KIPA Game Engine Seminars

1
KIPA Game Engine Seminars
Day 6

• Jonathan Blow
• Ajou University
• December 2, 2002

2
Level-of-Detail MethodOverview

• Traditional Purpose Speed Boost
• Ideal Render a fixed number of triangles always
• Doesnt matter how far your view stretches into
  the distance
• Diagram of pixel tesselation
• Object detail / triangle count as a function of
  distance

3
Future PurposeGeometric Antialiasing

• Discussion of scenes with many small objects far
  away
• In a rendering paradigm like MCRT we get a
  certain amount of antialiasing for free
• When projecting geometry onto the screen, we do
  not we need to implement something that provides
  antialiasing for us

4
Level-of-Detail Methods

• Static mesh switching
• Progressive mesh
• Continuous-LOD mesh
• Issues involving big objects (static and
  progressive mesh not good enough?)

5
Static mesh switching

• Pre-generate a series of meshes decreasing in
  detail
• Switch between them based on z distance of the
  mesh from the camera
• Perhaps be more analytical and switch based on
  max. projected pixel error?
• Nobody actually does this because it is far too
  conservative

6
Progressive Mesh

• Generate one sequence of collapses that takes you
  from high-res to 1 triangle
• Dynamically select number of triangles at runtime
• Works well with modern 3D hardware since you only
  modify a little bit of the index buffer at a
  time.

7
Progressive MeshDisadvantages

• Relies on frame coherence (bad!)
• Interferes with triangle stripping and vertex
  cache sorting (they become mutually impossible).
• High code complexity, and it makes everything
  else more complicated, and adds restrictions to
  everything else
• Example of normal map generation restricted to
  object space

8
Continuous Level-of-DetailAlgorithms

• Lindstrom-Koller, ROAM, Rottger quadtree
  algorithm
• Dynamically update tessellation based on estimate
  of screen-space error
• Crack fixing between adjacent blocks, etc

9
Continuous LOD

• Example of binary triangle trees
• There are other formats (quadtree, diamond, etc)
  but the ideas are similar

10
Continuous LODDisadvantages

• Extremely complicated implementations
• Slow on modern hardware
• Extreme reliance on frame coherence (bad!)
• Not conducive to unified rendering (hard to make
  work on curved surfaces, arbitrary topologies)

11
Continuous LOD

• Has a lot of hype in the amateur and academic
  communities
• Is currently not competitive with other LOD
  approaches
• This is not likely to change any time soon

12
LOD Metrics
13
Introduction

• We need an effective way to benchmark / judge LOD
  schemes
• The academic world is not really doing this right
  now!
• We need a standard set of data with comparable
  results
• University of Waterloo Brag Zone for image
  compression

14
LOD Metric?

• We often create metrics for taking each small
  step in a geometric reduction
• We dont have a metric for comparing a fully
  reduced mesh with the source model or another
  reduced mesh
• Because our mesh representations are so ad hoc

15
Image Compression guyshave a metric

• (even though they know its not that good)
• PSNR measures difference between compressed image
  and original
• They know it has problems (not perceptually
  driven) and are working on a better metric
• But at least they have a way of comparing
  results, which means they are sort of doing
  science!

16
Metric ideas

• Sum of closest-point distances
• Continuous, which is good
• Very expensive to compute
• Non-monotonic (!), which is bad
• Monotonic for small changes, usually, which might
  be good enough
• Ignores texture warping, which is bad
• Unless we try it in 5-dimensional space
• Ignores vertex placement
• Important for rasterization (iterated vertex
  properties!)
• Example of big flat area
• Ignores cracks in destination model

17
Lindstrom/Turk screenspaceLOD comparison

• Guide compression of a mesh by taking snapshots
  of it from many different viewpoints and PSNRing
  the images
• This can work but PSNR is not necessarily stable
  with respect to small image-space motions

18
Lindstrom/Turk screenspaceLOD comparison

• (Talking about paper, showing figures from it)

19
The Fundamental Problem

• Our rendering methods are totally ad-hoc we have
  3 different things
• Vertices
• Topology
• Texture
• A metric that uniformly integrates these things
  is very difficult.

20
Complexity of metric

• The more complicated a metric is, the more
  difficult it is to program correctly, ensure we
  are using it correctly
• That our simplest possible metric should be
  something so complicated that is a bad sign.

21
Compare with Voxels

• Voxel geometry representations can basically use
  something like PSNR directly no need for
  complicated metrics
• Lightfields can also (though its a little harder)

22
Digital Geometry Processing

• Work by Peter Schroeder at Caltech, and many
  others
• Attempts to develop DSP-like ideas for geometry
  manipulation
• Heavy use of subdivision surfaces

23
(Overview of subdivision surfaces)
24
How DGP works

• Apply a scaled filter kernel to the neighborhood
  of a vertex
• Like wavelet image analysis in its multiscale
  aspects
• But unlike wavelets/DSP in that the
  inputs/outputs are not homogeneous
• What exactly is the high-pass residual after a
  low-pass filter?
• This is because of that whole topology-different-f
  rom-vertices thing

25
Actual effective DGP would be ?

• I dont know. (Its a hard problem!)
• Spherical harmonics would work, for shapes
  representable as functions over the sphere

26
Solutions/Details
27
What I Use

• Garland/Heckbert Error Quadric Simplification
• Static Mesh Switching
• I want to do a unified renderer this way
  (characters, terrain, big airplanes, whatever)
• People seem to think crack fixing is hard but it
  is actually easy
• Maybe thats why people havent tried this yet?

28
Discussion ofGarland/Heckbert Algorithm

• (whiteboard)

29
Garland/Heckbert References

• Surface Simplification Using Quadric Error
  Metrics
• Simplifying Surfaces with Color and Texture
  using Quadric Error Metrics

30
G/H is useful also if you are making progressive
meshes

• It just tells you how to collapse the mesh
  doesnt dictate how you will use that information.

31
Review of GH AlgorithmIn code

• (looking at the code)
