Title: Conformal Brain Mapping using Variational Methods and PDEs


1
Conformal Brain Mapping using Variational Methods
and PDEs
Tony F. Chan Math Department, UCLA IPAM Brain
Mapping Summer School July 13, 2004
Collaborated with Y. Wang, X. Gu , P. Thompson
and S.T. Yau
2
Overview
  • Motivation
  • Brain Surface Conformal Mapping
  • Volumetric Brain Harmonic Map
  • Optimize the Conformal Parameterization by
    Landmarks
  • Future Work

3
Brain Mapping Tasks
Surface conformal mapping
Volumetric harmonic map
Sphere carving algorithm
4
Growth patterns in the developing human brain
  • Thompson et.al Growth patterns in the developing
    brain detected by using continuum mechanical
    tensor maps, Nature, 2000.

5
Overview
  • Motivation
  • Brain Surface Conformal Mapping
  • Volumetric Brain Harmonic Map
  • Optimize the Conformal Parameterization by
    Landmarks
  • Future Work

6
Benefits for Conformal Mapping
  • Any surface without holes or self-intersections
    can be mapped conformally onto the sphere
  • This mapping, conformal equivalence, is
    one-to-one, onto, and angle preserving
  • Locally, distances and areas are only changed by
    a scaling factor (conformal factor)
  • A canonical space is useful for subsequent work

7
Algorithm Requirement
  • Intrinsic, independent of triangulation, tolerant
    to resolution
  • Easy to combined with various constraints
  • Easy to trace the point correspondence during
    evolvement
  • Tolerant to boundaries e.g. easily generalizable
    to surfaces with one boundary.

8
Approaches for Conformal and Harmonic Surface
Parameterization
9
Approaches for Conformal and Harmonic Surface
Parameterization (Cont.)
10
Approaches for Conformal and Harmonic Surface
Parameterization (Cont.)
  • Most algorithms work only on genus zero surface
    with one boundary. Tannenbaums method can work
    on genus zero closed surface and genus one
    surface. Circle packing algorithm and conformal
    structure methods can work on surfaces with
    arbitrary topologies.
  • Circle packing algorithm only considers the
    connectivity but not surface metric. Conformal
    structure method considers surface metric.

11
Previous Work on Brain Conformal Mapping
  • Laplacian operator linearization
  • Haker et al. 00s
  • Joshi Leahy. 02s
  • Circle packing
  • Hurdal et al. 00s

12
Hakers Method
  • Linearize Laplacian-Beltrami operator
  • Solve the corresponding linear system
  • Restriction the target surface must be S2, there
    are big distortions near the north pole.

Haker et al. Conformal Surface Parameterization
for Texture Mapping, IEEE TVCG, Vol. 6, No. 2,
2000
13
Joshi and Leahys Method
  • Extension of Hakers work.
  • Achieving a unique conformal mapping by fixing
    three points. It eliminates six degree freedom
    on translation and rotation.

14
Circle Packing Method
  • Another way to compute the conformal mapping via
    circle packing.
  • It can handle arbitrary topologies.

K. Stephenson, Circle Packing A Mathematical
Tale, Notices of AMS, Vol. 50 No. 11, 2003
15
New Method
  • Treat surfaces as Riemann surface
  • Compute conformal structure based on metric
    tensor
  • Dependent on metric continuously

16
Definition Conformal Mapping
  • Conformal Scaling first fundamental
    form
  • Angle preserving
  • Geometry similarities in the small

F
M1
M2
17
Conformal Mapping Properties
  • Intrinsic to geometry
  • Independent of triangulation and resolution
  • Depends on metric continuously

18
(No Transcript)
19
Geometric Morphing with Conformal Mapping
20
Genus 0 surfaces
  • All conformal mappings between two given surfaces
    are equivalent
  • Harmonic is equivalent to conformal
  • Automorphism group Mobius group

21
Mobius Transformation
  • Linear rational group on complex plane
  • 6 dimensional group

Morphing between two conformal mappings
22
Demo of the conformal mapping
Demo of the Mobius Transformation
23
Algorithm at a Glance
  • Minimize Harmonic Energy
  • Use absolute derivative (on tangent plane)
  • All computation are on the target surface,
    without projecting to complex plane

24
Algorithm Details
  • Harmonic energy
  • Discrete harmonic energy
  • Discrete Laplacian

25
Spherical parameterization algorithm for genus
zero surface
  • Use Gauss map as the initial degree one map
  • Compute the gradient vector of harmonic energy on
    each vertex
  • Project the gradient vector to the tangent space
    on S2 at each vertex
  • Update the image of each vertex along the
    tangential gradient direction
  • Normalize to the surface of the sphere
  • Normalize the mapping by shifting the center of
    the mass to the sphere center

26
Example
27
Brain Conformal Mapping
28
Example
Two brain surfaces are of the same subject.
Conformal mapping is robust to the noise.
29
Example
30
(No Transcript)
31
Spherical Harmonic Analysis
  • A function f S2?? is called a Spherical Harmonic
    if it is an eigenfunction of Laplace-Beltrami
    operator.
  • There is a countable set of spherical harmonics
    which form an orthonormal basis for L2(S2) the
    analytical expressions are known.
  • Once brain surface is conformally mapped to S2,
    the surface can be represented as 3 spherical
    functions.
  • Useful for geometric compression, matching,
    surface denoising, feature detection shape
    analysis.

original
1/8
1/64
1/256
32
More Genus 0 Surfaces
33
Application Paint on 3D Brain
  • By conformal parameterization results, we can
    directly pick points on a 3D brain surface, e.g.
    landmarks.

34
Discussion
  • Compared with Hakers and Joshi/Leahys method,
    our method is more geometric no big distortion
    areas more stable good extension ability (e.g.
    it is possible to do brain mapping between two
    brains using our algorithm.)
  • Compared with Hurdals method, our algorithm
    considers both connectivity and surface metric.

35
Overview
  • Motivation
  • Brain Surface Conformal Mapping
  • Volumetric Brain Harmonic Map
  • Optimize the Conformal Parameterization by
    Landmarks
  • Future Work

36
Volumetric Harmonic Map
  • We get a canonical intrinsic volumetric map with
    volumetric harmonic map. It is useful for 3D
    shape registration and its subsequent
    applications.
  • 3D registration
  • Automatic Segmentation
  • MRI / CT image registration

37
Motivations for Brain Mapping Research
  • Brain surface conformal mapping reseasrch has
    been successful and this motivates our more
    general investigation of 3D volumetric brain
    mapping.
  • 3D harmonic mapping of brain volumes to a solid
    sphere can provide a canonical coordinate system
    for feature identification and segmentation, as
    well as anatomical normalization.

38
Contributions of the Work
  • A sphere carving algorithm which calculates the
    simplicial decomposition of volume adapted to
    surfaces.
  • Propose a method which can find harmonic map from
    a 3 manifold to a 3D solid sphere.

39
State of Art of Brain Volumetric Model Generation
  • Marching cube
  • Interval volume Tetrahedralization
  • Not too much research on brain volumetric mesh
    construction
  • Kikinis group
  • Mohamed and Davatzikos

40
Sphere Carving Algorithm
  • Input (a sequence of volume images and a desired
    surface genus number)
  • Output (a tetrahedral mesh whose surface has the
    desired genus number)
  • Build a solid handle body tetrahedral mesh
    consisted of tetrahedra, such that the sphere
    totally enclose the 3D data. Let the boundary of
    the solid sphere be S. We cut the model without
    topology changes (using Eulers formula) until we
    get the object 3D tetrahedral model.

41
State of Art of Brain Volumetric Analysis
  • Thompson et al. (1996) ---- weighted linear
    combination of radial function.
  • Gee (1999) ---- generalized elastic matching
    method
  • Ferrant et al. (2000) ---- non-rigid registration
  • Wang et al. (2004) ---- Volumetric
    parameterization using harmonic foliation

42
Harmonic Map
  • The map minimizes the stretching energy.
  • Geodesics are harmonic maps from a circle to the
    surface.
  • Electric magnet fields on surfaces can be
    described as harmonic maps.
  • In general, harmonic maps may not exist, or
    unique.
  • For genus zero closed surface, harmonic map
    always exists and is equivalent to conformal map.

43
Harmonic Map
  • Depends on the Riemannian metrics, Independent of
    the embeddings
  • Harmonic Energy
  • The Euler-Lagrange differential equation is a
    non-linear elliptic partial differential equation

44
Harmonic Map
  • For 3-manifold, the existence of harmonic maps,
    the uniqueness of harmonic maps, the
    diffeomorphic properties of harmonic maps are
    extremely difficult theoretic problems.
  • Between convex 3-disk, harmonic map exists and is
    most likely diffeomorphism.

45
Algorithm Details
  • Harmonic energy
  • Steepest Descent Method

46
Volumetric Harmonic Map
Cube surface conformally mapped to a sphere
surface
Cube volume harmonically mapped to a solid sphere
47
Volumetric Harmonic Map (Interior View)
48
Volumetric Brain Model Construction
49
Prostate Volumetric Data Construction
50
Volumetric Brain Harmonic Map
51
Volumetric Harmonic Map on Prostate Model
52
Overview
  • Motivation
  • Brain Surface Conformal Mapping
  • Volumetric Brain Harmonic Map
  • Optimize the Conformal Parameterization by
    Landmarks
  • Future Work

53
Optimize the Conformal Parameterization by
Landmarks
  • We define a metric to measure the quality of the
    parameterization.
  • Suppose two brain surfaces S1,S2, two conformal
    parameterizations are denoted as f1 S2?S1 and
    f2 S2?S2, the matching metric is defined as

54
Optimize the Conformal Parameterization by
Landmarks (Cont.)
  • Let ? be the group of Möbius transformations. We
    can compose a Möbius transformation such that
  • Landmarks are commonly used in brain mapping.
    They are a set of sulcal curves manually drawn on
    the brain surfaces.
  • We can use landmarks to obtain such a Möbius
    transformation.

55
With Landmark
56
Optimize the Conformal Parameterization by
Landmarks (Cont.)
  • Landmarks are represented as discrete point sets.
    We can reduce the brain matching metric by
    reducing the matching metric on landmark sets.
  • First we project the sphere onto the complex
    plane. We find a Möbius transformation on the
    complex plane which reduces the matching metric
    on landmark sets. Then we project the results
    back to the sphere.

57
Optimize the Conformal Parameterization by
Landmarks (Cont.)
  • For a Möbius transformation on the complex plane
    u, since it maps infinity to infinity, it means
    the north poles of the spheres are mapped to each
    other.
  • Then u can be represented as a linear form azb.
    Let pi and qi, i1 n, are corresponding landmark
    points. The functional of u can be simplified as
  • where zi is the stereo-projection of pi, ?i
    is the stereo-projection of qi, g is the
    conformal factor from the plane to the sphere.

58
Experimental Results
The matching metric is reduced after the
landmark matching by Möbius Transformation
59
Overview
  • Motivation
  • Brain Surface Conformal Mapping
  • Volumetric Brain Harmonic Map
  • Optimize the Conformal Parameterization by
    Landmarks
  • Future Work

60
Future Work
  • Brain Conformal Mapping with Implicit Surface
    Level Set Method
  • Automatic brain feature identification
  • Brain registration
  • Brain structure segmentation
  • Brain surface denoising
  • Easy surface visualization

61
Thank You!
Write a Comment
User Comments (0)
About PowerShow.com
