Introduction to Flash Memories

1
Introduction to Flash Memories

• Anxiao (Andrew) Jiang

CSCE 689 Frontiers in Storage Systems
Texas AM University
August - December 2010
2
Storage Technologies

• Magnetic recording
• Optical recording
• Electronic memories

3
Applications of Flash Memories

• Flash memory is the major type of NVM
• (more than 90 of NVM market)

4
What is a flash memory cell?
5
Physics of Flash Memory
Cell array in a flash memory
A flash memory cell (Floating gate)

• A flash memory cell can store charge. And the
  charge level represents data.

6
How does a cell store a bit?
0
7
How does a cell store a bit?
1
8
Single-level cell and Multi-level cell

• Single-level cell Two levels ? One bit

0
cell

• Multi-level cell q levels ?
  bits

0
1
2
q-1
cell
cell
cell
cell
Typical number of cell levels 2, 4, 8, 16
9
How is a cell programmed?

• Through multiple rounds of charge injection

Target level
A flash cell
10
Speed and physical limits
Speed of operations
Read Fast
Write Slower (due to multiple rounds of
programming)
Erase Very slow
Physical limits
Endurance. (In NOR, a block can stand about
100,000 to 1,000,000 erasures.
In NAND, it can stand 10,000 to
100,000 erasures.)
Physical size (e.g., 34nm).
Voltage.
Number of electrons.
11
NOR and NAND Flash Memories
NOR Older, still used. NAND Newer, much more
popular now.
12
What is a NOR flash memory

• Cells form blocks. A block
• has about 100,000 cells.

2. NOR is a random-access device. Every cell is
directly addressable by the processor. That is, a
cell can be individually read and programmed.
13
What is a NOR flash memory
Block erasure!!!!!!
14
Block erasure
In NOR, the level of a cell can be increased
individually and multiple times. But to lower
any cell level, the whole block must be erased at
the same time.
Block
block of cells
15
What is a NAND flash memory
Cells form blocks. Every block is an array. Every
row is a page.
Block
page
page
Typically 32 to 128 rows (pages)
page
page
Read and write A page as a unit.
Typically 512 to 2048 cells in a
row (page)
Block erasure!!!!!!
16
Writing a page in NAND
A page can be written only once before the block
is erased. It is even recommended that the pages
are written sequentially.
Page 1
Partial writing A page is partitioned into 4
parts, and we can write a part at a time.
Page 2

Page 64
Part 1
Part 2
Part 3
Part 4
A page
Note This is logic partition.
Why? Programming is not very accurate,
especially with multiple times of
writing (for the same page, and for
the interference between pages).
17
A typical NAND page with spare bytes
64 Bytes of spare area
2KB of data
A page
Metadata ECC Undefined bits
18
Comparison of NOR NAND flash
Basic difference Different ways to connect cells
in a block.
Additional difference Ways to inject charge,
used voltages.
NOR cells are independent
NAND Cells in the same column are connected
(and disturb each other).
19
Comparison of NOR NAND flash
NOR
NAND
1. Lower density.
1. Higher density.
2. Random access.
2. Page access.
3. More reliable.
3. Less reliable, error-prone. (Requires
ECCs.)
4. Slower erase.
4. Faster erase.
5. Faster random read.
5. Faster streaming read.
6. Mainly to store code.
6. Mainly to store data.
20
Constraints of NAND and NOR Flash Memories
Hard constraint Block erasure (i.e., a block is
erased together).
For both NOR flash and NAND flash, fundamentally,
the cells can be programmed individually (not
only as an individual page or byte, but also as
an individually cell), and programmed in any
order.
Then why does NAND flash require cells to be
programmed a page at a time (or at least a
partial page), and sometimes require the pages
in the same block to be programmed sequentially?
Answer To reduce the effect of write disturbance
(programming a cell will affect the
level of the other cells in the same row or
column in the block. By reducing the
number of writes and making writes
sequential, an appropriate programming algorithm
can be used to control the cell
levels more accurately.
New solution Use coding or signal processing
techniques to tolerate the effect of write
disturbance, to allow cells to be written/read
randomly and individually (which are useful for
random access and rewriting data). It is a new
(and hot) research topic in the data storage
community.
21
Flash File System
Wear leveling
Garbage collection
Mapping
22
Wear leveling
Wear leveling Let the blocks be erased about the
same number of times. Method Write data in
different places (instead of the same block).
How to know the blocks level of wearing out
Count the number of erasures, or
Measure the performance of its cells (e.g., erase
latencies), or
Other methods?
Alternative approach Just use randomization
(i.e., randomly use
the blocks, and hopefully, things will even
out).
23
Wear leveling techniques
Simple case
If all the data in a block are obsolete, just
erase it. Write in blocks that are less worn out.
What if the blocks contain both obsolete and
valid data?
Page 1 valid
Page 2 obsolete
Page 3 obsolete
Page 4 obsolete

Page 64 valid
24
Combining wear leveling with garbage collection
This happens when we want to re-use those blocks
that contain both valid and invalid (obsolete)
data.
Approaches

• Use a cost/benefit ratio to decide which block
  to erase.
• (Before erasing it, the valid data need to
  be moved first.)

(2) Store frequently-changing data together, and
store data that do not change much
together. (Reason After a while, in a
block containing frequently-changing data, most
of the data are probably already invalid.)
(3) Many heuristic approaches. (And many patents.)
Most important Design it based on the
application.
25
When garbage collection is done

• Garbage collection (of blocks) can happen when
• As background work, i.e., when CPU is idle or
• (2) On demand, i.e., when there is not enough
  free space.

26
Mapping
How to use flash memories to store data?
One approach Treat the flash memory as a block
device, much like disk sectors.
Advantage Allow standard file systems to use
flash.
Problems with a simple linear mapping from
virtual blocks to flash-memory pages
Some blocks can be erased too often.
Unable (or inefficient) to write data smaller
than a flash block.
Solution Wear leveling (that is, to move data
around).
Mapping between virtual blocks and physical pages
is needed.
The spare part in a page may have bits indicating
if the page is free/used or valid/obsolete.
27
Mapping
Direct map
Virtual blocks Physical pages
Stored in RAM, or partially in RAM and partially
in flash.
Inverse map
Physical pages Virtual blocks
Stored in flash.

• Flash Translation Layer (FTL)
• A technique to
• store some of the direct map in flash, and
• reduce the cost of updating the maps stored in
  flash.

28
Flash file systems
Tens of flash file systems (FFS) have been
designed. Clearly, more of them will be designed
A flash file system
Is a data structure that represents a collection
of mutable random-access files in a hierarchical
name space.
Provides the block mapping technique.
Does wear leveling and garbage collection.
Maybe design a different, more flash-specific
file system?
Do the same for data structures, such as B-trees
and R-trees.
29
More flash-specific file systems
Most of the flash-specific file systems use the
same overall principle, that of a log-structured
file system.
Why? It is easier to record the small changes
(and write them down sequentially), than to
rewrite the whole file.
30
What happens when the blocks are
read/erased/written again and again
31
Disturb mechanisms
Write/read disturb When a cell is programmed (or
read), the cells in
the same column/row are softly programmed.
For some MLC, it is even recommended that after
reading the same page 1000 times, write the
clean data back again.
32
Errors, Signal processing, and ECCs
When a block is erased, its quality goes down.
The rate of errors increases
Types of errors
Random errors.
Fixed-position errors (because the cells really
become defected).
Cells in the same column can become bad together.
Ways to correct errors
Signal processing
ECCs (Hamming, BCH codes.) (Reed-Solomn
codes? LDPC codes? Under study.)
33
New Area in Information Theory Coding for
Flash Memories
34
Summary of recent results
Rewriting codes
Worst-case performance Jiang,Bohossian,Bruck,ISI
T07, Bohossian,Jiang,Bruck,ISIT07,

Jiang,Bruck,ISIT08,
Yaakobi,Siegel,Vardy,Wolf,Allerton08,

Jiang,Langberg,Schwartz,Bruck,ISIT09
,
Mahdavifar,Siegel,Vardy,Wol
f,Yaakobi,ISIT'09
Expected performance Finucane,Liu,Mitzenmacher,A
llerton08, Jiang,Langberg,Schwartz,Bruck,ISIT0
9
Rank modulation
Rewriting Jiang,Mateescu,Schwartz,Bruck,ISIT08
Error-correction codes Jiang,Schwartz,Bruck,ISIT
08
Sequences Jiang,Mateescu,Schwartz,Bruck,ISIT08
, Wang,Jiang,Burck,ISIT09
Capacity Jiang,Bruck,ISITA08,
Lastras-Montano,Franceschini,Mittelholzer,Sharma,
ISITA'08,
Lastras-Montano,Franceschini,Mittelholzer,Karidis
,Wegman,ISIT'09, Jiang,Li,PACRIM09
Error correcting/scrubbing codes
Cassuto,Schwartz,Bohossian,Bruck,ISIT07,
Jiang,ISIT07,

Jiang,Li,Wang,CWIT09
Data movement Jiang,Mateescu,Yaakobi,Bruck,Siege
l,Vardy,Wolf,ISIT09,
Jiang,Langberg,Matees
cu,Bruck,Allerton09
35
Rewriting codes
WOM (write-once memory) code
Floating code Joint coding of multiple variables
Example 2 bits are stored in 3 cells with 4
levels. Every time one bit is changed.
How many rewrites can be supported?
1,1
0,1
1,1
1,0
0,1
0,0
1,0
0,0
Now use floating codes.
36
Floating codes
Example 2 bits are stored in 3 cells with 4
levels. Every time one bit is changed.
cell levels
data
37
Rewriting codes
WOM (write-once memory) code
Floating code Joint coding of multiple variables
Example 2 bits are stored in 3 cells with 4
levels. Every time one bit is changed.
How many rewrites can be supported?
1,1
0,1
0,0
1,0
Now use floating codes.
1,1
0,1
0,0
1,0
38
Floating codes
When two binary variables are stored in n cells
of q levels, an optimal floating code can support
rewrites.
When k variables of alphabet size L are stored in
n cells of q levels, the number of rewrites that
a floating code can support is
If n is large ?
rewrites
If k,L are large ? Roughly
rewrites
No coding ? Roughly rewrites
39
More general model for rewriting
Floating codes Every rewrite changes one
variable.
011
111
State transitions of data
001
101
Example 3 binary variables
Hypercube
010
110
000
100
Buffer codes Remember most recent data. BJB07
State transitions of data De Bruijn graph
011010100010010010111101
More general JLSB09
Maximum degree
The data change in a bounded-degree graph.
40
Trajectory code for bounded-degree rewrite
Model The state-transition diagram of the data
has bounded degree .
This code is asymptotically optimal.
Jiang, Langberg, Schwartz, Bruck, ISIT09
41
Rank Modulation
J, Mateescu, Schwartz, Bruck, ISIT08
42
Cell Programming

• Noisy, monotonic
• Trend more levels, smaller cells
• Question How to write data
• reliably when cells cannot be
• programmed reliably?
• Challenges overshoot, worst-case constraint.
• Approach adaptive cell-ensemble programming.
• Rank modulation is such an approach.

43
Rank Modulation

• Analog cell levels induce permutations.
• Example 3 cells can induce 3!6 permutations
• Permutations represent data.
• Method of programming from low to high.
• Advantage no overshoot, adaptive coding.

132
213
231
312
321
123
44
Rewriting Error correction

• Rewrite How to rewrite data in the rank
  modulation scheme?
• Error correction How to design error-correcting
  codes? What does error mean?

45
A few other topics (3) Data movement
Block 1
Block 2
Block n
Empty block
erasures are needed.
No coding
erasures are needed.
With coding
Jiang, Mateescu, Yaakobi, Bruck, Siegel, Vardy,
Wolf, ISIT09
46
Summary of recent results
Rewriting codes
Worst-case performance Jiang,Bohossian,Bruck,ISI
T07, Bohossian,Jiang,Bruck,ISIT07,

Jiang,Bruck,ISIT08,
Yaakobi,Siegel,Vardy,Wolf,Allerton08,

Jiang,Langberg,Schwartz,Bruck,ISIT09
,
Mahdavifar,Siegel,Vardy,Wol
f,Yaakobi,ISIT'09
Expected performance Finucane,Liu,Mitzenmacher,A
llerton08, Jiang,Langberg,Schwartz,Bruck,ISIT0
9
Rank modulation
Rewriting Jiang,Mateescu,Schwartz,Bruck,ISIT08
Error-correction codes Jiang,Schwartz,Bruck,ISIT
08
Sequences Jiang,Mateescu,Schwartz,Bruck,ISIT08
, Wang,Jiang,Burck,ISIT09
Capacity Jiang,Bruck,ISITA08,
Lastras-Montano,Franceschini,Mittelholzer,Sharma,
ISITA'08,
Lastras-Montano,Franceschini,Mittelholzer,Karidis
,Wegman,ISIT'09, Jiang,Li,PACRIM09
Error correcting/scrubbing codes
Cassuto,Schwartz,Bohossian,Bruck,ISIT07,
Jiang,ISIT07,

Jiang,Li,Wang,CWIT09
Data movement Jiang,Mateescu,Yaakobi,Bruck,Siege
l,Vardy,Wolf,ISIT09,
Jiang,Langberg,Matees
cu,Bruck,Allerton09
