Intermediate Language

1
Intermediate Language

• COMP431 (Compilers) by Dr Alex Potanin

2
Program Analysis Compilers
Source Code
Parser
Optimiser
Code Generator
IR
AST
Front End
Back End

• Parser translates program code to machine
  readable form
• Optimiser Translates Abstract Syntax Tree (AST)
  into Intermediate Representation (IR) and
  performs optimisations where possible.
• Code Generator generates machine code as
  efficiently as possible for target CPU. Many
  compilers (e.g. gcc) can target many different
  architectures!

3
Abstract Syntax Tree (AST)

• Human readable form of source code
• Produced by parser!

Program
x 0 while(x lt 10) x x 1
While

x
0
lt

x

x
10
x
1
Java Code
Abstract Syntax Tree (AST)
4
Example IL Program

• Intermediate Language (IL)
• Close to assembly language / Java Bytecode
• Unstructured control-flow

class Test int i1 void f(int y) 1 x
1 2 z 0 3 if x gt y goto 7 4 x x
2 5 z z 1 6 goto 4 7 this.i1
z
class Test private int i1 public void f(int
y) x 1 z 0 for(xltyxx2)
z i1 z
IL
5
An Example of Intermediate Language
c ? Num // Integer constants v ? Var
// Local Variables t ? Terms //
Terminal expressions e,e1,e2 ? AExp //
Arithmetic Expressions s,s1,s2 ? Stmts //
statements L,L1,L2 ? Lab // Labels m ?
Methods // Methods F ? Fields // Fields C
? Classes // Class names t c v e
v.f new N(t1,,t2) t t1 t2 t1 t2
t1 t2 t1 lt t2 s L ve L1 v.f
t s s1s2 L1 goto L2 L1 if e
goto L2 L return t L v1 v2.m(t1,,tn)
6
JKIL (Expressions)

• Expr Value LVal UnOp BinOp Invoke
• Cast New Exception
• LVal LocalVar Deref
• Value BoolVal CharVal ByteVal ShortVal

• IntVal LongVal FloatVal DoubleVal
• LocalVar Name
• UnOp ( '!' '' '-' '--' '' ) Expr

• Expr ( '--' '' )
• BinOp Expr ('' '-' '' '/' 'ltlt'
  'gtgt'
• 'ltltlt' '' '' '' '' ''
  'lt'
• 'lt' 'gt' 'gt' '' '!') Expr
• Deref Expr '.' Name
• Invoke Expr '.' Name '(' (Expr) ')
• Cast '(' Type ')' Expr
• New 'new' Type '(' (Expr) ')'

7
JKIL (Statements)

• Stmt Assign Return Throw Nop
• Assign LVal '' Expr
• Return 'return' (Expr)?
• Throw 'throw' Expr
• The expressions and statements are defined inside
  jkit.core.FlowGraph class (for you to examine in
  your spare time)
• Much more simple language than the AST produced
  by the parser (no for loops, etc)
• Much closer, but not too close to bytecode

8
Lecture 15

• Starts here

9
FlowGraph Use Example

• import jkit.core.FlowGraph
• FlowGraph.BinOp add1_2
• new FlowGraph.BinOp(FlowGraph.BinOp.ADD,
• new IntVal(1),
• new IntVal(2),
• Type.intType())
• Produces a representation of 1 2 expression of
  type int

10
Control-Flow Graphs (CFG)

• Simple graphical notation of instruction sequence
• Branches are represented by directed edges

void f(int y) 1 z 1 2 if y gt 10 goto
6 3 z z y 4 y y 1 5 goto 2 6
y 0
IL
CFG
11
More Control-Flow Graphs
y?
void f(int y) 1 z 1 2 if y gt 1 goto 5
3 z y y 4 goto 6 5 z y y 6 y
z 1
y gt 1
yes
no
zyy
zyy
yz1
IL
CFG
12
Flow Graph Example in JKit

• void aMethod(int x)
• String r
• if(x gt 0) r Greater"
• else r Smaller"
• System.out.println(r)

entry point
labelled edge is only taken if condition holds
(no conditions can overlap)
13
Flow Graph Example in JKit

• void anotherMethod(int x)
• while(x lt 10)
• if(x -1) break
• x x 1

entry point
labelled edge is only taken if condition holds
(no conditions can overlap)
14
JKIL in FlowGraph in JKit

• Maintains a list of edges in the flow graph
  (x,y,c) where edge goes from x to y if condition
  c (which can be null for nothing) holds
• Contains unique names for each variable, thus
  avoiding the need for scoping of local variables
  (these are uniquely renamed when going from
  ANTLRs AST to the JKIL)
• Run JKit with -t jkil to view how JKIL looks
  like (it is close, but not quite like bytecode)

15
Example of JKIL

• void aMethod(int x)
• String 4r
• L0
• if (xint gt 0int)boolean goto L1
• 4rjava.lang.String Smaller"java.lang.Str
  ing
• goto L2
• L1
• 4rjava.lang.String Greater"java.lang.Str
  ing
• L2
• java.lang.System.outjava.io.PrintStream
• .println(4rjava.lang.String)void
• return

16
Exception Edges

• In addition to conditional edges we saw, JKIL
  also has exceptional edges labelled with the
  corresponding exceptions

try is somewhere before here
first statement after catch
17
JKIL and other ILs

• See Appels chapter 7 for an alternative IL that
  is closer to bytecode than JKIL and contains some
  optimisations that JKIL does not
• JKil main design criteria was to simplify
  dataflow analyses.
• Reduced number of constructs compared with Java
• So less cases in every dataflow analysis!
• JKil supports recursive expressions, rather than
  e.g.three-address code (e.g. xy op z) as
  gimple, jimple do.
• JKil does not use SSA form (for simplicity)
• Note that sequences of code statements without
  any edges coming out of them (for exceptions or
  conditionals) are termed basic blocks
• Next lecture well look at generating IL from the
  AST
