Parallel Objects: Virtualization

1
Parallel Objects Virtualization In-Process
Components

• Orion Sky Lawlor
• Univ. of Illinois at
• Urbana-Champaign
• POHLL-2002

2
Introduction

• Parallel Programming is hard
• Communication takes time
• Message startup cost
• Bandwidth contention
• Synchronization, race conditions
• Parallelism breaks abstractions
• Flatten data structures
• Hand off control between modules
• Harder than serial programming

3
Motivation

• Parallel Applications are either
• Embarrassingly Parallel
• Trivial, 1 RA-week effort
• E.g. Monte Carlo, parameter sweep, SETI_at_home
• Communication totally irrelevant to performance

4
Motivation

• Parallel Applications are either
• Embarrassingly Parallel
• Excruciatingly Parallel
• Massive, 1 RA-year effort
• E.g. Pure MPI codes 10k lines
• Communication, synchronization totally determine
  performance

5
Motivation

• Parallel Applications are either
• Embarrassingly Parallel
• Excruciatingly Parallel
• Well be done in 6 months
• Several parallel libraries codes groups,
  dynamic adaptive
• E.g. Multiphysics simulation

6
Serial Solution Abstract!

• Build layers of software
• High-level Libc, C STL,
• Mid-level OS Kernel
• Silently schedule processes
• Keep CPU busy even when some processes block
• Allows a process to ignore other processes
• Low-level assembler

7
Parallel Solution Abstract!

• Middle layers are missing
• High-level ScaLAPACK, POOMA..
• Mid-level ? Kernel
• Silently schedule components
• Keep CPU busy even when some components block
• Allows a component to ignore other components
• Low-level MPI

8
The missing middle layer

• Provides dynamic computation and communication
  overlap, even across separate modules
• Handles inter-module handoff
• Pipelines communication
• Improves cache utilizationsmaller components
• Provides nice layer for advanced features, like
  process migration

9
Examples Multiprogramming
10
Examples Pipelining
11
Middle Layer Implementation

• Real OS processes/threads
• Robust, reliable, implemented
• High performance penalty
• No parallel features (migration!)
• Converse/Charm
• In-process components efficient
• Piles of advanced features
• AMPI, MPI interface to Charm
• Application Framework

12
Charm

• Parallel library for Object-Oriented C
  applications
• Messaging via method calls
• Communication proxy objects
• Methods called by scheduler
• System determines who runs next
• Multiple objects per processor
• Object migration fully supported
• Even with broadcasts, reductions

13
Mapping Work to Processors
System implementation
User View
14
AMPI

• MPI interface, implemented on Charm
• Multiple virtual processors per physical
  processor
• Implemented as user-level threads
• Very fast context switching
• MPI_Recv only blocks virtual processor, not
  physical
• All the benefits of Charm

15
Application Frameworks

• Domain-specific interfaces unstructured grids,
  structured grids, particle-in-cell
• Provide natural interface to application
  scientists (Fortran!)
• Encapsulate communication
• Built on Charm
• Most popular interfaces to Charm

16
Charm Features Migration

• Automatic load balancing
• Balance load by migrating objects
• Application-independent
• Built-in data collection (cpu, net)
• Pluggable strategy modules
• Adaptive Job Scheduler
• Shrink/expand parallel job, by migrating objects
• Dramatic utilization improvment

17
Examples Load Balancing
1. Adaptive Refinement
3. Chunks Migrated
2. Load Balancer Invoked
18
Examples Expanding Job
19
Examples Virtualization
20
Conclusions

• Parallel applications need something like a
  kernel
• Neutral party to mediate CPU use
• Significant utilization gains
• Easy to put good tools in kernel
• Work migration support
• Load balancing
• Consider using Charm

http//charm.cs.uiuc.edu/
