Your Connectivity Partner

1

• Your Connectivity Partner

2
Locations
Main Office High Tech Products Lallio, Italy
USA Office HTP Connectivity Parsippany, NJ
3
Locations
Manufacturing HTP CHINA LTD Guangdon Province,
China
4
DIN 43650 Moulded Assemblies Connectors
5
DIN 43650

• Typically used to electrically connect hydraulic
  pneumatic solenoids, filter pressure switches
  and sensors
• This connector group is used by the majority of
  valve manufacturers

6
DIN 43650 Molded Assemblies

• Saves installation time and expense
• Available in any length, in all 5 DIN 43650
  types
• With or without light indication and surge
  suppression
• For 24, 110 220 volt applications

7
DIN 43650 Connectors

• Provides a greater range of connectors then
  offered by the valve manufacturers
• Circuits available include
• Without components
• LED Only
• Varistor LED
• Diode LED
• For 24, 110 220 volt applications

8
M12 to DIN 43650

• Typically used to connect solenoid valves or
  sensors to distribution boxes
• All DIN 43650 types available
• With or without LED and Suppression
• .5 Meter standard cable length (other lengths
  available upon request)

9
DIN Double Y Cable

• Used to double the outputs from a Distribution
  Box
• Available in all the DIN43650 Connector Types
• With or without LED Suppression

10
DIN Triple Y Cable

• Used to provide multiple outputs from a single
  M12 connector
• Available in all the DIN43650 Connector Types
• With or without LED Suppression

11
Multiple Connector Assemblies

• Up to 10 connectors
• with 1 cable
• One individual to
• each connector
• Common negatives
• and grounds (on 2
• position)

12
DIN 43650 to M12 Connector

• Allows connection to a DIN43650A or DIN43650B
  valve with an M12 Connector
• Available also with different circuit

13
New Big DIN 43650A

• Separate circuit board allow larger components to
  be used

14
DIN Male Panel Mount (Basis)

• Male DIN43650 connectors
• For panel and special mounting

15
Special Industrial Connector

• 15mm X 15mm with 4 diagonal pins

16
DIN Extension Cables

• Female to Male Connections
• Allows DIN43650 Cable to be Extended
• Available in all DIN Types

17
In Line Cycle Timer Now Available

• The HTP in-line timer is designed to cycle power
  on and off, to either pneumatic or hydraulic
  solenoid valves.
• Typical applications include draining water from
  compressor tanks, periodic product sampling, and
  control of lubricating or irrigation systems.
• Plugs in-line between male female connectors
• Works with any voltage from 24 to 240 VAC/DC
• ON 0.5 to 10 sec OFF 0.5 to 45 min
• For pneumatic or hydraulic solenoid valves
• ON and OFF LED status indication
• Manual push button override

18
New Products Now Available

• Industrial Form B Molded Assemblies with Dual
  Ground Pins
• Works with both ground down and ground up cable
  positions

19
M12 Connectors and Molded Assemblies
20
M12 Connector Wiring
M12 Connectors are a very popular way to connect
sensors switches. Changing a sensor or switch
is much faster when a connector is used, reducing
down time and labor expense.

• 3 Pole Versions
• 1 Positive
• 3 Negative
• 4 Signal
• 4 Pole Versions
• 1 Positive
• 3 Negative
• 2 Signal 1
• 4 Signal 2
• 5 Pole Versions
• 1 Positive
• 3 Negative
• 2 Signal 1
• 4 Signal 2
• 5 Ground

21
M12 Connector Assemblies

• 3, 4, 5, 8 or 12 pole versions
• Male or female
• Straight or right angle
• Single or Double Ended
• PVC, Shielded or PUR cable (other cable available
  on request)
• Standard Length 3 meters (1meter for double
  ended)
• 2 or 3 LEDs for PNP or NPN switch indication
• NEW Fully Shielded Versions Available

22
M12 T Connectors

• T connectors are designed to expand the ports
  on hard wired distribution boxes, by splitting
  the two individual wires into two connectors
• NEW Transparent T With Light Indication

23
M12 Y Cable

• Can be used to double the capacity of an M12
  Distribution Box, by splitting the individual
  inputs

24
M12 Triple Y Cable

• Used to provide multiple outputs from a single
  M12 connector

25
M12 Field Wire Connectors

• 4, 5, or 8 pole versions
• Screw terminals
• Straight or right angle
• Single or dual cable entry

26
M12 Field Wire Connectors

• NEW!! 12 pole versions

27
Metal Field Wire M12 Connector

• Housing in Nickel Plated Brass
• For Tough Environments
• Rated IP 67
• Completely Shielded

28
M12 Panel Mount Connectors

• 4, 5, 8 or 12 pole versions
• Female or male connectors
• Front or back mounting
• Solder or PCB connections or pre-wired

29
M8 Connectors and Assemblies
30
M8 Connector Wiring
M8 Connectors are a very popular way to connect
sensors switches. Changing a sensor or switch
is much faster when a connector is used, reducing
down time and labor expense.

• 3 Pole Versions
• 1 Positive
• 3 Negative
• 4 Signal
• 4 Pole Versions
• 1 Positive
• 3 Negative
• 2 Signal 1
• 4 Signal 2

31
M8 Connector Assemblies

• 3 or 4 pole versions
• Male or female
• Straight or right angle
• Single or Double Ended
• PVC, Shielded or PUR cable
• Standard Length 3 meters (1meter for double
  ended)
• 2 LEDs for PNP or NPN switch indication
• NEW Fully Shielded Versions Available

32
M8 Y Assemblies

• Both the Y assemblies are designed to expand
  the ports on hard wired distribution boxes, by
  splitting the two individual wires into two
  connectors

33
M8 Field Wire Connectors

• 3 or 4 pole versions
• Solder or screw terminals
• Straight

34
M8 Panel Mount Connectors

• 3 or 4 pole versions
• Female or male connectors
• Front mounting
• Solder or PCB connections or pre-wired

35
M12 Distribution Boxes
36
Distribution Boxes

• Distribution Boxes eliminate the need to run
  multiple cables back to the control panel and
  create a plug and play system
• They can be used for both input output devices
• Commons within the box reduces wiring time at the
  control panel
• Distribution Boxes are designed around the
  standard wiring used for the connectors. Common
  wiring (to each connector position) is provided
  for positive, negative and ground positions. Each
  connector has 2 individual wires available to
  transfer NO NC position status for input
  devices or one wire can be used to provide
  separate power for output devices

37
M12 Distribution Boxes Field Wire

• 5 pole M12 connector
• 4, 6 or 8 ports
• Self wire or molded main cable
• With or without LED indication for PNP or NPN
  sensors

38
M12 Distribution Boxes Triple signal

• 5 pole M12 connector
• 4 or 8 ports
• Self wire or molded main cable
• Without LED indication for PNP or NPN sensors

39
M12 Distribution Boxes Molded Cable

• 5 pole M12 connector
• 4, 6 or 8 ports
• Molded main cable in 5, 10 or 15 meters
• With or without LED indication for PNP or NPN
  sensors

40
Magnetic Sensors

• For use with aluminum cylinders with target
  magnetic
• Available in dry contact (reed switches) or solid
  state (PNP or NPN)
• With many different mounting and body styles
• With molded cable, M12 or M8 connection

41
New Products Now Available

• 7/8 MINI CHANGE
• 3, 4 and 5 poles

42
New Products Now Available

• 7/8 MINI CHANGE male / female
• 3, 4 and 5 poles
• Fieldwire connectors

43
New Products Now Available

• 7/8 MINI CHANGE male / female
• 3, 4 and 5 poles
• Molded cable

44
New Products Now Available

• 7/8 MINI CHANGE male / female
• 3, 4 and 5 poles
• Panel mount

45
New Product now available

• 7/8 MINI CHANGE male / female
• 3, 4 and 5 poles
• T-splitter

46
New Products Now Available

• M8 Distribution Boxes
• 6 8 10 Positions
• Terminal Blocks

47
New Products Now Available

• M8 Distribution Boxes
• 6 8 10 12 Positions
• Molded cable

48
New Products Now Available

• M8 Distribution Boxes
• 6 12 Positions
• M12 with 8 pole connector

49
New Products in Development

• M16 M23 Connectors and Assemblies

50
Thank-you!
