Title: Digital Image Quality:


1
Digital Image Quality
  • Is there a sacrifice?

Terri L. Fauber, R.T. (R)(M) Virginia
Commonwealth University School of Allied Health
Professions Department of Radiation Sciences
2
Topics
  • Radiation Risk
  • Image Receptors
  • Patient Exposure
  • Research Experiment
  • Reducing Patient Exposure

3
Radiation Exposure
  • High-dose radiation exposure is harmful.
  • Low-dose radiation exposure can be harmful.
  • Practice ALARA
  • As Low as Reasonably Achievable.

4
Low Dose Exposure
  • Important societal issues
  • Cancer screening tests
  • Nuclear power
  • Occupational exposure
  • Frequent-flyer
  • Manned space exploration
  • Radiologic terrorism
  • Brenner et al, 2003

5
Radiation Risk
  • Most of our knowledge about risk to low doses of
    radiation is estimated using extrapolation
    techniques.
  • Estimating a value beyond the range of known
    values.

Some believe low dose risks have been
underestimated and others believe it may be
overestimated.
6
Radiation Risk
  • The debate continues on the health risks due to
    low-dose radiation exposures.
  • Linear dose-response relationship.
  • Threshold vs. nonthreshold.
  • Radiation hormesis.

7
Linear Nonthreshold Effect
  • The response is directly proportional to the
    radiation dose.
  • Even a small dose will have an effect.

Response
Dose
8
Linear Threshold
  • A certain level of radiation dose must be
    reached before an effect occurs.

Response
Dose
9
Radiation Risk
  • The U.S. Department of Health and Human Services
    identified x-rays as a known human carcinogen.
  • National Academies support the belief that low
    levels of radiation may cause harm.

(Supports linear nonthreshold risk model.)
10
Radiation Risk
  • Exposure to x-rays (lt 0.2 Gy or 20 rads)
    is strongly associated with leukemia and cancer
    of the thyroid, breast and lung.
  • (11th Report on Carcinogens, 2005)
  • Direct epidemiological evidence demonstrates
    that an organ dose of 0.01 Gy or 1 RAD of
    diagnostic x-rays is associated with an
    increase in cancer risk.
  • (Brenner et al, 2003)

Risks may vary for acute vs. protracted low dose
exposure.
11
USRT National Study
  • In 1982 a national longitudinal study of R.T.s
    certified between 1926 and 1982 was initiated to
    evaluate health outcomes associated with
    long-term occupational exposure to radiation.
  • The third survey was completed in 2004.

12
USRT National Study
  • Radiographers who began working before 1950 had
    an increased risk of developing breast cancer.
  • Compared with similar people in the general U.S.
    population, radiologic technologists had lower
    mortality risks for all causes of death and for
    all cancers combined.

Mohan et al, 2003
13
Radiation Hormesis
  • Proposes small doses of radiation may actually
    be healthful by stimulating the immune system.
  • Some scientific evidence indicates that low
    radiation doses increase life span.

14
Radiation Hormesis
  • Proponents say benefits of radiation have been
    known for the past century.
  • It is suggested that this evidence has been
    suppressed by special interest groups.

15
Biological Variability
  • Mutagens
  • Carcinogens
  • Tumor promoters
  • Cancer-protective substances
  • Environment
  • Diet
  • Lifestyle
  • Age

Prasad at el, 2003
16
The Continuing Debate
  • Until undisputed research confirms or refutes the
    harmful effects of low radiation dose, we will
    not truly know its effect.
  • Regardless, we must continue to protect our
    patients from unnecessary radiation exposure.

17
Image Receptor Technology
  • Film-screen
  • Exposure errors apparent on image.
  • Repeats typically due to exposure errors.
  • Digital
  • Wide dynamic range.
  • Reduction in repeats due to exposure errors.
  • Provides information on radiation exposure to
    receptor.

18
Digital Radiography
  • An advantage of digital radiography is its wider
    dynamic range.
  • Produces diagnostic densities within a wider
    range of exposures
  • Computer can display a wider range of optical
    densities

19
Digital Image Processing
  • Adjustments made for low or high exposures
  • Exposure Indicator a number displayed to
    indicate the level of x-ray exposure received to
    the imaging plate.
  • Kodak Exposure index (EI) uses a logarithmic
    scale and every 300 EI change in exposure x 2.
  • Agfa Log median value (LgM) uses logarithmic
    scale and every 0.3 change in exposure x 2
  • Fuji Sensitivity number (S)
  • S value is inversely proportional to the mR
    (exposure) reaching the image receptor, an S
    value of 200 indicates proper exposure, 400 S
    value ½ as much exposure and 100 S value 2 x
    exposure

20
Digital Radiography
  • Computed Radiography (Cassette-based)

Memory storage
Digital data
Reader (laser)
Display monitor
X-ray photons exiting pt.
Laser printer
Photostimulable phosphor
  • Direct Digital Radiography (Cassetteless)

Memory storage
Digital data
Display monitor
X-ray photons exiting pt.
Laser printer
Fixed imaging plate
21
Computed Radiography
22
Direct Digital Radiography
23
Digital Image Receptors
  • Computed radiography (CR)
  • Photostimulable phosphor (IP).
  • CR reader extracts latent image.
  • Light energies converted to digital data.
  • Direct Digital Radiography (DR)
  • Electronic detectors.
  • Direct capture of latent image.
  • Indirect or direct conversion of latent image
    to digital image.

24
Digital Image Characteristics
  • A digital image is displayed as a combination
    of rows and columns known as matrix
  • The smallest component of the matrix is the
    pixel (picture element)
  • The location of the pixel within the image
    matrix corresponds to an area within the
    patient or volume of tissue referred to as
    voxel

25
Matrix Size
For a given field of view, a larger matrix size
includes a greater number of smaller pixels.
26
Image Characteristics
  • Each pixel is assigned a numeric value that
    represents a shade of gray based on the
    attenuation characteristics of the volume of
    tissue imaged

27
Pixel Depth
  • Each pixel has a bit depth and the number of
    bits determines the number of shades of gray the
    system is capable of displaying on the digital
    images.
  • 10- and 12- bit pixel can display 1024 and 4096
    shades of gray, respectively.
  • Increasing pixel bit depth improves image quality

28
Digital Image Visibility
  • The center or midpoint of the window level and
    the width of the window will demonstrate density
    and contrast of the displayed image.

29
Image Receptors
  • Digital
  • Wide exposure latitude.
  • Acquisition of data separate from processing
    and display.
  • Post-processing capabilities.
  • Film-screen
  • Narrow exposure latitude.
  • Film acquires,
  • processes and displays image.
  • No changes after processing.

30
Current Literature
  • Digital technologies compensate for under- and
    overexposures.
  • Low radiation exposures increase the amount of
    quantum mottle (noise).
  • High radiation exposures produce a more visually
    appealing image
  • (less noisy).

31
Current Literature
  • New relationships exist between radiation
    exposure and digital image receptors and
    radiographers might not be aware of increased
    radiation exposure to patients.
  • Radiographers might not be as precise in
    selecting optimal exposure techniques.

Exposure Factor Creep
32
Patient Radiation Exposure
  • Compagnone et al, 2006 study compared patient
    radiation doses for six standard exams using
    film-screen, CR, and DR.
  • Entrance skin dose (ESD) and Effective dose (E)
    were calculated.
  • Image quality was assessed by radiologists.

33
Study Findings
  • CR generally results in higher ESDs than
    film-screen and DR.
  • Effective doses for DR were lower than CR and
    Film-screen
  • Radiologists preferred the appearance of the DR
    images.

(Compagnone et al, 2006.)
34
Patient Radiation Exposure
  • Warren-Forward et al, 2007 conducted a
    retrospective analysis of exposure indices for
    chest and lumbar exams within two hospitals.
  • Also, phantoms were exposed to a range of
    kilovoltages to evaluate the relationship
    between exposure indices and ESD.

35
Study Findings
  • A high percentage of exposure indices were
    outside of the recommended range for both
    hospitals, indicating that over- and
    underexposures had occurred.
  • The experimental phantom exposures found that a
    small increase in exposure indices produced a
    large increase in entrance-surface dose.

(Warren-Forward et al, 2007.)
36
Patient Radiation Exposure
  • Concerns raised regarding patient CR exposures,
    especially for pediatric patients.
  • Optimum image quality not necessary for
    follow-up CR images.
  • Manufacturer-recommended exposure ranges may be
    set too high.

37
Research Experiment
  • Investigated the effect of varying radiation
    exposures on CR image quality.
  • Optical density.
  • Density differences (contrast).
  • Low and high.
  • Resolution ( of line pairs visible)

38
Research Question
  • What effect will extreme variation in the
    quantity of radiation incident on the CR imaging
    plate have on optical density, contrast and
    resolution?

39
Research Design
  • True Experimental
  • Independent Variable
  • Quantity of radiation incident on the CR
    imaging plate (IP).
  • Dependent Variables
  • Optical densities.
  • Density differences.
  • of line pairs visible.

40
Equipment
  • GE MVP 60 3-phase radiographic unit.
  • Fuji FCR 1 Shot QC phantom.
  • Fuji FCR XG-1 Smart CR Reader.
  • 5 14 x 17 Fuji Smart CR IPs, Type C.
  • FujiFilm FM DPL laser printer.
  • X-rite Densitometer Model 301.

41
Baseline Phantom Image
  • Contrast Patches
  • High-density differences.
  • Low-density differences.
  • Resolution Test Pattern
  • Line pairs/mm.
  • Density Circle

42
Data Collection
  • Baseline image created according to Fuji QC
    specifications.
  • Exposure groups determined by dividing baseline
    mAs by a factor of 2 and multiplying baseline
    mAs by a factor of 2.
  • Exposures ranged from 1 to 125 mAs, yielding 8
    groups.
  • Five images were exposed, processed and printed
    for each exposure group.
  • Optical densities were measured with a
    densitometer.
  • High- and low-contrast density patches were
    measured and the difference between the
    circle densities calculated.
  • of Lp/mm was determined visually using a
    magnifying glass.

43
Results
  • S number
  • 1 mAs 1847
  • 2 mAs 818
  • 4 mAs 396
  • 8 mAs 204
  • 16 mAs 102
  • 32 mAs 52
  • 64 mAs 27
  • 125 mAs 13
  • Resolution in Line pairs/mm
  • 1 mAs 2.500
  • 2 mAs 2.625
  • 4 mAs 2.875
  • 8 mAs 2.875
  • 16 mAs 2.700
  • 32 mAs 2.750
  • 64 mAs 2.750
  • 125 mAs 2.875

Inverse proportional change in S
Less resolution at extremely low mAs
44
Optical Density
8
125
1
Increasing mAs
Range 1.40 1.432
Difference .032 lt.05 O.D.)
45
High-density Differences
8
4
2
1
125
64
32
16
mAs
Difference 0.09 gt 0.05 O.D.
Range 0.868 - 0.776
46
Research Findings
  • Exposure indicator reflected proportional change
    in mAs.
  • Optical density stable for extreme exposure
    variation.
  • Low-density differences stable for extreme
    exposure variation.
  • High-density differences decreased for high
    exposures (decreases contrast).
  • Resolution decreased at low exposures.

47
Conclusions
  • Computed radiography can compensate for extreme
    radiation exposure variability.
  • Resolution decreased at low exposures.
  • High-density differences (contrast) decreased at
    high exposures.

48
Implications
  • Exposure errors will not reduce image quality.
  • The radiographer is responsible for selecting
    exposure techniques that will produce quality
    digital images with the least amount of
    exposure to the patient.

49
Additional Research
  • Replicate study on other types of digital
    equipment.
  • Investigate extreme exposure variation on the
    image quality of patient- equivalent phantoms.
  • Investigate radiologists perception of digital
    quality for images created with extreme exposure
    variation.

50
  • Recognize and comprehend the different
    relationship between radiation exposure and
    digital imaging systems.

51
Reducing Patient Exposure
  • Select exposure techniques that reduce patient
    exposure while maintaining diagnostic image
    quality.
  • Use higher kVp and lower mAs whenever possible.
  • Monitor exposure indicator for feedback on
    patient exposure.

52
Strategies
  • Use automatic exposure control (AEC) devices
    routinely and correctly.
  • Develop and use technique charts.
  • Use less exposure for acceptable quality
    whenever possible.

53
Continuing Education
  • Become more knowledgeable about digital
    technologies.
  • Dosimetric monitoring systems may be a reality,
    including
  • Reference values.
  • Calculated entrance skin dose and dose-area
    product (DAP).
  • Warning message for exposure errors.
  • Patient exposure dose audits

54
This research project was supported by a grant
from the ASRT Education and Research Foundation.
Write a Comment
User Comments (0)
About PowerShow.com
