TELESCOPIC ASTRONOMY

1
TELESCOPIC ASTRONOMY
2
First Telescope

• 1608- Hans Lippershey. Dutch lens grinder.
• 1609- Galileo. Built his own telescope, used it
  for scientific study.
• Mountains and valleys on Moon
• Moons of Jupiter
• Phases of Venus
• Saturns rings
• Sunspots

3
Galileos Telescope
4
Powers of a Telescope

• Light-gathering power-
• This is the ability of a telescope to collect
  light.

5
Powers of a Telescope

• Resolving Power
• the ability of a telescope to reveal fine
• detail.

6

• When light is focused into an image, a blurred
  fringe surrounds the image (diffraction fringe).
• We can never see any detail smaller than the
  fringe.
• Large diameter telescopes have small fringes and
  we can see smaller details. Therefore the larger
  the telescope, the better its resolving power.
• Optical quality and atmospheric conditions limit
  the detail we can see.

7
Powers of a Telescope

• Magnifying power
• the ability to make the image
• bigger

8

• Magnification of a telescope can be changed by
  changing the eyepiece. We cannot alter the
  telescopes light-gathering Or resolving power.
• Astronomers identify telescopes by diameter
  because that determines both light-gathering
  power and resolving power.

9
Optical Telescopes

• Refracting telescope uses a large lens to gather
  and focus light.
• Reflecting telescope uses a large mirror

10
Focal length the distance from the lens or
mirror to the image formed of a distant light
source
11

• Primary lens
• the main lens in a refracting
• telescope. It is also called an
• objective
• lens.

12

• Primary mirror
• the main mirror in a
• reflecting
• telescope. It is also called an
• objective
• mirror.

13

• Eyepiece
• A small lens to magnify the image produced by the
• objective (primary)
• lens

14
Chromatic Aberration

• When light is refracted through glass, shorter
  wavelengths bend more than longer wavelengths,
  and blue light comes to a focus closer to the
  lens than does red light.

15
Chromatic Aberration

• If we focus on the blue image, the red image is
  out of focus and we see a red blur around the
  image. This color separation is called chromatic
  aberration.

16
Achromatic Lens

• An achromatic lens is made of two components made
  of different kinds of glass and brings the two
  different wavelengths to the same focus. Other
  wavelengths are still out of focus.

17
Yerkes Refracting Telescope

• Largest refracting telescope in the world is at
  Yerkes Observatory in Wisconsin
• Lens is 1m in diameter
• ½ tonne
• The glass sags under its own weight

18
Newtons Reflecting Telescope

• 1666- Newton found that a prism breaks up white
  light into a rainbow of colours
• Telescope lenses do the same
• 1663- James Gregory designed a telescope with a
  large concave primary mirror and a smaller
  concave secondary mirror
• 1672- Newton modified the design, and it won huge
  acclaim

19
Benefits of Reflecting Telescopes

• Less expensive. Only the front surface of the
  mirror must be ground.
• The glass doesnt need to be perfectly
  Transparent
• The mirror can be supported over its back surface
  to reduce sagging.
• They do not suffer from chromatic aberration
  because the light is reflected toward the focus
  before it can enter the glass.

20
Four ways to look through reflecting telescopes
21
Prime Focus
22
Newtonian Focus
23
Cassegrain Focus
24
Schmidt-Cassegrain
25
Hershels Telescope

• Late 1770s, William Hershel was making the best
  metallic mirrors and telescopes in the world.
• 1781- Discovered Uranus
• 1789 - Built a giant telescope which he used with
  his sister Caroline
• His telescope had a 125cm mirror
• 40ft in length

26
Rosses Telescope

• 1838- Earl of Rosse, Ireland, taught himself
  mirror-making and built a 91cm telescope
• 1842- attempted to build a 181cm telescope but it
  broke when moved
• built another one that couldnt be moved

27
Observatories

• 1874- 91cm telescope and observatory at
  University of California (James Lick)
• 1880- 76cm telescope in France
• 1897- 102cm telescope at Yerkes Observatory in
  Wisconsin
• 1908- 153cm telescope on Mount Wilson California
  (George Ellery Hale)
• 1917- 254cm telescope also built on Mount Wilson
  (John D. Hooker)
• 1948- 500cm mirror. Hale Observatory, Mount
  Palomar, California.

28
Observatories are built on top of mountains
because

• air is thin and more transparent
• the sky is darker
• stars are brighter
• 4) wind blows smoothly over some mountaintops
• there is less pollution

29
New Generation Telescopes
30
Keck Telescope

• 1993 Keck telescope 1000cm mirror, made of
  smaller segments
• Photographic plates were more sensitive and
  permitted a permanent record of observations
• Photographic plates have since been replaced by
  electronic imaging devices

31
A large mirror sags in the middle. To prevent
this

• Mirrors can be made very thick but they are very
  heavy and very costly.

32
A large mirror sags in the middle. To prevent
this

• Spincasting an oven turns and molten glass
  flows outward in a mold to form a concave upper
  surface.

33
A large mirror sags in the middle. To prevent
this

• A mirror can be made in
• segments.

34
A large mirror sags in the middle. To prevent
this

• Thin mirrors (floppy mirrors) can have their
  shape controlled by a computer called active
  optics. They cool quickly to adjust to
  surrounding temperatures.

35
Radio Telescopes

• Objects in space emit light waves of many
  different wavelengths.
• Radio Telescopes receive very long wavelengths
  (radio waves).
• 1937 first Radio telescope picks up long wave
  radio emissions from deep space

36
Handicaps to Radio Telescopes

• Poor resolution
• To improve resolution, two or more radio
  telescopes can be combined to improve the
  resolving power (called a radio interferometer).
  Resolving power equals the separation of the
  telescopes.

37
Handicaps to Radio Telescopes

• Low intensity
• In order to get strong signals focused on the
  antenna, the radio astronomer must build large
  collecting dishes. The largest dish is the 300 m
  dish at Arecibo, Puerto Rico.

38
Handicaps to Radio Telescopes

• Interference
• This occurs because of poorly designed
  transmitters in Earth satellites to automobiles
  with faulty ignition systems.

39
Space Telescopes

• Hubble
• Spitzer
• Kepler
• Webb
• Chandra
• Hershel
• Planck
• Fermi
• XMM-Newton
