Humming Code

1
Humming Code

• COSC 4436 E Computer Networks

2
Error Detection and Correction

• Telephone system has three parts switches,
  interoffice trunks and local loops.
• Switches and interoffice trunks are almost
  entirely digital.
• Local loops are still analog twisted pair.
  Expensive to replace

3
Error Detection and Correction

• Errors are rare on the digital medial
• Errors are still common on the local loops
• Wireless communications are becoming more common
  and the error rates here are orders of magnitude
  in comparison to fiber and copper media.

4
Error Detection and Correction

• Transmission errors are going to be with us for
  very long time
• We have to learn how to deal with them
• Errors come in bursts or single-bit

5
Two basic strategies for dealing with errors

• One way is to include enough redundant
  information with each block of data enabling the
  receiver to deduce what the transmitted data was.
  (Error-correcting codes)
• The other way is to include only enough
  information enabling the receiver to deduce that
  an error has occurred and request retransmission.
  (Error-detecting codes)

6
Two basic strategies for dealing with errors

• On channels with higher reliability, such as
  fiber, it is cheaper to use error-detecting
  codes. The receiver will just simple ask for the
  retransmission.
• On channels, such as wireless that make many
  errors, it is better to add enough redundancy to
  each block forcing the receive to figure out the
  original block of data.

7
Humming code history

• Hamming worked at Bell Labs in the 1940s on the
  Bell Model V computer.
• Input was fed in on punch cards punch cards,
  which would invariably have read errors.
• During weekdays, special code would find errors
  and flash lights so the operators could correct
  the problem.

8
Humming code history

• During after-hours periods and on weekends, when
  there were no operators, the machine simply moved
  on to the next job.
• Hamming worked on weekends, and grew increasingly
  frustrated.
• Over the next few years he worked on the problem
  of error-correction
• In 1950 he published what is now known as Hamming
  Code, which remains in use in some applications
  today.

9
Types of Humming code

• Hamming codes with additional parity (SECDED)
• Hamming(7,4) code
• Hamming(8,4) code
• Hamming(11,7) code. We are going to talk about
  this code.

10
Humming Code

• 7-bit data word "0110101".
• d to signify data bits and p to signify parity
  bits.
• The data bits are inserted into their appropriate
  position.
• Parity bits calculated in each case using even
  parity.

11
Humming Code
12
Humming Code
13
Humming Code

• The new data word (with parity bits) is now
  "10001100101".
• We now assume the final bit gets corrupted and
  turned from 1 to 0.
• Our new data word is "10001100100"
• We analyze how the Hamming codes were created we
  flag each parity bit as 1 when the even parity
  check fails.

14
Humming Code
15
Humming Code

• The final step is to evaluate the value of the
  parity bits.
• The integer value of the parity bits is 11,
  signifying that the 11th bit in the data word
  (including parity bits) is wrong and needs to be
  flipped

16
Humming Code

• Flipping the 11th bit changes 10001100100 back
  into 10001100101.
• Removing the Hamming codes gives the original
  data word of 0110101.
• Questions .
