Catalytic Properties of Fullerene Materials

1
Catalytic Properties of Fullerene Materials

• Ripudaman Malhotra, Al Hirschon, Don McMillen
• SRI International, Menlo Park, CA
• and
• Bill Bell, TDA Corporation,
• Wheat Ridge, CO

2
Outline

• FULLERENES
• Range of Fullerene Materials
• WHY FULLERENES?
• HYDROGEN-TRANSFER REACTIONS
• Dealkylation
• Reduction (hydrogenation)
• METHANE ACTIVATION
• Thermal Background and Fullerene-Soot Catalysis
• Comparison of Fullerene Soot with Other Carbons
• Effect of Various Pretreatments/Doping of
  Fullerene Soot
• OTHER CATALYTIC APPLICATIONS
• Selective Reductions
• Hydroformylation

3
Fullerenes

• A newly discovered form of carbon
• Structure consists of cages made of carbon atoms
• Cages formed by including pentagons in a lattice
  of hexagons

4
Range of Fullerene Materials

• Soluble Fullerenes C60, C70, C84, ...
• Insoluble Soot, metallized soot
• Fullerene Derivatives
• Functionalized
• Endohedrals
• Nanotubes, nanoparticles, encapsulates

COMMON DENOMINATOR Pentagon surrounded by
hexagons
5
(No Transcript)
6
Pentagon imparts...

• Electrophilicity and an ability to stabilize
  radicals

7
Krotos Suggestion A good model for Fullerene
Soot
8
Fullerenes catalyze coupling and transalkylation
reactions
9
Fullerenes Catalyze Cleavage of Dinanphthylmethane
10
Systems to probe H-transfer reactions
11
Dealkylation of less reactive aromatic nuclei
-1
Dimethylnaphthalene Dealkylation Rate Constant,
sec
-6
X 10
Carbon Type
Fullerene soots are more effective than either
acetylene black or activated carbons.
12
Dealkylation of more reactive polynuclear
aromatics
-1
sec
Methylpyrene Dealkylation Rate Constant,
-6
X 10
Carbon Type
Dealkylation is rapid in the presence of all
carbons tested
13
Transfer Hydrogenations
Carbon Type
Fully active NiMo sulfide is counterproductive
for this purpose
14
Dehydrogenation of Tetralin
Percent Tetralin Dehydrogenation
Carbon Type
Fullerene soots are more effective than other
carbons
15
Hydrogenation of Anthracene
Metal loaded fullerene soots are very effective
with gas phase H2
16
Dealkylation under H2 pressure
Fullerene soots are more effective under H2
pressure even without metal loading
17
Schemes for Methane Conversion
18
Fullerene soot shows higher conversion despite
lower surface area
19
Yield of higher hydrocarbons not limited by
conversion

• Only gases and char observed during soot
  catalysis no tars
• Increased C production with increasing flow-rate
  in the soot-catalyzed case indicates competing
  secondary reactions

20
SALI Evidence for Chemisorption of Methane on
Fullerene Soot
21
Doping with K or Mn increases the selectivity to
C2 and higher hydrocarbons
22
Fullerenes as Ligands

• Hydroformylation Studies (Claridge et al., J.
  Mol. Catal. 89, 113,1994)
• C60 displaces PPh3 ligands from RuH(CO)(PPh3)3
  fluxional ligand
• Turnover frequency unchanged for ethene
• TO frequency for propene hydroformylation
  significantly reduced by C60, as is the
  n/iso-ratio

23
Regioselective Reductions
-
Planeix and coworkers, 1994
24
Conclusions

• Wide range of fullerene materials
• Fullerenes, including fullerene soots, catalyze
  H-transfer reactions.
• Their ability to catalyze hydrodealkylations
  makes them potentially useful for petroleum
  upgrading
• Fullerene soot is very effective in converting
  methane into higher hydrocarbons
• Selectivity to C2 increased by doping with K or
  Mn
• Fullerene materials are promising candidates for
  catalyst supports

25
Acknowledgment

• Initial finding ACT project from NEDO
• Methane Activation US-DOE, PETC

26
Flow Apparatus for Methane Conversion

• About 1.0 g soot supported on alumina frit
• Preheater set at 600C
• Temperature in reactor varied between 600 and
  1000C
• Upward gas flow through the catalyst bed
• Product gases quencehed and analyzed by on-line GC
