UDDIe

1
UDDIe
An Extended Registry for Web Services
Ali Shaikh Ali Department of Computer Science an
d Welsh E-Science/Grid Computing Centre
Cardiff University
A.Shaikhali_at_cs.cf.ac.uk
2
My Background

• Currently working on my BSc degree
• Project on UDDIe
• Course on Computer Science
• Distributed Computing
• Databases/Advanced Databases
• Computer Security
• Knowledge Based Systems (KBS)
• Particular interest in
• KBS and Distributed Computing

3
Agenda..

• Introduction to Web Services
• What are Web Services?
• Web Services Architecture
• Web Services Challenges
• UDDI
• The Role of UDDI as a Business Registry.
• The UDDI Architecture.
• Limitation of UDDI
• UDDIe
• UDDIe properties.
• Design
• Implementation
• Use Case QoS in service-oriented computing

4
Buying a Car

• Wake up one day
• Its a good day to buy a car
• Have breakfast
• Go down to showroom and pick a car
• However, may not get a good deal
• Alternatives?
• Start to Google.com
• Magazine AutoTrader, FreeAds etc
• Ask a friend
• Approaches to help you search for cars
• All of these are time consuming

5
Buying a Car made easier

• Try to interact with
• Car buying Service
• Reveal your preferences to service
• Service interacts with registries of a number of
  showrooms concurrently

• Brings up a number of offers
• Much easier than Google or asking a friend (who
  may want the same car also!)

6
Web Services..

• An approach to building standards based
  distributed applications

• Concept is not new
• CORBA
• DCOM
• RPC
• Characteristics
• More loosely coupled than traditional distributed
  computing models.

• The way to Standardisation

7
What are Web Services?

• No single definition of what the term Web
  Services is.

• Web Services expose useful functionality through
  a standard Web protocol.

• Simple Object Access Protocol (SOAP)
• Provide a way to describe their interfaces in
  enough detail.

• Web Services Description Language (WSDL)
  document.

• Registered with a Business Registry.
• The Universal Discovery Description and
  Integration (UDDI).

8
Web Services Architecture

• The Architecture pattern is an example of
  service-oriented Architecture (SOA)

Figure is taken from IBM
9
Web Services An Example
10
Web Service Challenges

• Who provides Web Services?
• How are they implemented?
• Where are they exposed?
• What is their behaviour?
• Is an application compatible?
• What are they for?
• ... searching and indexing
• (find the right services at the right time)

11
Agenda..

• Introduction to Web Services
• What is Web Services?
• Web Services Architecture
• Web Services Challenges
• UDDI
• The Role of UDDI as a Business Registry.
• The UDDI Architecture.
• Limitation of UDDI
• UDDIe
• UDDIe properties.
• Design
• Implementation
• Use Case QoS in service-oriented computing
• UDDIe and Mobile Agents

12
UDDIan approach for such challenges
13
What is UDDI?

• Universal Description Discovery and Integration
• Industry-wide initiative supporting web services
• Specifications
• Schemas for service description
• Schemas for business (service implementers)
  description

• Developed on industry standards (XML, HTTP, IP,
  SOAP)


14
What Problems Does UDDI Solve?
15
UDDI Registry Entries

• Entities register published informationabout
  themselves


16

• Business name
• General business description
• Any number of languages
• Contact info
• Names, phone numbers, fax numbers, web sites,
  etc.

• Known identifiers
• List of unique identifiers for a business
• D-U-N-S, domain name, other

17

• Contains classification information about the
  types and location of the services that the
  business entity offers.

• 3 standard taxonomies in V1
• Industry NAICS (Industry codes - US Govt.)
• Product/Services UN/SPSC (ECMA)
• Location Geographical taxonomy (ISO 3166)
• more in upcoming releases
• For BT the classification could be
  Telecommunication, System developer.

18

• New set of information businesses use to describe
  how to do e-commerce with them

• Contain technical information about the details
  of how to invoke the offered services

• If BT were to offer a Billing service online, its
  Green pages entry would have a reference to its
  Billing service URL.

19
How UDDI Works
1.
Software companies, standards bodies, and
developers populate the registry with
descriptions (specifications) of types of services
Marketplaces, search engines, and business
applications query the registry to discover
services at other companies
4.
2.
UDDI Registry
Service Types
Implementations
5.
Implementers populate the registry with
descriptions of the services they support
Business uses this data to facilitate easier
integration with each other over the Web
20
Public Registry Operation

• Peer registry nodes (websites)
• Information registeredwith any node
• Registrations replicatedon a daily basis
• Complete set ofregistered recordsavailable at
  all nodes

• Common set ofSOAP APIs supportedby all nodes
• Compliance enforced by business contract
• All technologies applied
• Interoperability verified constantly

• Peer registry nodes (websites)
• Information registeredwith any node
• Registrations replicatedon a daily basis
• Complete set ofregistered recordsavailable at
  all nodes

• Common set ofSOAP APIs supportedby all nodes
• Compliance enforced by business contract
• All technologies applied
• Interoperability verified constantly

queries
IBM
IBM
Ariba
Ariba
other
UDDI.org
other
other
Microsoft
Microsoft
21
UDDI Limitations

• Dealing with missing services -- and similarly,
  service documents which are out of date

• Search for services restricted to service name
  and classification -- this is quite restrictive

• Cannot find partial matches to services

22
Agenda..

• Introduction to Web Services
• What are Web Services?
• Web Services Architecture
• Web Services Challenges
• UDDI
• The Role of UDDI as a Business Registry.
• The UDDI Architecture.
• Limitation of UDDI
• UDDIe
• UDDIe properties.
• Design
• Implementation
• Use Case QoS in service-oriented computing

23
UDDIe

• An Extension to UDDI v.2
• Support the notion of Blue Pages
• A new way to describe and discover Services
• dynamic meta-data
• A new way to control Services
• dynamic service life period

24
dynamic meta-data Service Properties

• Each service has one or more properties.
• Service Properties could describe any thing, i.e.
  QoS attributes.

• Discover services based on Service Properties.

25
dynamic service life period Service Leasing

• Services published for limited time periods
• Deals with services which change often or missing
  services

• Finite Lease
• Must define exact time periods for which service
  may be discoverable

• Infinite Lease
• Service made available as persistent services

26
Service Leasing ..2

• Future Lease
• Allow lease period to start at a future point in
  time (i.e. service discoverable only after this
  time period)

• Immediate Lease
• standard with UDDI -- service discoverable
  immediately on publication


27
Lease Manager

• Checks registry at periodic intervals
• responsible for ensuring leases obtained for
  duration (or multiples) specified by admin.

• Services request lease based on this
• Checks services based on service expiry times
• Lease manager is independent of database/registry

28
UDDIe Architecture..
BusinessEntity businessInfo
BusinessService
BusinessService
categoryBag ServiceName ServiceDescription Prop
ertyBag
ServiceLease
categoryBag ServiceName ServiceDescription
UDDIe
BindingTemplate
TModel
29
PropertyBag

• List of service properties that may be searched
• CPU
  number 800



User Defined -- may use some predefined ontology
or metadata format (can be strings or number)

• Additional find qualifiers
• exactPropertyMatch (services which
• have exactly the requested properties)
• exactMatch (also uses keyedReference
• and categoryBag)

30
Lease
DD/MM/YYYY hhmmss
Number of times lease renewed
31
APIs

• Inquiry APIs
• find_binding find_business find_relatedBusines
  ses find_service find_tModel get_bindingDetail
  get_businessDetail get_businessDetailExt
  get_serviceDetail get_tModelDetail

• Publishing APIs
• get_authToken discard_authToken
  delete_binding delete_business delete_publisherAss
  ertiondelete_service delete_tModel
  get_assertionStatusReport get_publisherAssertions
  get_registeredInfo save_binding save_business
  save_service save_tModel renew_lease
  set_publisherAssertions start_lease_manager

32

• xmlns"urnuddi.orgapi_v2"

• keyName"" keyValue"" /

• rtyFindQualifier

•


•

•


33
Property Find Qualifiers

• GREATER_THAN
• GREATER_OR_EQUAL
• LESS_THAN_OR_EQUAL
• EQUAL_TO
• NOT_EQUAL_TO
• AND/OR

34
Implementation
35
Agenda..

• Introduction to Web Services
• What are Web Services?
• Web Services Architecture
• Web Services Challenges
• UDDI
• The Role of UDDI as a Business Registry.
• The UDDI Architecture.
• Limitation of UDDI
• UDDIe
• UDDIe properties.
• Design
• Implementation
• Use Case QoS in service-oriented computing

36
Case Study QoS in Grid Computing
Jointly between Cardiff and University
Of New South Wales, Sydney

• Support for resource and service discovery based
  on QoS properties

• Support for providing QoS guarantee at
  application, middleware and network level, and
  establishing service level agreements (SLAs) to
  enforce these QoS parameters
• Providing QoS management on allocated resources.

37
G-QoSm Architecture
Jointly between Cardiff and University
Of New South Wales, Sydney
38
UDDIe Supporting Discovery Based on Service QoS
Properties

• UDDIe forms the service registry system in the
  context of the G-QoSM framework

• Publish services with their QoS information
• Search for services based on QoS attributes
• Open Grid Service Architecture (OGSA) requires
  defining QoS attributes in WSDL document

39
G-QoSm Integration Tools
40
WSDL with QoS attributes

• type"intfMathService"

• transport"http//schemas.xmlsoap.org/soap/http"/


• style"rpc"/

• s.xmlsoap.org/soap/encoding/" namespace"http//Ma
  thService-Interface" use"encoded"/

• as.xmlsoap.org/soap/encoding/" namespace"http//M
  athService-Interface" use"encoded"/

• 100
• 150

41
Publishing QoS-aware Services into UDDIe

• i_v2"

• MathService
• cpu_count
• number

• 100
•
  disk_storage

• number


• 150


42
Discovering QoS- aware Services from UDDIe

• i_v2"

• MathService
• equal_topertyFindQualifier

• cpu_counte

• number

• 100
• equal_toopertyFindQualifier

• disk_storageyName

• number


• 150


43
Conclusion..

• Importance of UDDIe in service-oriented
  architecture.

• UDDIe with Agents.
• May be used to record properties of agents (and
  services managed by agents)
