Title: Parameterized Complexity
1Parameterized Complexity
- Hans Bodlaender
- IPA Basiscursus Algoritmiek
2Today
- First session
- Parameterized complexity what is it about
- FPT algorithms branching
- FPT algorithms color coding
- Hardness proofs
- Second session
- FPT algorithms Kernelisation
- FPT algorithms Iterative compression
- Third session
- Treewidth
31
- Introduction
- Parameterized complexity
- What is it about?
4Fixed Parameter Complexity
- Many problems have a parameter
- Analysis what happens to problem when some
parameter is small
5Motivation
- In many applications, some number can be assumed
to be small - Time of algorithm can be exponential in this
small number, but should be polynomial in usual
size of problem - Or something is fixed
6Parameterized problem
- Given Graph G, integer k,
- Parameter k
- Question Does G have a ??? of size at least (at
most) k? - Examples vertex cover, independent set,
coloring,
7Examples of parameterized problems (1)
- Graph Coloring
- Given Graph G, integer k
- Parameter k
- Question Is there a vertex coloring of G with k
colors? (I.e., c V 1, 2, , k with for all
v,wÎ E c(v) ¹ c(w)?) - NP-complete, even when k3.
8Clique
- Subset W of the vertices in a graph, such that
each pair has an edge
9Examples of parameterized problems (2)
- Clique
- Given Graph G, integer k
- Parameter k
- Question Is there a clique in G of size at least
k? - Solvable in O(nk) time with simple algorithm.
Complicated algorithm gives O(n2k/3). Seems to
require W(nf(k)) time
10Vertex cover
- Set of vertices W Í V with for all x,y Î E x Î
W or y Î W. - Vertex Cover problem
- Given G, find vertex cover of minimum size
11Examples of parameterized problems (3)
- Vertex cover
- Given Graph G, integer k
- Parameter k
- Question Is there a vertex cover of G of size at
most k? - Solvable in O(2k (nm)) time
12Three types of complexity
- When the parameter is fixed
- Still NP-complete (k-coloring, take k3)
- O(f(k) nc)
- W(nf(k))
13Fixed parameter complexity theory
- To distinguish between behavior
- O( f(k) nc)
- W( nf(k))
- Proposed by Downey and Fellows.
14Parameterized problems
- Instances of the form (x,k)
- I.e., we have a second parameter
- Decision problem (subset of 0,1 x N )
15Fixed parameter tractable problems
- FPT is the class of problems with an algorithm
that solves instances of the form (x,k) in time
p(x)f(k), for polynomial p and some function f.
16Hard problems
- Complexity classes
- W1 Í W2 Í Wi Í WP
- Defined in terms of Boolean circuits
- Problems hard for W1 or larger class are
assumed not to be in FPT - Compare with P / NP
17Examples of hard problems
- Clique and Independent Set are W1-complete
- Dominating Set is W2-complete
- Version of Satisfiability is W1-complete
- Given set of clauses, k
- Parameter k
- Question can we set (at most) k variables to
true, and al others to false, and make all
clauses true?
18So what is parameterized complexity about?
- Given a parameterized problem
- Establish that it is in FPT
- And then design an algorithm that is as fast as
possible - Or show that it is hard for W1 or higher
- Try to find a polynomial time algorithm for fixed
parameter - Or even show that it is NP-complete for fixed
parameters - Solve it with different techniques (exact or
approximation)
19FPT techniques
- Branching algorithms
- Bounded search trees
- Greedy localization
- Color coding
- Kernelisation (local rules, global rules)
- Induction
- Iterative compression
- Extremal method
- Win/Win
- Well quasi ordering
- Structures (e.g., treewidth)
FollowingSloper/Telle taxonomy
20Disclaimer
- Here focus on techniques, not on best known
results - Time arguments often too crude
- Also parameterized problems are considered with
something else as parameter - Pair of integers, string,
- Assumed to be fixed
- Can be mapped to integer
212
- FPT Algorithmic techniques
- Branching
22Branching
- More or less classic technique of search tree
- Counting argument helps to keep size of search
tree small - At each step, we recursively create a number of
subproblems answer is yes, if and only if at
least one subproblem has yes as answer
23Vertex cover
- First example vertex cover
- Select an edge v,w. Note that a solution
includes v or it includes w - If we include v, we can ignore all edges incident
to v in subproblems
v
w
24Branching algorithm for Vertex Cover
- Recursive procedure VC(Graph G, int k)
- VC(G(V,E), k)
- If G has no edges, then return true
- If k 0, then return false
- Select an edge v,w Î E
- Compute G G V v (remove v and incident
edges) - Compute G G V w (remove w and incident
edges) - Return VC(G,k 1) or VC(G,k 1)
25Analysis of algorithm
- Correctness
- Either v or w must belong to an optimal VC
- Time analysis
- At most 2.2k recursive calls
- Each recursive call costs O(nm) time
- O(2k (nm)) time FPT
26Independent Set on planar graphs
- Given a planar graph G(V,E), integer k
- Parameter k
- Question Does G have an independent set with at
least k vertices, i.e., a set W of size at least
k with for all v, w Î V v,w Ï E - NP-complete
- Easy to see that it is FPT by kernelisation
- Here O(6k n) algorithm
27The red vertices form an independent set
28Branching
- Each planar graph has a vertex of degree at most
5 - Take vertex v of minimum degree, say with
neighbors w1, , wr, r at most 5 - A maximum size independent set contains v or one
of its neighbors - Selecting a vertex is equivalent to removing it
and its neighbors and decreasing k by one - Create at most 6 subproblems, one for each x Î
v, w1, , wr. In each, we set k k 1, and
remove x and its neighbors
29v
w1
w2
30Closest string
- Given k strings s1, ,sk each of length L,
integer d - Parameter d
- Question is there a string s with Hamming
distance at most d to each of s1, ,sk - Application in molecular biology
- Here FPT algorithm
- (Gramm and Niedermeier, 2002)
31Subproblems
- Subproblems have form
- Candidate string s
- Additional integer parameter r
- We look for a solution to original problem, with
additional condition - Hamming distance at most r to s
- Start with s s1 and rd ( original problem)
32Branching step
- Choose an sj with Hamming distance gt d to s
- If Hamming distance of sj to s is larger than
dr NO - For all positions i where sj differs from s
- Solve subproblem with
- s changed at position i to value sj (i)
- r r 1
- Note we find a solution, if and only one of
these subproblems has a solution
33Example
- Strings 01113, 02223, 01221, d3
- First position in solution will be a 0
- First subproblem (01113, 2)
- Creates three subproblems
- (02113, 1)
- (01213, 1)
- (01123, 1)
34Time analysis
- Recursion depth d
- At each level, we branch at most at d r 2d
positions - So, number of recursive steps at most d2d1
- Each step can be done in polynomial time O(kdL)
- Total time is O(d2d1 . kdL)
- Speed up possible by more clever branching and by
kernelisation
35More clever branching
- Choose an sj with Hamming distance gt d to s
- If Hamming distance of si to s is larger than
dr NO - Choose arbitrarily d1 positions where sj differs
from s - Solve subproblem with
- s changed at position i to value sj (j)
- r r 1
- Note still correct, and running time can be
made O(kL kd dd)
36Technique
- Try to find a branching rule that
- Decreases the parameter
- Splits in a bounded number of subcases
- YES, if and only if YES in at least one subcase
373
- FPT Algorithmic techniques
- Color coding
38Color coding
- Interesting algorithmic technique to give fast
FPT algorithms - As example
- Long Path
- Given Graph G(V,E), integer k
- Parameter k
- Question is there a simple path in G with at
least k vertices?
39Problem on colored graphs
- Given graph G(V,E), for each vertex v a color
in 1,2, , k - Question Is there a simple path in G with k
vertices of different colors? - Note vertices with the same colors may be
adjacent. - Can be solved in O(2k (nm)) time using dynamic
programming - Used as subroutine
40DP
- Tabulate
- (S,v) S is a set of colors, v a vertex, such
that there is a path using vertices with colors
in S, and ending in v - Using Dynamic Programming, we can tabulate all
such pairs, and thus decide if the requested path
exists
41A randomized variant
- For each vertex v, guess a color in 1, 2, , k
- Check if there is a path of length k with only
vertices with different colors - Note
- If there is a path of length k, we find one with
positive chance ( 2k /k!) - We can do this check in O(2k nm) time
- Repeat the check many times to get good
probability for finding the path
42Derandomization
- Instead of randomly selecting a coloring, check
all colorings from a k-perfect family of hash
functions - A k-perfect family of hash functions on a set V
is a collection H of functions V 1, ,k, such
that for each set W Í V, Wk, there exists an h
Î H with h(W) 1, ,k - Algorithm
- Generate a k-perfect family of hash functions
- For each function in the set, check for the
properly colored path of length k
43Existence and generation of k-perfect families
of hash functions
- Alon et al. (1995) collection with O(ck log n)
functions exist and can be deterministically
generated - Hence O((2c)k nm log n) algorithm for Longest
Path - Generate all elements of k-perfect family of hash
functions, and for each, solve the colored
version with dynamic programming - Refined techniques exist
444
45Remember Cooks theorem
- NP-completeness helps to distinguish between
decision problems for which we have a polynomial
time algorithm, and those for which we expect no
such algorithm exists - NP-hard NP-completeness reductions
- Cooks theorem first NP-complete problem used
to prove others to be NP-complete - Similar theory for parameterized problems by
Downey and Fellows
46Classes
- FPT Í W1 Í W2 Í W3 Í Í Wi Í Í WP
- Theoretical reasons to believe that hierarchy is
strict
47Parameterized m-reduction
- Let L, L be parameterized problems.
- A standard parameterized m-reduction transforms
an input (I,k) of L to an input (f(I,k), g(k)) of
L - (I,k) Î L if and only if (f(I,k), g(k)) Î L
- f uses time p(I) h(k) for a polynomial p, and
some function h - Note time may be exponential or worse in k
- Note the parameter only depends on parameter,
not on rest of the input
48A Complete Problem
- Classes W1, are defined in terms of circuits
(definition skipped here) - Short Turing Machine Acceptance
- Given A non-deterministic Turing machine M,
input x, integer k - Parameter k
- Question Does M accept x in a computation with
at most k steps? - Short Turing Machine Acceptance is W1-complete
(compare Cook) - Note easily solvable in O(nkc) time
49More complete problems for W1
- Weighted q-CNF Satisfiability
- Given Boolean formula in CNF, such that each
clause has at most q literals, integer k - Parameter k
- Question Can we satisfy the formula by making at
most k literals true? - For each fixed q gt 1, Weighted q-CNF
Satisfiability is complete for W1.
50Hard problems
- Independent Set, Clique W1-complete
- Dominating Set W2-complete
- Longest Common Subsequence III W1-complete
(complex reduction to Clique) - Given set of k strings S1, , Sk, integer m
- Parameter k, m
- Question is there a string S of length m that is
a subsequence of each string Si, 1 i k?
51Example of reduction
- Precedence constrained K-processor scheduling
- Instance set of tasks T, each taking 1 unit of
time, partial order lt on tasks, deadline D,
number of processors K - Parameter K
- Question can we carry out the tasks on K
processors, such that - If task1 lt task2, then task1 is carried out
before task2 - At most one task per time step per processor
- All tasks finished at most at time D
52Transform from Dominating Set
- Let G(V,E), k be instance of DS
- Write n V, c n2, D knc 2n.
- Take the following tasks and precedences
- Floor D tasks in series
1
2
3
D-2
D-1
D
53Floor gadgets
- For all j of the form j n-1 ac bn (0 a lt
kn, 1 b n), take a task that must happen on
time j (parallel to the jth floor vertex)
1
2
j-1
j
j1
D-1
D
54Selector paths
- We take k paths of length D-n1
- Each models a vertex from the dominating set
- To some vertices on the path, we also take
parallel vertices - If vi, vj Ï E, and i ¹ j, then place a vertex
parallel to the n-1acin-jth vertex for all a, 0
a lt kn
1
D-n-1
55Lemma and Theorem
- Lemma We can schedule this set of tasks with
deadline D and 2k processors, if and only if G
has a dominating set of size at most k - Theorem Precedence constrained k-processor
scheduling is W2-hard - Note size of instance must depend in polynomial
way on size of G (and hence on k lt V) - It is allowed to use transformations where new
parameter is exponential in old parameter
56Conclusions
- Fixed parameter proofs method of showing that a
problem probably has no FPT-algorithms - Often complicated proof ?
- But not always ?
575
- FPT Algorithmic techniques
- Kernelisation
58Kernelisation
- Preprocessing rules reduce starting instance to
one of size f(k) - Should work in polynomial time
- Then use any algorithm to solve problem on kernel
- Time will be p(n) g(f(k))
59Simple exampleIndependent Set on planar graphs
- A planar graph has an independent set of at least
n/4 vertices - 4-color the graph, and take the set of vertices
with the most frequent color - Kernelisation algorithm
- If n ³ 4k, then return YES
- Else return G
60Vertex cover observations that helps for
kernelisation
- If v has degree at least k1, then v belongs to
each vertex cover in G of size at most k. - If v is not in the vertex cover, then all its
neighbors are in the vertex cover. - If all vertices have degree at most k, then a
vertex cover has at least m/k vertices. - (mE). Any vertex covers at most k edges.
61Kernelisation for Vertex Cover
- H G ( S Æ )
- While there is a vertex v in H of degree at least
k1 do - Remove v and its incident edges from H
- k k 1 ( S S v )
- If k lt 0 then return false
- If H has at least k21 edges, then return false
- Solve vertex cover on (H,k) with some algorithm
62Time
- Kernelisation step can be done in O(nm) time
- After kernelisation, we must solve the problem on
a graph with at most k2 edges, e.g., with
branching this gives - O( n m 2k k2) time
- O( kn 2k k2) time can be obtained by noting
that there is no solution when m gt kn.
63Maximum Satisfiability
- Given Boolean formula in conjunctive normal
form integer k - Parameter k
- Question Is there a truth assignment that
satisfies at least k clauses? - Denote number of clauses C
64Reducing the number of clauses
- If C ³ 2k, then answer is YES
- Look at arbitrary truth assignment, and the
mirror truth assignment where we flip each value - Each clause is satisfied in one of these two
assignment - So, one assignment satisfies at least half of all
clauses
65Bounding number of long clauses
- Long clause has at least k literals
- Short clause has at most k-1 literals
- Let L be number of long clauses
- If L ³ k answer is YES
- Select in each of the first k long clause a
literal, whose complement is not yet selected - Set these all to true
- k long clauses are satisfied
66Reducing to only short clauses
- If less than k long clauses
- Make new instance, with only the short clauses
and k set to k-L - There is a truth assignment that satisfies at
least k-L short clauses, if and only if there is
a truth assignment that satisfies at least k
clauses - gt choose for each satisfied short clause a
variable that makes the clause true. We may
change all other variables, and can choose for
each long clause another variable that makes it
true - lt trivial
67An O(k2) kernel for Maximum Satisfiability
- If at least 2k clauses return YES
- If at least k long clauses return YES
- Else remove all L long clauses, and set kk-L
68Formal definition of kernelisation
- Let P be a parameterized problem. (Each input of
the form (I,k).) A reduction to a problem kernel
is an algorithm, that transforms A inputs of P to
inputs of P, such that - (I,k)) Î P , if and only if A(I,k) Î P for all
(I,k) - If A(I,k) (I,k), then k f(k), and I
g(k) for some functions f, g - A uses time, polynomial in I and k
69Kernelisation implies FPT and vice versa
- If P has a reduction to a problem kernel, and is
decidable, then P is in FPT - Use transformation
- Solve remaining instance
- Uses polynomial time, plus T(g(I)) time
- If P is in FPT, then P has a (perhaps trivial)
reduction to a problem kernel - Suppose we have an f(k) nc algorithm
- If I gt f(k), solve problem exactly this is
O(nc1) time - Formality take small yes or no-instance
afterwards - Otherwise, take original instance as kernel
70Improved kernelisation for Vertex Cover
- Nemhauser/Trotter kernel for VC of size at most
2k - ILP formulation of Vertex Cover
- Minimize SvÎ V xv
- For all v,w Î E xv xw ³ 1
- For all v Î V xv Î 0,1
71Relaxation
- Solve relaxation
- Minimize SvÎ V xv
- For all v,w Î E xv xw ³ 1
- For all v Î V 0 xv 1
- Define
- C0 v Î V xv lt 0.5
- V0 v Î V xv 0.5
- I0 v Î V xv gt 0.5
72Theorem and reduction
- Theorem There is a minimum size vertex cover S
with C0 Í S and S Ç I0 Æ . - Reduction rule remove all vertices in C0 and I0
and set k k - C0 . - Safe
- New, equivalent instance (GV0, k - C0 )
- If V0 gt 2k, relaxation, and hence also ILP has
optimal solution gt k, answer NO. - We have a kernel with at most 2k vertices.
73Example to explain techniques
- Convex recoloring
- Techniques
- Annotation
- Rules that either
- Decide
- Make the instance smaller
- Improve structural insight
74Connected tree coloring
- Tree
- Each vertex has a color
- Coloring is connected, if each set of vertices
with the same color is connected
75Connected recoloring
- Given vertex-colored tree T
- Task give some vertices a different color, such
that we obtain a connected coloring. - With as few as possible recolored vertices
76Two recolored vertices
77A problem on evolution trees
- Tree models evolutionary ancestry of species
- Colors model values for some attributes
- Often only once evolutionary change to specific
value is made - Set of species with a specific value forms
connected part of tree - Correct data connected coloring of tree
- Incorrect data how to change as few as possible
values to obtain consistent tree?
78Problem definition
- Convex tree recoloring
- Given Tree T(V,E), color c(v) for each vertex
v, integer k - Parameter k
- Question can we change the color of at most k
vertices such that for each color, all vertices
with this color form a subtree?
79Results
- For this problem B et al. O(n2) size kernel
- Here polynomial kernel
- Reducing number of vertices per color
- Reducing number of colors
80Fixing colors
Fixing colors improves structural insight
- Trick annotation some vertices get a fixed
color - Annotation solving a different (generalized)
problem, with some additional conditions for
objects in problem - At end undoing annotation
- Simple example if v is incident to k2 vertices
with color C, then v must have color C
81Color fixing rule
- Suppose the trees of T-v have a1 a2 ar
vertices with color c, and a1 ar-1 ³ k1. - Then in any solution v gets color c.
- Otherwise we must recolor the vertices with color
c in all but one of the subtrees of T-v at least
k1 recolorings. - Give v fixed color c possibly decrease k by 1
v
k4
82Analysis
- If there are at least 2k 3 vertices with color
C, then we can fix a vertex with color C
83One fixed color vertex per color
- If v and w have the same color C, both fixed,
then - Fix the color of all vertices on the path from v
to w to C, possibly decreasing k, or rejecting if
there is a vertex with a different fixed color on
the path - If v and w are adjacent, and have the same fixed
color C, then contract the edge v,w - After these rules each color C has at most one
vertex with fixed color C
84Subtrees for a fixed color vertex
- Suppose v has a fixed color C. Look at the
subtrees T-v - If one of these has at least 2k3 vertices with
color C, we can fix a vertex with color C in this
subtree, and reduce T - So, to bound the number of vertices with color C,
we should make sure that v has small degree
85Getting rid of uninteresting subtrees
- Uninteresting subtree No color in the subtree is
broken, except perhaps C, and the vertices with
color C are connected and incident to v, v has
fixed color C - Rule remove all vertices in an uninteresting
subtree
v
Red, yellow, green do not appear elsewhere in T
86Bounding degree of fixed color vertices
- If v has degree at least 2k1, a fixed color, and
each subtree of T-v is interesting, then return
NO - Each color change can help at most 2 subtrees
of T-v - Bounds number of vertices per color to O(k2)
after reductions - If more than 2k2 vertices, we can fix a vertex
with color C - One fixed color C vertex
- Each subtree has at most 2k2 vertices with color
C - At most 2k subtrees in T-v
87Types of colors
- Broken colors the vertices with color C are not
connected - Unbroken colors
- Rule If there are more than 2k broken colors,
return NO - Each color change can fix at most 2 colors the
old and new color of the recolored vertex - Consequence there are at most 2k broken colors
88Broken colors
- A color is broken, if it is not connected in the
given coloring. - If there are more than 2k broken colors, there is
no solution. - Each recoloring can correct at most two colors
(the old and the new color of the vertex) but not
more. - So Assume there are at most 2k broken colors.
v
v
89Bounding number of colors
- A color is interesting, if it is
- Broken, or
- Appears on a path of length at most k between two
vertices with the same broken color - We never need to recolor vertices that are not
interesting - Rule remove all vertices whose color is not
interesting - Gives a forest
90Rough analysis
- O(k) broken colors, each with O(k2) vertices
- O(k3) possible paths in tree, so O(k4)
interesting colors - O(k6) vertices in reduced instance
- Working harder gives better bound (quadratic)
- We are not yet finished going back to original
problem - From forest to tree
- Without fixed colors
91From forest to tree
- Take one new color, and one vertex v with this
color, fixed. - Make v incident to a vertex with this color at
each subtree
Like this (click)
92From forest to tree
- Take one new color, and one vertex v with this
color, fixed. - Make v incident to a vertex with this color at
each subtree
93Getting rid of annotations
- If v with color C is annotated (fixed color),
then add k2 leaves with color C, incident to v
and remove the annotation - Still O(k6) size
94Lessons
- Reduction rules that
- Make the graph smaller and transform
Yes-instances to Yes-instances and No-instances
to No-instances - Or improve structural map insight in instance
- Different rules ensure that different aspects of
the resulting instance are small - Annotation
- Analysis of problem and sizes
956
96Idea of Iterative Compression
- Take small subset of input
- Repeat until we have a solution on entire input
- Solve problem on small subset
- We have a solution from the previous round, and
this often helps! - If solution gt k, return NO
- Add tiny part of input to subset of input, e.g.,
add one additional vertex
97Example
- Feedback vertex set problem
- Recent (Chen et al. 2007) result, combining
different techniques
98Feedback Vertex Set
- Instance graph G(V,E)
- Parameter integer k
- Question Is there a set of at most k vertices W,
such that G-W is a forest? - Known in FPT
- Here recent algorithm O(5k p(n)) time algorithm
- Can be done in O(5k kn) or less with kernelisation
99Iterative compression technique
- Number vertices v1, v2, , vn
- Let X v1, v2, , vk
- for i k1 to n do
- Add vi to X
- Note X is a FVS of size at most k1 of v1, v2,
, vi - Call a subroutine that either
- Finds (with help of X) a feedback vertex set Y of
size at most k in v1, v2, , vi set X Y OR - Determines that Y does not exist stop, return NO
100Compression subroutine
- Given graph G, FVS X of size k 1
- Question find if existing FVS of size k
- Is subroutine of main algorithm
- for all subsets S of X do
- Determine if there is a FVS of size at most k
that contains all vertices in S and no vertex in
X S
101Yet a deeper subroutine
- Given Graph G, FVS X of size k1, set S
- Question find if existing a FVS of size k
containing all vertices in S and no vertex from X
S - Remove all vertices in S from G
- Mark all vertices in X S
- If marked cycles contain a cycle, then return NO
- While marked vertices are adjacent, contract them
- Set k k - S. If k lt 0, then return NO
- If G is a forest, then return YES S
102Subroutine continued
- If an unmarked vertex v has at least two edges to
marked vertices - If these edges are parallel, i.e., to the same
neighbor, then v must be in a FVS (we have a
cycle with v the only unmarked vertex) - Put v in S, set k k 1 and recurse
- Else recurse twice
- Put v in S, set k k 1 and recurse
- Mark v, contract v with all marked neighbors and
recurse - The number of marked vertices is one smaller
103Other case
- Choose an unmarked vertex v that has at most one
unmarked neighbor (a leaf in GV-X) - By step 7, it also has at most one marked
neighbor - If v is a leaf in G, then remove v
- If v has degree 2, then remove v and connect its
neighbors
104Analysis
- Precise analysis gives O(5k) subproblems in
total - Imprecise 2k subsets S
- Only branching step
- k is decreased by one, or
- Number of marked vertices is decreased by one
- Initially number of marked vertices k is at
most 2k - Bounded by 2k.22k 8k
1057
106Conclusions
- Fixed parameter tractability gives interesting
new insights on combinatorial problems - Here examples from (mainly) graphs and logic
- Can be applied to different fields
