LOD Metrics

1
LOD Metrics

• Jonathan Blow
• Bolt Action Software
• jon_at_bolt-action.com

2
Motivation

• Spent a lot of time on terrain research
• Goal spend energy wisely
• Goal Maximize simplicity and benefit
• Communicate what I see in the academic papers
  from being real far into it.
• Disclose the things you wont read in anyones
  LOD paper.

3
Lecture Structure

• Goal of LOD
• Choosing a metric to meet that goal
• See how implementation details get in the way
• Look deeper at what our algorithms are doing
• Examine the role of analysis in formulating these
  algorithms.

4
I. The Goal of LOD
5
LOD is about reducing resource usage

• Usually triangle, but also textures, etc
• We substitute cheaper models where people
  wouldnt notice the difference
• This is not a very formal definition

6
No Objective Quality Goal

• Scientific method test hypothesis against world
  to determine truth or falsehood
• LOD researchers are pulling this stuff out of
  their ass (e.g. metric).
• The more complex the algorithm, the more
  ass-pulling is involved -gt more likely it is
  wrong.

7
Objective Goal Analogy - PSNR

• Used widely in image processing
• Definition L2-norm of the N-vector between two
  images.

8
Drawbacks of PSNR

• Doesnt match human visual system
• e.g. Each pixel independent
• People are working on replacements, nobody agrees
  on one

9
The Order in whichBugs Get Fixed

• Things that dont compile
• Things that crash
• Obvious functional errors
• Subtle functional errors that require careful
  analysis to diagnose and that still leave the
  software pretty much working.

10
II. Choosing a metric and using it
11
Metrics in the small vs. in the large

• A common metric is projected pixel error
• We dont have anything in the large (analogy of
  PSNR)

12
To be fast, algs degrade tess efficiency

• EQS or progressive mesh - mega conservative
• regular samples for BTT vs TIN
• structure of BTT forces extra splits (crack
  fixing)
• top-down view-dependant algorithms give up tess
  efficiency (often without realizing it!)

13
Measurement of projected pixel error computation
is arbitrary

• GH along normal
• LK along z direction
• Why not measure terrain along normal? Or a
  general mesh along local verticality? What about
  texture popping? Etc.

14
Metric as simplifier

• breaks down lots of complex spatial relations
  into e.g. a scalar
• algorithms try to use vertex correlation to speed
  things up
• they usually use the scalar and forget that all
  this info is available
• Instead use isosurfaces, big speed improvement.

15
III. Implementation details get in the way
16
Icky non-cooperation of different data types
(tri, tex, light)
Changes in vert positions
geometry
Changes in normals
texture
irradiance
how the scene looks
17
How might this be simplified?

• Example of LODd voxel space
• galactic armada of signal processing

18
Bump mapping (and other anisotropy eg BRDF)
screws us

• Our hardware and API implementations give us less
  flexibility with this kind of lighting than with
  old-school lambertian stuff
• tangent frames can only be pinned to vertices
• This sucks ass when combined w/ LOD.

19
IV. Looking deeper at our algorithms processes.
20
Edge collapse is a linear interpolation between
samples.

• When we look at this as a filter what does it
  tell us?
• Translate bilinear filter into sequence of
  fundamental signal processing operations.
• What this does to frequency content fold, then
  mirror, then transfer by 1.5cos(x).

21
V. Better planning of future algorithms
22
Metric defines system behavior

• So we can tell a lot about what a system will do
  by thinking about the metric and the data it
  operates on.
• This can help us understand where to best focus
  our effort.

23
Example What it means to limit projected pixel
error

• Metric projected pixel error
• Algorithm keep projected error near some
  constant
• Effect Screen-space triangles are roughly the
  same size

24
In an LODd scene, polygons tend to be roughly
the same size in screen pixels.
25
A large percentage of polygons are small and
close (50? 60?)
26
Why polygons tend to be the same size in screen
pixels.

• Projected size of any delta value is roughly
  constant (stabilized point of algorithms
  action). ?/z k
• Big delta values tend to be attached to big
  edges, small deltas to small edges. ?
  md d edge length, m some constant

27
Why polygons tend to be the same size in screen
pixels.

• ? /z k ? ? 1/z1 k ?2/z2
• ? md ? md1/z1 k md2/z2
• Screen area ? 1/2(d/z)2 1/2(k/m)2
• This is a constant.

28
Conclusions

• Push metric in the small into the realm of the
  frame buffer sample? (Video cards already screw
  the pooch at this scale so maybe we would be just
  hiding all our error in there)
• Thank-you and good night.
