On Object Maintenance in PeertoPeer Systems IPTPS 2006

1
On Object Maintenance in Peer-to-Peer
SystemsIPTPS 2006

• Kiran Tati and Geoffrey M. Voelker
• UC San Diego

2
Object Maintenance

• Storage is an essential service provided by p2p
  systems
• Challenge is maintaining object availability and
  reliability in face of node churn
• Node unavailability and failures impact object
  availability
• Various object maintenance strategies have been
  developed
• Farsite, DHash, PAST, OceanStore, TotalRecall,
  etc.
• Minimize maintenance bandwidth overhead using
• Placement strategies (successors, leaf sets,
  random indirect)
• Redundancy mechanisms (replication, erasure
  coding)
• Repair strategies (react immediately, lazily to
  failures)

3
Goals

• Revisit how churn impacts maintenance overheads
• Provide insight into issues and approaches
• Highlight differences in system environments
• Separate impact of temporary vs. permanent churn
• Implications on object maintenance overhead
• What should strategies focus on optimizing?
• Try to provide insight independent of a
  particular strategy

4
Churn Review

• Temporary Churn
• Node leaves but eventually comes back
• Object data is not lost
• Permanent Churn
• Node departs and never shows up again
• Data on these nodes lost forever
• Churn varies depending on system environment
• Wide-area platforms PlanetLab
• Corporate FarSite
• File sharing Overnet

5
Churn Spectrum
High
File Sharing
Permanent Churn
PlanetLab
Corporate
Low
Low
High
Temporary Churn
6
Temporary Churn

• Lets look at temporary churn effects
• No permanent churn (no data loss)
• No significant change in node availabilities
• Idealistic, but provides useful intuition
• Object maintenance strategies place redundant
  data on fixed set of nodes
• Object availability depends on node availability
• As nodes come and go, object availability can
  change
• Lets track the available nodes from a group of
  nodes that are online at some point in time

7
Node Churn
If we have enough redundancy to survive the
minimum point, we mask the temporary churn
Initially number of available nodes in a group
decreases as nodes leave the system
After reaching a minimum value, it again
increases as nodes rejoin the system
This process continues till the object removed
8
Implications

• Can mask temporary churn
• Redundancy inversely proportional to minimum
  point in graph
• Want to create object with this degree of
  redundancy
• Proactive Estimate using node availability
  history
• Reactive Extend redundancy on-demand
• Once sufficient redundancy reached, maintenance
  overhead very low for this object due to
  temporary churn
• React only to shifts in node availabilities, etc.
• If not reached, overhead extremely high
• Environments with low permanent churn (PlanetLab)
• Redundancy to mask temporary churn dominates
  object maintenance overhead
• Tuning such redundancy has biggest impact on
  overhead

9
Permanent Churn

• Permanent churn induces repairs
• Repairs replenish redundancy lost due to
  permanent failures
• In practice, eventually every node fails
• Repair frequency depends on
• Amount of permanent churn
• Redundancy used to create/repair an object

10
Repairs

• At each repair, a strategy can choose
• Large redundancy factor
• Fewer repairs
• Extra storage cost
• Small redundancy factor
• Extra bandwidth for each repair
• Reduces storage cost
• What should an object maintenance strategy
  choose?

11
Analysis

• Consider repairing an object of size f
• Nodes fail permanently at rate d (half death
  time)
• Repair triggered when availability threatened
• Threshold x is redundancy needed for temporary
  churn
• Below this threshold, object not available
• Restore redundancy onto N new nodes using chunks
  of size c
• Repair cost is (f Nc) (x N) / 2 N d
• Minimize for N, of additional nodes to place
  data
• N sqrt(x)
• Optimum depends on amount of redundancy needed to
  mask temporary churn not the degree of
  permanent churn

12
Incremental Repairs
13
Implications

• Repairs dominate object maintenance overhead in
  environments with high permanent churn
• Tuning repair strategy has biggest impact on
  overhead
• PlanetLab Low permanent churn, not the critical
  problem
• Also depends on object lifetime ? longer lived,
  more repairs
• Interestingly, choosing amount of redundancy to
  repair depends on temporary churn (not permanent)
• Repairs triggered when object availability
  threatened
• Better to make small repairs frequently
• Also reduces storage

14
Capacity and Maintenance

• Storage capacity also impacts object maintenance
  overhead
• When a strategy creates/repairs, it stores
  redundant data on randomly chosen online nodes
• Highly available node gets picked more often
• Favoring highly available nodes reduces the
  redundancy required to mask temporary churn
• Also less redundancy to cope with permanent churn
• As storage utilization increases
• More redundancy required to deal with churn
• Higher per-object maintenance overheads as system
  fills

15
Implications
16
Conclusions

• System environment matters
• Different degrees of both temporary and permanent
  churn
• Temporary churn
• Can mask with sufficient redundancy
• Dominant overhead is creating objects when low
  perm churn
• Permanent churn
• As permanent churn increases, repairs dominate
  overhead
• Repair amount depends on degree of temporary
  churn
• Storage
• More redundancy, maintenance overhead as systems
  fills up
