Dynamic Routing and OSPF

1

• Dynamic Routing and OSPF
• (part 1)

2
IP routing

• Each router or host makes its own routing
  decisions
• Sending machine does not have to determine the
  entire path to the destination
• Sending machine just determines the next-hop
  along the path.
• This process is repeated until the destination is
  reached
• Forwarding table consulted to determine the
  next-hop

3
IP routing

• Classless routing
• route entries include
• destination
• next-hop
• mask (prefix-length) indicating size of address
  space described by the entry
• Longest match
• for a given destination, find longest prefix
  match in the routing table
• example destination is 35.35.0.0/19
• routing table entries are 35.0.0.0/8 and
  35.35.0.0/16

4
IP routing

• Default route
• where to send packets if dont have an entry for
  the destination in the routing table
• most machines have a single default route
• often referred to as a default gateway

5
Static routing

• each router manually configured with a list of
  destinations and the next hop to reach those
  destinations
• ideal for small number of destinations or stub
  networks
• stub network - network with only one or two paths
  to the rest of the network

6
Dynamic Routing

• routers compute routing tables dynamically based
  on information provided by other routers in the
  network
• routers communicate topology to each other via
  different protocols
• routers then compute one or more next hops for
  each destination - trying to calculate the most
  optimal path

7
Static and Dynamic Routing

• Static routing is a simplistic approach
• Shortcomings
• Cumbersome to configure
• Cannot adapt to link/node failures, addition of
  new nodes and links
• Doesn't scale to large networks
• Solution Dynamic Routing

8
Desirable Characteristics

• Automatically detect and adapt to network
  topology changes
• Optimal routing
• Scalability
• Robustness
• Simplicity
• Speed of convergence
• Some control of routing choices (e.g. which links
  we prefer to use)

9
Convergence - Why do I care?

• Convergence is when all the routers have the same
  routing information
• When a network is not converged, there is network
  downtime
• Packets don't get to where they are supposed to
  be going routing loops, black holes
• Occurs when there is a change in the status of a
  router or link

10
Dynamic Protocols

• Metrics can be calculated based on a single
  characteristic of a path or by combining multiple
  characteristics
• Metrics commonly used
• Bandwidth
• Hop count
• Cost
• administratively defined metrics

11
OSPF magic exercise

• delete your static routes
• config t
• no ip route x.x.x.x y.y.y.y z.z.z.z
• enter the following
• router ospf 1
• network x.x.x.x 0.0.0.0 area 0
• x.x.x.x ip address of your backbone interface
• redistribute connected subnets

12
OSPF magic exercise

• Verify connectivity to all PCs in the network
• Do not save your config

13
Dynamic Routing Protocols and OSPF (part 2)
14
Types of Routing Protocols

• EGP
• Exterior Gateway Protocol
• Example BGP
• IGP
• Interior Gateway Protocol
• Example OSPF, RIP

15
Types of Routing Protocols

• Link-state
• Distance-vector

16
IGP

• Used within a single Autonomous System (AS)
• Within a single network

17
Other Interior Gateway Protocols (IGPs)

• RIP
• Lots of scaling problems
• RIPv1 is classful and officially obsolete
• RIPv2 is classless
• EIGRP
• Proprietry (Cisco only)
• IS/IS
• The forerunner of OSPF
• Multiprotocol (OSPF is IP only)

18
Distance Vector Protocols

• Listen to neighboring routes
• Install all routes in a table
• Advertise all routes in table
• Very simple
• Very Stupid
• example RIP

19
RIP

• routing information protocol
• distance-vector algorithm
• cost is hop count
• broadcast information to all neighbors every 30
  seconds

20
RIP
ROUTING TABLE for A A - B 1 C 2 D 3 E 2
21
Why not use RIP?

• Distance Vector algorithm
• Broadcasts everything (not scalable)
• Metric is hop-count only
• Infinity of 16 (not large enough)
• Slow convergence (routing loops)
• Poor robustness

22
OSPF

• Open Shortest Path First
• Dynamic IGP (Interior Gateway Protocol)
• Use within your own network
• Link state algorithm

23
Shortest Path First
Metric Link Cost
3
A
B
15
4
4
C
D
7
24
Link State Algorithm

• Each router maintains a database containing map
  of the whole topology
• Links
• State (including cost)
• All routers have the same information
• All routers calculate the best path to every
  destination

25
Link State Algorithm (con)

• Any link state changes are flooded across the
  network
• "Global spread of local knowledge

26
Link State vs. Distance vector

• Distance Vector
• views net topology from neighbors perspective
• adds distance vectors from route to router
• frequent, periodic updates slow convergence
• passes copies of routing table to neighbor routers

27
Link State vs. Distance vector

• Link-State
• gets common view of entire network topology
• calculates the shortest path to other routers
• event-triggered updates faster convergence
• passes link-state routing updates to other routers

28
Distance Vector and Link State Protocols

• Distance vector routers compute the best path
  from information passed to them from neighbors
• Link State routers each have a copy of the entire
  network map
• Link State routers compute best routes from this
  local map

29
Note Routing is not the same as Forwarding

• Forwarding passing packets along to the next hop
• There is only one forwarding table
• Just has prefix and next-hop info
• Routing populating the forwarding table
• You might have multiple routing databases - e.g.
  both OSPF and BGP
• Routing databases have more information

30
Routing and Forwarding
BGP
OSPF
Static
Forwarding Table
On Cisco, if the same prefix is received from
multiple protocols, the "administrative distance"
is used to choose between them
31
OSPF

• open shortest path first
• dynamic IGP
• not distance vector
• Link-State algorithm

32
OSPF How it works (1)

• "Hello" packets sent periodically on all
  OSPF-enabled interfaces
• become "neighbors"
• establishes that link can carry data
• used to determine if neighbor is up
• Adjacencies (virtual point-to-point links) formed
  between some neighbors

33
How it works (2)

• Once an adjacency is established, trade
  information with your neighbor
• Topology information is packaged in a "link state
  announcement"
• Announcements are sent ONCE, and only updated if
  there's a change (or every 30 minutes)

34
How it works (3)

• Each router sends Link State Announcements (LSAs)
  over all adjacencies
• LSAs describe router's links, interfaces and
  state
• Each router receives LSAs, adds them into its
  database, and passes the information along to its
  neighbors

35
How it works (4)

• Each router builds identical link-state database
• Runs SPF algorithm on the database to build SPF
  tree
• Forwarding table built from SPF tree

36
How it works (5)

• When change occurs
• Broadcast change
• All routers run SPF algorithm
• Install output into forwarding table

37
HELLO

• Broadcast HELLO on network segment
• Receive ACK
• Establishes 2-way communication
• Repeat periodically
• Default HELLO sent every 10 seconds
• Default if no HELLO heard for 40 seconds, link
  is assumed to be dead
• Now establish adjacencies

Actually uses Multicast addresses (224.0.0.9,
224.0.0.10) so that non-OSPF devices can ignore
the packets
38
The HELLO packet
HELLO
HELLO
HELLO

• Router priority
• Hello interval
• Router dead interval
• Network mask
• List of neighbors

These must match
39
Neighbors

• Bi-directional communication
• Result of OSPF hello packets
• Need not exchange routing information

40
Who is adjacent?

• "Adjacent" neighbors exchange routing information
• Not all neighbors are adjacent
• On a point-to-point link
• everyone
• On broadcast medium
• not everyone
• why?

41
Broadcast neighbors
Order of N2 adjacencies
A
B
C
D
42
Broadcast medium

• Select a neighbor Designated Router (DR)
• All routers become adjacent to DR
• Exchange routing information with the DR
• DR updates all the other neighbors
• Scales
• Adjacencies reduced from N2 to 2N
• Backup Designated Router (BDR)

43
LSAs propagate along adjacencies
DR
BDR
44
Other nice features of OSPF

• Authentication (optional)
• Equal-cost multipath
• more than one "best" path - share traffic
• Proper classless support (CIDR)
• Multiple areas
• For very large networks (gt150 routers)
• Aggregate routes across area boundaries
• Keep route flaps within an area
• Proper use of areas reduce bandwidth and CPU
  utilisation
• Backbone is Area 0

45
Cisco OSPF commands and configuration

• show ip route
• show ip ospf neighbor
• show ip ospf database

46
Configuring OSPF

• router ospf ltprocess-idgt
• network x.x.x.x m.m.m.m area ltarea-idgt
• m.m.m.m wildcard mask
• 0 dont care bit
• 1 check bit
• 0.0.0.0 mask for exact match
• network 203.167.177.10 0.0.0.0 area 0
• network 203.167.177.0 0.0.0.255 area 0

47
Classroom Layout
A
B
Router
PC
Router
PC
C
D
PC
Router
PC
Router
F
E
PC
Router
PC
Router
G
H
PC
Router
PC
Router
I
J
PC
Router
PC
Router
SWITCH
48
Serial Links for exercise
A
B
133.27.162.96/28
133.27.162.112/28
133.27.162.48/30
133.27.162.60/30
C
D
133.27.162.128/28
133.27.162.144/28
F
E
133.27.162.16/28
133.27.162.160/28
133.27.162.176/28
133.27.162.52/30
133.27.162.64/30
G
H
133.27.162.192/28
133.27.162.208/28
I
J
133.27.162.224/28
133.27.162.240/28
133.27.162.56/30
