Towards software components

1
C O M P U T A T I O
N A L R E S E A R
C H D I V I S I O N
Towards software components for efficient and
easy communication and data integration in P2P
networks W. Hoschek Jan. 21, 2005
2
Overview

• Communication and data integration in P2P
  networks is difficult
• Most APIs for network I/O either do not scale
  well, or are hard to use
• XML is great but its APIs are harder to use than
  expected (generality)
• Large overheads related to XML serialization and
  deserialization
• It need not be that way

3
Overview

• Seek to enable
• robust and powerful commodity XML tool chains
• while retaining good messaging performance
• Components for
• asynchronous non-blocking network I/O
• binary encoding of XML
• XQuery/XPath manipulations of messages
• Trade-offs formed by
• performance, usability, flexibility, expressive
  power
• Some preliminary performance results

4
Synchronous blocking I/O

• Requires one thread per connection
• Many threads scheduling inefficiencies
• Concurrency and synchronization issues subtle and
  non-intuitive, hard to find debug
• Serious degradation under overload

5
Async non-blocking I/O

• Stages, Queues, Events, Event Handlers, Threads
• One (or few) threads for N connections
• Event driven design rather than OO call interface
• Few concurrency bugs since (mostly) single
  threaded
• Can avoid overload via explicit queue
  shaping/priorities

6
Implementation

• SEA toolkit
• A layer on top of Java NIO
• TCP UDP
• Overhead of toolkit
• (preliminary, not measuring network)
• 30000 msg/s (tiny msg size)
• 200 MB/s (large msg size)
• Documentation
• http//dsd.lbl.gov/sea

7
Easy API (Hello World Server)
agent new NetAgent() myStage new
StageManager().createStage().start() agent.addLis
tenPort(myStage, 9000) agent.start() onAccept
ed(rsp) rsp.getAgent().enqueue( new
ChannelRequest.WriteData(rsp.getKey().channel(),
hello world))
8
XML Serialization Deserialization Overheads

• XML is complex and very general
• Standards compliant XML handling --gt
  inefficiencies
• Serialization
• 4-5 MB/s (standard textual XML)
• 15-50 MB/s (bnux binary XML)
• Deserialization (parsing)
• 2-11 MB/s (standard textual XML)
• 30-101 MB/s (bnux binary XML)
• Data compression factor
• 1.2 - 4
• Guarantees well-formed XML, preserving W3C XML
  Infoset and W3C Canonical XML(!)

9
Binary XML Applications

• Tightly coupled high-performance systems
• exchanging large volumes of networked XML data
• Compact main memory caches
• Short-term storage as BLOBs
• in backend databases or files
• e.g. "session" data with limited duration
• Not a standard - thus
• not intended as a replacement for standard
  textual XML in loosely coupled systems where
  maximum long-term interoperability is the
  overarching concern
• not intended for long-term data storage

10
XML Serialization Deserialization Overheads

• BNUX Binary XML
• Eliminate tag redundancy via tokenization and
  string pooling
• Eliminate DTD and XML Schema checking
• Efficient buffer (re)use
• Fast Unicode conversions
• Careful implementation (profiling)
• Simplicity is key to performance
• Guarantees well-formed XML, preserving W3C XML
  Infoset and W3C Canonical XML(!)

11
Easy BNUX API
Document doc new Builder().build("/tmp/test.xml"
) // write binary XML document to file
BinaryXMLCodec codec new BinaryXMLCodec()
byte data codec.serialize(doc, 0)new
FileOutputStream("/tmp/test.xml.bnux").write(data)
// read binary XML document from filebyte
data XOMUtil.toByteArray( new
FileInputStream("/tmp/test.xml.bnux")) Document
doc codec.deserialize(data) System.out.println
(doc)
12
Easy yet powerful XML XQuery XPath

• Manipulating and querying XML data
• Manual SAX/DOM cumbersome at best
• XSLT often too complicated
• Most APIs have steep learning curve, contain
  quite a few bugs
• XQuery XPath are powerful yet simple
• Essentially SQL for XML data

Document doc // retrieve timeout of a given
transaction// from XML protocol message
timeout XQueryUtil.xquery(doc,
"/opentransactionID123/scope/timeout)
13
XQueries can be powerful

• List books published by Addison-Wesley after
  1991, including their year and title

ltbibgt for b in doc("http//bstore1.example.
com/bib.xml")/bib/book where b/publisher
"Addison-Wesley" and b/_at_year gt 1991 return
ltbook year" b/_at_year "gt
b/title lt/bookgt lt/bibgt
14
Implementation

• Leveraging existing software
• standards compliance, efficiency, maturity
• Designed straightforward API (Nux)
• Internally glues Saxon XQuery engine to XOM
  library
• Tricky internals (!)
• Preliminary performance for simple queries
• 2000 (100000) queries/sec over 100 (0.5) KB input
  documents 200 (50) MB/s
• served from memory, commodity PC 2004, Java 1.5
• Example ballpark figures
• use cases, documents and query complexity can
  vary wildly
• Documentation at http//dsd.lbl.gov/nux

15
Putting it all together

• Components
• Async non-blocking I/O
• Binary XML encoding
• XQuery and Xpath
• Enable use of
• robust and powerful commodity XML tool chains
• while retaining good performance,
• sweet spot in the space of trade-offs formed by
  performance, usability, flexibility and
  expressive power

16
Future Work

• Integration with firefish, scishare, P2P routing
  and maintainance strategies, etc. as outlined in
  LDRD
• More detailed performance studies
• End-to-end rather than isolated studies
