Power analysis and hypothesis testing with multiple samples

1
Power analysis and hypothesis testing with
multiple samples

• ESM 206
• 6 April 2006

2
Types of error

• Type II fail to reject null hypothesis when its
  really false
• Desired level b
• Is associated with a given effect size
• E.g., want a probability 0.1 of failing to reject
  when true difference between means is 0.35.

• Type I reject null hypothesis when its really
  true
• Desired level a

3
Setting error levels

• a is controlled by setting critical P-value for
  rejecting null hypothesis
• b decreased by
• increasing a
• Increasing sample size (n)
• Decreasing sample variance, var(x)
• increasing effect size, D
• Tradeoff between a and b
• Need to balance costs associated with type I and
  type II errors
• Power is 1-b

• POWER ANALYSIS
• Take a few samples to get an estimate of var(x)
• Assume that population has mean m0 D and
  variance var(x)
• If I take n samples, what is the probability of
  failing to reject the null hypothesis (getting P
  gt a)?
• Either through simulation or theory
• Adjust n to get the desired error level

4
Power and the water temperature test

• 3
• Testing
• H0 m 56

5
Effect of sample size on power
6
Statistics Decision Making EPAs Data Quality
Objectives (DQOs)

• What are DQOs? DQOs are qualitative and
  quantitative statements, developed using the DQO
  Process, that clarify study objectives, define
  the appropriate type of data, and specify
  tolerable levels of potential decision errors
  that will be used as the basis for establishing
  the quality and quantity of data needed to
  support decisions. DQOs define the performance
  criteria that limit the probabilities of making
  decision errors by considering the purpose of
  collecting the data defining the appropriate
  type of data needed and specifying tolerable
  probabilities of making decision errors.
• See link on class website

7
The DQO process

• State the Problem
• Define the problem identify the planning team
  examine budget, schedule.
• Identify the Decision
• State decision identify study question define
  alternative actions.
• Identify the Inputs to the Decision
• Identify information needed for the decision
  (information sources, basis for Action Level,
  sampling/analysis method).
• Define the Boundaries of the Study
• Specify sample characteristics define
  spatial/temporal limits, units of decision making.

• Develop a Decision Rule
• Define statistical parameter (mean, median)
  specify Action Level develop logic for action.
• Specify Tolerable Limits on Decision Errors
• Set acceptable limits for decision errors
  relative to consequences (health effects, costs).
• Optimize the Design for Obtaining Data
• Select resource-effective sampling and analysis
  plan that meets the performance criteria.

8
Preliminary assessment of household lead dust

• State the Problem
• Describing the problem. The owners wish to
  evaluate the potential hazards associated with
  lead in dust in a single-family residence because
  other residences in the Athington Park House
  neighborhood had shown levels of lead in dust
  that might pose potential hazards.
• Establishing the planning team. The planning team
  included the property owners, a certified risk
  assessor (to collect and handle dust samples and
  serve as a liaison with the laboratory), and a
  quality assurance specialist. The decision makers
  were the property owners.
• Describing the conceptual model of the potential
  hazard. The conceptual model described a
  single-family residence in a neighborhood where
  hazardous levels of lead had been detected in
  other residences. Interior sources of lead in
  dust were identified as lead-based paint on
  doors, walls, and trim, which deteriorated to
  form, or attach to, dust particles. Exterior
  sources included lead in exterior painted
  surfaces that had deteriorated and leached into
  the dripline soil, or lead deposited from
  gasoline combustion fumes that accumulated in
  soil. In these cases, soil could be tracked into
  the house, and collected as dust on floors,
  window sills, toys, etc. As this dust could be
  easily ingested through hand-to-mouth activities,
  dust was considered to be a significant exposure
  route. Levels of lead in floor dust were to be
  used as an indicator of the potential hazard.
• Identifying the general intended use of collected
  data. The data collected in this study will be
  used to determine if a heath hazard is present at
  Athington Park House using the criteria
  established under 40 CFR 745. This is a decision
  making (test of hypothesis) DQO Process.
• Identifying available resources, constraints, and
  deadlines. The property owners were willing to
  commit up to 1,000 for the study. To minimize
  inconvenience to the family, all sampling would
  be conducted during one calendar day.

• Identify the Decision
• Specifying the primary study question. The
  primary question to be addressed is to determine
  if there were significant levels of lead in floor
  dust at the House.
• Determining the range of possible outcomes from
  this study. If there were significant levels of
  lead in floor dust at the residence, the team
  planned follow-up testing to determine whether
  immediately dangerous contamination exists and
  the location of the contamination in the
  property. If not, then there was no potential
  lead hazard, and testing would be discontinued.

9
Preliminary assessment of household lead dust

• Identify the Inputs to the Decision
• Identifying the types of information that is
  needed to resolve the decision statement. The
  assessment of a dust lead hazard would be
  evaluated by measuring dust lead loadings by
  individual dust wipe sampling according to
  established protocol.
• Identifying the source of information. The EPA
  proposed standard stated that if dust lead levels
  were above 50 µg /ft2 on bare floors, a lead
  health hazard was possible and follow-up testing
  and/or intervention should be undertaken (40 CFR
  745).
• Identifying how the Action Level will be
  determined. The Action Level is the EPA standard
  specified in 40 CFR 745.
• Identifying appropriate sampling and analysis
  methods. Wipe samples were collected according to
  ASTM standard practice E1728. These samples were
  digested in accordance with ASTM standard
  practice E1644 and the sample extracts were
  chemically analyzed by ASTM standard test method
  E1613. The results of these analyses provided
  information on lead loading (i.e., µgof lead per
  square foot of wipe area) for each dust sample.
  The detection limit was well below the Action
  Level.

• Define the Boundaries of the Study
• Specifying the spatial and temporal boundaries
  for collecting data. The spatial boundaries of
  the study area were defined as all floor areas
  within the dwelling that were reasonably
  accessible to young children who lived at, or
  visited, the property. Dust contained in each one
  ft.2 area of each floor of the residence was
  sampled and sent to a laboratory for analysis.
• Specifying other practical constraints for
  collecting data. Permission from the residents of
  Athington Park House was required before risk
  assessors could enter the residence to collect
  dust wipe samples. Sampling was completed within
  1 calendar day to minimize the inconvenience to
  the residents.
• Specifying the scale of estimates to be made. The
  test results were considered to appropriately
  characterize the current and future hazards. It
  was possible that lead contained in soil could be
  tracked into the residence and collect on
  surfaces, but no significant airborne sources of
  lead deposition were known in the region. The
  dust was not expected to be transported away from
  the property therefore, provided the exterior
  paint was maintained in intact condition, lead
  concentrations measured in the dust were not
  expected to change significantly over time.
• Specifying the scale of inference for decision
  making. The decision unit was the interior floor
  surface (approximately 1,700 ft2) of the
  residence at the time of sampling and in the near
  future.

10
Preliminary assessment of household lead dust

• Develop a Decision Rule
• Specifying the Action Level. This was given in 40
  CFR 745 which specified 50 µg/ft2.
• Developing the population of interest and the
  theoretical decision rule. From 40 CFR 745, the
  median was selected as the appropriate parameter
  to characterize the population under study. The
  median dust lead loading was defined to be that
  level, measured in µg/ft2, above and below which
  50 of all possible dust lead loadings at the
  property were expected to fall. If the true
  median dust loading in the residence was greater
  than 50 µg/ft2, then the planning team required
  followup testing. Otherwise, they decided that a
  dust lead hazard was not present and discontinued
  testing.

11
Preliminary assessment of household lead dust

• Determining the impact of decision errors and
  setting tolerable decision error limits. The edge
  of the gray region was designated by considering
  that a false acceptance decision error would
  result in the unnecessary expenditure of scarce
  resources for follow-up testing and/or
  intervention associated with a presumed hazard
  that did not exist. The planning team decided
  that this decision error should be adequately
  controlled for true dust lead loadings of 40
  µg/ft2 and below. Since human exposure to lead
  dust hazards causes serious health effects, the
  planning team decided to limit the false
  rejection error rate to 5. This meant that if
  this dwellings true median dust lead loading was
  greater than 50 µg/ft2, the baseline condition
  would be correctly rejected 19 out of 20 times.
  The false acceptance decision, which would result
  in unnecessary use of testing and intervention
  resources, was allowed to occur more frequently
  (i.e., 20 of the time when the true dust-lead
  loading is 40 µg/ft2 or less).

• Specify Tolerable Limits on Decision Errors
• Setting the baseline condition. The baseline
  condition adopted by the property owners was that
  the true median dust lead loading was above the
  EPA hazard level of 50 µg/ft2, due to the
  seriousness of the potential hazard. The planning
  team decided that the most serious decision error
  would be to decide that the true median dust lead
  loading was below the EPA hazard level of 50
  µg/ft2, when in truth the median dust lead
  loading was above the hazard level. This
  incorrect decision would result in significant
  exposure to dust lead and adverse health effects.


12
(No Transcript)
13
EXAMPLE LEAD DUST

• Preliminary sampling suggests that the standard
  deviation of lead dust observations is 30 mg/ft2
• We want to know how many observations we need to
  take so that b is 0.2 if the true mean dust
  concentration is 10 mg/ft2 below the
  contamination threshold and we are using an a of
  0.05

For t-test, a for 1-sided test equivalent to 2a
for 2-sided test
1 - b
14
Interlude the lognormal distribution
15
LEAD DUST DONE RIGHT
Effect size is log(50) log(40) 0.22 Std.
dev. of log(lead) est. as 1.5
16
Cleanup of a contaminated site

• THE PROBLEM
• A site has suffered the release of a toxic
  chemical (TcCB) into the soil, and the company
  responsible has undertaken cleanup activities.
• How should we decide whether the cleanup has been
  adequate?

• THE DATA
• We have samples of TcCB concentration (measured
  in ppb) in the soils at the cleanup site, as well
  as samples of concentrations at an uncontaminated
  reference site with similar soil
  characteristics.
• The concentrations of TcCB at the reference site
  are not zero, and we need to determine what the
  normal levels of this chemical are.

17
EPA standards for assessing site contamination

• If a site has not been declared to be
  contaminated, then the null hypothesis should be
  that it is clean, i.e., there is no difference
  from the control site. The alternative
  hypothesis is that the site is contaminated. A
  non-significant test results leads to the
  conclusion that there is no real evidence that
  the site is contaminated.

• If a site has been declared to be contaminated,
  then the null hypothesis should be that this is
  true, i.e., there is a difference (in an
  unacceptable direction) from the control site.
  The alternative hypothesis is that the site is
  clean. A non-significant test results leads to
  the conclusion that there is no real evidence
  that the site has been cleaned up.

USEPA (1989) Methods for Evaluating the
Attainment of Cleanup Standards. Vol. 1 Soils
and Solid Media. EPA Report 230/02-89-042,
Office of Policy, Planning and Evaluation,
Washington, DC.
18
COMPARING TWO GROUPS

• Two-sample t-test
• Tests for differences between means of two groups
• Null hypotheses
• Under null hypothesis, difference in means,
  standardized by standard deviations of both
  groups, should follow a t distribution

19
TcCB cleanup conclusion

• Using the null hypothesis that the cleanup site
  is contaminated with respect to the control site,
  we fail to reject the hypothesis that the cleanup
  site is still contaminated (one-sided two-sample
  t-test with unequal variances, t 1.45, df
  76.05, P 0.925).

20
Comparing fuel efficiency of two gasoline blends

• THE PROBLEM
• The owner of a taxi company is evaluating two
  gasoline blends, and wants to use the one that
  produces greater fuel efficiency
• How should she decide which (if either) produces
  greater efficiency?

• THE DATA
• On one day, all the taxis in the fleet were
  fueled with gas A, and at the end of the day the
  efficiency of each car (in mpg) was calculated.
• On the next day, all the taxis in the fleet were
  fueled with gas B, and at the end of the day the
  efficiency of each car was calculated.

21
Two-sample t-test of gas data
Want to control for variability among drivers
22
COMPARING TWO GROUPS

• Paired t-test
• Each observation is a pair of measurements
• Water quality upstream and downstream of a road
  crossing
• Fuel mileage by a taxi driver using two brands of
  gasoline
• Natural variability between sampling units might
  swamp differences between the means
• Streams have different background water quality
• Drivers have different driving styles
• Instead, test for mean of differences

23

• CONCLUSION
• We find strong evidence that mileage differs
  between gas A and gas B (paired t-test, t 3.12,
  df 9, P 0.012). On average, the fuel
  efficiency with gas B is 0.6 mpg greater than
  with gas A.

24
COMPARING MEANS OF 3 OR MORE GROUPS

• ANOVA (ANalysis Of VAriance)
• Like 2-sample t-test, but with multiple groups
• H0 All groups have the same mean
• HA Not all groups have the same mean
• Rejecting H0 doesnt tell you which groups differ
• Can do a bunch of t-tests for this

25
CONCLUSION Very strong evidence that highway
mileage differs among car types (one-way ANOVA, F
23.67, df 5,86, P lt 0.0001)
26
HYPOTHESIS TESTING OVERVIEW
27
ASSUMPTIONS OF T-TEST AND ANOVA

• T-test
• Distribution within each group is normal
• ANOVA
• Distribution within each group is normal
• Variances of all groups are the same
• Both tests are robust to moderate violations of
  these assumptions
• Regard P value as an approximate value

• TcCB data
• Assumption of normality is badly violated
• Solution do tests on transformed data
• Car mileage data
• Assumption of equal variances is badly violated
• Solution perform Welch ANOVA

28
(No Transcript)
