argument to the
  Thread Constructor.
• The ThreadStart delegate is a void method that
  takes no arguments.
• A Running thread enters the Stopped (or Dead)
  state when its ThreadStart delegate terminates.
• A program can force a thread into the Stopped
  state by calling the Abort method.
• Method Abort throws a ThreadAbortException which
  causes the thread to terminate.
• When a thread is in a stopped state and there are
  no references to the thread object, the garbage
  collector can remove the thread object from
  memory.
• A thread enteres the Blocked state when the
  thread issues an input/output request.
• A blocked thread cannot use a processor, even
  when one is available.

5
Thread States (Continued)

• There are three ways in which a Running thread
  enters the WaitSleepJoin state.
• If a thread encounters code that is cannot
  execute yet (normally because a condition is not
  satisfied), the thread can call Monitor method
  Wait to enter the WaitSleepJoin state. Once in
  this state, the thread returns to the Started
  state when another thread invokes Monitor method
  Pulse or PulseAll. Method Pulse moves the next
  waiting thread back to the started state.
• A running thread can call Thread method Sleep to
  enter the WaitSleepJoin state for a period of
  milliseconds specified as the argument to Sleep.
  A sleeping thread returns to the Started state
  when its designated sleep time expires. Any
  thread that enters the WaitSleepJoin state by
  calling Monitor method Wait or by calling Thread
  method Sleep also leaves the WaitSleepJoin state
  and returns to the Started state if the sleeping
  or waiting threads interrupt method is called by
  another thread in the program.
• If a dependent thread cannot continue executing
  unless another thread terminates, the dependent
  thread calls the other threads Join method to
  join the two threads. The dependent thread
  leaves the WaitSleepJoin state when the other
  thread finishes execution (i.e., enters the
  Stopped state)
• If a running threads Suspend method is called,
  the running thread enters the suspend state. A
  suspended thread returns to the started state
  when another thread in the program invokes the
  threads Resume method

6
Life Cycle of a Thread
Unstarted
Start
Pulse PulseAll Interrupt Sleep interval expires
Started
Quantum expiration
Dispatch Assign a Processor
I/O Completion
Running
Issue I/O request
Wait Sleep, Join
complete
Suspend
Blocked
WaitSleepJoin
Suspended
Stopped
Resume
7
Thread Priorities Thread Scheduling

• Every thread has a priority in the range between
  ThreadPriority.Lowest to ThreadPriority.Highest.
  The values come from the ThreadPriority
  enumeration found in namespace System.Threading.
  The enumeration consists of Lowest, BelowNormal,
  Normal, AboveNormal, and Highest. By default,
  each thread has a priority of Normal.
• Timeslicing is when the operating system enables
  thread of equal priority to share a processor.
• With timeslicing, each thread recieves a brief
  burst of processor time, called a quantum.
• At the completion of the quantum, the processor
  is taken away from the thread and given to the
  next thread of equal priority, if one is
  available.
• The job of the operating system thread scheduler
  is to keep the highest-priority thread running at
  all times and, if there are more than one
  highest-priority thread, to ensure that all such
  threads execute for a quantum in round-robin
  fashion.

8
Thread Priority in Scheduling

• Multilevel Priority Queue
• A single processor computer
• A B execute for a quantum in round-robin
  fashion until both complete execution
• Next, thread C runs to completion
• Threads D,E,F run in round-robin fashion until
  all are completed.
• New high priority threads could indefinitely
  postpone execution of lower priority threads,
  This is called starvation.
• Question What are the ways in which a thread
  ceases execution?

Highest
A
B
C
Above Normal
Normal
Below Normal
E
D
F
Thread Tester
Lowest
G
9
Thread Synchronization Class Monitor

• In many instances, multiple threads of execution
  manipulate shared data. The threads accessing
  data maybe modifying the data and this may cause
  incorrect values.
• Suppose the data is an array in which threads
  could update separate parts concurrently. It is
  likely that part of the data will reflect the
  information from one thread while another part
  of the data will reflect the information from a
  different thread.
• The problem of multiple concurrent access can be
  solved by giving one thread at a time exclusive
  access to code that manipulates the shared data.
  Other threads needing to access the shared data
  are placed in a wait state. This technique is
  called mutual exclusion or thread
  synchronization.
• C uses .NET Framework monitors to perform
  synchronization.
• Class monitor provides the methods for locking
  objects to implement synchronized access to
  shared data.

10
Thread Synchronization Class Monitor

• When a thread needs to acquire exclusive control
  over an object, the thread invokes the Monitor
  method Enter to acquire a lock on the object.
• Each object has a SyncBlock that maintains the
  state of the objects lock.
• Methods of the class Monitor use the data in
  SyncBlock to determine the state of the objects
  lock.
• After acquiring a lock, a thread can manipulate
  an objects data.
• When the thread that locked the shared object no
  longer requires the lock, the thread invokes the
  Monitor method Exit in order to release the
  object.
• C provides another means of manipulating an
  objects lock using the keyword lock.
• lock( objectReference )
• // code that requires synchronization goes
  here
• If a thread determines that it cannot perform its
  task on a locked object, the thread can call
  Monitor method Wait and pass as an argument the
  object on which the thread will wait until the
  thread can perform its task.
• This discussion is best presented with examples
  (Circular Buffer).

11
Producer/Consumer Relationship without Thread
Synchronization
Write more data
Yes
Yes
Producer Finished Writing?
Empty Buffer?
Pulse
Wait
No
No
Producer
Consumer
Shared Data
Write
Read
No
Finished Reading?
Read More
Consumer Finished Reading?
Yes
Wait
Pulse
No
Yes
This program shows the Hazards of not using
Synchronized Threads
Wake up the Writer
This program demonstrates Thread
synchronization Between producer consumer
12
(No Transcript)
13
Circular Buffer Code Example
14
Click on a button to view the source
Circular Buffer
Priority
Timeslice
Sleep
Deadlock
Starvation
Synchronized
Unsynchronized
15
Assignment

•
• Write a simple multi-threading program that adds
  and removes elements in an ArrayList.
• Use a Producer button to create a producer thread
  that adds elements to the the ArrayList.
• The maximum number of elements that can be added
  to the ArrayList is 100 and the producer thread
  has to wait until the consumer thread(s)
  remove(s) elements from the ArrayList. The
  consumer thread is started by pressing a consume
  button. As the consumer consumes, the producer
  thread adds more elements to the ArrayList.
