Java Secured Socket Extension JSSE

1
Java Secured Socket Extension (JSSE)

• By
• Gijo Joseph

2
Topics

• JSSE Overview
• JSSE Features
• SSL/TLS Overview
• Cryptography Concepts- A refresher
• SSL Protocol
• JSSE Architecture/Implementation
• References

3
JSSE Overview

• JSSE is a Java package that enables secure
  network communications
• - Data encryption, Authentication, Message
  integrity
• Implements java version of SSL and TLS (Transport
  Layer Security) protocols
• Using JSSE, we can provide secure transfer of
  data over TCP/IP and other protocols such as
  HTTP, Telnet, NNTP, IMAP, LDAP, FTP that runs
  over TCP/IP.

4
JSSE Overview (cont.)

• JSSE encompasses many of the same concepts and
  algorithms as those in JCE (Java Cryptography
  Extension) but automatically applies them
  underneath a simple stream socket API extension.
• Latest release is JSSE 1.0.2. This is a
  non-commercial reference implementation

5
JSSE Features

• Pure Java implementation
• Exportable
• Supports for SSL v2 v3, TLS1.0
• Classes to create secure channels
• Cipher suite negotiation
• Client and Server authentication
• Server session management APIs

6
JSSE Features (cont.)

• Runs on Personal Java 3.1
• HTTPS Support
• RSA Cryptography Algorithms
• Basic utilities for key and certificate
  management
• Cryptographic suites, including
• - RSA, RC4, DES, Triple DES, Diffie- Hellman,
  DSA etc.

7
SSL/TLS Overview

• SSL (Secured Socket Layer) was created by
  Netscape Communication Corporation in 1994
• SSL provides a standard protocol operating over
  TCP/IP
• SSL provides secured services confidentiality
  through encryption, integrity via a MAC
  algorithm, optional authenticity and
  non-repudiation of both a socket client and a
  socket server.

8
SSL/TLS Overview (cont.)

• SSL also operates under other TCP based protocols
  such as HTTP, NNTP, ...
• SSL is the most widely used protocol for
  implementing cryptography on the web.
• SSL v3 is the most current SSL standard.
• TLS (Transport Security Protocol) defined by
  IETF, in 1999, extends SSL v3 with enhancements
  to the authentication aspects of the SSL
  algorithms.
• RFC2246 is the TLS document

9
Cryptography Concepts A refresher

• Secret Key (Symmetric Key) Algorithms
• Public Key (Asymmetric Key) Algorithms
• Message Digest
• Message Authentication Code (MAC)
• Digital Signature
• Digital Certificate

10
Symmetric Key Algorithm
Key
Cipher Text
Plain Text
Plain Text
Receiver
Sender
11
Public Key Encryption
Step One Step Two
Sender
Receivers public key
Receiver
Plain Text
Cipher Text
Plain Text
Sender
Receiver
Receivers public key
Receivers private key
12
Message Digest
Message
One-way hash function
Message digest
13
Message Authentication Code (MAC)

• Similar to Cryptographic hash (Message Digest),
  except that it is based on a secret key
• Typically, message authentication codes are used
  between two parties that share a secret key in
  order to validate information transmitted between
  these parties.

14
Digital Signature
Sender
Document
Hash Function
Message Digest
Digital Signature
Receiver
Senders Private key
15
Digital Signature Verification
document
?
digital signature
message digest
message digest
senders public key
16
Digital Certificate

• A public key certificate is a digitally signed
  statement from one entity (usually, CA) saying
  that the public key (and some other info) of
  another entity has some specific value.
• Public key certificate contains several fields,
  including Issuer, Period of validity, Subject,
  Subjects public key, Signature.

17
SSL Protocol

• SSL connection is divided in to two phases
  Handshake and Data Transfer
• During handshake
• - client and server agree on a set of algorithms
• - client and server establish a set of
  cryptographic keys
• - server optionally authenticates client
• Data Transfer occurs after handshake is complete.
  Data (with MAC) is encrypted (secret key). Each
  data fragment has a Record header.

18
SSL Handshake process
Client
Server
(1) Supported ciphers, Random
(2) Chosen cipher, Random, Certificate
(3) Encrypted Master Secret
(4)Compute keys
(4) Compute keys
(5) MAC of handshake messages
(6) MAC of handshake messages
19
SSL Handshake process (cont.)

• The client sends the server a list of algorithms
  its willing to support, along with a random
  number used as input to the key generation
  process
• The server chooses a cipher out of that list and
  sends it back along with a certificate containing
  the servers public key. The certificate also
  provides the servers identity for authentication
  purposes and the server supplies a

20
SSL Handshake process (cont.)

• random number which is used as part of the key
  generation process
• The client verifies the servers certificate and
  extracts the servers public key. The client then
  generates a random secret string called the
  pre_master_secret and encrypts it using the
  servers public key. It sends the encrypted
  public key to the server.

21
SSL Handshake process (cont.)

• The client and server independently compute the
  encryption and MAC keys from the
  pre_master_secret and the client and servers
  random values.
• The client sends a MAC of all the handshake
  messages to the server
• The server sends a MAC of all the handshake
  messages to the client

22
JSSE Architecture

• JSSE is based on the same design principles found
  else where in the Java Cryptography Architecture,
  such as
• - Implementation Independence
• - Algorithm Independence
• - Provider architecture

23
JSSE Packages

• javax.net.ssl
• - contains the set of core classes and
  interfaces for the JSSE APIs.
• javax.net
• - this is not specific to the JSSE, but it is
  needed to support basic client socket and server
  socket factory functionality.
• javax.security.cert
• - is also not specific to the JSSE, but it is
  needed to support basic certificate management
  functionality.

24
JSSE Packages (cont.)

• com.sun.net.ssl
• Provides classes related to creating and
  configuring secure socket factories. These
  classes are provided with the Reference
  implementation of JSSE. They are not part of
  JSSE1.0.2 standard API, and thus may not be
  available with other implementations

25
JSSE Class Diagram
26
JSSE Classes

• SSLSocket - A socket that supports SSL, TLS
  secure socket protocols
• SocketFactory - A factory for socket objects
• SSLSocketFactory - A factory for ServerSocket
  objects
• SSLServerSocket - A server socket that supports
  SSL, TLS secure socket protocols
• ServerSocketFactory - A factory for
  ServerSocket objects

27
JSSE Classes (contd..)

• SSLServerSocketFactory - A factory for
  SSLServerSocket objects
• SSLSession - An interface to an object
  encapsulating an SSL session
• SSLSessionContext - An interface to an object
  encapsulating a collection of SSL sessions
  identified with a session ID
• SSLBindingEvent - An event class encapsulating
  SSL session binding and unbinding events

28
JSSE Classes (cont.)

• SSLBindingListener - A listener interface
  implemented by objects wanting to be made aware
  of SSL session binding and unbinding events
• HandshakeCompletedEvent - An event class
  encapsulating the fact that an SSL handshake has
  completed
• HandshakeCompletedListener - A listener
  interface implemented by objects wanting to be
  made aware of SSL handshke completion events

29
JSSE Providers

• JSSE follows the same provider configuration
  scheme as in JCA
• - to configure statically, add a line in the
• JRE-HOME\lib\security\java.security file
• security.provider.xcom.sun.net.ssl.internal.ssl
  .Provider
• - to configure dynamically,
• java.security.Provider provider new
• com.sun.net.ssl.internal.ssl.Provider()
• java.security.Security.addProvider(provider)

30
References

• Java Secured Socket Extension 1.0.2 API Users
  Guide
• Java Security Handbook
• - Jamie Jaworski Paul Perrone
• java-security_at_sun.com archives
• SSL and TLS Essentials Securing the web
• - Stephen Thomas
• SSL and TLS Designing and Building Secured
  Systems
• - Eric Rescorla

31
Some URLs

• http//java/sun.products/jsse
• http//archives.java.sun.com/archives/java-securit
  y.html
• http//home.netscape.com/eng/ssl3/ssl-toc.html
• http//developer.netscape.com/docs/manuals/securit
  y.html
• http//www.iplanet.com/developer/docs/articles/sec
  urity/ssl.html
• http//www.ietf.org/rfc/rfc2246.txt
