DB Seminar Series: The Semisupervised Clustering Problem

1
DB Seminar Series The Semi-supervised Clustering
Problem

• By Kevin Yip
• 2 Jan 2004
• (Happy New Year!)

2
First of all, an example

• Where are the 2 clusters?

3
First of all, an example

• Where are the 2 clusters?

What if I tell you that these two are in the same
cluster
and these two are in the same cluster?
4
First of all, an example

• Where are the 2 clusters?

5
Observations

• The clustering accuracy was greatly improved
  (from 50 accuracy to 100).
• All objects were unlabeled gt classification not
  possible.
• Only a small amount of knowledge was added (the
  relationships between 2 pairs of objects, out of
  the total 105 pairs).
• gt Semi-supervised clustering

6
Observations

• Is it more natural to form 4 clusters instead?
• True, but then how many clusters are there?

• It is most natural to set k to the number of
  known classes.

7
Outline

• The problem (no formal definitions)
• Why not clustering? Classification?
• Potential applications of semi-supervised
  clustering
• Supervision what to input?
• When to input?
• How to alter the clustering process?
• Some examples
• Future Work

8
The problem

• Input
• A set of unlabeled objects, each described by a
  set of attributes (numeric and/or categorical)
• A small amount of domain knowledge
• Output
• A partitioning of the objects into k clusters
  (possibly with some discarded as outliers)
• Objective
• Maximum intra-cluster similarity
• Minimum inter-cluster similarity
• High consistency between the partitioning and the
  domain knowledge

9
Why not clustering?

• The clusters produced may not be the ones
  required.
• Algorithms that fit the cluster model may not be
  available.
• Sometimes there are multiple possible groupings.
• There is no way to utilize the domain knowledge
  that is accessible (active learning v.s. passive
  validation).

(Guha et al., 1998)
10
Why not classification?

• Sometimes there are insufficient labeled data
• Objects are not labeled.
• The amount of labeled objects is statistically
  insignificant.
• The labeled objects do not cover all classes.
• The labeled objects of a class do not cover all
  cases (e.g. they are all found at one side of a
  class).
• The underlying class model may not fit the data
  (e.g. pattern-based similarity).

11
Potential applications

• Bioinformatics (gene and protein clustering)
• Document hierarchy construction
• News/email categorization
• Image categorization
• Road lane detection
• XML document clustering?
• gt Cluster properties not well known, but some
  domain knowledge is available

12
What to input?

• A small amount of labeled data
• Instance-level constraints
• Must-link two objects must be put to the same
  cluster.
• Cannot-link two objects must not be put to the
  same cluster.
• Objects that are similar/dissimilar to each
  other.
• First-order logic language
• Good cluster, bad cluster
• General comments (e.g. clustering too fine)
• Others

13
When to input?

• At the beginning of clustering
• During cluster validation, to guide the next
  round of clustering
• When the algorithm requests
• The user may give a dont know response.

14
How to alter the clustering process?

• Guide the formation of seed clusters.
• Force/recommend some objects to be put in the
  same cluster/different clusters.
• Modify the objective function.
• Modify the similarity function.
• Modify the distance matrix.

15
Examples
16
Wagstaff et al. 2001

• Input knowledge must-link and cannot-link
  constraints
• Algorithm constrained K-means (COP-KMeans)
• Generate cluster seeds.
• Assign each object to the closest seed in turn,
  such that no constraints are violated (otherwise,
  report error and halt).
• Make the centroid of each cluster as the new
  seed.
• Repeat 2 and 3 until convergence.

17
Wagstaff et al. 2001

• Some results
• Soybean (47 x 35, 4 classes)

• At most 47 x 46 / 2 1081 constraints
• 100 coverage can be achieved by 43 must-links.

18
Wagstaff et al. 2001

• Some results
• Mushroom (50 x 21, 2 classes)

19
Wagstaff et al. 2001

• Some results
• Tic-tac-toe (100 x 9, 2 classes)

20
Basu et al. 2002

• Input knowledge a small set of labeled objects
  for each class
• Algorithm Seeded-KMeans
• Use the centroid of each set of objects as an
  initial seed.
• Assign each object to the closest seed.
• Make the centroid of each cluster as the new
  seed.
• Repeat 2 and 3 until convergence.

21
Basu et al. 2002

• Algorithm Constrained-KMeans
• Use the centroid of each set of objects as an
  initial seed.
• Assign each object to the closest seed in turn,
  such that all labeled objects of each class are
  put to the same cluster.
• Make the centroid of each cluster as the new
  seed.
• Repeat 2 and 3 until convergence.

22
Basu et al. 2002

• Some results
• Same-3 Newsgroups (300 x 21631, 3 classes)

23
Basu et al. 2002

• Some results
• Different-3 Newsgroups (300 x 21631, 3 classes)

24
Klein et al. 2002

• In the previous 2 approaches, unconstrained
  objects are not much affected if the amount of
  input is small.
• Is it possible to propagate the influence to the
  neighboring objects?

25
Klein et al. 2002

• An illustration

26
Klein et al. 2002

• Idea modify the distance matrix such that
  must-link objects have zero distances and
  cannot-link objects have large distances.
• Two problems
• The effects are still restricted to constrained
  objects.
• The resulting distance matrix may not satisfy the
  triangle inequality.
• Solutions
• Propagate the must-link influence by running an
  all-pairs shortest paths algorithm.
• Propagate the cannot-link influence implicitly
  during clustering.

27
Klein et al. 2002

• Must-link propagation

C
B
D
A
28
Klein et al. 2002

• Must-link propagation

C
B
D
A
29
Klein et al. 2002

• Must-link propagation

C
B
D
A
30
Klein et al. 2002

• Cannot-link propagation
• Similarly, if there is a cannot-link constraint
  on a pair of objects, the distance between the
  objects is set to a certain large value.
• But it is harder to fix the triangle inequality.
• If A and B must link, they will be given the same
  coordinates.
• But if A and B cannot link, what coordinates
  should be given to them?
• In general, it is desirable to have the new
  distance matrix as similar as the original one,
  but this poses a difficult optimization problem.

31
Klein et al. 2002

• Cannot-link propagation
• Solution not to propagate, but choose an
  algorithm that can implicitly produce the same
  effect during the clustering process.
• E.g. complete-link hierarchical algorithm
• Distance between two clusters longest distance
  between two objects each taken from one of the
  clusters
• If A is cannot-linked with B, when A merges with
  C, C will also be cannot-lined with B.

32
Klein et al. 2002

• Active learning
• Up to now, we assume all constraints are inputted
  at the beginning.
• Is it possible for the algorithm to request for
  useful constraints?
• Advantages
• Need fewer constraints
• Constraints being input must be the most useful
  ones
• Disadvantages
• Need to answer queries on the fly
• Not all queries can be answered

33
Klein et al. 2002

• Active learning
• Allow the algorithm to ask at most m questions
• Observations
• In hierarchical clustering, errors usually occur
  at later stages.
• In complete-link clustering, the merged-cluster
  distance must be monotonically non-decreasing.
• Idea estimate the distance ? such that all
  merges that involve clusters with distance ? ?
  are guided by the m questions.

34
Klein et al. 2002

• Experiments
• Algorithms
• CCL (distance matrix learning)
• CCL-Active (CCL active learning)
• COP-KMeans (forced relationships)

35
Klein et al. 2002

• Results on synthetic data (held-out acc.)

36
Klein et al. 2002

• Results on synthetic data (held-out acc.)

37
Klein et al. 2002

• Results on real data (held-out acc.)
• Iris (150 x 4, 3 classes)
• Crabs (200 x 5, 2 classes)
• Soybean (562 x 35, 15 classes)

38
Klein et al. 2002

• Effect of constraints

39
Xing et al. 2003

• Is it possible to propagate the effects of
  constraints by transforming the distance function
  instead of the distance matrix?
• Mahalanobis distance
• When AI (identity matrix), d(x,y) is the
  Euclidean distance between x and y.
• When A is a diagonal matrix, d(x,y) is the
  weighted Euclidean distance between x and y.

40
Xing et al. 2003

• Input knowledge a set S of object pairs that are
  similar.
• Objective find matrix A that minimizessubject
  to the constraints that
• (to avoid the trivial solution of A0)
• A is positive semi-definite (to ensure triangle
  inequality and d(x,y) ? 0 for all x, y)
• (Is it also needed to minimize the deviation of
  the resulting distance matrix from the original
  one?)

41
Xing et al. 2003

• Case 1 A is a diagonal matrix
• It can be shown that the problem is equivalent to
  minimizing the following functionwhich can be
  solved by the Newton-Raphson method.

42
Xing et al. 2003

• Case 2 A is not a diagonal matrix
• Newtons method becomes very expensive (O(n6))
• Use a gradient descent method to optimize the
  functions of an equivalent problem.
• In both cases, metric learning is performed
  before the clustering process.

43
Xing et al. 2003

• Visualization of the power of metric learning
  (with 100 input)

44
Xing et al. 2003

• Experiments
• Algorithms
• KMeans
• KMeans learn diagonal A
• KMeans learn full A
• COP-KMeans
• COP-KMeans learn diagonal A
• COP-KMeans learn full A
• Input size
• Little domain knowledge number of resulting
  connected components (Kc) 90 dataset size
• Much domain knowledge Kc 70 data size

45
Xing et al. 2003

• Some results on real data

46
Basu et al. 2003

• Main contributions
• Combine both metric learning and constraints
  enforcing.
• Soft constraints constraint violations cause
  penalties instead of algorithm halt.
• Introduce a new active learning method.

47
Basu et al. 2003

• The generalized K-Means model
• Maximizing the complete data log-likelihood is
  equivalent to minimizing the following objective
  function
• Can be optimized (locally) by an EM algorithm.

48
Basu et al. 2003

• Adding constraint violation penalties
• M/C a set of must-link/cannot-link constraints
• ?, ? weights of constraints based on external
  knowledge
• 1true1, 1false0
• FM, FC weights of constraints based on the
  distance between the objects (should FM(x, y) be
  larger or smaller when d(x, y) is larger?)

49
Basu et al. 2003

• A simplified objective function
• Algorithm (PCKMeans)
• From M and C, identify the pre-specified
  connected components.
• Use the centroids of the largest connected
  components as the initial seeds. If there are not
  enough seeds, use objects that are cannot-linked
  to all connected components. If still not enough,
  use random seeds.
• Perform KMeans with the modified objective
  function.

50
Basu et al. 2003

• A new active learning algorithm ask questions as
  early as possible
• Explore step to form k initial
  neighborhoods.Observation k-means centers are
  usually remote from each other.Procedure
• Draw a point that is farthest to all drawn
  points.
• Ask at most k questions to determine which
  neighborhood the point should be assigned to.
• Repeat until k neighborhoods are formed (or no
  more questions are allowed).

51
Basu et al. 2003

• Consolidate step to form k clusters.Observation
  each object is close to its corresponding
  seed.Procedure
• Use the centroids of the k neighborhoods as the
  initial seeds (all objects in a neighborhood is
  immediately assigned to the cluster).
• Pick a non-assigned object x.
• Starting from the closest seed, ask for the
  relationship between x and an object in the
  cluster until the response is a must-link.
• Repeat to assign all objects (if running out of
  questions, resume to normal KMeans).

52
Basu et al. 2003

• Some experiment results
• News-all20 (2000 x 16089, 20 classes) left
• News-diff3 (300 x 3251, 3 classes) right

53
Discussions and Future Work

• Special clustering problems
• How can input knowledge help dimension selection
  in projected clustering / pattern-based
  clustering?
• Is it possible to refine produced clusters when
  new knowledge becomes available?
• Other uses of input knowledge
• Can input knowledge help determine algorithm
  parameter values / stopping conditions?

54
Discussions and Future Work

• Clustering algorithm
• What kind of algorithms could potentially benefit
  most from knowledge inputs?
• Should we work on constrained objects first, or
  to mix them with other objects at the beginning?
  (Induction v.s. transduction)
• Performance concerns
• How is the speed/space performance affected by
  the introduction of external knowledge?
• How will the paradigm be affected if there is a
  limited amount of memory?

55
Discussions and Future Work

• Active learning
• What to ask? Questions that are difficult for
  algorithms but easy for users.
• When to ask? When there is a major consequence.
• Noise
• How to handle contradicting constraints/
  constraints that may not be 100 correct?
• How much should be charged for a constraint
  violation?
• What is the significance of knowledge inputs when
  the data is noisy?

56
Discussions and Future Work

• Debate questions (from ICML 2003 Workshop
  homepage)
• Unlabeled data is only useful when there are a
  large number of redundant features.
• Why doesn't The No Free Lunch Theorem apply when
  working with unlabeled data?
• Unlabeled data has to come from the same
  underlying distribution as the labeled data.
• Can unlabeled data be used in temporal domains?
• Feature engineering is more important than
  algorithm design for semi-supervised learning.
• All the interesting problems in semi-supervised
  learning have been identified.
• Active learning is an interesting "academic"
  problem.

57
Discussions and Future Work

• Debate questions (from ICML 2003 Workshop
  homepage)
• Active learning research without user interface
  design is only solving half the problem.
• Using Unlabeled data in Data Mining is no
  different than using it in Machine Learning.
• Massive data sets pose problems when using
  current semi-supervised algorithms.
• Off-the-shelf data mining software incorporating
  labeled and unlabeled data is a fantasy.
• Unlabeled data is only useful when the classes
  are well separated.

58
References

• Ayhan Demiriz, K. P. Bennett and M. J. Embrechts,
  Semi-supervised Clustering using Genetic
  Algorithms, ANNIE 1999.
• Luis Talavera and Javier Bejar, Integrating
  Declarative Knowledge in Hierarchical Clustering
  Tasks, ISIDA 1999.
• David Cohn, Rich Caruana and Andrew McCallum,
  Semi-supervised Clustering with User Feedback,
  Unpublished Work 2000.
• Kiri Wagstaff and Claire Cardie, Clustering with
  Instance-level Constraints, ICML 2000.
• Kiri Wagstaff, Claire Cardie, Seth Rogers and
  Stefan Schroedl, Constrained K-means Clustering
  with Background Knowledge, ICML 2001.

59
References

• Sugato Basu, Arindam Banerjee and Raymond Mooney,
  Semi-supervised Clustering by Seeding, ICML 2002.
• Dan Klein, Sepandar D. Kamvar and Christopher D.
  Manning, From Instance-level Constraints to
  Space-level Constraints Making the Most of Prior
  Knowledge in Data Clustering, ICML 2002.
• Eric P. Xing, Andrew Y. Ng, Michael I. Jordan and
  Stuart Russell, Distance Metric Learning, with
  Application to Clustering with Side-information,
  Advances in Neural Information Processing Systems
  15, 2003.

60
References

• Sugato Basu, Mikhail Bilenko and Raymond J.
  Mooney, Comparing and Unifying Search-Based and
  Similarity-Based Approaches to Semi-Supervised
  Clustering, ICML-2003 Workshop on the Continuum
  from Labeled to Unlabeled Data in Machine
  Learning and Data Mining.
• Sugato Basu, Arindam Banerjee and Raymond J.
  Mooney, Active Semi-Supervision for Pairwise
  Constrained Clustering, not yet published, 2003.
