OIF Overview

1
Tom Afferton Member of OIF Board of
Directors Division Manager ATT
Labs Afferton_at_att.com OIF Website
www.oiforum.com
2
What is the OIF?

• Launched in April of 1998 with an objective to
  foster development of low-cost and scaleable
  internet using optical technologies
• The only industry group bringing together
  professionals from the data and optical
  communities
• Open forum 250 member companies
• international
• carriers
• component and systems vendors
• testing and software companies
• Mission To foster the development and deployment
  of interoperable products and services for data
  switching and routing using optical networking
  technologies

3
OIF Focus

• Low-cost Scaleable Optical Internetworking
• IP-Over-Switched Optical Network Architecture
• Physical layer
• Low-cost optical interfaces between networking
  elements
• Standard device level electrical interfaces for
  low-cost systems
• Control layer interoperability between data and
  optical layers
• Dynamic configuration using IP signaling and
  control mechanisms
• Accommodate legacy network under the new physical
  and control layer mechanisms

4
OIF StructureTechnical Committee 6 Working
Groups

• Carrier
• Requirements and applications
• Architecture
• Services, network requirements and architectures
• Signaling
• Protocols for automatic management of optical
  connections
• OAMP (Operations, Administration, Maintenance
  and Provisioning)
• Network management
• Physical and Link Layer
• Equipment and subsystem module interfaces
• Interoperability
• Interoperability testing

5
Output from OIF

• Implementation agreements, based upon
• Carrier groups requirements
• Existing standards and specification when
  available
• New solutions when necessary
• Interoperability testing procedures
• Ensures compliance to implementation agreements
  and ultimately interoperable products and
  networks
• Input into other standards bodies
• Formal liasons in place with numerous other
  organizations (e.g. ITU, IETF. Complete list in
  back-up slides)

6
OIF Process for Generating Implementation
Agreements

• Framework provided by Working Group structure
• Working groups establish consensus-driven
  projects to focus contributions
• Progress driven by member contributions
• Posted on OIF website
• Basis for activities at quarterly technical
  meetings
• Formal voting process for reaching Implementation
  Agreements
• Two step process
• Straw ballot passes with simple majority
• Principal ballot passes with 2/3rds majority
• Process enables open debate, incorporation of
  comments
• Formal votes at each step
• One vote per member company

7
OIF Activities Physical Layer

• Business Need
• Lower equipment costs through interface
  agreements that reduce customization
• Key Projects
• Internal system interfaces
• System/Physical Interface (SPI)
• SPI-3, SPI-4 complete for 10G
• SPI-5 in progress for 40G
• Serializer/Deserializer-Framer Interface (SFI)
• SFI-4 complete for 10G
• SFI-5 in progress for 40G
• Low cost premises equipment interfaces
• Very Short Reach (VSR)
• VSR-1, VSR-2, VSR-3, VSR-4 complete for 10 Gb/s
• VSR-5 in progress for 40 Gb/s
• Footprint specification for tunable lasers in
  progress

8
OIF Activities Control Layer Switched Optical
Networks

• A switched optical network is an optical network
  in which connections can be created using
  switching control technology.
• The OIF is among the organizations working on the
  interfaces to enable controllers to work together
  to perform this function

9
OIF Activities Control Layer

• Business Need
• Lower operations costs through automation of
  routing optical circuits
• Key Projects
• User-to-Network Interface enables client
  equipment to request a service across optical
  networks
• UNI 1.0 complete for SONET circuits
• 25 vendor interop. Demonstratation at Supercomm
  in June, 2001
• Built upon protocols from IETF
• Also completed Call Detail Records to support
  billing with UNI 1.0
• UNI 2.0 in progress to add other features
• Network-to-Network Interface enables optical
  networks to interact to deliver an end-to-end
  service
• NNI 1.0 in progress
• Targeting 1H03 for interoperability demonstration

Client
UNI
NNI
UNI
Client
10
Why do service providers care about optical
control plane interfaces?

• Intelligent control plane, in general, lowers
  operating costs
• Automatic discovery of elements, capacity and
  connections
• Automatic routing and recovery of circuits
• Improved survivability against complex failures
• Standardized control plane interfaces enable
• Wider adoption of control plane capabilities
• Multi-vendor/carrier interoperability
• New dynamic optical services with customer
  control
• Plug and play introduction of new
  vendors/technologies
• In advance of control plane deployment, service
  providers will continue to rely on centralized
  management systems

11
OIF control plane work vs. other organizations

• Internet Engineering Task Force (IETF)
• Community of individuals
• Generating tool box of protocols
• International Telecommunications Union
• Formal organization for establishing global
  standards
• In progress of developing comprehensive standards
  for Automatic Switched Optical Network
• Some overlap among OIF, IETF, ITU
• Healthy competition is evolving to cooperation

Reqts
Protocols
Reqts
Formals Standards
Implementation Agreements
12
Summary

• OIF brings together professionals from the data
  and optical worlds
• OIF is addressing issues important to carriers
  and their customers
• Control plane work is progressing well in OIF in
  collaboration with other organizations like the
  IETF and ITU

13
Thank You
14
OIF Membership Breakdown
Market Segment
(data as of 12/01)
15
Implementation Agreements

• SPI-3 System Packet Interface Level 3 for
  STS-48/STM-16
• SPI-4 phase 1 System Physical Interface Level
  4 for STS-192/STM-64
• SPI-4 phase 2 System Packet Interface Level 4
  for STS-192/STM-64
• SFI-4 Serdes/Framer Electical Interface
  Common electrical interface between framers and
  serializer/deserializer parts for STS-192/STM-64
  interfaces.
• SFI-5 Serdes/Framer Electical Interface 40Gb/s
  interface for physical devices
• SPI-5 OC-768 System Packet Interface
• Very Short Reach (VSR) OC-192 Interface based on
  12 fiber Parallel Optics
• Serial OC192 1310 nm Very Short Reach (VSR)
  Interfaces
• Very Short Reach (VSR) OC-192 Interface based on
  4 fiber Parallel Optics
• Serial OC192 850 nm Very Short Reach (VSR)
  Interfaces
• User Network Interface (UNI) 1.0
• CDR Call Detail Records for UNI 1.0 billing

16
OIF and other Standards Bodies

• Established Liaisons With
• American National Standards Institute - ANSI T1
• International Telecommunications Union - ITU-T
• Internet Engineering Task Force - IETF
• ATM Forum
• IEEE 802.3ae 10 Gb Ethernet
• Network Processing Forum - NPF
• Metro Ethernet Forum - MEF
• Tele Management Forum - TMF

17
OIF and other Standards Bodies
