Setup

1
Setup
LCD Projector
LCD Projector

• Professional Development 2006
• Judy Forman

2
Assemble all components

• Lcd projector
• Power cord
• RGB cable
• Power cord
• Network cable

3
Connect Power Cords

• 1. Connect power cords

4
Connect RGB Cable

• 2. Connect computer to Projector - Connect blue
  RGB plug to lcd RGB port.
• Connect blue RGB plug to laptop RGB port.

5
Connect to Network

• 3. Connect computer to network

6
Turn On Power

• 4. Turn on Laptop Power

5. Turn on lcd Projector Power
7
Check Power Lights
8
Ready to Project..

• The laptop lcd projector are now ready to use.

Let the Show Begin!
