Multiset Rewriting and Security Protocol Analysis

1
Multiset Rewriting and Security Protocol Analysis

• John Mitchell
• Stanford University
• I. Cervesato, N. Durgin, P. Lincoln, A. Scedrov

2
Outline

• Protocol security
• Analysis methods
• Multiset rewriting with ?
• Rewrite formalism with choose new value
• Protocol modeling within this framework
• Decision problems
• Applications of the MSR framework

3
Protocol Security

• Cryptographic Protocol
• Program distributed over network
• Use cryptography to achieve goal
• Attacker
• Read, intercept, replace messages, and remember
  their contents
• Correctness
• Attacker cannot learn protected secret or cause
  incorrect protocol completion

4
Needham-Schroeder Protocol

• A, Noncea
• Noncea, Nonceb
• Nonceb

Kb
A
B
Ka
Kb
Result A and B share two private numbers not
known to any observer without Ka-1, Kb -1
5
Run of protocol
B
A
Correct if no security violation in any run
6
Anomaly in N-S Protocol
Lowe
A, Na
Ke
A
E
Na, Nb
Ka
Nb
Ke
A, Na
Na, Nb
Evil agent E tricks honest A into
revealing private key Nb from B.
Kb
Ka
B
Evil E can then fool B.
7
Contract Signing (Fair Exchange)
Immunity deal

• Both parties want to sign a contract
• Neither wants to commit first

8
General protocol outline
A
B

• Trusted third party can force contract
• Third party can declare contract binding if
  presented with first two messages.

9
Asokan-Shoup-Waidner protocol
Agree
Abort
B
A
m1 sign(A, ?c, hash(r_A)? )
A
B
sign(B, ?m1, hash(r_B)? )
a1
Network
???
r_A
T
r_B
If not already resolved
sigT (a1,abort)
Resolve
Attack?
m1
A
B
m2
A
Net
???
T
T
sigT (m1, m2)
10
Secure Sockets Layer
http
ftp
Application
telnet
nntp
SSL
Common use https http over SSL
11
Handshake Protocol
Signature signCA Encryption K
Hash Hash( )
ClientHello C ? S C, VerC, SuiteC, NC
ServerHello S ? C VerS, SuiteS, NS,
signCA S, KS ClientVerify C ? S
signCA C, VC
VerC, SecretC
signC Hash( Master(NC, NS,
SecretC) Pad2
Hash(Msgs C Master(NC, NS,
SecretC) Pad1)) (Change to negotiated
cipher) ServerFinished S ? C Hash(
Master(NC, NS, SecretC) Pad2
Hash( Msgs S
Master(NC, NS, SecretC) Pad1))
ClientFinished C ?
S Hash( Master(NC, NS, SecretC) Pad2
Hash(
Msgs C Master(NC, NS, SecretC) Pad1))

KS
Master(NC, NS, SecretC)
Master(NC, NS, SecretC)
12

• II. Analysis Methods

13
Protocol Analysis Methods

• Non-formal approaches (useful, but no tools)
• Some crypto-based proofs Bellare, Rogaway
• Communicating Turing Machines Canetti
• BAN and related logics
• Axiomatic semantics of protocol steps
• Methods based on operational semantics
• Intruder model derived from Dolev-Yao
• Protocol gives rise to set of traces
• Denotation of protocol set of runs involving
  arbitrary number of principals plus intruder

14
Example projects and tools

• Prove protocol correct
• Paulsons Inductive method, others in HOL, PVS,
• MITRE - Strand spaces
• Process calculus Abadi-Gordon, Gordon-Jeffrey
• Search using symbolic representation of states
• Meadows NRL Analyzer, Millen CAPSL
• Exhaustive finite-state analysis
• FDR, based on CSP Lowe, Roscoe, Schneider,

• Murphi, CASPER, CAPSL,

All depend on behavior of protocol in presence of
attack
15

• Multiset Rewriting Method
• A form of rewriting with
• One associative, commutative operator
• (Banatre, LeMetayer Chem Abs Machine)
• ? to generate fresh data
• Conventions for modeling protocols, adversary
  using rewriting

16
A notation for inf-state systems

• Many previous models are buried in tools
• Define common model in tool-independent formalism

17
Modeling Requirements

• Express properties of protocols
• Initialization
• Principals and their private/shared data
• Nonces
• Generate fresh random data
• Model attacker
• Characterize possible messages by attacker
• Cryptography
• Set of runs of protocol under attack

18
Notation commonly found in literature
A ? B A, Noncea Kb B ? A Noncea, Nonceb
Ka A ? B Nonceb Kb

• The notation describes protocol traces
• Does not
• specify initial conditions
• define response to arbitrary messages
• characterize possible behaviors of attacker

19
Rewriting Notation

• Non-deterministic infinite-state systems
• Facts
• F P(t1, , tn)
• t x c f(t1, , tn)
• States F1, ..., Fn
• Multiset of facts
• Includes network messages, private state
• Intruder will see messages, not private state

Multi-sorted first-order atomic formulas
20
Rewrite rules

• Transition
• F1, , Fk ?? ?x1 ?xm. G1, , Gn
• What this means
• If F1, , Fk in state ?, then a next state ? has
• Facts F1, , Fk removed
• G1, , Gn added, with x1 xm replaced by new
  symbols
• Other facts in state ? carry over to ?
• Free variables in rule universally quantified
• Note
• Pattern matching in F1, , Fk can invert
  functions
• Linear Logic F1??Fk ?? ?x1 ?xm(G1??Gn)

21
Finite-State Example
a
q1
a
a
b
q0
q3
b
b
a
b

• Predicates State, Input
• Function ?
• Constants q0, q1, q2, q3, a, b, nil
• Transitions State(q0), Input(a ? x) ?
  State(q1), Input(x)
• State(q0), Input(b ? x) ?
  State(q2), Input(x)
• ...
• Set of rewrite transition sequences set of runs
  of automaton

q2
b
22
Simplified Needham-Schroeder

• Predicates
• Ai, Bi, Ni
• -- Alice, Bob, Network in state i
• Transitions
• ?x. A1(x)
• A1(x) ?? N1(x), A2(x)
• N1(x) ?? ?y. B1(x,y)
• B1(x,y) ?? N2(x,y), B2(x,y)
• A2(x), N2(x,y) ?? A3(x,y)
• A3(x,y) ?? N3(y), A4(x,y)
• B2(x,y), N3(y) ?? B3(x,y)
• picture next slide

• A ? B na, AKb
• B ? A na, nbKa
• A ? B nbKb
• Authentication
• A4(x,y) ? B3(x,y) ? yy

23
Sample Trace

• ?x. A1(x)
• A1(x) ? A2(x), N1(x)
• N1(x) ? ?y. B1(x,y)
• B1(x,y) ? N2(x,y), B2(x,y)
• A2(x), N2(x,y) ? A3(x,y)
• A3(x,y) ? N3(y), A4(x,y)
• B2(x,y), N3(y) ? B3(x,y)

A1(na)
N1(na)
A2(na)
B1(na, nb)
A2(na)
N2(na, nb)
B2(na, nb)
A2(na)
B2(na, nb)
A3(na, nb)
N3( nb)
B2(na, nb)
A4(na, nb)
B3(na, nb)
A4(na, nb)
24
Adversary and Cryptography

• How powerful is the adversary?
• Simple replay of previous messages
• Block messages Decompose, reassemble, resend
• Statistical analysis, traffic analysis
• Timing attacks
• How much detail in underlying data types?
• Plaintext, ciphertext and keys
• atomic data or bit sequences
• Encryption and hash functions
• perfect cryptography
• algebraic properties encr(xy) encr(x)
  encr(y) for
• RSA
  encrypt(k,msg) msgk mod N

25
Common Intruder Model

• Derived from Dolev-Yao model
• Adversary is nondeterministic process
• Adversary can
• Block network traffic
• Read any message, decompose into parts
• Decrypt if key is known to adversary
• Insert new message from data it has observed
• Adversary cannot
• Gain partial knowledge
• Guess part of a key
• Perform statistical tests,

26
Formalize Intruder Model

• Intercept, decompose and remember messages
• N1(x) ?? M(x) N2(x,y) ??
  M(x), M(y)
• N3(x) ?? M(x)
• Decrypt if key is known
• M(enc(k,x)), M(k) ?? M(x)
• Compose and send messages from known data
• M(x) ?? N1(x), M(x)
• M(x), M(y) ?? N2(x,y), M(x), M(y)
• M(x) ?? N3(x), M(x)
• Generate new data as needed
• ?x. M(x)
• Highly nondeterministic, same for any protocol

27
Attack on Simplified Protocol

• ?x. A1(x)
• A1(x) ? A2(x), N1(x)
• N1(x) ? M(x)
• ?x. M(x)
• M(x) ? N1(x), M(x)
• N1(x) ? ?y. B1(x,y)

A1(na)
N1(na)
A2(na)
A2(na)
M(na)
A2(na)
M(na), M(na)
N1(na)
A2(na)
M(na), M(na)
B1(na, nb)
A2(na)
M(na), M(na)
Continue man-in-the-middle to violate
specification
28
Protocols vs Rewrite rules

• Can axiomatize any computational system
• But -- protocols are not arbitrary programs

Choose principals
Select roles
Client
Client
TGS
Server
29
Protocol theory

• Initialization theory
• Bounded theory that precedes protocol run
• Example ? key. Principal(key)
• Role generation theory
• Principal(key) ?? A0(key), Principal(key)
• Principal(key) ?? B0(key), Principal(key)
• Role theory
• Finite ordered list of rules
• Ai(), Nj() ?? ? Ak(), Nl(x)
  where iltk, jltl
• Can also have persistent predicates on left/right

30
Two-phase intruder theory

• Avoid pointless looping by intruder
• M(x), M(y) ?? N(x,y), M(x), M(y)
• N (x,y) ?? M(x), M(y)
• Phase 1 Decomposition
• Phase 2 Composition

31
Thesis MSR Model is accurate

• Captures Dolev-Yao-Needham-Millen-Meadows-
  model
• MSR defines set of traces protocol and attacker
• Connections with approach in other formalisms
• Useful for protocol analysis
• Errors shown by model are errors in protocol
• If no error appears, then no attack can be
  carried out using only the actions allowed by the
  model

32

• IV. Decision Problems

33
Complexity results using MSR
NP complete
Undecidable
??
DExp time
All Finite number of different roles, each role
of finite length, bounded message size

• Key insight existential quantification (?)
  captures cryptographic nonce main source of
  complexity

Durgin, Lincoln, Mitchell, Scedrov
34
Corresponding rewrite systems
Durgin, Lincoln, Mitchell, Scedrov
NP complete
Undecidable
??
DExp time

• Standard set of rules, standard rewrite sequence
• Partition into disjoint subsets
• Each subset progresses finitely
• Fixed set of rules move terms from one subset to
  another
• Bounded number of function symbols in any term

35
Lower bounds from Horn clauses
NP-complete Provable by bounded-length proof
Undecidable Datalog ?
??
Dexptime Datalog
All Finite number of different roles, each role
of finite length, bounded message size

• Need to show that hard instances of Horn clause
  inference can be be represented in the restricted
  form of a security protocol

Durgin, Lincoln, Mitchell, Scedrov
36
Additional decidable cases

• Bounded role instances, unbounded msg size
• Huima 99 decidable
• Amadio, Lugiez NP w/ atomic keys
• Rusinowitch, Turuani NP-complete, composite keys
• Other studies, e.g., Kusters unbounded data
  fields
• Constraint systems
• Cortier, Comon Limited equality test
• Millen, Shmatikov Finite-length runs
• All bound number of role instances

37

• IV. Refinement and applications of multiset
  rewriting framework

38
Using MSR for protocol analysis

• Extensions and general properties
• Add dependent types and subsorting C
• DY intruder is most powerful attacker C
• Relate to other models
• Strand space model CDLMS
• Linear logic provability CDKS
• Prove protocols correct
• Contract signing Chadha, Kanovich, Scedrov
• Kerberos 5 Butler, Cervesato, Jaggard, Scedrov

39
A glimpse of contract signing
Chadha, Kanovich, Scedrov

• Each party enters contract with goal
• Party who wants contract acts to complete the
  contract
• Correctness is relative to goal
• Do not want well-intentioned party to suffer
• Leads to game-theoretic notions
• If A follows strategy S, then B cannot achieve
  win over A
• Or, A follows strategy from some class

40
Strategy example
S

• Define execution tree using MSR
• Prune tree according to assumed strategy
• Determine correctness

41
Honest participant

• Principle A is said to be honest if
• A moves only according to protocol
• Equivalent As key not known to adversary

42
Interested participant

• Honest A is said to be interested if
• Whenever A can choose between
• waiting for a message from B
• asking TTP for an abort
• A waits and allows B to move next

Chadha, Mitchell, Scedrov, Shmatikov
43
Optimistic participant

• Honest A is said to be optimistic if
• Whenever A can choose between
• waiting for a message from B
• contacting TTP for any purpose
• A waits and allows B to move next

44
Hierarchy

• Advantage against honest A
  H-adv
• ?
• Advantage against interested A
  I-adv
• ?
• Advantage against optimistic A
  O-adv
• MSR model lets us define execution tree
• Define strategies, correctness over execution
  model
• (End glimpse of contract signing)

45
Protocol analysis spectrum
Hand proofs
?
High
Poly-time calculus
Multiset rewriting with ?
Spi-calculus
?
Sophistication of attacks
Strands
Paulson
?
?
?
?
NRL
?
Bolignano
BAN logic
?
?
Low
Model checking
Protocol logic
?
?
Murj
FDR
Low
High
Protocol complexity
46
Whats missing? (Future directions)

• Specification language
• MSR defines traces, execution tree
• Need to specify correctness formally
• Programming language?
• Separate commands done from those that remain
• Distinguish local knowledge from global state
• Quantification over protocols
• Every protocol satisfying ? also satisfies ?.
• Composition Properties of Compose(P, Q) from
  properties of P and Q

47
Conclusions

• Thesis
• Protocol analysis requires precise definition of
  possible runs under attack
• Multiset rewriting with ?
• Provides natural, usable formalism
• Captures set of runs
• Exhibits uniformity of DY attacker
• Related to linear logic, other protocol notations
• Can use proof-theoretic results from LL
• Can approximate MSR model by finite-state analysis

48
Conclusions

• Results
• Decision problems
• NP-complete with bounded role instances
• Dexp-time complete with bounded nonces (?)
• Undecidable even if everything else bounded
• Applications
• Metatheory
• Two attackers no better than one
• Correctness of model checking optimizations
• Protocol analysis
• Contract signing, Kerberos v5

49
(No Transcript)
