Evaluation with Users

• SEng 5115University of Minnesota
• John Kruse
• Spring 2008

2
Evaluation with usersThe Gold Standard

• Big investment, big potential
• Big investment is debatable
• Potential isnt
• Many issues
• dealing with human subjects
• which users? which tasks?
• when in the process?
• what to measure?
• how to measure?

3
An early test
4
Why not just design

• The Superbook story
• Landauer, Trouble with Computers, at BellCore
• Superbook was online version of 1,000s pages
  manual
• First try wasnt better than paper
• even though designed by knowledgeable experts
• 2nd was better than paper, 3rd lots better

5
Why not just interview

• People dont know what they know
• People dont remember what they did
• What people say about their work is different
  from what they actually do
• Occasional mismatches between what people like
  and what works
• People like what works on desktop
• But no correlation on web

6
Why not just inspect

• Heuristic evaluation (HE) is good, cheap
• Tends not to catch the domain-specific stuff
• Unless you have double experts (Domain and
  usability experts)
• Tends not to have a task focus
• What is good about a Web site
• Users behavior is chaotic
• HE and testing complement each other

7
Early in the process

• Early is important
• Low investment
• Less inertia --gt time to change
• Mock-ups and drawings are OK
• issues in how to handle user choice
• Partial prototypes when necessary

8
Early, on-the-fly prototyping

• Paper prototypes Testing redesign
• Revise during test session
• Allow entire team to participate
• building prototypes
• watching users

9
Late in the process

• Can measure productivity, timing, etc
• May require more elaborate prototype
• or actual code
• Post-release usability sessions are useful
• Observational or designed test
• Flexibility of development organizations
  response is limited
• Cost of fixing errors goes up
• If late testing is the only testing is it worth
  it?

10
User testing as team building

• Prototypes provide a medium for people to work
  together
• User testing can be fun
• Even if users are abusing your finest work
• Make observers stay away (behind glass)
• Managers have seen teams crystallize around paper
  prototyping user testing

11
What to measure 1 of 3

• Feasibility of a product approach
• Utility acceptance
• Microwave Cakes
• Ease of initial use learning
• Intuitiveness
• Need for manual
• Icon interpretation
• Problems, questions, reactions
• What users are thinking

12
What to measure 2 of 3

• Ease of remembering
• Is it retained, or does it conflict with previous
  or interleaved experiences learning
• Efficiency of Use / Productivity
• Mostly later for usability measurement
• Limited applicability early in design
• Thinking Aloud related interrupts interfere
  with timing
• But timing can be done early in some cases
• Parts of workflow besides software

13
What to measure 3 of 3

• Affective reactions
• Do they like it?
• Which parts do they like?
• Measuring affect choice can be tricky
• Observation during use is the fundamental method
• Forced choice and ratings can help

14
Affective reactions

• It may relate to self-evaluation perceived
  competency more than aesthetics
• In task-oriented systems
• On the Web, marketing considerations
• If there are problems, then probe
• The persons reactions to similar products
• The background and experience of the person
• Their expectations about the technology

15
Home page visual impact

• 5-second test show users the home page
• What does the owner do, what is the companys
  business
• What attracted your attention? What did it mean,
  or how did it make you feel?
• What can you do on this page?

16
Wizard of Oz

• UI can be simple
• All you need to do is envision the use
• Smoke mirrors are quite adequate

3 books detected War Peace HOLD for M. Smith
17
Example Concept feasibility productivity

• Library workstation with RFID
• Study the utility of the device
• Study acceptability of approach
• Is multiple book at a time check-in better then
  one book at a time?
• Wizard of Oz study
• Visual Basic, Monitor, Speakers, Cardboard Box
• Marked books
• Experimenter

18
Library Wizard of Oz (cont)

• Participants thought it was very realistic
• Multiple was not better
• Handling exceptions is disruptive
• Discovered early cheaply
• Continues to be a business goal

19
Productivity data

• Specific measurements
• Median/mean time for task
• Comparison of alternatives
• Focus on one type of test at a time
• Think-aloud can slow down completion times

20
Experimental design

• Most user testing is not rigorous hypothesis
  testing experimentation
• has too low n
• lacks good control conditions
• Usually is formative evaluation
• Summative evaluation
• Usually experiments
• Work out the statistics involved
• Statistics cookbooks

21
Experimental design principles

• Counterbalancing
• Logically remove the possibility of competing
  explanations
• If you want to study system X vs system Y
• DO not have all your participants do X, then Y
• Fatigue will decrease performance
• Practice will increase it
• You CANT really predict which will win

22
Testing usability of icons 1

• 17 icons for UI, 4 sets created
• Ease of learning
• Show icons, ask what do you think
• Present task/description, have user pick from
  entire set
• Since icons are not seen in isolation
• Present all names, all icons, have users match

23
Testing usability of icons 2

• Efficiency
• Users who had learned the icons
• Given name, then timed on Y/N discrimination
• Given random set, asked to click on specified
  icon
• Subjective satisfaction
• Rate each one easy -- difficult
• Select preferred one from 4 alternatives

24
General User Test guidelines

• Plan ahead of time
• what data to record
• what instructions to deliver
• what to do if user falls off prototype
• when to provide help, and what help
• Know your objectives
• but never lose sight of the user

25
General guidelines

• Do a pilot study
• Get professional help for big studies
• In general, it is better if developers
  designers arent present during testing
• too much bias
• subtle clues
• stay behind one-way glass

26
Documents for user testing

• Observer briefing
• Welcome for participants
• Introduction
• Informed consent
• Training materials
• Test task(s)

• Data collection sheet
• Data summary sheet
• Data analysis sheet
• Pre-test questionnaire
• Post-test questionnaire

27
Tasks

• Keep close to the real tasks
• May need to shorten some for time reasons
• Task selection heuristics
• Common tasks
• Areas of risk
• Safety, New approaches, Uncertainties
• Design the tasks
• Iteratively
• Get them reviewed

28
Test tasks 1

• What you want them to accomplish
• Typically not how
• Example Create a form letter using MS Word,
  which results in Thank-you letters to 3
  recipients, each with individualized
• Salutation (Dear Aunt Abigail)
• Name of gift (necktie)
• Attribute of gift (color)

29
Home Health Clinical Test tasks 1

• Set up the new patient Jinnys visit calendar for
  a visit frequency of 3x Week for 2 Weeks
• Locate todays visit schedule all patients to
  be seen today by a Ruth, a nurse
• Initiate a visit note for Sam, an existing
  patient, from todays schedule
• ...and define the discipline, program,
  activities type of services to be provided

30
User-generated tasks

• Users behave differently when they care about the
  task
• On the web, with eCommerce, lots of potential
  tasks
• Interview them, let them define tasks that they
  can do with a web site.

Spool, User Interface Engineering
31
Observers

• Better to be there
• Than hear / read about it afterwards
• Seeing video clips can be very persuasive
• Better to be few unobtrusive
• No reactions to users choices
• No talking
• Unless behind one-way mirror

Marketing mgr at a session, standing right behind
the user, saw a new design (two columns
reversed), and said aloud Amy, youve got it all
wrong Social situation use process to tell
this higher-ranking customer that it is not OK
to talk, and why. Amy had good reasons for
showing in this order (counterbalancing), and for
not biasing.
32
Users

• Real users, as much as possible
• If real users are scarce, try surrogates
• If 3M people cant use it, then maybe its too
  hard
• Availability of users might influence testing
  approach
• Recruiting is non-trivial effort
• Money always helps

33
Welcome, Orientation

• Welcome, description of project
• Description may be truncated
• Brief intro to usability testing concept
• Test is of software under real-world conditions
• You wont help them
• Unless necessary
• Explanations afterwards
• How long it will take

34
Participant (Human Subjects)

• Remind them that you are not testing them
• You are testing your own product
• But tell them you would rather not help them
• Informed, voluntary consent
• Understand that they can quit at any time
• Explain test in lay terms
• Privacy anonymity, use of image/voice

35
Informed Consent

• This is very important
• Participant is volunteer
• Can leave at any time
• Is video being collected?
• What will it be used for?
• Who will see it?
• If you want to record, get permission

36
Pre-test questionnaire

• About users background
• Experience with OS, software, etc.
• Experience with job
• How many hours per day do you use a computer?
• What is your educational level (degrees,
  certificates, fields of study)?

37
Training Materials

• What do they need to know?
• What is real-world?
• What will they get at work for training?
• Dont just look at best, or worst-case
• Instruct about software conventions
• Task orientation
• Explain things very thoroughly
• Practice, demonstrate (?)

38
Thinking-Aloud Method 1

• User asked to think-aloud
• Running commentary, like at sports event
• What they are thinking or looking for or trying
  to do
• What they like, dont like, good, bad, anything
  is OK and helpful
• They should guess, ask questions
• You wont answer them

39
Thinking-Aloud Method 2

• They should not let this interfere with their
  normal process
• Generally, dont explain decisions, or make
  design suggestions, until after then its
  welcome
• Have them practice it
• Or have the first task be reasonably easy

40
How to help users

• Not too soon
• Encourage them to try things out
• Be encouraging in general
• Tell them they cant make a mistake
• You will learn from everything they do or say
• When to help
• If they get stuck stay stuck
• When they look upset

41
How to help users

• Dont give answers if at all possible
• Ask the user questions
• General at first
• Ones that will get them thinking about their
  conceptual model
• Then more specific (Leading) questions
• Give them hints
• General at first, then more specific
• Is their conceptual model OK?

42
Making users comfortable

• Break after every task
• Recap, offer drink break
• Answer users questions if possible
• Dont let users start designing
• Until after users have completed their tasks

43
Pairs of participantsA thinking aloud variant

• Thinking Aloud is difficult for people to do
• Users can work in pairs
• They talk to each other
• This is more comfortable for them

44
Test facilitators role

• Flight attendant
• Responsibility for comfort safety of subjects
• Prevent distress, embarrassment
• Scientist
• During
• Maintain objectivity
• Gather data
• Before After
• Plan
• Reports

45
Data Collection Sheet

• For quick observation, without recording where in
  program
• Success, comments they made
• Failure, kind of failure

46
Web usability testing - Data

• Things happen fast
• Abbreviate, or
• Prepare checkoff sheets with likely actions
• Prepare page miniatures, to make notes on

47
Special Materials - Greeking test

• Or Mumble text
• For layout
• On web site
• Greek all the text, but keep graphics
• Evaluate alternative web page designs
• Does layout communicate function?
• Or, does it matter where items go?
• Ksdiudhk dkji
• Mm Mmmmm mmmm

48
Videotaping

• Usually too much work to go back over it
• Good for driving home your points
• Developers who werent there
• Disagreement on interpretation
• Management
• Split screen useful
• Camera for screen, camera for face

49
Modern Data Capture

• Morae, from Techsmith
• Screen Cursor Clicks
• Face Voice
• Keystrokes
• Pages with timestamps
• Optional concurrent observers time-stamped
  events
• Start Ron video with Morae

50
Post-test questionnaire

• Ratings scales are good
• Then ask them to talk elaborate
• How hard was it (Extremely easyModerately
  difficultExtremely difficult)
• Would you use it (Neversometimesalways)
• Did you understand the part where...
• Did you like it, find it attractive, etc?
• Anything missing from it?

51
Reporting the findings

• Say something positive
• Make recommendations to improve things
• For Summative evaluation
• Common Industry Format for Usability Test Reports
  Version 1.1, October 28, 1999
• Produced by the Industry USability Reporting
  project www.nist.gov/iusr
• For Formative evaluation
• Write for your audience

52
Observing what didnt happen 1

• Establish expectations for user behavior
• e.g., this link will be followed for this reason
  by this kind of user
• Note when it does not happen, explain
• Look for what didnt take place in debriefing
  afterwards
• e.g. users in a study didnt look in online
  books TOCs

53
Observing what didnt happen 2

• Users at antique fair did not use Community
  link
• They used search facility, found peoples web
  sites
• Said I didnt know she had a web site -- I know
  her
• Look for behavior that doesnt make sense

54
Empirical studies of usability testing

• Usability test of a web site, by 9 teams
• All teams given same objectives for the same
  interface
• Each team then conducted a study using their
  organization's standard procedures and
  techniques.
• Molichs

55
Results of study of usability testing

• More than 300 problems found in total
• Most were "reasonable and in accordance with
  generally accepted advice on usable design."
• There wasn't a single problem that every team
  reported.

56
Tasks as the basis of usability testing

• 9 teams created 51 different tasks for the same
  UI
• Each task was well designed valid
• but little agreement on which tasks were
  critical.
• If each team used the same best practices, then
  they should have all derived the same tasks from
  the test scenario

57
What to do to improve things

• Task design is important
• Agree on them
• Maybe Goals are more important
• Better result reporting is needed
• The teams reports differed widely
• Ranged from 5 pages to 52 pages
• Iterations are useful
• With intervening design changes
• Culture attitude of continuous testing

58
Empirical ResultsHow much is enough?

• For applications, rule of thumb 8 is plenty
• 80 problems w 4-5 users
• For some web sites 8 is not enough
• Task purchase CD online (general)
• Important, new problems with each of 18 users
• 247 total obstacles-to-purchase, 5 new per user

Spool etc, User Interface Engineering, CHI 2001
-- We conducted usability tests on an e-commerce
web site using a very straightforward task
buying a CD from an online music store. We chose
users who had a history of purchasing music
online. We asked these users to make a shopping
list of CDs they wanted to buy and gave them
money to spend on these items.
59
Is 8 really enough?

• It depends
• For iterative UCD, 5-6 users OK
• To find all usability problems requires a large n
• Sample of tasks matters need good coverage
• Can you do repeated trials with same user?
• Or do they learn all the workarounds?

60
How many users

• One at a time, at 3M and Microsoft
• Then made changes
• Then ran another
• Achieved good results
• Some opportunities just make sense
• Weve had 3 observers in the room
• With no obvious ill effects
• Except I needed to moderate

61
Other techniques Surveys

• QUIST Questionaire for User Interaction
  Satisfaction, Univ of Maryland
• How long have you worked on this system?
• How many operating systems have you worked with?
• Overall reaction to the system
• Terrible .. Wonderful
• Frustrating Satisfying
• Characters, screen layouts, terminology
• questions about all aspects of a system

62
Logging to study use

• User actions performance
• Page visits
• High-frequency search terms
• Search results, success, etc.
• High-frequency error messages
• Special Events
• Back button
• History / Bookmarks / Favorites

63
Project assignment

• Take a few good questions
• Describe how you want the data to look
• Or at least what the comparisons will be
• To help you make business decisions
• Dont talk about how you would process it
• How would you summarize large numbers of episodes
  of use, with people taking different paths, and
  dropping out at different points?

64
Framework for Logging Usability Data (FLUD)

• Design of a File Format for Logging Website
  Interaction
• National Institute of Standards and Technology
  Special Publication 500-248
• Web Metrics Testbed
• tools and techniques that support rapid, remote,
  and automated testing and evaluation of website
  usability http//zing.ncsl.nist.gov/WebTools/

65
Opentracker.net

• Website statistics provide insight
• Make daily decisions based on customer behavior
• Traffic statistics are a form of direct feedback
• Generate marketing numbers - not guesswork
• Learn what customers do adjust content to meet
  their needs
• Adjust strategies according to what works
• Identify non-effective strategies and drop them
• Profit from informed advertising and content
  management decisions

66
Other data-gathering techniques

• Online/telephone consultants
• Online suggestion box
• Interviews, focus panels
• Eye movements
• Example from useit.com
• Using Eye Tracking to Compare Web Page Designs A
  Case Study
• Agnieszka Bojko. Journal of Usability Studies,
  Issue 3, Volume 1, May 2006, pp. 112-120

67
Field Experiments Observation

• Productivity experiments on book sorting at a
  library
• Act as though you had some device
• Do the devices work ahead of time
• Ask user to do the newly-defined (partial) task
• Observational studies
• Where does the time go
• Whats it worth to automate a step

68
Summary

• Get real (representative) users
• Orient them
• Testing product not them
• They can quit. OK to record?
• Talking aloug
• Tell them
• what you want them to accomplish
• not how to do it
• Let them do it
• Train only as much as is realistic
• Help only as necessary, asking hinting at first
• Note what they so
