MonALISA framework

1
Monitoring of adistrubuted computing systemthe
Grid AliEn_at_CERN
Marco MEONI
Master Degree 19/12/2005
2
Content

• MonALISA Adaptationsand Extensions

• Grid Conceptsand Grid Monitoring

• PDC04 Monitoring and Results

• Conclusions and Outlooks

http//cern.ch/mmeoni/thesis/eng.pdf
3
Section I
Grid Concepts and Grid Monitoring
4
ALICE experiment at CERN LHC
1) Heavy Nuclei and proton-proton colliding
5) ALICE physicists analyse the the data and
search for physics signals of interest
2) Secondary particles are produced in the
collision
4) Particle properties (trajectories, momentum,
type) are reconstructed by the AliRoot software
3) These particles are recorded by the ALICE
detector
5
Grid Computing

• Grid Computing definition
• coordinated use of large sets of heterogenous,
  geographically distributed resources to allow
  high-performance computation
• The AliEn system
• - pull rather than push architecture the
  scheduling service does not need to know the
  status of all resources in the Grid the
  resources advertise themselves
• - robust and fault tolerant, where resources can
  come and go at any point in time
• - interfaces to other Grid flavours allowing for
  rapid expansion of the size of the computing
  resources, transparently for the end user.

6
Grid Monitoring

• GMA Architecture

• R-GMA an example of implementation
• Jini (Sun) provides the technical basis

7
MonALISA framework

• Distributed monitoring service system using
  JINI/JAVA and WSDL/SOAP technologies
• Each MonALISA server acts as a dynamic service
  system and provides the functionality to be
  discovered and used by any other services or
  clients that require such information

8
Section II
MonALISA Adaptations and Extensions
9
MonALISA Adaptations
A Web Repository as a front-end for production
monitoring

• Stores history view of the monitored data
• Displays the data in variety of predefined
  histograms and other visualisation formats
• Simple interfaces to user code custom consumers,
  configuration modules, user-defined charts,
  distributions

Farms monitoring

• User Java class to interface MonALISA and bash
  script to monitor the site

Remote Farm
WEB Repository
CE
Monitoring script
Monitored data
Java interface class
WNs
User code
MonALISA framework
Grid resources
10
Repository Setup
A Web Repository as a front-end for monitoring

• Keeps full history of monitored data
• Shows data in a moltitude of histograms
• Added new presentation formats to provide a full
  set (gauges, distributions)
• Simple interfaces to user code custom
  consumers, custom tasks

Installation and Maintenance

• Packages installation (Tomcat, MySQL)
• Configuration of main servlets for ALICE VO
• Setup of scripts for startup/shutdown/backup

• All the produced plots have been built and
  customized as from as many configuration files

• SQL, parameters, colors, type
• cumulative or averaged behaviour
• smooth, fluctuations
• user time intervals
• many others

11
AliEn Jobs Monitoring

• Centralized or distributed?
• AliEn native APIs to retrieve job status
  snapshots

Job is submitted
(Error_I)
INSERTING
AliEn TQ
WAITING
(Error_A)
ASSIGNED
CE
(Error_S)
QUEUED
(Error_E)
STARTED
(Error_R)
RUNNING
ZOMBIE
WN
gt1h
(Error_V, VT, VN)
VALIDATION
FAILED
(Error_SV)
gt3h
SAVING
DONE
TOMCATJSP/servlets
12
Repository DataBase(s)
Data Collecting

• 7 Gb of performance information, 24.5M records
• During DC data from 2K monitored parameters
  arrive every 2/3 mins

1min
10 min
100 min

60 bins for each basicinformation
Averaging
process
FIFO

• ROOT
• CARROT

• MonALISA Agents
• Repository Web Services
• AliEn API
• LCG Interface
• WNs monitoring (UDP)
• Web Repository

Grid Analysis
Data collecting and Grid Monitoring
13
Web Repository

• Storage and monitoring tools of the Data
  Challenge running parameters, task completion
  and resource status

14
Visualisation Formats
Menù
Statistics and real-time tabulated
CE Load factors and tasks completion
Stacked Bars
Running history
Snapshots and Pie charts
15
Monitored parameters

• 2k parameters and 24,5M records with 1 minute
  granularity
• Analysis of the collected data allows for
  improvement of the Grid performance

1868

• Derived classes

16
MonALISA Extensions

• Job monitoring of Grid users
• Application Monitoring (ApMon) at WNs
• Repository Web Services

• Using AliEn commands (ps a, jobinfo jobid, ps
  X -st) output parsing
• Jobs JDL scanning
• Results presented in the same web front end

• ApMon is a set of flexible APIs that can be used
  by any application to send monitoring information
  to MonALISA services, via UDP datagrams
• Allows for data aggregation and scaling of the
  monitoring system
• Developed a light monitoring C class to
  include within the Process Monitor payload

• Alternative to ApMon for WEB repository
  purposes - dont need MonALISA agents - store
  data directly into the DB repository
• Used to monitor Network Traffic through the ftp
  servers of ALICE at CERN

17
MonALISA Extensions

• Distributions for principle of Analysis

• First attempt for a Grid performance tuning,
  based on real monitored data
• Use of ROOT and Carrot features
• Cache system to optimize the requests

ROOT histogram server process (central cache)
HTTP
A p a c h e
1. ask for histogram
2. query NEW data
3. send NEW data
MonALISA Repository
4. send resulting object/file
ROOT/Carrot histogram clients
18
Section III
PDC04 Monitoring and Results
19
PDC04

• Purpose test and validate the ALICE Offline
  computing model
• Produce and analyse 10 of the data sample
  collected in a standard data-taking year
• Use the complete set of off-line software AliEn,
  AliROOT, LCG, Proof and, in Phase 3, the ARDA
  user analysis prototype
• Structure logically divided in three phases
• Phase 1 - Production of underlying PbPb events
  with different centralities (impact parameters)
  production of pp events
• Phase 2 - Mixing of signal events with different
  physics content into the underlying PbPb events
• Phase 3 Distributed analysis

20
PDC04 Phase 1

• Task - simulate the data flow in reverse events
  are produced at remote centres and stored in the
  CERN MSS

Storage
21
Total CPU profile

• Aiming for continuous running, not always
  possible due to resources constraints

Total number of jobs running in parallel 18
computing centres participating

• Start 10/03, end 29/05 (58 days active)
• Maximum jobs running in parallel 1450
• Average during active period 430

22
Efficiency

• Calculation principle jobs are submitted only
  once

Successfully done jobs all submitted
jobs
Error (CE) free jobs all submitted
jobs
Error (AliROOT) free jobs all
submitted jobs
23
Phase 1 of PDC04 Statistics
24
PDC04 Phase 2

• Task - simulate the event reconstruction and
  remote event storage

Central servers
Master job submission, Job Optimizer (N
sub-jobs), RB, File catalogue, processes
monitoring and control, SE
Register in AliEn FC LCG SE LCG LFN AliEn PFN
Sub-jobs
Sub-jobs
Storage
AliEn-LCG interface
CERN CASTOR underlying events
Underlying event input files
RB
Storage
CEs
CEs
CERN CASTOR backup copy
Job processing
Job processing
Output files
Output files
zip archive of output files
Local SEs
Local SEs
File catalogue
Primary copy
Primary copy
edg(lcg) copyregister
25
Individual sites CPU contribution

• Start 01/07, end 26/09 (88 days active)
• As in the 1st phase, general equilibrium in CPU
  contribution
• AliEn direct control 17 CEs, each with a SE
• CERN-LCG is encompassing the LCG resources
  worldwide (also with local/close SEs)

26
Sites occupancy

• Outside CERN, sites such as Bari, Catania and
  JINR have generally run always at the maximum
  capacity

27
Phase 2 Statistics and Failures
28
PDC04 Phase 3
File Catalogue query

• Task user data analysis

Data set (ESDs, other)
Job Optimizer
Grouped by SE files location
Sub-job 2
Sub-job n
User job (many events)
Job Broker
Submit to CE with closest SE
Job output
CE and SE
CE and SE
CE and SE
processing
processing
processing
Output file 2
Output file n
File merging job
29
Analysis

• Start September 2004, end January 2005
• Distributions charts built on top of ROOT
  environment using the Carrot web interface

• Distribution of number of running jobs
• - mainly depends on number of waiting jobs in
  TQ and availability of free CPU at the
  remote CEs

• Occupancy versus the number of queued jobs
• - there is an increase of the occupancy as
  more jobs are waiting in the local batch
  queue and a saturation is
• reached at around 60 queued jobs

30
Section IV
Conclusions and Outlook
31
Lessons from PDC04

• User jobs have been running for 9 months using
  AliEn
• MonALISA has provided a flexible and complete
  monitoring framework successfully adapted to the
  needs of Data Challenge
• MonALISA has given the expected results for
  performance tuning and workload balancing
• Approach step by step from resources tuning to
  resources optimization
• MonALISA has been able to gather, store, plot,
  sort and group large variety of monitored
  parameters, either basic or derived in a rich set
  of presentation formats
• The Repository has been the only source of
  historical information and the modular
  architecture has made possible a development of
  variety of custom modules (800 lines of
  fundamental source code and 3k lines to perform
  service tasks)
• PDC04 has been a real example of successful Grid
  interoperability by interfacing AliEn and LCG and
  proving the AliEn design scalability
• The usage of MonALISA in ALICE has been
  documented in an article for a conference at
  Computing in High Energy and Nuclear Physics
  (CHEP) 04, Interlaken - Switzerland
• Unprecedented experience to develop and improve a
  monitoring framework on top of a real functioning
  Grid, massively testing the involved software
  technologies
• Easy to extend the framework and replace
  components with equivalent ones following the
  technical needs or strategic choices

32
Credits

• Dott. F.Carminati, L.Betev, P.Buncic and all
  colleagues in ALICE
• for the enthusiasm they trasmitted during
  this work
• MonALISA team
• collaborative anytime I needed
