Random Cellular Automata: A case study of Neuropercolation

1
Random Cellular Automata A case study of
Neuropercolation

• Dr. R. KozmaPresented by Hui Chen

2
Major References

• Balister, P., Bollobas, B., and Kozma, R., Random
  Cellular Automata, to be published, 2002
• Grimett, G., Percolation, New York, Berlin,
  Heidelberg Springer-Verlag, 1989
• Kozma, R., Balister, P., Bollobas, B.,
  Self-Organized Development of Behaviors in
  Spatio-Temporal Dynamical Systems, to appear in
  WCCI 2002 Proceedings, May 12-17, 2002
• Kozma, R., Neuropercolations Dynamical
  Percolation Models of Phase Transition in
  Physical and Biological Systems, Lecture in BISC
  Seminar, University of California at Berkeley,
  February 21, 2002

3
Neuropercalations Models of Neurodynamics
4
Modeling Mesoscopic Behavior of Neuron Population
Kozma, 2002

• Neuropil
• Densely connected filamentous texture of neural
  tissue (Freeman, since 70s)
• Possible phase transitions from connectivity/gain
  change

• Percolation
• Lattice/Torus
• Randomly initialized
• Rules of Aprousal and Drepression based on
  defined neighborhood

5
NEUROPERCOLATION MODELS AS GENERAL (SOFT)
COMPUTATIONAL TOOLSKozma, 2002

• Governed by probabilistic rules
• And not on differential equations
• Emphasis is on connectivity
• Instead of complex functionality of individual
  units
• Relatively simple functionality of nodes
• Motivation
• This approach with simple units can give very
  complex behavior ? can approximate solution to
  ode/pde if needed
• More general than calculus ant it can solve
  problems unreachable by traditional tools

6
Random Cellular Automata

• Probability introduced ? Bootstrap Percolation ?
  Random Cellular Automata ? Chaotic behavior
• Computation Model with
• Cell each cell only has limited computational
  power to change its properties
• Topology
• Neighborhoods
• Property updating rule with probability
• Update the properties of the desired cell based
  on the properties of itself and its neighbors

7
Current RCA MODEL Model of Simple Neural Network

• Updating/Transition Rule
• if greater than 2 active in neighborhoods,
  activate with probability p
• if less than 3 active in neighborhoods,
  inactivate with probability 1-p

8
Density, Probabity and Clusters

• Density (d)
• d (number of active cells)/(total number of
  cells
• Probability (p)
• On this probability the cell is going to change
  its properties according to the properties of
  itself and its neighbors.
• Clustering
• How density is changing with time or different
  probability?
• Critical Probability (pc)

9
Critical Prabability pc

• Probability Model
• p0
• d 0 or 1 depends on initial configuration
• p?
• d?0 and d ?1, so d? or d? depends on initial
  configuration.
• p 0.5
• totally random, d?
• Deterministic Model
• there exists a pc
• what happends when p lt pc or p gt pc (many small
  clusters, few big clusters)

?
10
RCA runs on 128 x 128 torus
11
Probability 0.040
12
Probability 0.080
13
Probability 0.120
14
Probability 0.133
15
Probability 0.134
16
Probability 0.135
17
Probability 0.136
18
Probability 0.140
19
Probability 0.200
20
Critical Probability
21
Residence Time Distribution
22
p 0.134
23
p 0.1338
24
p0.1335
25
p0.1333
26
p0.133
27
Summary
