CS 2130

1
CS 2130

• Lecture 13
• Formal Language Concepts

2
Where are we going?

• Compilers
• or
• How does a computer program translate one program
  into another?

3
Compilers
4
Parts of Compilers
Analysis
(0. Preprocessor)
1. Lexical Analysis 2. Syntax Analysis 3.
Semantic Analysis
Front End
Synthesis
4. Code Generation 5. Optimization
Back End
5
Sidebar...HTML

• What is an HTML file?
• What does a browser do?
• Not all analysis leads to code

6
For today...

• Assume that we have broken a program up into
  pieces called tokens
• a b c
• How does the compiler determine if this statement
  is legal or not?
• To answer we need to first answer another
  question...

Token
Tokens
7
What is a grammar?

• Or to put it another way...

8
What grammar a is?
9
Speech

• How does natural language work when two persons
  communicate?
• One person speaks a language using known words
  arranged in a certain order
• The other person knows the meaning of the words
  and the rules of the arrangements and derives
  meaning

10
A Sentence

• The quick brown fox jumps over the lazy dog.

11
A Sentence

• The quick brown fox jumps over the lazy dog.

verb
noun
noun
article
article
adjective
adjective
adjective
preposition
prepositional phrase
predicate
subject
12
Diagrammatically
fox
jumps
over
dog
Remember in the 3rd grade when you said, "We'll
never see diagramming sentences again?"
13
Natural Language

• Rules of grammar specify legal syntax
• Rules are typically very complex with numerous
  exceptions and special cases

14
Computer Language

• Still use a grammar to specify syntax
• Grammar is much simpler than natural language

15
Grammar

• Sentential forms
• Noam Chomsky MIT 60s and 70s
• Chomsky Type 2 Grammar
• Backus-Naur Form (BNF)
• Algol

16
Example

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltnoun-phrasegt ltcmplx-noungt
• ltcmplx-noungtltprep-phrasegt
• ltverb-phrasegt ltcmplx-verbgt
• ltcmplx-verbgtltprep-phrasegt
• ltprep-phrasegt ltprepgtltcmplx-noungt
• ltcmplx-noungt ltarticlegtltnoungt
• ltcmplx-verbgt ltverbgt ltverbgtltnoun-phrasegt
• ltarticlegt a the
• ltnoungt boy girl flower
• ltverbgt touches likes sees
• ltprepgt with

17
Example

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltnoun-phrasegt ltcmplx-noungt
• ltcmplx-noungtltprep-phrasegt
• ltverb-phrasegt ltcmplx-verbgt
• ltcmplx-verbgtltprep-phrasegt
• ltprep-phrasegt ltprepgtltcmplx-noungt
• ltcmplx-noungt ltarticlegtltnoungt
• ltcmplx-verbgt ltverbgt ltverbgtltnoun-phrasegt
• ltarticlegt a the
• ltnoungt boy girl flower
• ltverbgt touches likes sees
• ltprepgt with

Terminal Symbols
18
Example
ltNon-terminal Symbolsgt

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltnoun-phrasegt ltcmplx-noungt
• ltcmplx-noungtltprep-phrasegt
• ltverb-phrasegt ltcmplx-verbgt
• ltcmplx-verbgtltprep-phrasegt
• ltprep-phrasegt ltprepgtltcmplx-noungt
• ltcmplx-noungt ltarticlegtltnoungt
• ltcmplx-verbgt ltverbgt ltverbgtltnoun-phrasegt
• ltarticlegt a the
• ltnoungt boy girl flower
• ltverbgt touches likes sees
• ltprepgt with

19
Example
ltStart Symbolgt

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltnoun-phrasegt ltcmplx-noungt
• ltcmplx-noungtltprep-phrasegt
• ltverb-phrasegt ltcmplx-verbgt
• ltcmplx-verbgtltprep-phrasegt
• ltprep-phrasegt ltprepgtltcmplx-noungt
• ltcmplx-noungt ltarticlegtltnoungt
• ltcmplx-verbgt ltverbgt ltverbgtltnoun-phrasegt
• ltarticlegt a the
• ltnoungt boy girl flower
• ltverbgt touches likes sees
• ltprepgt with

20
Example
Rules

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltnoun-phrasegt ltcmplx-noungt
• ltcmplx-noungtltprep-phrasegt
• ltverb-phrasegt ltcmplx-verbgt
• ltcmplx-verbgtltprep-phrasegt
• ltprep-phrasegt ltprepgtltcmplx-noungt
• ltcmplx-noungt ltarticlegtltnoungt
• ltcmplx-verbgt ltverbgt ltverbgtltnoun-phrasegt
• ltarticlegt a the
• ltnoungt boy girl flower
• ltverbgt touches likes sees
• ltprepgt with

21
Note

• ltnoungt boy girl flower
• Equivalent to
• ltnoungt boy
• ltnoungt girl
• ltnoungt flower

22
TypicalDerivation
ltsentencegt ltnoun-phrasegtltverb-phrasegt ltnoun
-phrasegt ltcmplx-noungt
ltcmplx-noungtltprep-phrasegt ltverb-phrasegt
ltcmplx-verbgt
ltcmplx-verbgtltprep-phrasegt ltprep-phrasegt
ltprepgtltcmplx-noungt ltcmplx-noungt
ltarticlegtltnoungt ltcmplx-verbgt ltverbgt
ltverbgtltnoun-phrasegt ltarticlegt a
the ltnoungt boy girl flower ltverbgt
touches likes sees ltprepgt
with

• ltsentencegt ltnoun-phrasegtltverb-phrasegt
• ltcmplx-noungtltverb-phrasegt
• ltarticlegtltnoungtltverb-phrasegt
• a ltnoungtltverb-phrasegt
• a boy ltcmplx-verbgt
• a boy verb ltverbgt
• a boy sees

23
BNF Grammar

• Terminal Symbols
• Non-Terminal Symbols
• Start Symbol (non-terminal)
• Rules
• Use grammar to parse statements into n-ary tree
• Each statement becomes a tree
• Terminal symbols correspond to leaf nodes
• Non-terminal symbols correspond to internal nodes
• Start symbol corresponds to root node

24
Example Expression Grammar

• ltexprgt ltexprgt lttermgt lttermgt
• lttermgt lttermgt ltfactorgt ltfactorgt
• ltfactorgt ( ltexprgt ) ltnumgt
• ltnumgt 0 1 2 3 4 5 6 7 8 9

lt...gt Non-terminal
symbols ( ) 0 1 2 3 4 5 6 7 8 9 Terminal
symbols Rules
Non-terminal symbol only appearing on right side
or Left-hand side of first rule
Start symbol
25
Grammars

• ltexprgt ltexprgt lttermgt lttermgt
• lttermgt lttermgt ltfactorgt ltfactorgt
• ltfactorgt '(' ltexpr ')' ltnumgt
• ltnumgt 0 1 2 3 4 5 6 7 8 9
• This grammar will parse arithmetic expressions
  involving and which use parentheses for
  grouping and numbers from 0 to 9
• What if a given "sentence" can't be parsed?

26
Parse Tree(Syntax Tree)

• ltexprgt ltexprgt lttermgt lttermgt
• lttermgt lttermgt ltfactorgt ltfactorgt
• ltfactorgt '(' ltexpr ')' ltnumgt
• ltnumgt 0 1 2 3 4
• 5 6 7 8 9

1 2 3
ltexprgt
ltexprgt

lttermgt
lttermgt
lttermgt

ltfactorgt
ltfactorgt
ltfactorgt
ltnumgt
ltnumgt
ltnumgt
1
2
3

1

2
3
27
Note

• All symbols were used
• Tree has all valid leaf nodes that are terminal
  symbols
• Said to be a "Successful parse"
• Sentence "1 2 3" was syntactically correct

28
Parse Tree(Syntax Tree)
1 2 3

1

3
2
29
Binary Tree!
1 2 3

1

3
2
30
Traversals?
1 2 3

Preorder In order Post order Breadth-first Depth-
first

1
3
2
31
Traversals?
1 2 3

Preorder 1 2 3 In order 1 2 3 Post
order 1 2 3

1
3
2
32
Traversals?
1 2 3

Preorder 1 2 3 In order 1 2 3 Post
order 1 2 3 Preorder returns
Prefix notation similar to that used in Lisp or
Scheme ( 1 ( 2 3))

1
3
2
33
Traversals?
1 2 3

Preorder 1 2 3 In order 1 2 3 Post
order 1 2 3 Preorder can also be used to
reproduce the original tree

1
3
2
34
Traversals?
1 2 3

Preorder 1 2 3 In order 1 2 3 Post
order 1 2 3 In order returns
original expression.

1
3
2
35
What is the value of

• 1 2 3
• a.) 1 2 3 9
• b.) 1 2 3 7
• Why?

36
Traversals?
1 2 3

Preorder 1 2 3 In order 1 2 3 Post
order 1 2 3 Post order returns post-fix
notation otherwise known as Reverse Polish
Notation or RPN

1
3
2
37
Note

• Both preorder and postorder traversals (which
  generated prefix and postfix notation) which
  followed the "normal" rules of precedence did so
  because the grammar was set up to do so.

38
Historical Note

• Hewlett-Packard Calculators typically use the RPN
  or postfix notation system
• The following sequence of keystrokes would
  calculate as follows
• 1 ltentergt
• 2 ltentergt
• 3

39
RPN Stack Calculators
stack
0
0
0
1
(Display)
After pressing 1
40
RPN Stack Calculators
stack
0
0
1
1
(Display)
After pressing ltENTERgt
41
RPN Stack Calculators
stack
0
0
1
2
(Display)
After pressing 2
42
RPN Stack Calculators
stack
0
1
2
2
(Display)
After pressing ltENTERgt
43
RPN Stack Calculators
stack
0
1
2
3
(Display)
After pressing 3
44
RPN Stack Calculators
stack
0
0
1
6
(Display)
After pressing
45
RPN Stack Calculators
stack
0
0
0
7
(Display)
After pressing
46
The preceding sequence brought to you by

• Hewlett Packard

47
Parse Tree

• Introduces
• Syntax
• Semantics
• Order of Operations
• Must be built-in to grammar

48
Bad Grammar!

• ltexprgt ltexprgt ltexprgt
• ltexprgt ltexprgt
• '(' ltexprgt ')'
• 0 1 2 3 4
• 5 6 7 8 9

49
ltexprgt ltexprgt ltexprgt ltexprgt
ltexprgt '(' ltexprgt ')'
0 1 2 3 4 5 6 7
8 9
Problem?
50
ltexprgt ltexprgt ltexprgt ltexprgt
ltexprgt '(' ltexprgt ')'
0 1 2 3 4 5 6 7
8 9
What about?
51
ltexprgt ltexprgt ltexprgt ltexprgt
ltexprgt '(' ltexprgt ')'
0 1 2 3 4 5 6 7
8 9
Ambiguous!
52
Ambiguous grammars have their place.
53
Metasymbols

• means OR (alternation)
• means "defines a"
• lt...gt means a non-terminal
• (...) means grouping
• ' means enclosed metasymbol is terminal
• There are others...
• ...and there is no "standard" set of symbols.

54
Metasymbol Examples

• ltnumgt 0123456789
• ltsigned numgt ltnumgt - ltnumgt
• ltsigned numgt (-) ltnumgt
• Using pipe in Unix
• foo '' bar '' baz

55
Questions?
56
