Title: Patterns in Property Specifications for Finitestate Verification


1
Patterns in Property Specifications for
Finite-state Verification
  • Matthew B. Dwyer, George S. Avrunin, and James C.
    Corbett
  • ICSE, May,1999
  • 2002.10.22
  • Presented by Soon-deok, Kim

2
Contents
  • Introduction
  • Specification pattern system
  • Property Specification Patterns
  • Pattern scopes
  • Specification Patterns System
  • The Patterns
  • Organization
  • Pattern Mapping
  • Survey of property specifications
  • Conclusions
  • Further Work

3
Introduction(1/3)
  • Formal specification and verification offer
    practitioners some significant advantages
  • Transition of this technology from research to
    practice has been slow
  • Practitioners are unfamiliar with specification
    processes, notations, and strategies

4
Introduction(2/3)
  • exgt Between the time an elevator is called at a
    floor and the time it opens its doors at that
    floor, the elevator can arrive at that floor at
    most twice

(Transitions to at a floor-state occur at most 2
times) Between call and open
AG( call -gt !E!open U (!atfloor !open
EX(atfloor E!open U (!atfloor
!open EX(atfloor E!open
U (!atfloor !open EX(atfloor !open
EF(open))))))))
5
Introduction(3/3)
  • Specification pattern system is
  • a collection of parameterizable, high-level,
    formalism-independent specification abstractions
  • This paper adopted a pattern-based approach to
    presenting their specification abstractions
  • Focus on the matching of problem characteristics
    to solution strategies
  • Would also be successful in the domain of
    property specification for finite-state
    verification

6
Property Specification Patterns(1/2)
  • Generalized description of a commonly occurring
    requirement on the permissible state/event
    sequences in a finite-state model of a system
  • Describes the essential structure of some aspect
    of a systems behavior
  • Provides expressions of systems behavior in a
    range of common formalisms

7
Property Specification Patterns(2/2)
  • 5 basic patterns
  • Universal
  • To be true throughout the execution
  • Absence
  • Never true in the execution
  • Existence
  • Is true at some point in the execution
  • Precedence
  • Designated state/event always occurs before first
    occurrence of another designated state/event
  • Response
  • Designated state/event is followed by another
    designated state/event

8
Pattern Scopes(1/2)
  • 5 basic scopes
  • Global
  • the entire program execution
  • Before
  • the execution up to a given state/event
  • After
  • the execution after a given state/event
  • Between
  • any part of the execution from one given
    state/event to another given state/event
  • After-until
  • like between but the designated part of the
    execution continues even if the second
    state/event does not occur

9
Pattern Scopes(2/2)
10
Specification Pattern System(1/8)
  • A set of patterns
  • Organized into one or more hierarchies with
    connections between related patterns
  • Grow over time as developers encounter property
    specifications of real systems that do not easily
    map onto the existing patterns
  • Hypothesis
  • only a small fraction of the possible properties
    that can be specified commonly occur in practice

11
Specification pattern system(2/8)The
Patterns(1/2)
  • Absence A given state/event does not occur
    within a scope
  • Existence A given state/event must occur within
    a scope
  • Bounded Existence A given state/event must
    occur k times within a scope.
  • Universality A state/event occurs throughout a
    scope
  • Precedence A state/event P must always be
    preceded by a state/event Q within a scope. Fig1
    gives the key elements of the pattern.

12
Specification pattern system(3/8)The
Patterns(2/2)
  • Response A state/event P must always be
    followed by a state/event Q within a scope
  • Chain Precedence -A sequence of states/events
    P1,.. , Pn must always be preceded by a sequence
    of states/events Q1,Qm.
  • Chain Response A sequence of states/events
    P1,Pn must always be followed by a sequence of
    states/events Q1,Qm.

13
Specification pattern system(4/8)Organization
  • Organize the patterns in a hierarchy based on
    their semantics

14
Specification pattern system(5/8) Patterns
Mapping(1/4)
  • They provide mappings to
  • Linear Temporal Logic (LTL)
  • Computation Tree Logic (CTL)
  • Quantified Regular Expressions (QREs)
  • The Inca query language
  • Graphical Interval Logic (GIL)
  • Action Computation Tree Logic (ACTL)
  • Regular Alternation-Free Mu-Calculus
  • Tool accepting property specifications
  • SPIN (accepts LTL)
  • JavaPathFinder (accepts LTL)
  • SMV (accepts CTL)
  • FLAVERS (accepts QREs)
  • CADP/EVALUATOR (accepts ACTL and Mu-Calculus)

15
Specification pattern system(6/8)Patterns
Mapping(2/4)
  • Absence
  • P is false

16
Specification pattern system(7/8)Patterns
Mappings(3/4)
  • Response
  • S response to P

(S response to P) between Q and R AG(Q !R -gt
A((P -gt A!R U (S !R)) AG(!R)) W R)
17
Specification pattern system(8/8)Patterns
Mappings(4/4)
  • Bounded Existence
  • Transitions to P-states occur at most 2 times

18
Survey of property Specifications(1/4)
  • This paper assumed that the specifications people
    write fall into a small number of categories
  • Empirical evidence for assumption
  • Most fall into a small number of familiar
    categories
  • Data Collection
  • 555 specifications from at least 35 different
    source
  • Wide variety of application domains

19
Survey of property Specifications(2/4)
  • Total for Patterns/Scopes

20
Survey of property Specifications(3/4)
  • Total Number of Instances for Patterns/Scopes

21
Survey of property Specifications(4/4)
  • Percentage of Specifications for Each
    Pattern/Scope

22
Conclusions
  • Their proposed specification system provides a
    set of commonly occurring high-level
    specification abstractions for formalisms
  • Definition and use of high-level abstractions in
    writing formal specifications
  • important factor in making automated formal
    methods
  • Finite-state verification tools, more usable
  • They have updated their pattern system to
    accommodate new patterns and variations of
    existing patterns in this survey

23
Further Work
  • Defining a language for property specification
    based on the patterns
  • Providing automated support for compiling
    properties expressed in that language to specific
    formalisms
  • Checking the legality of pattern substitutions
  • Approaches for checking the consistency of
    pattern mappings expressed in multiple formalisms
