Title: Problem Solving Unit 9 Ohms Law


1
Problem SolvingUnit 9Ohms Law
GE184 Problem Solving
  • John Elberfeld
  • JElberfeld_at_itt-tech.edu
  • 518 872 2082

2
Electrical Charges
  • People have seen the effects of electricity for
    thousands of years
  • Lightning, electric shocks, static cling
  • Only two types of electric charges exist
    positive ( ) and negative ( - )

3
Atomic Structure
  • Nucleus has positive protons and neutral neutrons
  • Very light negative electrons revolve in orbit
    around the nucleus
  • Only electrons move away from the atom and make
    up electric current

4
Electricity
  • Electric current is the flow of electrons
  • Electrons flow easily through some materials.
  • Other materials resist the flow of electrons

5
Conductors and Insulators
  • Current electricity is the movement of electrons
  • Conductors let electrons move easily and so offer
    low resistance to current flow
  • Insulators oppose the flow of electrons and so
    offer high resistance to current flow
  • Semiconductors offer moderate, controllable
    resistance
  • Resistance to current flow depends on the atomic
    structure of the material

6
Conductors
  • Conductors contain a large number of free
    electrons.
  • High conductance means the material is a good
    electricity conductor (low resistance)

7
Insulators
  • Insulators prevent the flow of electricity
  • A material with high insulation (resistance) is a
    poor conductor of electricity

8
Current Flow
  • Electron current flow occurs as electrons move
    away from the negative terminal towards the
    positive terminal.


9
Analogy for Current Flow
10
Charges
  • Electrons have a negative charge
  • Protons have a positive charge
  • The charge on an electron is equal in magnitude
    but opposite in sign to a proton
  • The charge on an electron is the smallest unit of
    electrical charge that exists in nature

11
Real World Measurements
  • We usually deal with billions and billions of
    electrons
  • 1 coulomb 6.25 x 1018 electrons
  • The charge on a object depends on how many EXTRA
    charged particles are there
  • Usually the number of electrons balances the
    number of protons, so the net charge is 0

12
Charges
  • When an object has a negative charge, it has
    more electrons than protons
  • Charge is determined by how many more electrons
    it has
  • When an object has a positive charge, it is
    missing electrons and has more protons than
    electrons
  • Protons do NOT move only electrons move to and
    from an object
  • A positively charged objects has had electrons
    removed from it

13
Large and Small Numbers
  • In electricity, you will work with very large and
    very small numbers
  • You must use engineering notation in your work
    and in your answers
  • 736 400 736.4 x 103
  • Engineering notation is like scientific notation,
    but the exponent is always a multiple of three
    (3) 3, 6, 9. -3, -6

14
Powers of Ten


15
Positive Powers of 10
  • If you move the decimal point in the number to
    the left, you are making the number smaller.
  • To keep the same value, you must multiply by a
    bigger power of 10

16
Negative Powers of 10
  • If you move the decimal point in the number to
    the right, you are making the number bigger.
  • To keep the same value, you must multiply by a
    negative power of 10

17
Engineering Notation
  • Write the number using powers of ten.
  • Move the decimal point left while increasing the
    exponent or right while decreasing the exponent.
  • The final exponent must be zero or a number that
    is evenly divisible by three.
  • The number itself must be greater than one and
    less than 1000


18
Practice Exercises NOW!
  • Convert the following numbers into engineering
    notation
  • 1 2 3 4 5 6 7. 1.234567 x 106
  • .0 0 1 2 3 1.23 x 10-3
  • 1 2 3 . 4 x 105 12.34 x 106
  • 1. 2 3 x 10-7 123. x 10-9

19
Set Your Calculator
  • Set your calculator to Engineering mode
  • If you are an electronics student, and you dont
    have a good calculator with Engineering mode, buy
    one as soon as possible (Casio is good)
  • In engineering mode, the calculator always shows
    numbers as a power of ten with an exponent a
    multiple of three

20
Practice Exercises NOW!
  • Enter the following numbers into your calculator
    and compare results when you choose engineering
    mode
  • 1 234 567
  • .00123
  • 12.3 x 105
  • 1.23 x 10-7
  • .0123 x 108
  • .00123 x 10-5
  • 123.5

21
Calculations with Exponents
  • When multiplying, you add exponents
  • (10x10x10)x(10x10) 10x10x10x10x10 105
  • 103 x 102 1032 105
  • 6 x 104 x 2 x 102 12 x 106
  • Use your calculator in Engineering notation to
    find
  • 3.21 x 105 x 12.98 x 108
  • 3.21 EXP 5 x 12.98 EXP 8 416.7 x 1012

22
More Calculations
  • When dividing, you subtract exponents
  • 10x10x10x10x10 10x10 10210x10x10
  • 105 /103 105-3 102
  • 10x10 1
    10-310x10x10x10x10 10x10x10
  • 102 / 105 102-5 10-3

23
Example
  • Fact 1 Coulomb (C) 6.25 x 1018 electrons
  • A capacitor stores a charge of 1.5 x 10-5 C. How
    many extra electrons are in the capacitor?
  • 93.75 x 1012 electrons
  • This is a simple unit conversion problem

24
Example
  • Fact 1 C 6.25 x 1018 electrons
  • How many coulombs in 3.0 x 1013 electrons?
  • 4.8 x10-6 C

25
On your own
  • Fact 1 C 6.25 x 1018 electrons
  • If you have 25.2 x 1026 extra electrons, what is
    the charge in coulombs in engineering notation?
  • If you have 428 x 10-6 coulomb, what number of
    extra electrons do you have?

26
Prefixes
  • Engineers usually replace the power of ten with a
    prefix
  • Because all powers of 10 are multiples of 3 in
    Engineering Notation, we dont have so many to
    remember
  • Some prefixes use Greek letters as symbols
  • Procedure to use a prefix
  • 1. Write the quantity in engineering notation.
  • 2. Replace the power of ten with its prefix.

27
Prefixes and Symbols

28
Prefixes and Symbols

29
Practice
106M103k10-3 m10-6 µ10-9 n
  • Enter the following numbers in your calculator
    set in Engineering notation, hit the enter key,
    and use the proper prefix
  • 12 x 104 C 120x103 C 120 kC
  • .066 x 10-4 C
  • 2345 mC
  • .03 µC

30
Electric Current
  • Current
  • Movement of electrons from negatively charged
    atoms to positively charged atoms.
  • Represented as I.
  • Coulomb
  • 6.25 x 1018 electrons.
  • Represented as C.

31
Electric Current
  • Electric current is the motion of free electrons
    through a material.
  • Current is measured in Amperes
  • 1 Ampere of current has 1 coulomb of electrons
    flowing past a given point in the wire in just 1
    second
  • 1 A 1 C/s

32
Current Symbol
  • The symbol for current is the letter I.
  • I Q/T
  • C is already used for capacitors and coulombs, so
    I is less confusing for current, and Q for charge
  • Units are Coulombs/second Ampere
  • Batteries are a source of electric current
  • Electrons flow from the negative terminal through
    the wire to the positive terminal

33
Conventional Current
  • Before scientist knew about electrons, they
    guessed that electricity was the flow of positive
    particles, but they were wrong
  • However, many books and most electrical symbols
    are drawn to show the direction this positive
    current would flow.

Electrons
34
Current
  • Current formula

35
Current Calculations
106M103k10-3 m10-6 µ10-9 n
  • Fact I Q / t
  • What is the current if a charge (Q) of 12 mC
    passes a point in time (t) of .023 s?
  • I 12 mC / .023 s 522 mA
  • What is the current if 76 kC passes a point 834
    sec?
  • I

36
Voltage

  • Voltage is the push behind the moving electrons.
  • Voltage gives the electrons energy and gets them
    to move from a negative area to a positive area

37
Resistance
  • The property of a material where an opposition to
    the flow of electrons is offered is known as
    resistance.
  • Unit of resistance is Ohm and is denoted by the
    Greek letter omega, O.

38
Resistance
  • Not every material will conduct electricity
  • Copper and aluminum conduct electricity easily
    and are labeled conductors and have low
    resistance
  • Plastic and rubber do not conduct electricity
    easily and are labeled insulators and have high
    resistance

39
Measuring Resistance
  • Resistance is a measure of how much a material
    opposes the flow of electricity through it
  • A material with a resistance of 1 ohm requires 1
    volt of energy to get 1 coulomb of charge
    through it per second
  • 1 ohm 1 O 1 V / A

40
Resistance Ranges
  • Conductors have resistances of a few ohms or less
  • Insulators have resistances in range of millions
    of ohms or more
  • There is no absolute insulator or perfect
    conductor

41
Ohms Law
  • MEMORIZE V I R
  • Ohms Law
  • If you increase the voltage, you increase the
    current proportionally
  • 3 times the voltage gives you three times the
    current
  • Resistance (ohms) is the proportionality constant
    and depends on the atomic structure of the
    material conducting the current

42
Experiment
43
Graph of Data
x
V
x
x
x
x
I
44
Reasoning
V I R
  • Ohms Law V I R
  • High voltage produces high current for a given
    resistance
  • Low voltage produces low current for a given
    resistance
  • For a given voltage, a high resistance produces a
    low current
  • For a given voltage, a low resistance produces a
    high current

45
Electronic Circuit
  • A battery with the voltage V pushes a current I
    through a resistor R

V I R
46
Ohms Law
V I R
  • This is the BIG IDEA for the day (year)!
  • V I R
  • What if we divide both sides by R?
  • V I R R R
  • But R/R 1, so we dont need to write it down
  • I V I V / R R

47
Ohms Law
V I R
  • V I R
  • What if we divide both sides by I?
  • V I R I I
  • But I / I 1, so we dont need to write it down
  • R V R V / I I

48
Ohms Law
  • Memorize V I R
  • Use algebra to find
  • I V / R
  • R V / I
  • If you can, learn all three variations, but you
    can get by if you memorize
  • V I R

49
Practice
  • V I R
  • What voltage (V) is needed to push a current of
    10 Amperes (I) through a resistance of 7 Ohms (R)
    ?

50
Practice
  • V I R
  • What voltage (V) is needed to push a current of
    10 Amperes (I) through a resistance of 7 Ohms (R)
    ?
  • V I R
  • V 10 A x 7 O
  • V 70 V

51
Practice
  • V I R
  • What current (I) flows through a resistance of 8
    ohms when the resistor is connect to a 24 volt
    battery?

52
Practice
V I R
  • What current (I) flows through a resistance of 8
    ohms when the resistor is connect to a 24 volt
    battery?
  • V I R
  • 24 V I x 8 O
  • I 24 V / 8 O
  • I 3 A

53
Practice
V I R
  • What size resistor allows 4 amperes of current
    through it when it is connected to a 12 Volt
    power supply?

54
Practice
V I R
  • What size resistor allows 4 amperes of current
    through it when it is connected to a 12 Volt
    power supply?
  • V I R
  • 12 V 4 A x R
  • R 12 V / 4 A
  • R 3 O

55
Now we add prefixes
  • Very few electronics labs deal with simple volts,
    amps, and ohms.
  • There is almost always a prefix, like millivolts,
    microamperes, and kilo ohms
  • To work with real electric data, you have to be
    able to handle these units on your calculator

56
Examples
  • Ohms Law V I R k 103 µ 10-6 m10-3
  • How much voltage must be connected across a 1.2 k
    O resistor to cause 575 µA of current to flow?
  • V I R
  • V 575 µA 1.2 k O
  • V .69V 690 x 10-3V 690 mV

57
Examples
103k10-3 m10-6 µ
  • Ohms Law V I R
  • How much current flow through a 25 O resistor
    with 10 V across it?
  • V I R I V / R
  • 10 V I 25 O
  • I 10 V / 25 O
  • I .4 A or 400 x 10-3A 400 mA

58
Examples
103k10-3 m10-6 µ
  • Ohms Law V I R
  • If a certain resistor allows 250 mA to flow when
    35 V are across it, what is the resistance?
  • V I R R V / I
  • 35 V 250 mA R
  • R 35 V / 250 ma
  • R 140 O

59
Examples
103k10-3 m10-6 µ
  • Ohms Law V I R
  • How much current flows through a 3.3k O resistor
    with 4.5 mV across it?
  • V I R I V / R
  • 4.5 mV I 3.3k O
  • I 4.5 mV / 3.3k O
  • I 1.36 µ A

60
Series Circuit
  • A series circuit has one path for current flow.
  • The current is the same at any point in the
    circuit.

61
SERIES CIRCUITS
  • Total resistance in a series circuit is the
    summation of the individual resistor values
  • RT R1 R2 R3 . Rn
  • Where n the number of resistors

62
OHMS LAW
  • Total resistance in a series circuit is equal to
    the total circuit voltage divided by the total
    current Remember, IT is the same at every point
    in the circuit

VT ITRT IT VT / RT
63
Single Resistor Circuit
  • Single resistor example
  • V I R
  • 10 V 2 A x 5 O

64
OHMS LAW EXAMPLES
  • Voltage 25 V
  • Resistance 25 ?
  • I _____

65
OHMS LAW EXAMPLES
  • Voltage 15 V
  • Resistance 1 k?
  • I _______

66
OHMS LAW EXAMPLES
  • Resistance 50 ?
  • Current 2.5 A
  • Voltage _______

67
OHMS LAW EXAMPLES
  • Resistance 10 k?
  • Current 4 mA
  • Voltage ______

V ? V
I 4mA
R 10kO
68
OHMS LAW EXAMPLES
  • Current 15 mA
  • Voltage 15 V
  • Resistance _______

V 15V
I 15mA
R ?O
69
OHMS LAW EXAMPLES
  • Current 4 mA
  • Voltage 60 V
  • Resistance _______

70
BASIC CIRCUIT EXAMPLES
  • R 10 k?, I 10 mA, V _____
  • V 100 V
  • V 50 V, I 2 mA, R ______
  • R 25 k?
  • V 75 V, R 10 k?, I ______
  • I 7.5 mA

71
Example
  • Series circuit comprised of resistors
  • To calculate out the total resistance we use the
    formula RT R1 R2 R3 etc.
  • The total resistance for the figure is
  • RT 10O 20O 30O 60 OHMS

72
Replace The Resistors
IT VT/RT 120V / 60kO 2 mA
73
Summary
  • In a pure series circuit, the current in every
    resistor is the same the same as the current
    that leaves the battery
  • The effective resistance of the pure series
    circuit is the sum of all resistors in series

74
Replace The Resistors II
IT VT/RT 9V / 30kO 300 µA
75
Replace The Resistors III
-
-
V 11V
I ?mA
R 4.27kO
IT VT/RT 11V / 4.27kO 2.58mA
76
Series Circuit Review
  • There is just one path for the current
  • The current is the same in every component in a
    series circuit
  • Total resistance is the sum of the resistors

77
Parallel Circuits
  • There are two or more paths for current flow.
  • The voltage is the same across all parallel
    branches.
  • The total current entering any point is equal to
    the current leaving the point

78
Parallel Combination of Resistances
  • When all the resistors in a circuit are connected
    in parallel, the circuit is called a parallel
    circuit.

79
Voltage Drop in Parallel Resistive Circuit
  • The voltage drop across each component in a
    parallel circuit is the same, since all the
    resistances are connected in parallel. Thus, the
    voltage across each connection is equal to the
    supply voltage.
  • The voltage drop in a parallel circuit is
    where, V is the
    supply voltage.

80
A Practical Example
  • Car circuits (and house circuits) are all
    parallel
  • You can run the radio without the horn being
    turned on an advantage

81
OHMS LAW EXAMPLES
  • Voltage 25 V
  • Find the total Current_______
  • Find the equivalent Resistance ______

V 25V
R2 50O I2 ?
R1 25O I1 ?
82
Calculations
  • I1 V1/R1 25V/25O 1 A
  • I2 V2/R2 25V/50O .5A (500mA)
  • IT I1I2 1 A 500 mA 1.5 A
  • RT VT/IT 25V/ 1.5 A 16.7 O
  • Notice that the total resistance is LESS than any
    one resistor in the circuit.

83
TOTAL RESISTANCE
  • Ohms law method

84
Parallel Circuit Current
  • Current leaving the () terminal is the same
    current entering the () terminal.
  • This is referred to as total current (IT).
  • Individual electrons may follow a variety of
    paths, but every electron that leaves the battery
    is balanced by an electron entering the battery

85
Parallel Circuit Current
  • Since the total current in the individual
    resistors is equal to the current supplied by the
    source, the total current can be stated as
  • IT IR1 IR2 IRn

86
Sample Problems
R12kO
R36kO
R24kO
VT 36V
87
Sample Problems
R12kO
R36kO
R24kO
VT 36V
88
Finding Total Series Resistance
  • Finding the total resistance for resistors in
    SERIES is easy
  • In SERIES, just add up the all the resistors

89
Finding Total Parallel Resistance
  • Every resistor you add in parallel actually
    REDUCES the equivalent resistance in the circuit
  • Each resistor you add in parallel increases the
    current, which makes the resistance appear lower
  • Simple addition does NOT work for resistors in
    parallel

90
Finding Total Parallel Resistance
  • 1/RT 1/R1 1/R2 1/R3 1/R4

91
Equation
  • The reciprocal of the total resistance is equal
    to the sum of the reciprocals of the resistors in
    parallel
  • 1/RT 1/1kO 1/2kO 1/3kO

R11kO
R33kO
R22kO
VT 24V
A
B
C
92
Calculations
  • 1/RT 1/1kO 1/2kO 1/3kO
  • 1/1 1/2 1/3 6/6 3/6 2/6 11/6 1/RT
  • RT 6/11 .545 kO 545 O
  • RT 545 O
  • To check on a calculator
  • 1 EXP 3 INV 2 EXP 3 INV 3 EXP 3 INV
    EQUALS INV

93
Practice
R12kO
R36kO
R24kO
VT 36V
94
Series-Parallel Combination of Resistances
  • This type of circuit consists of a combination of
    resistances in series and parallel.
  • Series-parallel combination of resistances can be
    classified as
  • Simple series-parallel circuits
  • Complex series-parallel circuits

95
Parallel Resistors
  • For resistors to be in parallel, both ends of
    each resistor must be in direct electrical
    contact with each other with no resistance
    between the ends
  • Parallel Not Parallel (blue)

96
Recognizing Series Components
97
Series-Parallel Circuits
  • Pure series-parallel circuits can be reduced to a
    single equivalent resistor
  • Example

98
Example
  • Another simple series-parallel circuit

99
Example - Simple
100
Voltage Drop in Series-Parallel Resistive Circuit
  • To find the equivalent resistance of a
    series-parallel resistive circuit
  • Identify the resistance combinations as either
    series or parallel.
  • Simplify, combine and recombine series and
    parallel combinations
  • Find the value of the total resistance of the
    circuit.
  • Once you know the equivalent resistance, you can
    calculate voltage or current

101
Circuit Analysis
  • Combine the two parallel resistors to one
    equivalent resistor
  • 1/R23 1/20O 1/30O 3/60O 2/60O
  • 1/R23 5/60O
  • R23 12 O

R1 10O
R1 10O
V 25V
R3 30O
R23 12O
V 25V
R2 20O
102
Analysis
  • Combine the series resistors
  • R123 10 O 12 O 22 O

R123 22O
R1 10O
V 25V
V 25V
R23 12O
103
Analysis
  • V 25 V, RT 22O,
  • IT V/R 25V/22 O
  • IT 1.14 A

R1 10O
R3 30O
V 25V
R2 20O
104
Class Activity
  • What is the equivalent resistance of the
    following circuit?

R1 5.6kO
V 30V
R2 10kO
R5 3.3kO
R3 4.7kO
R4 2.2kO
105
Current Analysis
  • Combine resistors in series
  • R23 10kO 4.7kO 14.7kO

R1 5.6kO
V 30V
R5 3.3kO
R23 14.7kO
R4 2.2kO
106
Current Analysis
  • Combine parallel resistors
  • 1/R235 1/14.7 kO 1/3.3kO
  • (Use your calculator!)
  • R235 2.70 kO

V 30V
R1 5.6kO
R235 2.7 kO
R4 2.2kO
107
Current Analysis
  • Combine series resistors
  • R12345 5.6 kO 2.7kO 2.2 kO 10.5 kO

R12345 10.5kO
V 30V
108
More Analysis
  • IT VT/RT 30V / 10.5 KO
  • IT 2.85 mA

R1 5.6kO
V 30V
R2 10kO
R3 4.7kO
R4 2.2kO
109
Ready for Thought Projects
  • You are now ready to tackle Electronics Projects
    1 2 on pages 135 - 146
Write a Comment
User Comments (0)
About PowerShow.com
