Digital Billboards: What we Know Now

1
Digital BillboardsWhat we Know Now

• Presented to ASHTO SCOTE
• Manchester, New Hampshire
• Jerry Wachtel, The Veridian Group, Inc.
• June 16, 2009

2
Inattention vs. Distraction

• A driver may be inattentive for many reasons
  daydreaming, lost in thought, drowsiness, etc.
• Distraction - when a driver is delayed in the
  recognition of information needed to safely
  accomplish the driving task, because something
  within or outside the vehicle draws attention
  away from driving.
• It is the presence of a triggering event that
  distinguishes distraction from inattention.

3
In short

• Inattention is passive
• Drivers can be inattentive at any time and
  without reason
• Distraction is active (although it could be
  unconscious)
• Drivers engage in many distractions most of
  which we cannot control
• As an example

4
(No Transcript)
5
But roadside advertising as a distractor is
something that we can control.
6
Why are DBBs Different?

• The human eye is hard-wired to be drawn to the
  brightest objects in the scene and to those that
  display motion, or apparent motion.
• This phenomenon is sometimes called phototaxis or
  phototropism.
• Recent research (e.g. Theeuwes) shows that this
  response is both is automatic and unavoidable.
• DBBs use both brightness and movement to capture
  attention.

7
This DBB is Shown from a Distance of Six Miles
8
How Else do DBBs Differ from Conventional
Billboards?

• Size potential one sign is 90 x 65 ft 165 ft
  high
• Compelling photo-realistic/broadcast imagery
• Intermittency and image change at will
• Potential for message sequencing
• Potential for interactivity with driver

9
My Biases

• I have worked for the industry, including OAAA,
  NESA, and large outdoor advertising firms such as
  Lamar and Infinity.
• I have worked for local governments in developing
  and defending sign ordinances.
• I have performed research for Government and
  industry alike.

10
My Work Leads to These Conclusions

• Billboards have gone from paintings on barns, to
  print on poster paper, to vinyl sheets, and now
  to digital displays.
• Its not the technology of the display that
  should concern us, but the manner in which that
  display is used
• Were not concerned because they are digital, but
  because of their operational characteristics
  coupled with their location.

11
In Other Words

• IF a DBB was set to a luminance level appropriate
  to the ambient environment in which it is viewed,
  and
• IF the DBB message change interval was such that
  no driver saw more than one such change, and
• IF we ensured that location restrictions (e.g.
  interchange areas, horizontal curves, merges,
  lane drops, etc.) were truly enforced,
• THEN we should not be particularly concerned
  about safety impacts due to distraction.

12
Recent Research

• In recent years, independent research studies
  have been conducted in several countries
• U.S.
• Netherlands
• England
• Scotland
• South Africa
• Australia
• Brazil
• Finland

• Studies have included
• Laboratory
• Simulation
• On-road
• Interviews and focus groups
• Post-hoc crash analyses

13
The Research is Quite Clear

• The more recent the research, the stronger the
  findings, and
• The stronger the theoretical basis for
  understanding the nature of the problem
• Drivers eyes off the road for 1.6 seconds or
  longer leads to a substantially higher crash rate
• DBBs can attract drivers eyes for longer than
  1.6 seconds, and dramatically longer than for
  conventional billboards.

14
Only Two Recent Studies Show No Adverse Safety
Impact

• Tantala and Tantala
• Virginia Tech
• Both sponsored by the outdoor advertising
  industry
• Both severely criticized in peer review
• Both rejected for presentation or publication by
  TRB
• Ironically, the Virginia Tech human factors study
  found substantial degradation in eye glance
  behavior and did not report it.

15
The Virginia Tech Data on Long Eye Glances as
Reported
16
Glances longer than 1.6 sec 6 of all
glances Glances longer than 2.0 sec 2 of all
glances Glances longer than 3.0 sec 0 of all
glances
17
Glances longer than 1.6 sec. 9 of all
glances Glances longer than 2.0 sec 5 of all
glances Glances longer than 3.0 sec 0 of all
glances
18
Glances of 1.6 sec or longer 21 of all
glances Glances of 2.0 sec or longer 10 of all
glances Glances of 3.0 sec or longer 2 of all
glances
19
Glances of 1.6 sec or longer 13 of all
glances Glances of 2.0 sec or longer 7 of all
glances Glances of 3.0 sec or longer 3 of all
glances
20
Summary of Unanalyzed VA-Tech Data
21
Conclusions Unreported

• DBBs and comparison sites (mostly on-premise
  DBBs) together produced
• 2X as many glances gt 1.6 seconds as baseline
  sites and conventional billboards (34 - 15)
• 2.5X as many glances gt 2.0 seconds as baseline
  and conventional sites (17 - 7)
• 5 of glances gt 3.0 seconds no such glances
  were made to baseline or conventional sites.
• From a pilot study, the authors predicted
  significantly worse DBB performance at night.

22
On-Premise Signs Whats Wrong with This Picture?

• The Virginia Tech study found, as expected, that
  on-premise digital signs were as bad as, if not
  worse than, DBBs
• HBA regulates billboards, not on-premise signs
• These are left to local governments, typically
  through zoning and land use
• But, on premise signs may be
• Bigger
• Brighter
• Closer to the ROW
• Contain full motion video
• At or near interchanges, curves, etc.
• If our concern is driver distraction, isnt the
  potential just as high, or higher, for on-premise
  signs?

23
The Worlds Largest Digital Billboard 90 x 65
atop a 165 Post Visible for more than 2 Miles
Along I-495 in NYC
24
(No Transcript)
25
Advertising Signs on the ROW What Does the
MUTCD Say?

• Section 1A.01 Traffic control devices or their
  supports shall not bear any advertising messages
  or any other message that is not related to
  traffic control.
• Section 1A.02, requires that TCDs fulfill a
  need, convey a clear, simple meaning, and
  command respect from road users.
• Section 2E.21 Changeable message signs shall
  display pertinent traffic operational and
  guidance information only, not advertising.

26
What did Dudek Find?

• Recent NCHRP study on the use of CMS during
  non-incident, non-roadwork periods.
• States and toll authorities reported pressure to
  display public service messages, safety
  campaigns, and advertisements, often against the
  wishes of safety personnel
• There are excellent guidelines available for
  design and operation of CMSs not always
  followed.

27
Other Lessons from Dudek

• Long messages (e.g. telephone numbers, websites,
  license plate numbers) take too long to read and
  may cause drivers to slow
• Messages irrelevant to traffic safety/flow are
  strongly opposed by motorists
• Change blindness can occur if a message has
  changed from irrelevant to relevant
• Loss of credibility when CMSs display untimely or
  irrelevant messages
• These are the very characteristics of advertising
  signs.

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
The proposed DBB-CMS location in the opposite
direction
33
The Next ChallengeDBBs on Vehicles Moving in
Traffic

• New companies offer DBBs to be displayed on
  trucks in the traffic stream.
• Some use 40 trailers with huge LED screens
  displaying full motion video.
• Some governmental agencies are using this
  technology on public buses and trolleys.
• Some jurisdictions have amended their sign codes
  to prohibit such commercial displays.

34
(No Transcript)
35
(No Transcript)
36
And, Next on the Horizon Interactive Billboards
37
This sign sends a personalized message to the
approaching driver
38
An Interactive Billboard in Belgium
1. The driver sends an SMS using a code from the
sign 2. The billboard sends a return message with
a question 3. The driver messages a response to
the question 4. A correct answer causes the
billboard to act like a pinball machine the
driver is entered into a drawing a wrong answer
causes the billboard to tilt.
39
New Research and Regulatory Activity

• FHWA has begun its on-road research study.
• It will use an instrumented vehicle and highly
  sophisticated eye movement recording system
• Research will be done in two different cities
• Data collection should start this fall
• FHWA has begun an International Scan to learn
  about activities in other countries
• TRB Digital Signage subcommittee will develop
  research needs statements for on-premise and
  on-road DBBs we hope for AASHTO support
• But there is no concerted effort to address
  interactive DBBs or DBBs on moving vehicles.

40
Driver distraction is an increasing concern we
cant control all of it
41

But it is within our purview to control some of
it
42
Thanks very much for your attention.
