Pittsburgh Water

1

• Pittsburgh Water
• and Sewer Authority
• Pilot-Scale
• Drinking Water Treatment Plant

2
Unit Process Overview
3
Unit Process Summary

• Design Flow Rate 4 gal/min (15 L/min)
• Three-stage Flocculation
• G Values 25, 17 and 9.2 s-1
• Primary Sedimentation
• Loading Rate 0.24 gpm/ft2
• Dual Media Filtration
• Filtration Rate 1 gal/ft2/min
• Ozonation (Pre and Intermediate Ozonation)
• Chlorine Dioxine (Batch Feed)

4
Pilot-Scale Process Schematic
5
Available Water Sources

• Raw Water (P)
• Primary Clarifier Effluent (P)
• Secondary Sedimentation Effluent (G)
• Filter Influent
• Filter Effluent (G)
• Filter Backwashing

Note
P Pumped G Gravity Feed
6
SCADA System

• System Control And Data Acquisition System

7
Instrumentation

• Turbidimeters
• Hach 1720D Low Range Process Turbidimeter
• pH meters
• GF Signet pH/Orp Electrode Model No. 2714/2716
• Particle Counters
• Two Chemtrac 2400D digital on-line particle
  counters. Chemtrac Systems Inc. each instrument
  dedicated to two filters.

8
Conventional Train For SCADA
9
Experimental Train Screen For SCADA
10
Combined Train Screen For SCADA
11
Flow Splitting Box

• 15-gallon acrylic basin
• Design Flow 8 gpm.
• Each train will only use 4 gpm.
• Detention Time 1.9 minutes.

12
Flow Splitting Box
13
Flow Splitting Box
14
Pretreatment Basin

• A 22 gallon acrylic, baffled basin.
• Provides the necessary chemical contact time
• e.g., potassium permanganate or chlorine dioxide
• 5.6 minutes of detention time at 4 gpm.

15
Pretreatment Basin
16
Pretreatment Basin
17
Rapid Mix Basins

• Design Flow 4 gpm
• Detention Time per cell 23 seconds.
• Each Cell Volume 1.5 gallons.
• Flow is baffled in an over/under configuration.
• Chemicals are delivered to each rapid mix cell
  immediately below the mixer impeller through a
  stainless steel tube.
• Each mixer has a range of 0 to 1,000 sec-1 .

18
Rapid Mix Basins
19
Rapid Mix Basins
20
Flocculation Basins

• Three Acrlyic Flocculation Basins
• Total Volume 28 gallons
• Detention Time 21 minutes at design flow of 4
  gpm
• Detention Time 7 minutes per zone
• Flocculator Paddle Boards
• Zone 1 4 sets of 4 paddle boards (1.3 ft2 total
  area)
• Zone 2 3 sets of 4 paddle boards (1.0 ft2 total
  area)
• Zone 3 2 sets of 4 paddle boards (0.7 ft2 total
  area)
• Each paddle board is 0.5 inch wide by 2 feet
  long.
• Flocculation Mixing Range 10 to 70 sec-1.

21
Zone 1 Flocculator
22
Flocculation Basins
23
Flocculation Basins
24
Primary Clarifier

• Counter-Current Flow Lamella Plate Settler
• Settled water exits the top of the unit.
• Flocculated solids drop to the bottom.
• Sedimentation Basin is an Acrylic Tank with Seven
  Stainless Steel Plates
• Each plate is 1.5 feet wide by 3 feet deep.
• The plates are spaced 3 inches apart and inclined
  at a 60? angle.
• Area available for settling is 16 square feet.
• The design flowrate is 4 gpm.
• The projected loading rate is between 0.22 to
  0.44 gpm/ft2.

25
Primary Clarifier
26
Primary Clarifier (Plate Settling)
27
Secondary Sedimentation Basin

• Flow Rate Reduced from 4 gpm to 1 gpm. Simulates
  the Full-Scale Facility.
• The Design Detention Time at 1 gpm is
  Approximately 20 hours.

28
Secondary Sedimentation Basin
29
Secondary Sedimentation Basin
30
Filters

• 6-inch Acrylic Columns Approximately 16 Feet in
  Total Height.
• Each Pilot-Scale Filter Contains
• 18-inches of anthracite on top of 12-inches of
  filter sand.
• All media was taken from existing filters in the
  full-scale treatment plant. Media was aged for 6
  years.
• A ¾ inch thick Leopold Integral Media Support
  (IMS) cap is used in the pilot scale filter to
  support these granular layers.
• Maximum Allowable Filter Media Depth is 6 feet.
• Water Depth Above the Filter Media Can Range from
  6.5 to 9.5 feet.

31
Filters

• 2 filters are supplied water from the
  conventional train.
• 2 filters are fed water from the experimental
  train.
• The flow rate can be varied from 0.2 gpm to 1
  gpm.
• The filter loading rate range is between 1
  gpm/ft2 to 5 gpm/ft2.

32
Filters
33
Filter Appurtenances
34
Filter
35
Ozone Generator

• The generator is an OSMONICS OREC Ozone Generator
  SP 19-O-1059, with a capacity of 1 pound/day of
  ozone.
• Ozone dosing can be accomplished by using of an
  in-line injector (eductor) or a fine bubble
  diffuser.

36
Ozone Generator
37
Ozone Feed Gas Offgas Monitors
38
Ozone Eductor System
39
Ozone Diffuser
40
Ozone Offgas Destruction Unit
41
Ozone Offgas Destruction
42
Ozone Contactors

• Each contactor is made of glass, 6 inches in
  diameter, and 18 feet tall with 2 feet of
  freeboard.
• The water height in the contactors in operation
  is 16 feet in preozonation mode and 14 feet in
  intermediate ozonation mode.
• The design contact time at a flow of 4 gpm is
  5.9 minutes per contactor for preozonation and
  5.1 minutes per contactor for intermediate
  ozonation.

43
Ozone Contactors
44
Ozone Contactor
45
Ozone and Chlorine Dioxide Generators in a Fume
Hood
46
Chlorine Dioxide Generation

• A CDG Technologies Model MB-1000R pilot-scale
  generator.
• Can produce a stock solution of 1,000 to 3,000
  mg/L.
• Chlorine dioxide is generated by combining
  chlorine gas with sodium chlorite.

47
Chlorine Dioxide Generator
48
Chemical Feed System
49
SCADA Filter Screen
50
SCADA Data Screen
51
SCADA pH Trend Screen
52
SCADA Flow Trend Screen
53
SCADA Turbidity Trend Screen
54
SCADA Ozone Trend Screen
55
SCADA Particle Trend Screen
