IP Routing

1
IP Routing

• Redes de Datos 2002
• etapia_at_eie.fceia.unr.edu.ar

2
IP Routing

• IP router
• Connects different physical networks
• Datagrams forwarding
• Until they reach a router connected to the
  destinations LAN segment
• Selects the next hop device used to reach the
  destination
• The next hop is the next device along the path to
  reach the destination

3
IP Routing view
4
IP Routing Tables

• Routing Protocol
• Dynamically build and manage IP routing tables
• Information about a routers locally connected
  networks
• Network topology changes
• Routing tables are updated with minimal or no
  manual intervention

5
IP addresses
6
Net and Host Numbers
7
Recall that

• Any address starting with 127 is a loop back
  address
• It should never be used for addressing outside
  the host
• A host number of all binary 1's indicates a
  directed broadcast over the specific network
• For example, 200.1.2.255 would indicate a
  broadcast over the 200.1.2 network
• If the host number is 0, it indicates "this host
• If the network number is 0, it indicates "this
  network"

8
Network and Hosts
9
Two LAN Segments
10
Netmask

• Used to specify which part of the address is the
  network number part, and which is the host part
• This is accomplished by a logical bitwise-AND
  between the netmask and the IP address.The result
  specifies the network number
• For Class C, the netmask will always be
  255.255.255.0
• For Class B, the netmask will always be
  255.255.0.0 and so on.

11
VLMS

• XYZ Corporation
• Network number 160.6.0.0 from the InterNIC
• The world sees this company as 160.6.0.0
• Variable Length Subnet Masks (VLSM)
• Divide their world into a multi-level hierarchy
• Sub-subnets in a tree-structured network

12
Hierarchical Subnetting Example

• XYZ Corp has 23 field offices in all
• 32 subnets using a mask of 255.255.252.0. In
  binary. The mask bits are 11111111 11111111
  11111100 00000000 (64 different subnetworks)
• The designers want to further subdivide each site
  with a router
• Central routers are subnetted 255.255.252.0 and
  they differentiate between field offices
• The field office routers, are subnetted with
  255.255.255.128

13
VLMS view
Mask
14
Autonomous System (AS)

• Logical portion of a larger IP network
• Internetwork within an organization
• Administered by a single management authority
• Interior Gateway Protocols (IGPs)
• Allow routers to exchange information within an
  AS
• Open Short Path First (OSPF)
• Routing Information Protocol (RIP)

15
ASs
16
AS Example
17
Routing Protocols

• Exterior Gateway Protocols (EGPs)
• Allow exchange of summary information between ASs
• Border Gateway Protocol (BGP)

18
A Routing Taxonomy

• Static Routing
• Preprogrammed definitions on paths through the
  network
• Dynamic Routing Protocols
• Routers automatically discover and maintain
  awareness of the paths through the Network
• Differ on the way they discover and calculate new
  routes to destination networks

19
Dynamic Routing Protocols

• Distance vector protocols
• Link state protocols
• Hybrid protocols

20
Routing Protocols Diversity

• Different requirements for security, stability,
  and scalability
• Routing within a network
• Routing between networks
• New protocols
• Address deficiencies in established protocols.
• Different-sized networks
• Small to medium-sized networks
• Large networks

21
Static Routing

• Coordination Maintenance
• Static routes are not adaptative
• Network Topology changes
• Requires no network bandwidth
• To advertise routes between neighboring devices
• Uses less processor memory and CPU cycles
• To calculate network path

22
Static Routing contd

• Utilization or line tariffs
• Undesirable to send routing advertisement traffic
  through lower-capacity WAN connections.
• Traffic for a host traverses certain network path
• Provide a more secure network environment
• The administrator is aware of all subnetworks
  defined in the environment
• The administrator specifically authorizes all
  communication permitted between these
• To provide more efficient resource utilization

23
Distance Vector Routing

• Each router maintains the distance or cost from
  itself to every known destination
• Represents the overall desirability of the path
• The path represented by the smallest cost becomes
  the preferred path to reach the destination
• Distance vector table
• Periodically advertised to each neighboring
  router
• Each router processes
• Advertisements to determine the best paths
  through the network

24
Dynamic Routing contd

• Advantages
• Easy to implement and debug
• Useful in small networks with limited redundancy
• Disadvantages
• Excessive convergence time in complex
  internetworks
• Routing loops -Unstable packet forwarding
• Solution Maximum number of hops contained in a
  single route.

25
Distance Vector Routing Table

• Periodically transmitted
• To neighboring devices
• Even if no changes have been made
• Periods of increased utilization in reduced
  capacity environments
• Enhancements
• Convergence and counting to infinity
• RIP and BGP are two popular examples

26
DV Routing Table
27
Distance Vector Routing Messages
28
Distance Vector Routing Updates
29
Initiating Tables
30
Initiating Tables contd
31
Initiating Tables contd
32
Updating Routing Tables
33
Updating Routing Tables contd
34
Example
35
Example contd
36
Example contd
37
DVR Features
38
Count to Infinity Problem
39
Count to Infinity causes
40
Count to Infinity Solution 1
41
Count to Infinity Solution 2
42
Link State Routing

• Causes
• The growth in the size and complexity of networks

• Link state
• A link state is the description of an interface
  on a router
• IP address, subnet mask, type of network and its
  relationship to neighboring routers
• Link state database.

43
Link State Routing

• Routers determine network topology
• Each router identifies all other routing devices
  on the directly connected networks.
• Advertise a list of all directly connected
  network links and the associated cost of each
  link
• Link state advertisements (LSAs) with other
  routers in the network

44
Link State Routing

• Each router
• Creates a database detailing the current network
  topology
• The topology database in each router is identical
• Uses the information in the topology database to
  compute the most desirable routes to each
  destination network
• Updates the IP routing table

45
Shortest Path First (SPF)

• The SPF algorithm is used to process the
  information in the topology database
• Tree-representation of the network
• The device running the SPF algorithm is the root
  of the tree
• The output of the SPF algorithm
• List of shortest-paths to each destination
  network
• OSPF

46
SPF Example
47
Hybrid Protocols

• Combine the positive attributes of both distance
  vector and link state protocols
• Like distance vector, hybrid protocols use
  metrics to assign a preference to a route
• Accurate metrics. Like link state algorithms,
  routing updates in hybrid protocols are event
  driven rather than periodic
• Converge more quickly than distance vector
  protocols
• Reduce the overhead of link state updates and
  distance vector advertisements

48
Hybrid Routing Protocols

• Open hybrid protocols exist
• Proprietary EIGRP algorithm
• EIGRP was developed by Cisco Systems, Inc.

49
RIP History
50
RIP Features
51
RIP Packet Format
52
RIP Packets

• Request packets
• Query to neighboring RIP devices to obtain their
  distance vector table
• Indicate if the neighbor should return either a
  specific subset or the entire contents of the
  table.
• Response packets
• To advertise the information maintained in its
  local distance vector table
• The table is automatically sent every 30 seconds.
• The table is sent as a response to a request
  packet generated by another RIP node.

53
RIP Packets contd

• If triggered updates are supported, the table is
  sent when there is a
• change to the local distance vector table
• When a response packet is received
• Information contained in the update is compared
  against the local distance vector table
• If the update contains a lower cost route to a
  destination, the table is updated to reflect the
  new path

54
RIPv2 Subnet Mask
55
RIP Operation
56
RIP on UDP

• RIP packets are transmitted using UDP Datagrams
• RIP sends and receives datagrams using UDP port
  520
• RIP datagrams have a maximum size of 512 octets
• Larger updates are advertised in multiple
  datagrams.
• LAN environments
• RIP datagrams are sent using the MAC all-stations
  broadcast address and an IP network broadcast
  address
• In point-to-point (non-broadcast)
• RIP datagrams are addressed to the destination
  device

57
RIP modes of operation

• Active mode
• Advertise their distance vector table
• Receive routing updates from neighboring RIP
  hosts
• Routing devices
• Passive (or silent) mode
• Receive routing updates from neighboring RIP
  devices
• Do not advertise their distance vector table
• End stations

58
RIP Limitations

• Path cost limits
• The counting to infinity problem enforces a
  maximum cost for a network path
• Upper limit on the maximum network diameter (15
  hops)
• Network-intensive table updates
• Periodic broadcasting of the distance vector
  table can result in increased utilization of
  network resources

59
RIP Limitations

• Relatively slow convergence
• The algorithms rely on timers to initiate routing
  table advertisements.
• No support for variable length subnet masking
• Route advertisements in a RIP environment do not
  include subnet masking information

60
RIPv2
61
RIPv2 Packet Format
62
RIP Security
63
Routing inside UNIX
64
Routing in UNIX contd
65
References

• TCP/IP Tutorial and Technical Overview. IBM 2001
• http//ece.iisc.ernet.in/innic/docs/vlsm.htm
